Thank you for showing your condence in us by purchasing the BEHRINGER DYNAMICS COMPRESSOR DC9.

This ultimate eects pedal is specically designed to give a stable dynamics and an endless sustain to your

guitar by evening out the signal without degrading the original sound. You can also use the DC9 to boost

the overall volume of your instrument for solo parts.

A compressor limits the dynamic range of a signal by attenuating signal peaks exceeding a certain threshold level.

The amount of gain reduction is determined by the compression ratio. The result of compression is an attenuation

of the dierence between loudest and softest playing which achieves a more powerful and punchy tone.

1. Controls

(1) The SENSITIVITY control determines the compression ratio. The higher you set the

SENSITIVITY value, the more the compression intensies. In other words, as you increase

the SENSITIVITY, you reduce the level dierence between softest and loudest playing.

(2) The OUTPUT control adjusts the output level. Use it to compensate the gain reduction resulting

from the compression or to boost the output level of your instrument.

(3) The LED illuminates when the eect is activated. It also serves as a battery level indicator.

(4) Depress the footswitch to activate/deactivate the eect.

(5) Use this ¼" TS IN connector to plug in the instrument cable.

(6) The ¼" TS OUT connector sends the signal to your amp.

Use the DC IN connection to plug in a 9 V power supply (not included).

To install or replace the 9 V battery, remove the bottom side of the unit taking the four screws o.

◊ The DC9 has no on/o switch. As soon as you connect the jack to the in connector, the DC9

is switched on. When the DC9 is not being used, remove the jack from the in to extend

the battery life.

The SERIAL NUMBER is located on the bottom side of the device.

(2)

(6)

(1)

(5)

(3)

(4)

DYNAMICS COMPRESSOR DC9

Classic Dynamics Compressor

DYNAMICS COMPRESSOR DC9

TECHNICAL SPECIFICATIONS AND APPEARANCES ARE SUBJECT TO CHANGEWITHOUT NOTICE AND ACCURACY IS NOT GUARANTEED. BEHRINGER IS PART OF THE

MUSIC GROUP (MUSIC-GROUP.COM). ALLTRADEMARKS ARETHE PROPERTY OF THEIR RESPECTIVE OWNERS. MUSICGROUP ACCEPTS NO LIABILITY FOR ANY LOSS

WHICH MAY BE SUFFERED BY ANY PERSONWHO RELIES EITHER WHOLLY OR IN PART UPON ANY DESCRIPTION, PHOTOGRAPH OR STATEMENT CONTAINED HEREIN.

COLORS AND SPECIFICATIONS MAY VARY FROM ACTUAL PRODUCT. MUSIC GROUP PRODUCTS ARE SOLD THROUGH AUTHORIZED FULLFILLERS AND RESELLERS

ONLY. FULLFILLERSAND RESELLERS ARE NOT AGENTS OF MUSICGROUP AND HAVE ABSOLUTELY NO AUTHORITY TO BIND MUSICGROUP BY ANY EXPRESS OR

IMPLIED UNDERTAKING OR REPRESENTATION. THIS MANUAL IS COPYRIGHTED. NO PART OF THIS MANUAL MAY BE REPRODUCED OR TRANSMITTED IN ANY FORM

OR BY ANY MEANS, ELECTRONIC OR MECHANICAL, INCLUDING PHOTOCOPYING AND RECORDING OF ANY KIND, FOR ANY PURPOSE, WITHOUTTHE EXPRESS

Tortola, British Virgin Islands

2. Safety Instructions

Do not use near water, or install near heat sources. Use only authorized attachments/accessories.

Do not service product yourself. Contact our qualied servicing personnel for servicing or repairs,

especially when power supply cord or plug is damaged.

3. Warranty

Please register your new BEHRINGER equipment right after your purchase by visiting

http://behringer.com and read the terms and conditions of our warranty carefully.

4. Specications

Connector ¼" TS

Impedance 1 M

Out

Connector ¼" TS

Impedance 1 k

Power Supply

9 V

𝌂

, 100 mA regulated

BEHRINGER PSU-SB

USA/Canada 120 V~, 60 Hz

Europe/U.K./ 230 V~, 50 Hz

Australia

China/Korea 220 V~, 50/60 Hz

Japan 100 V~, 50/60 Hz

Power connector 2 mm DC jack,

negative center

Battery 9 V type 6LR61

Power consumption 9 mA

Physical/Weight

Dimensions approx. 2 ⁄ x 4 ⁄ x 2 ⁄"

(H x W x D) approx. 56 x 113 x 69 mm

Weight approx. 0.53 lbs / 0.24 kg

BEHRINGER is constantly striving to maintain the

highest professional standards. As a result of these efforts,

modifications may be made from time to time to existing

products without prior notice. Specifications and appearance

may therefore differ from those listed or shown.
