BCM MX56N Manuel d'installation et d'exploitation

MX56N

AMD G-Series APU with A55E Controller Hub (FCH) Mini ITX Motherboard

Startup Manual Ver. 1.0

BCM Advanced Research, An Industrial Leader Since 1990 in Industrial Motherboards & Systems

11 Chrysler, Irvine, CA 92618 USA | www.bcmcom.com | (PH)949.470.1888 | (FAX)949.470.0971

For Tech Support, please visit www.bcmcom.com/bcm_support_legacyProductSupport.htm or contact

BCMTechSupport@bcmcom.com

Packing List

Before you begin installing your single board, please make sure that the following parts

have been shipped.

1 x AA55E-IF Mini ITX Main board

1 x CD-ROM contains OS drivers

1 x CPU Cooler

1 x SATA cable

1 x I/O Shield

1 x Startup Manual

Disclaimer and Notice

The manufacturer reserves the right to make changes, without notice, to

any product, including circuits and/or software described or contained in this

manual in order to improve design and/or performance. The manufacturer

assumes no responsibility or liability for the use of the described product(s),

conveys no license or title under any patent, copyright, or masks work rights

to these products, and makes no representations or warranties that these

products are free from patent, copyright, or mask work right infringement,

unless otherwise specified. For the detail product information, please refer

to user’s manual.

Product Overview

Specifications

System

APU AMD G-Series DC T56N 1.6GHz/T48N 1.4GHz/T40N 1.0GHz/ SC T44R 1.2GHz

FCH AMD A55E Controller Hub (Hudson-E1)

BIOS AMI 16Mb SPI

System Chipset AMD G-Series+A55E Controller Hub

I/O Chipset Winbond W83627DHG-P

Memory One 204-pin SODIMM sockets support up to 4GB DDR3 1066 MT/s

SSD CFast connector on the back

Watchdog Timer Reset: 1 to 255 sec/min per step

H/W Status Monitor Monitoring temperature, voltage and cooling fan status. Auto throttling control

when CPU overheats.

Expansion Slots 1 PCI-E x4 Gen.2, 1 Mini PCI-E, 1 CFast

Power State S3, S4, S5

Wake up on LAN or Ring LAN

Smart Fan Control Yes

Display

Chipset AMD Radeon HD 6310 (T56N/T48N) / AMD Radeon HD 6250 (T40N/T44R)

Display Memory Shared Memory, up to 512MB

Dual Display VGA+LVDS, VGA+HDMI, HDMI+LVDS, eDP+HDMI, eDP+VGA

VGA Onboard, T56N/T48N (18W) supports up to 2560 x 1600

T40N/T44R (9W) supports up to 1920 x 1200

HDMI Onboard, supports HDMI 1.3a & up to 1920 x 1080

LVDS Onboard, 18-bit single channel LVDS

LVDS Backlight Yes, PWM Control (Backlight adjusted from AMD A55E Controller Hub)

eDP Onboard, Optional ( 18,24,30 bpp up to 1920x1200 9W / 2560 X1600 18W )

Audio

Audio Codec Realtek ALC892, 7.1 Channel HD Audio

Audio Interface Line-in, Line-out, Mic-in, S/PDIF, Front Audio Header

Ethernet

LAN1/LAN2 Realtek RTL8111DL GbE LAN

Jumpers

Label Function Note

CMOS1 Clear CMOS Normal *

Clear CMOS

COM3, COM4 RI/+5V/+12V RI +5V +12VJSETCOM3,

JSETCOM4

COM3

COM4

RI

+5V

+12V

AT MODE ATX MODEPSON1 AT/ATX Mode Select

JBL3 LCD POWER

(VDDSAFE)

3.3V 5V

Connectors

Label Function Note

COM3 COM4COM3, COM4 Serial Port

Connector

JFP1+JFP2 System Panel &

Speaker

PIN7-10

PIN1-10 Internal SPK

External SPK PIN3-6

PIN9-12 POWER BT

SYS_RESET

JFP3 Power LED &

Keylock

LVDS1 18-bit LVDS

Connector

JBL1 Inverter PWR

CN4 SPI connector

AAFP Audio Mic.-In &

Line-Out

Connector

SPDIF_OUT1 SPDIF OUT

CN10 Amp_R+ R-/

Amp_L+ L-
