Behringer Chorus Space-D CD400 Manuel utilisateur

CHORUS SPACE-D CD400

Thank you for showing your confidence in us by purchasing the BEHRINGER CHORUS SPACE-D

CD400. This ultimate effects pedal is designed to suit almost any application you can think of. Add

a breathtaking third dimension to your sound or instrument and experience the secret weapon of

professional recording studios.

The chorus effect adds a shifting detuned signal to the original, similar to playing in unison in a group

of instruments, and it is often used for dispersing sounds.

1. CONTROLS

Top view

The LEVEL control adjusts the effect sound level.

The EQ control allows you to shape your overall effect sound. Turning it to the right will

emphasize high frequencies while turning to the the left will cut them.

The RATE control determines the chorus effect speed.

Turn up the DEPTH control to achieve a fuller and deeper effect sound.

The ON/BATT LED illuminates when the effect is activated. It also serves as a battery level

indicator.

Use the footswitch to activate/deactivate the effect.

Use this 1/4" TS IN connector to plug in the instrument cable.

Thetwo1/4"TSOUTAandOUTBconnectorssendthesignaltoyouramp.Usebothconnectors

if you want to achieve full stereo chorus effect. For mono use plug in OUT A only.

Use the DC IN connection to plug in a 9 V power supply (not included).

The BATTERY COMPARTMENT is located underneath the pedal cover. To install or replace the 9 V

battery (not included), press the hinges with a ballpoint pen and remove the pedal cover. Be careful

not to scratch the unit.

The CD400 has no on/off switch. As soon as you insert the plug into the IN connector, the

CD400 begins running. When not using the DC400, remove the plug from the IN connector.

This extends the life of the battery.

The SERIAL NUMBER is located on the underside.

In rare cases interferences of the normal function may appear by external influence (e.g.

electrostatic discharge), as for example sound disturbances or malfunctions. If this

occurs, please turn down the volume on subsequent amplifiers and disconnect the

input connector briefly to restart the application.

CHORUS SPACE-D CD400

2. WARRANTY

For our current warranty terms, please refer to our website at http://www.behringer.com.

3. SPECIFICATIONS

IN Connector 1/4"TS

Impedance 500kΩ

OUTA Connector 1/4"TS

Impedance 1 kΩ

OUT B Connector 1/4"TS

Impedance 1 kΩ

Power supply 9 V_, 100 mA, regulated

BEHRINGER PSU-SB

USA/Canada 120 V~, 60 Hz

Europe/U.K./Australia 230 V~, 50 Hz

China 220 V~, 50 Hz

Korea 220 V~, 60 Hz

Japan 100 V~, 50/60 Hz

Powerconnector 2 mm DC jack, negative center

Battery 9 V type 6LR61

Powerconsumption 30 mA

Dimensions (H x W x D) approx. 54 mm (2 1/8") x 70 mm (2 3/4") x 123 mm (4 4/5")

Weight approx. 0.33 kg (0.73 lbs)

BEHRINGER is constantly striving to maintain the highest professional standards. As a result of these efforts, modifications may be made

from time to time to existing products without prior notice. Specifications and appearance may therefore differ from those listed or shown.

4. SAFETY INSTRUCTIONS

Donotusenearwater,orinstallnearheatsources.Useonlyauthorizedattachments/accessories.Donotserviceproductyourself.

Contactourqualifiedservicing personnelforservicingorrepairs,especiallywhenpower supply cord orplugisdamaged.

Noutilizarcercadeaguaoinstalarcercadefuentesdecalor.Utilicesóloaccesoriosyaditamentosautorizados.Nointenté

repararel productoustedmismo.Contacteanuestropersonaltécnicocualificadoparaservicioyreparaciones, especialmente

cuando la fuente o el cable de alimentación estén dañados.

Не эксплуатируйте прибор вблизи от источников воды и тепла. Применяйте только авторизованные дополнительные

устройства. Никогда не ремонтируйте прибор самостоятельно. Ремонт может производить только квалифицированный

специализированный персонал, особенно при повреждениях сетевого провода или сетевой вилки.

Die deutsche Anleitung ist erhältlich @ www.behringer.com

Manuel francophone en téléchargement sur www.behringer.com

Manualenespañoldisponibleen www.behringer.com

Manualiitalianidisponibili@ www.behringer.com

Русскоязычное руководство @ www.behringer.com

Polska instrukcja dostępna jest pod adresem @ www.behringer.com

Nederlandsehandleidingbeschikbaar@www.behringer.com

Suomenkielinen käyttöohje saatavilla osoitteesta www.behringer.com

Svensk manual finns tillgänglig på www.behringer.com

Dansk vejledning findes på @ www.behringer.com

Manualportuguês disponível @ www.behringer.com

Åëëçíéêü åã÷åéñßäéï õðÜñ÷åé äéáèÝóéìï óôç äéåýèõíóç www.behringer.com

Technicalspecificationsandappearancesubject tochangewithoutnotice.Theinformationcontainedhereiniscorrectatthe time

ofprinting.BEHRINGERacceptsnoliabilityforanylosswhichmaybesufferedby anypersonwhorelies eitherwhollyorin part

uponanydescription,photographorstatement contained herein. Colours and specification may vary slightly from product.

Productsare sold through ourauthorised dealers only. Distributors anddealers are not agentsof BEHRINGERand have

absolutelynoauthoritytobindBEHRINGERbyanyexpressorimpliedundertakingorrepresentation.Nopartofthismanualmay

bereproducedortransmittedinanyformorbyanymeans,electronicormechanical,includingphotocopyingandrecordingofany

kind,foranypurpose,withouttheexpresswrittenpermissionofBEHRINGERInternationalGmbH.BEHRINGER,theBEHRINGER

Hanns-Martin-Schleyer-Str.36-38,47877 Willich-MünchheideII,Germany.Tel. +49215492060, Fax+4921549206 4903
