Greenheck MP2985 & MP2986 Motors with Belimo FSxx Series January 2015

INSTRUCTION SHEET

Replacement of Greenheck MP2985 & MP 2986

Motors with Belimo FSxx Series

Contents

UL®................................................................................................................2

Code and Standard Issues.............................................................................2

NFPA 80 (Fire) & NFPA 105 (Smoke)............................................................3

Local Code Approval......................................................................................4

Cross Reference............................................................................................5

Application.....................................................................................................7

Mounting......................................................................................................12

Linkage mounting ........................................................................................15

Miscellaneous parts.....................................................................................16

Thermal sensor replacements –BAE165 US...............................................16

Building Official / Fire Marshal Notification Form..........................................20

Contacts:

East Coast 800 543-9038 x3119 West Coast 800 987-9042

Aaron Nobel 203 749-3119 Larry Felker 775 355-2461 (250-4160 Cell)

Mike Knipple 203 749-3170 Laure Pomianowski 775 355-2466

WARNING!

Installer must be trained and experienced with repair

of fire and smoke dampers and actuators.

WARNING!

Before replacing actuator, damper must be inspected and

determined to be fully functional. See NFPA 80 &/or NFPA 105 for

recommended check list.

Greenheck MP2985 & MP2986 Motors with Belimo FSxx Series January 2015

UL®

Code and Standard Issues

In general, the administrative section of codes state that all mechanical and electrical systems

must be kept in working order and an individual section may state that all life safety devices

and systems must be operable. NFPA 80 (Fire) & NFPA 105 (Smoke) require periodic testing

and repair of dampers as soon as possible after any deficiency is uncovered.

Chapter 7 IBC & IFC "Containment” Dampers

Commissioning

End of first year

Every 4 years except in hospitals every 6 years

Chapter 9 IFC "Smoke Control System” Dampers

Dedicated

Non-dedicated

Commissioning

Semi-annually

Annually

Chapter 9 IBC & IFC

Fire detection & Smoke control systems

Dedicated

Non-dedicated

Weekly self-test

Not required

Fire & smoke dampers are appliances and field replacement of components is required when

failure of any component occurs.

The Authority Having Jurisdiction (local Fire Marshal and/or Building Official) must be

consulted if any blade or auxiliary switches are employed and are connected to the fire alarm

system or to a Fire Fighters Smoke Control System (FSCS) panel. Retesting is required. A

permit and inspection may be required since connections to an alarm system have been

touched.

In the “Marking & Application Guide, Dampers for Fire Barrier and Smoke Applications &

Ceiling Dampers” April 2013 by Underwriters Laboratories Inc.®, page 6 they state:

DAMPER ACTUATORS

“… field mounting or substitution of actuators is not covered within the scope of the UL

certification of the product. However, this does not necessarily preclude replacement of

actuators in the field. Like any appliance, field servicing of these products is not covered

under the scope of the UL certification and factory follow-up service program. As with any

part of the damper, it is expected that replacement of actuators in the field be done in

accordance with the damper manufacturer’s normal field servicing program.”

Greenheck MP2985 & MP2986 Motors with Belimo FSxx Series January 2015

NFPA 80 (Fire) & NFPA 105 (Smoke)

See NFPA 80 & NFPA 105 for details. The damper cleaning and examination check

list here is based on them.

Damper installation shall meet code requirements. Fire stopping and drywall integrity shall be

confirmed. Damper blades shall be in plane of wall. Duct shall be fall away with no fasteners

connected to damper sleeve.

a. Dampers and ducts shall be cleaned of all foreign debris and dust build-up.

b. All exposed moving parts of the damper shall be dry lubricated as required by the

manufacturer. Do not use oil as it draws dirt.

c. Damper shall be examined without defective old motor or new actuator to determine:

i. The damper shall fully close from the open position.

ii. Damper shall fully open from the closed position.

iii. There are no obstructions to the operation of the damper. The damper shall not be

blocked from closure in any way due to rusted, bent, misaligned, or damaged frame

or blades. The damper shall not have defective hinges, side &/or blade seals, or

other moving parts. The damper frame shall not be penetrated by any foreign

objects that would affect operation.

d. If the damper is equipped with a fusible link, the link shall be removed for testing to ensure

full closure and lock-in-place if so equipped. If the link is damaged or painted, it shall be

replaced with a link of the same size, temperature, and load rating.

e. The fusible link shall be reinstalled after testing is complete.

After installation and wiring of new actuator it shall be tested.

a. The checklist may be customized using material here and in NFPA Standards. Multiple

geometric configurations of springs, fusible link, thermal sensor(s), and actuation are possible.

Confirm with AHJ if any additional requirements exist.

b. Electric thermal sensors, if present, must be tested and replaced if defective.

c. The test shall be conducted with normal HVAC airflow.

d. When equipped with smoke detection activation, the smoke detector shall be activated and

damper operation observed.

NFPA requires damper inspection and repair of dampers.

See www.nfpa.org. for Standards.

Test voltage input to actuators and repair as necessary if voltage is not correct.

Old breakers often deliver below 115V and failed actuators may be due to power

supply problems.

Greenheck MP2985 & MP2986 Motors with Belimo FSxx Series January 2015

Local Code Approval

While it is not detailed in codes, the following rules should be followed for selecting Belimo

actuators for replacement:

Check the technical specifications to ensure an “equal or better” actuator is used.

Temperature –the replacement actuator shall have been UL555S tested at the same or

better temperature as the original actuator. 250˚F or 350˚F are standard.

Time –the replacement actuator shall drive open and spring closed at a speed equal or

faster than presently required by codes. (The AHJ may grant an exception and

“grandfather” slower actuators where the original actuator was slower.)

Torque –replacement actuator shall have equal or greater torque than the failed

actuator.

Voltage –replacement actuator shall have the same voltage rating as the original.

Amperage –the replacement actuator(s) shall not draw more amperage than the

original(s) and cause the total connected amp draw on a circuit breaker to be greater

than allowed by electrical code.

Final Testing –actuated damper and associated devices shall be tested for proper

operation. See Acceptance testing details below.

(Mnemonic device: TTT-VAT)

WARNING!

In all cases, installation must comply with any and all local electrical

and life safety codes. Operation of the system after installation must

be performed to verify proper damper cycling. Final checkout requires

verifying correct function.

WARNING!

Note that where any fire alarm wiring is touched, the fire department

must be informed.

Greenheck MP2985 & MP2986 Motors with Belimo FSxx Series January 2015

Cross Reference

MultiProducts

There is no one to one replacement. Rather, all the old linkage parts, external spring, and

motor are removed and the new actuator is direct coupled to the damper shaft. Double

check that the fusible link and shaft spring are intact. See BAE 165 below if not.

MP2985E 115V 24W .335A Run .36A Stall Belimo FSLF12O

MP2986A 24V 19W 1.5A Run 1.6A Stall Belimo FSLF24

Honeywell

VAC

Torque

Replacement

Notes

in-lb

ML4105A1000

120

FSLF120*

Any of these with

ML4105B1009

120

FSLF120*

32003532-002 auxiliary

M4105C1008, D1007

230

FSLF230*

switch package: add –S

ML4115A1009, B1008

120

FSLF120

To Belimo part number.

ML4115C, D, H, J

230

FSLF230

ML4105 no longer made.

ML4202

120

FSLF120

ML4302

120

FSLF120

ML8202, M8302

FSLF24

ML8105A1006, B1005

FSLF24*

ML8105 no longer made.

ML8115A1005, B1004

FSLF24

ML8115H, J

FSLF24

MS4209F

120

FSNF120*

MS4309F

120

FSNF120*

MS8209F

FSNF24*

MS8309F

FSNF24*

MS4120F1006

120

175

FSAF120*

No aux

MS4120F1204

120

175

FSAF120-S*

2 SPST

MS8120F1002

175

FSAF24*

No aux

MS8120F1200

175

FSAF24-S*

2 SPST

32003532-002 Aux switches

Use –Smodel Belimo.

Nominal sq.ft. per UL555S

testing.

Sq.ft.

Temp

Actuator

350°F

FSLF

Up to 30” x 30” and 36” x

24”. See NOTE below.

<12

350°F

FSNF

<16

250°F

FSNF

<12

250°F

FSAF

* More important than the torque rating is the

damper manufacturers’ UL555S testing.

Each manufacturer tests Belimo separately

and has different sizes UL555S listed.

NOTE. Although an actuator may pass a

larger sized damper use the UL listed sizing.

See

www.belimo.us/firesmoke “What’s New”

for a cross reference by manufacturer.

Greenheck MP2985 & MP2986 Motors with Belimo FSxx Series January 2015

Barber Colman-Siebe—Invensys

Model

Power

Torque-Stroke

Belimo

Replacement

MA318

60-180 stroke

FSNF24

MA418

120

60-180 stroke

FSNF120

MA220

23VA

120

FSLF120

FSNF120

MA221

23VA

240

FSLF230

FSNF230

MA223

23VA

FSLF24

FSNF24

MA230

36VA

120

FSLF120

FSNF120

MA231

36VA

230

FSLF230

FSNF230

MA233

36VA

FSLF24

FSNF24

MA240

No direct

replacement.

MA250

Same as

MA220/230

series.

Siemens

For more detail see Belimo Cross Reference at

www.belimo.us/firesmoke "What's New"

Make & Model

Power

Belimo Replacement

GGD121

FSAF24

FSNF24

GGD221

120

FSAF120

FSNF120

GGD321

230

FSAF230

FSNF230

GND12x.1x

24V

FSLF24

GND22x.1x

120V

FSLF120

GND32x.1x

230V

FSLF230

Electronic Fuse Link (24 Vac)

ASK79.165 165°F (74°C)

BAE165 US

ASK79.212 212°F (100°F)

None. Call if needed.

ASK79.250 250°F (121°C)

None. Call if needed.

ASK79.350 350°F (177°C)

None. Call if needed.

Optional

Two Auxiliary Switches Fixed 5° and 85°

For more MultiProducts and ECM see Belimo Cross Reference at www.belimo.us/firesmoke

NOTE: Remove external spring. If single spring was used for both fire and

smoke function, then a modern SPST, NC thermal sensor must be installed.

Call for instructions.

SEE

NOTE

BELOW.

Greenheck MP2985 & MP2986 Motors with Belimo FSxx Series January 2015

Application

Greenheck used a dual spring approach. The external spring closes the motor.

A hidden internal spring is held back by a fusible link. It is not involved in the smoke

function and should not be changed.

The motors above are connected by linkage as shown in the photographs below. The

Belimo FSLF can be direct coupled if space exists for mounting. A bracket may have to

be fabricated from 16 ga. Sheet metal to hold the anti-rotation strap. The geometry of

the situation determines the mounting method.

Below and right. Black arrow

points to the 1/4” motor shaft

and spring. White arrow

points to the damper shaft

which is hidden.

Greenheck MP2985 & MP2986 Motors with Belimo FSxx Series January 2015

View of damper frame, blade, and shaft. Detail of spring, arm, and fusible link.

RIGHT!

The Greenheck high temperature

damper closing is accomplished

with a fusible link and a shaft

spring.

Replace the fusible link if

necessary and test the closing

function.

THIS SPRING AND FUSIBLE

LINK MUST REMAIN IN PLACE.

WRONG!

This spring has been

disconnected from the linkage.

It must be repaired or the damper

replaced.

Test when reattached to ensure

the damper closes if fusible link

melts.

Greenheck MP2985 & MP2986 Motors with Belimo FSxx Series January 2015

Spring. Motor is applied the

same as any linkage application.

Remove spring and actuator.

This shaft is not mounted to

the damper.

Crankarm is connected to the damper shaft. The

Belimo may be direct coupled over the shaft. For

short shaft mounting, place clamp of actuator

between actuator and damper. See p9.

If a linkage is needed due to space constraints,

use FSNF with ZG-AF or other linkage kit with

rod. See Mounting Methods Guide and

Mechanical Accessories Booklets at

www.belimo.us.

Close-up view showing external shaft spring and part of the linkage.

Both will be removed so that the Belimo can be mounted on the shaft.

Greenheck MP2985 & MP2986 Motors with Belimo FSxx Series January 2015

Disassembly of MP mounted motor

Damper shaft / Jackshaft

extends out thru motor.

Damper

shaft

Damper

frame

Bracket

Motor

External

Spring

View from below the damper

and actuator

Autres manuels pour FS Series

Table des matières

Autres manuels Belimo Unité de contrôle

Belimo

Belimo Z2075Q-K Manuel utilisateur

Belimo

Belimo ZoneTight Z2050Q-F Manuel utilisateur

Belimo

Belimo VRU-M1R-BAC Mode d’emploi

Belimo

Belimo Z2050QPT-D Manuel utilisateur

Belimo

Belimo EPIV Series Guide produit

Belimo

Belimo Clear Edge EAP005 Manuel utilisateur

Belimo

Belimo Energy Valve EV015R+BAC Manuel d'instructions

Belimo

Belimo NMV-D2M Manuel utilisateur

Belimo

Belimo F6 Series Manuel utilisateur

Belimo

Belimo Z2050Q-J Manuel utilisateur

Belimo

Belimo GVA-CPL Manuel utilisateur

Belimo

Belimo Z2075QS-K Manuel utilisateur

Belimo

Belimo Z2050QPT-F Manuel utilisateur

Belimo

Belimo B2100VB-024 Mode d’emploi

Belimo

Belimo BKS24-1B Guide de démarrage rapide

Belimo

Belimo Z2050QS-J Manuel utilisateur

Belimo

Belimo H650SP Mode d’emploi

Belimo

Belimo 6-Way ePIV Manuel utilisateur

Belimo

Belimo UGVL Series Manuel utilisateur

Belimo

Belimo F6 HS Series Manuel utilisateur

Belimo

Belimo LRB24-SA Manuel utilisateur

Belimo

Belimo SHP Series Mode d'emploi

Belimo

Belimo EFB Series Guide de référence

Belimo

Belimo L Series Manuel utilisateur

Manuels Unité de contrôle populaires d'autres marques

Festo

Festo Compact Performance CP-FB6-E Manuel de la liste des pièces

Elo TouchSystems

Elo TouchSystems DMS-SA19P-EXTME Manuel utilisateur

JS Automation

JS Automation MPC3034A Manuel utilisateur

JAUDT

JAUDT SW GII 6406 Series Guide rapide

Spektrum

Spektrum Air Module System Manuel utilisateur

BOC Edwards

BOC Edwards Q Series Manuel utilisateur

KHADAS

KHADAS BT Magic Manuel utilisateur

Etherma

Etherma eNEXHO-IL Manuel utilisateur

PMFoundations

PMFoundations Attenuverter Manuel utilisateur

GEA

GEA VARIVENT Manuel utilisateur

Walther Systemtechnik

Walther Systemtechnik VMS-05 Manuel utilisateur

Altronix

Altronix LINQ8PD Instructions de montage

Eaton

Eaton Powerware Series Manuel utilisateur

WAGO

WAGO 750-407/040-000 Manuel utilisateur

Sony

Sony CCU-590 Manuel utilisateur

Graco

Graco 25D614 Manuel utilisateur

Task Force Tips

Task Force Tips YE-RF-900 Manuel de programmation

Shini

Shini SPV-U Series Manuel utilisateur
