Beckhoff KM4602 Manuel de l'opérateur

Documentation

KM4602

Two Channel Analog Output Module with Manual and

Automatic Operation

2.2.0

2019-05-02

Version:

Date:

Table of contents

KM4602 3Version: 2.2.0

Table of contents

1 Foreword ....................................................................................................................................................5

1.1 Notes on the documentation..............................................................................................................5

1.2 Safety instructions .............................................................................................................................6

1.3 Documentation issue status ..............................................................................................................7

2 Product overview.......................................................................................................................................8

2.1 Introduction........................................................................................................................................8

2.2 Technical data ...................................................................................................................................9

3 Mounting and wiring................................................................................................................................10

3.1 Recommended mounting rails.........................................................................................................10

3.2 Mounting and demounting - terminals with front unlocking .............................................................10

3.3 Dimensions......................................................................................................................................12

3.4 Connection ......................................................................................................................................13

4 Access from the user program ..............................................................................................................15

4.1 Process image.................................................................................................................................15

4.2 Mapping...........................................................................................................................................15

4.3 Control and status byte....................................................................................................................17

4.4 Register overview ............................................................................................................................19

4.5 Register description.........................................................................................................................20

4.6 Examples of Register Communication ............................................................................................23

4.6.1 Example 1: reading the firmware version from Register 9............................................... 23

4.6.2 Example 2: Writing to an user register............................................................................. 23

5 Appendix ..................................................................................................................................................27

5.1 Support and Service ........................................................................................................................27

Table of contents

KM46024 Version: 2.2.0

Foreword

KM4602 5Version: 2.2.0

1 Foreword

1.1 Notes on the documentation

Intended audience

This description is only intended for the use of trained specialists in control and automation engineering who

are familiar with the applicable national standards.

It is essential that the documentation and the following notes and explanations are followed when installing

and commissioning these components.

It is the duty of the technical personnel to use the documentation published at the respective time of each

installation and commissioning.

The responsible staff must ensure that the application or use of the products described satisfy all the

requirements for safety, including all the relevant laws, regulations, guidelines and standards.

Disclaimer

The documentation has been prepared with care. The products described are, however, constantly under

development.

We reserve the right to revise and change the documentation at any time and without prior announcement.

No claims for the modification of products that have already been supplied may be made on the basis of the

data, diagrams and descriptions in this documentation.

Trademarks

Beckhoff®, TwinCAT®, EtherCAT®, EtherCATP®, SafetyoverEtherCAT®, TwinSAFE®, XFC® and XTS® are

registered trademarks of and licensed by Beckhoff Automation GmbH.

Other designations used in this publication may be trademarks whose use by third parties for their own

purposes could violate the rights of the owners.

Patent Pending

The EtherCAT Technology is covered, including but not limited to the following patent applications and

patents: EP1590927, EP1789857, DE102004044764, DE102007017835 with corresponding applications or

registrations in various other countries.

The TwinCAT Technology is covered, including but not limited to the following patent applications and

patents: EP0851348, US6167425 with corresponding applications or registrations in various other countries.

EtherCAT® is registered trademark and patented technology, licensed by Beckhoff Automation GmbH,

Germany.

The reproduction, distribution and utilization of this document as well as the communication of its contents to

others without express authorization are prohibited.

patent, utility model or design.

Foreword

KM46026 Version: 2.2.0

1.2 Safety instructions

Safety regulations

Please note the following safety instructions and explanations!

Product-specific safety instructions can be found on following pages or in the areas mounting, wiring,

commissioning etc.

Exclusion of liability

All the components are supplied in particular hardware and software configurations appropriate for the

application. Modifications to hardware or software configurations other than those described in the

documentation are not permitted, and nullify the liability of Beckhoff Automation GmbH & Co. KG.

Personnel qualification

This description is only intended for trained specialists in control, automation and drive engineering who are

familiar with the applicable national standards.

Description of instructions

In this documentation the following instructions are used.

These instructions must be read carefully and followed without fail!

DANGER

Serious risk of injury!

Failure to follow this safety instruction directly endangers the life and health of persons.

WARNING

Risk of injury!

Failure to follow this safety instruction endangers the life and health of persons.

CAUTION

Personal injuries!

Failure to follow this safety instruction can lead to injuries to persons.

NOTE

Damage to environment/equipment or data loss

Failure to follow this instruction can lead to environmental damage, equipment damage or data loss.

Tip or pointer

This symbol indicates information that contributes to better understanding.

Foreword

KM4602 7Version: 2.2.0

1.3 Documentation issue status

Version Comment

2.2.0 • Update Technical data

• Update structure

2.1.0 • Description of Control Byte corrected

2.0.0 • Migration

1.0.0 • First publication

Firmware and hardware versions

Documentation, version Firmware version Hardware version

2.2.0 1C 03

2.1.0 1C 03

2.0.0 1C 02

1.0.0 1C 01

The firmware and hardware versions (delivery state) can be taken from the serial number printed on the side

of the terminal module.

Syntax of the serial number

Structure of the serial number: WWYYFFHH

WW - week of production (calendar week)

YY - year of production

FF - firmware version

HH - hardware version

Sample with ser. no.: 35 05 00 01:

35 - week of production 35

05 - year of production 2005

00 - firmware version 00

01 - hardware version 01

Product overview

KM46028 Version: 2.2.0

2 Product overview

2.1 Introduction

Fig.1: KM4602

The KM4602 analog output terminal has two potential-free analog outputs (0 to 10VDC). Both outputs are

internally connected to a common ground.

For each channel a switch enables selection between automatic and manual mode:

• In automatic mode, an analog value is output as a function of the process data.

• In manual mode, the value set via the potentiometer is applied to the output.

The 24VDC (UL) Bus Coupler supply voltage is also required for manual mode.

The state of the switches can be read by the controller (bit 0 of the status bytes).

Product overview

KM4602 9Version: 2.2.0

2.2 Technical data

Technical data KM4602-0000

Number of outputs 2

Connection technology Single ended

Output voltage 0 to 10 VDC

Load > 5kΩ (short-circuit-proof)

Resolution 12 bit

Output error < ±0.1% (based on the end value)

Power supply for the electronics via the K-bus

Current consumption from K-bus typically 175 mA

Width of a bus terminal block Maximum 64 standard Bus Terminals or 80cm

(one KM4602-0000 corresponds to 2 standard Bus

Terminals here)

Data width in the input process image 8 bit status, 16 bit data

Data width in the output process image 8 bit control, 16 bit data

Configuration no address or configuration settings

Operation modes Manual or automatic operating mode

Electrical isolation 500 V (K-Bus/signal voltage)

Dimensions without antenna (W x H x D) approx. 26.5mm x 100mm x 55mm (width aligned:

24mm)

Weight approx. 85 g

Permissible ambient temperature range during

operation

0°C ... + 55°C

Permissible ambient temperature range during

storage

-25°C ... + 85°C

Permissible relative humidity 95%, no condensation

Mounting [}10] on a 35 mm mounting rail [}10] (e.g. DIN rail TH

35-7.5 conforming to EN 60715)

Vibration/shock resistance conforms to EN 60068-2-6 / EN 60068-2-27

EMC immunity/emission conforms to EN61000-6-2/ EN61000-6-4,

EN300-440-02

Protection class IP20

Installation position variable

Approval CE

Mounting and wiring

KM460210 Version: 2.2.0

3 Mounting and wiring

3.1 Recommended mounting rails

Terminal Modules und EtherCAT Modules of KMxxxx and EMxxxx series, same as the terminals of the

EL66xx and EL67xx series can be snapped onto the following recommended mounting rails:

• DIN Rail TH35-7.5 with 1mm material thickness (according to EN60715)

• DIN Rail TH35-15 with 1,5mm material thickness

Pay attention to the material thickness of the DIN Rail

Terminal Modules und EtherCAT Modules of KMxxxx and EMxxxx series, same as the terminals of

the EL66xx and EL67xx seriesdoes not fit to the DIN Rail TH35-15 with 2,2 to 2,5mm material

thickness (according to EN60715)!

3.2 Mounting and demounting - terminals with front

unlocking

The terminal modules are fastened to the assembly surface with the aid of a 35 mm mounting rail (e.g.

mounting rail TH 35-15).

Fixing of mounting rails

The locking mechanism of the terminals and couplers extends to the profile of the mounting rail. At

the installation, the locking mechanism of the components must not come into conflict with the fixing

bolts of the mounting rail. To mount the recommended mounting rails under the terminals and cou-

plers, you should use flat mounting connections (e.g. countersunk screws or blind rivets).

WARNING

Risk of electric shock and damage of device!

Bring the bus terminal system into a safe, powered down state before starting installation, disassembly or

wiring of the Bus Terminals!

Mounting

• Fit the mounting rail to the planned assembly location.

and press (1) the terminal module against the mounting rail until it latches in place on the mounting

rail (2).
