Behringer BOD100 Manuel utilisateur

BASS OVERDRIVE BOD100

Thank you for showing your confidence in us by purchasing the BEHRINGER BASS

O ERDRI E BOD100. This high-quality effects pedal is specifically designed for bass

applications. Thanks to its high-performance features you will achieve tube-like distortion,

smooth sustain and super fat tone with maximum punch.

1. CONTROLS

Top view

The LEVEL control adjusts the output level.

The HIGH control allows you to boost/cut the high-frequency range.

The LOW control allows you to boost/cut the low-frequency range.

Use the GAIN control to adjust the amount of overdrive.

With the BAL(ance) control you can adjust the amount of the dry direct signal and

the effect signal.

The ON/BATT LED illuminates when the effect is activated. It also serves as a

battery level indicator.

Use the footswitch to activate/deactivate the effect.

Use this 1/4" TS IN connector to plug in the instrument cable.

The 1/4" TS OUT connector sends the signal to your amp.

Use the DC IN connection to plug in a 9 power supply (not included).

The BATTERY COMPARTMENT is located underneath the pedal cover. To install or

replace the 9 battery, press the hinges with a ballpen and remove the pedal cover. Be

careful not to scratch the unit.

+The BOD100 has no on/off switch. As soon as you insert the jack into the

IN connector, the BOD100 begins running. hen not using the BOD100,

remove the jack from the IN connector. This extends the life of the

battery.

BASS OVERDRIVE BOD100

The SERIAL NUMBER is located at the bottom.

2. WARRANTY

For our current warranty terms, please refer to our website at http://

www.behringer.com.

3. SPECIFICATIONS

Connector 1/4" TS

Impedance 500 kW

Out

Connector 1/4" TS

Impedance 1 kW

Power supply 9 , 100 mA DC regulated

PSU-SB-CN BEHRINGER 220 AC adaptor China

PSU-SB-EU BEHRINGER 230 AC adaptor Europe

PSU-SB-JP BEHRINGER 100 AC adaptor Japan

PSU-SB-SAA BEHRINGER 240 AC adaptor Australia

PSU-SB-UK BEHRINGER 240 AC adaptor UK

PSU-SB-UL BEHRINGER 115 AC adaptor USA

Power connector 2 mm DC jack, negative center

Battery 9 type 6LR61

Power consumption 30 mA

Dimensions (H x W x D) approx. 54 mm (2 1/8") x 70 mm (2 3/4") x 123 mm (4 4/5")

Weight approx. 0.33 kg (0.73 lbs)

BEHRINGER is constantly striving to maintain the highest professional standards. As a result of these efforts, modifications

may be made from time to time to e isting products without prior notice. Specifications and appearance may therefore differ from

those listed or shown.

4. SAFETY INSTRUCTIONS

Do not use near water, or install near heat sources. Use only authorized attachments/accessories. Do not service product yourself.

Contact our qualified servicing personnel for servicing or repairs, especially when power supply cord or plug is damaged.

No utilizar cerca de agua o instalar cerca de fuentes de calor. Utilice sólo accesorios y aditamentos autorizados. No intenté

reparar el producto usted mismo. Contacte a nuestro personal técnico cualificado para servicio y reparaciones, especialmente

cuando la fuente o el cable de alimentación estén dañados.

Íåýêñïëóàòèðóéòåïðèáîðâáëèçèîòèñòî÷íèêîââîäûèòåïëà.Ïðèìåíÿéòåòîëüêîàâòîðèçîâàííûåäîïîëíèòåëüíûå

óñòðîéñòâà.Íèêîãäàíåðåìîíòèðóéòåïðèáîðñàìîñòîÿòåëüíî.Ðåìîíòìîæåòïðîèçâîäèòüòîëüêîêâàëèôèöèðîâàííûé

ñïåöèàëèçèðîâàííûéïåðñîíàë 

îñîáåííîïðèïîâðåæäåíèÿõñåòåâîãîïðîâîäàèëèñåòåâîéâèëêè.

Technical specifications and appearance subject to change without notice. The information contained herein is correct at the time

of printing. The names of companies, institutions or publications pictured or mentioned and their respective logos are registered

trademarks of their respective owners. Their use neither constitutes a claim of the trademarks by BEHRINGER® nor affiliation of

the trademark owners with BEHRINGER®. BEHRINGER® accepts no liability for any loss which may be suffered by any person

who relies either wholly or in part upon any description, photograph or statement contained herein. Colours and specification may

vary slightly from product. Products are sold through our authorised dealers only. Distributors and dealers are not agents of

BEHRINGER® and have absolutely no authority to bind BEHRINGER® by any e press or implied undertaking or representation.

No part of this manual may be reproduced or transmitted in any form or by any means, electronic or mechanical, including

photocopying and recording of any kind, for any purpose, without the e press written permission of BEHRINGER Spezielle

Studiotechnik GmbH, Hanns-Martin-Schleyer-Str. 36-38, 47877 Willich-Münchheide II, Germany. Tel. +49 2154 9206 0,

Fa +49 2154 9206 4903

Die deutsche Anleitung ist erhältlich @ www.behringer.com

Manuel francophone en téléchargement sur www.behringer.com

Manual en español disponible en www.behringer.com

Manuali italiani disponibili @ www.behringer.com

Ðóññêîÿçû÷íîåðóêîâîäñòâî@www.behringer.com

Polskainstrukcjadostêpnajestpodadresem@www.behringer.com

Nederlandse handleiding beschikbaar @ www.behringer.com

Suomenkielinen kä ttöohje saatavilla osoitteesta www.behringer.com

Svensk manual finns tillgänglig på www.behringer.com

Dansk vejledning findes på @ www.behringer.com

Manual português disponível @ www.behringer.com

Åëëçíéêü åã÷åéñßäéï õðÜñ÷åé äéáèÝóéìï óôç äéåýèõíóç www.behr nger.com
