Baumatic BTT970SS Manuel utilisateur

BTT970SS

Cooker Hood

User Manual for your Baumatic

BTT970SS

90 cm Telescopic cooker hood

NOTE: This User Instruction Manual contains important

information, including safety & installation points, which will

enable you to get the most out of your appliance. Please keep it

in a safe place so that it is easily available for future reference; for

you or any person not familiar with the operation of the appliance.

GS 21/07/10

Contents Page

Environmentalnote 4

IMPORTANT SAFETY INFORMATION 5 – 7

Specifications of your cooker hood 8

Using your Baumatic cooker hood 9 – 11

Settingthetimeofday 10

Switching the cooker hood on and setting the fan speed 10 - 11

Thecutofftimer 11

Cleaning your Baumatic cooker hood 12

The grease filters 12

Maintenance 13 - 15

Removing and cleaning the grease filters 13 - 14

Changingalightbulb 14-15

Installation 15 - 23

Electrical connection 15 - 16

Before beginning installation 16 - 17

Installing your cooker hood 17 - 20

Fitting the chimney 20 – 22

Completing the installation 23

Troubleshooting 24 – 25

Contactdetails 26

ENVIRONMENTAL NOTE

Note: Before discarding an old appliance, switch off and

disconnect it from the power supply. Cut off and render any

plug useless. Cut the cable off directly behind the appliance to

prevent misuse. This should be undertaken by a competent

person.

CONFORMITY TO W.E.E.E. DIRECTIVE

IMPORTANT SAFETY INFORMATION

Your safety is of the utmost importance to Baumatic.

Please make sure that you read this instruction booklet

before attempting to install or use the appliance. If

you are unsure of any of the information contained in

this booklet, please contact the Baumatic Advice Line.

IMPORTANT: Any installation work must be

carried out by a qualified electrician or

competent person.

oThe hood must be installed in accordance with the installation

instructions and all measurements followed.

oIf the cooker hood is installed for use above a gas appliance then

the provision for ventilation must be in accordance with the Gas

Safety Codes of Practice BS.6172, BS.5440 & BS.6891 (Natural

Gas) and BS.5482 (LP Gas) 1994, the Gas Safety (Installation &

Use) Regulations, the Building Regulations issued by the

Department of the Environment, the Building Standards

(Scotland) (Consolidated) Regulations issued by the Scottish

Development Department.

oIt is dangerous to alter the specifications or to modify this

product. Do not tamper with it or attempt to modify the

appliance in any way.

oWhen installing the hood, ensure that the following

recommended distances are observed between the highest point

on the hob top (including the burners) and the bottom of the

cooker hood:

¾Electric cookers: 700 mm

¾Gas cookers: 700 mm

¾Coal/ oil cookers: 800 mm

IMPORTANT: DO NOT SET YOUR COOKER HOOD LESS

THAN 700mm ABOVE YOUR COOKER.

oWhen installed between adjoining wall cabinets, the cabinets

must not overhang the hob.

oThe edges of the cooker hood are sharp – be mindful of this as

you handle your appliance, especially during installation and

cleaning. DO NOT CLEAN IN BEHIND THE GREASE FILTERS!

oIf the room where the cooker hood is to be used contains a fuel

burning appliance such as a central heating boiler then its flue

must be of the sealed or balanced flue type.

oIf other types of flue or appliances are fitted, ensure that there is

an adequate supply of air in the room.

oWhen the hood is being used in its extractor function, ensure

that the ducting is fire retardant and that there are no bends

sharper than 90 degrees as this will reduce the efficiency of the

hood.

oEnsure the ducting for the extractor function has the same

diameter as the outlet hole all the way through.

oKeep young children from using, playing with

or tampering with the cooker hood. Older

children and infirm persons should be

supervised if they are using the cooker hood.

oYour cooker hood is for domestic use only.

oPlease dispose of the packing material carefully – children are

especially vulnerable to it.

oDirty oil is an even greater fire risk.

oAlways put lids on pots and pans when cooking

on a gas cooker.

oThe manufacturer refuses to accept any responsibility for

damages arising to the hood or it catching on fire, from a failure

to observe the fire safety advice contained in this instruction

booklet.

oRemember that your cooker hood is removing air from your

room. Ensure that proper ventilation measures are being

observed.

oNote: Your cooker hood is designed to remove cooking

odours from the room and not steam.

oWarning - Always ensure that the cooker

hood has been disconnected from the

power supply before carrying out any work

on the hood, including replacing light bulbs.

oDo not connect the ducting system of this appliance to any

existing ventilation system which is being used for any other

purpose.

oDo not install above a cooker with a high level grill.

oNever leave frying pans unattended during use

as overheated fats and oils might catch fire.

oThe lights on this appliance should only be used during operation

of the cooker hood. They should not be left on permanently and

used as a lighting source.

oThe cooker hood should not be exposed to a direct heat source

from the cooking device underneath it, i.e. a naked flame from a

gas burner or heat from electric hob zones without a pan on

them.

oDo not attempt to use the cooker hood if it is damaged in any

way. Never attempt to use it without the grease filters fitted or

if the filters are excessively greasy!

oNever flambé cook under this cooker hood.

THE MANUFACTURER DECLINES ALL

RESPONSIBILITY IN THE EVENT OF FAILURE TO

OBSERVE THE INSTRUCTIONS GIVEN HERE, FOR

INSTALLATION, MAINTENANCE AND SUITABLE

USE OF THE HOOD.

Specifications of your cooker hood

Congratulations on purchasing a Baumatic cooker hood

PRODUCT DIMENSIONS

Height: 575 - 1055 mm *

Width: 900 mm

Depth: 330 - 485 mm

DIMENSIONS OF CHIMNEY SECTION:

Width: 303 mm

Depth: 276 mm

Your cooker hood is fitted with:

oElectronic pushbutton control operation

oLCD display

o3 Speeds

oCut-off timer

o2 x Metallic grease filters

o2 x Halogen lights

oExtraction capacity: 750 m³/hr

Using your cooker hood

oIMPORTANT: The telescopic part of the cooker hood will

extend automatically when the hood is turned on by

selecting the first motor speed.

oMake sure that it has been installed by a suitably qualified

person, as per the information contained in Baumatic’s

installation instructions.

oFind the control panel, which is located in the middle of the

canopy.

oThere are several buttons on the control panel, which perform

separate functions.

IMPORTANT: IDEALLY YOU SHOULD TURN ON YOUR

HOOD TEN MINUTES BEFORE YOU START TO COOK.

OR AT THE VERY LEAST WHEN YOU BEGIN COOKING.

YOU SHOULD ALSO RUN YOUR HOOD FOR TEN MINUTES AFTER

YOU HAVE FINISHED COOKING.

oAfter switching off the hood, the telescopic part of the hood will

return to its original position automatically.

Setting the time of day

IMPORTANT: After the cooker hood is connected to the power

supply, the time of day should be set. However it is only possible to

set the time if the light is not switched on and the cooker hood fan

is not running.

oPress and hold the timer button until the hour digits of the LED

display flash.

oUse the speed selection button to increase the hour number

shown on the LED display or the light ON/OFF button to decrease

the hour number shown on the LED display.

oIf “23” appears on the LED display, the speed selection will no

longer operate and if “00” appears on the LED display, the light

ON/OFF button will no longer operate.

oWhen the correct hour digits appear on the LED display, press

and hold the timer button until the minute digits of the LED

display flash.

oUse the speed selection button to increase the minute number

shown on the LED display or the light ON/OFF button to decrease

the minute number shown on the LED display.

oIf “59” appears on the LED display, the speed selection will no

longer operate and if “00” appears on the LED display, the light

ON/OFF button will no longer operate.

oWhen the correct minute digits appear on the LED display, press

the timer button for a third time to confirm the time of day.

Switching the cooker hood on and setting the fan speed

oPress the ON/OFF button to switch the cooker hood on.

oUse the speed selection button to regulate the speed that the

motor is running at. The motor will run at the following speeds:-

One push - Low speed

Two pushes - Medium speed

Three pushes - High speed
