BCM GT440ZX Manuel utilisateur

Advanced Pentium II

Motherboard

GT440ZX

USER’S MANUAL

DECLARATION

Rights:

No part of this manual, including but not limited to the products and

software described in it, may be reproduced, transmitted, transcribes,

stored in a retrieval system, or translated in any form or by any means

without the expressed written permission of the manufacture.

Products and corporate names appearing in this manual may or may not be

registered trademarks or copyrights of their respective companies and are used

only for identification or explanation purposes without intent to infringe.

♦Intel, MMX and Pentium are registered trademarks of Intel Corporation.

♦IBM and OS/2 are registered trademarks of International Business Machines.

♦AWARD is a registered trademark of Award Software Inc.

Responsibility:

This manual is provided “As is” with no warranties of any kind, either expressed

or implied, including, but not limited to the implied warranties or conditions of

this product’s fitness for any particular purpose. In no event shall we be liable for

any loss of profits, loss of business, loss of data, interruption of business, or

indirect, special, incidental, or consequential damages of any kind, even the

possibility of such damages arising from any defect or error in this manual or

product. We reserve the right to modify and update the user manual without prior

notice.

COMPLIANCE & CERTIFICATE

ISO 9001 Certificate:

This device was produced in our plant with advanced quality

system certified by DNV QA Ltd. in according to ISO 9001.

This Certificate is valid for:

DESIGN & MANUFACTURE OF MOTHER BOARDS AND

PERSONAL COMPUTERS.

CE Declaration:

CE marking is a visible declaration by the manufacturer or

his authorized representatives that the electrical equipment to

which it relates satisfies all the provisions of the 1994

Regulations.

FCC Compliance:

FCC stands for Federal Communications Commission.

This product complies with FCC Rules Part 15 and has been

tested, and complied with the EMI rules by a certified body.

In normal operation, there shall be no harmful interference

caused by this device nor shall this devise accept any

interference received, including interference that may cause

undesired operation of this product.

Year 2000 Compliance:

This product is tested to be qualified to bear the NSTL Year

2000 Compliant logo. Year2000 problem is mainly a

problem of computer software (OS), and the hardware issue.

With the support of BIOS on motherboard, the Y2K problem

can be thoroughly conquered.

EASY INSTALLATION

Easy Installation Steps

The following “Easy Installation” steps are for

users accustomed to the assembly of a computer

system. For those individuals requiring more

specific information please refer to the more

detailed descriptions located within the latter

chapters of this manual. Note: You must keep

your power cable unplugged until the following

installation steps are completed.

Getting Start:

Touch a grounded metal surface to release static electricity

stored in your body before unpacking your motherboard. For

details please refer to Precaution section in Chapter 3.

Install the CPU by correctly aligning the CPU with the slot1 as

noted in the motherboard diagram. Once aligned, press down on

the CPU gently but firmly and lock it. Next, install the 3.3 volt

unbuffered SDRAM into the 168 pin

DIMMs. See Sec. 3.2 & Sec. 3.3.

Set CPU speed in according to Sec.3.2.

After completing the above steps, install any expansion

Cards( PCI, ISA) into riser card and have the riser card installed

firmly into the slot for riser card on board. See Sec. 3.4.

Plug in all cables included in the package except for the

power cord. Please see Sec. 3.5.

Please recheck all steps to ensure no mistakes

have been made and then plug in the power cord

and turn on the power to enter the BIOS setup, Chapter 4.

Release

Static Electricity

Couple

Connectors Of

HDD, FDD…

Install All

Expansion Slots

Set Jumpers of

CPU

Insert CPU &

RAM

EASY INSTALLATION

CONTENTS

1INTRODUCTION....................................................................8

2FEATURES............................................................................9

3INSTALLATION......................................................................12

3.1 SLOTS AND CONNECTORS ..................................................15

3.2 CPU (CENTRAL PROCESSING UNIT).....................................16

3.2.1 Install CPU..........................................................................16

3.2.2 Set CPU Speed ..................................................................18

3.3 SYSTEM MEMORY (DRAM) .................................................20

3.3.1 DIMM (Dual Inline Memory Module).....................................20

3.3.2 Installation Procedure..........................................................20

3.3.3 DIMM Module Combinations................................................21

3.4 EXPANSION SLOTS .............................................................22

3.5 CONNECTORS....................................................................23

3.5.1 Primary IDE Connector (J21, 39-pin block)..........................23

3.5.2 Secondary IDE Connector (J18, 39-pin block) .....................23

3.5.3 Floppy Drive Connector (J23, 33-pin block) .........................24

3.5.4 Power Input Connector (J20, 20-pin block)..........................24

3.5.5 Front Panel connectors.......................................................25

3.5.6 Back Panel Connectors.......................................................27

Additional Connectors......................................................................30

4BIOS SETUP .........................................................................36

4.1 HOW TO ENTER BIOS SETUP.............................................36

4.1.1 Setup Keys.........................................................................37

4.1.2 Getting Help........................................................................37

4.1.3 In Case of Problems............................................................37

CONTENTS

4.2 MAIN SETUP MENU.............................................................38

4.3 STANDARD CMOS SETUP MENU.........................................40

4.4 BIOS FEATURES SETUP MENU ...........................................44

4.5 CHIPSET FEATURES SETUP MENU........................................47

4.6 POWER MANAGEMENT SETUP MENU....................................49

4.7 PCI CONFIGURATION SETUP MENU......................................52

4.8 INTEGRATED PERIPHERALS MENU ........................................53

4.9 LOAD SETUP DEFAULTS......................................................56

4.10 USER PASSWORD ..............................................................56

4.11 IDE HDD AUTO DETECTION ...............................................56

4.12 SAVE & EXIT SETUP ...........................................................56

4.13 EXIT WITHOUT SAVING .......................................................57

1. INTRODUCTION

How To Use This Manual

This manual provides information necessary

for Original Equipment Manufactures (OEMs)

and home users to build a PC-AT compatible

system using the Pentium II PCI/ISA/AGP

motherboard. Just follow the installation

procedure presented on the EASY

INSTALLATION Page and refer to the section number following each

step if you require more detailed instructions.

Check Your Device Items

The standard package should contain

following items marked with a “4”, If you

find any these items missing or damaged.

Please contact your retailer.

4The GT440ZX motherboard

4Universal Retention Mechanism ( Support both Pentium II & Celeron CPU)

41 IDE ribbon cable

41 floppy ribbon cable

41 CD with drivers of Audio and PIIX4E Bus Master.

2. FEATURES

Photo Of The Motherboard

2. FEATURES

Features Of The Motherboard

The GT440ZX motherboard integrates the Pentium II 

microprocessor, memory, I/O and AGP, and is designed to fit into a

Micro ATX form factor chassis. Page 14 illustrates the Layout for

the GT440ZX motherboard. Below lists the key features provided

by this motherboard:

Processor (+Cache)

lSingle Slot-1 for Intel Pentium II Processor.

lIntel Pentium II CPU with built-in 512K/128K/0K L2 Cache.

lSupport Pentium II, Celeron processor speeds (233-500MHz)

Chipset

lIntel 440ZX, PIIX4E Chipset

lWinbond W83977EF super I/O Controller.

lCreative Lab. ES1373 PCI 3D Audio Chip, AC97 Codec.

System Memory

lTwo168-pin DIMM sockets

lMinimum 8MB up to maximum 256 MB Memory Capacity.

l66MHz / 100MHz SDRAM DIMM module.

PCI Bus Master IDE Controller

lIntegrated PCI Bus Master IDE Controller Chip with Ultra-DMA33 capabilities. Up to

four IDE devices can be supported using the two onboard IDE connectors. Also supported

is PIO Modes 3&4, Bus Master IDE DMA Mode 2 and Enhanced IDE devices such as

Tape Backup machines and CD-ROMs. Either the 5.25-inch or 3.5 inch (1.44MB or

2.88MB) floppy drives can be used without requiring an external card. Additionally,

Floppy 3 mode (Japanese standard 3.5 inch disk drive, 1.2MB) and LS-120 floppy disk

drives (3.5 inch disk drive: 120MB, 1.44MB, 720K) are also supported.

Integrated I/O

l1 Floppy Port (up to 2.88 MB), 1 Parallel Port (ECP/EPP).

l2 Serial Ports (16C550 Fast UART Compatible).

l1 IrDA TX/RX Port. (option, shared with COM2)

l1 PS/2 Mouse Connector, 1 PS/2 Keyboard connector.

l2 Standard USB Connector (48MHz).

System BIOS

l2MB with bootblock flash BIOS. Award PCI BIOS.

lPC97 and PnP compatible. ACPI, APM and DMI support.

lBootable from CD-ROM supported.

Green Features

lPower Management: APM 1.2.
