Baumatic BT3060SS Manuel utilisateur

y 1

BT3060SS

Mixed fuel cooker

User Manual for your Baumatic

BT3060SS

60 cm Mixed fuel cooker

NOTE: This User Instruction Manual contains important

information, including safety & installation points, which will

enable you to get the most out of your appliance. Please keep it

in a safe place so that it is easily available for future reference; for

you or any person not familiar with the operation of the appliance.

DD 18/07/07

Contents

Environmental note 4

Important safety information 5 – 9

Specifications 10 - 11

Control Panel 12 – 13

Setting and using the oven programmer/timer 14 - 18

Selecting manual operation mode 14

Setting the time of day 14

Setting the minute minder function (top and main oven) 15

Setting the duration function (main oven only) 16

Setting the end cook function (main oven only) 17

Setting the start and end time function (main oven only) 18

Description of your appliance 19

Using the main and top oven 20 – 30

Before first use 20

Using the main oven 20 – 24

Using the top oven 24 – 27

Grilling 27–28

General cooking guidelines 29

Warnings 29 – 30

Using the gas hob top 30 – 32

Cleaning and maintenance 32 – 34

Replacing the oven bulb 34

Installation 34 – 45

Positioning 35 – 36

Gas connection 37 – 38

Gas Safety (Installation and Use) Regulations 38

Gasconnection 39

Gas adjustment (Conversion to LPG and flow adjustment) 40

Minimum flow adjustment for hob gas taps 41

Fittingastabilitychain 42

Electrical connection 43 – 45

My appliance isn’t working correctly 46 – 47

Baumatic Ltd. Conditions of Guarantee 48

Contactdetails 49

Environmental note

oThe packaging materials that Baumatic uses are environmentally

friendly and can be recycled.

oPlease discard all packaging material with due regard for the

environment.

Important safety information

Your safety is of the utmost importance to Baumatic.

Please make sure that you read this instruction booklet

before attempting to install or use the appliance. If you

are unsure of any of the information contained in this

booklet, please contact the Baumatic Technical

Department.

General Information

oThis appliance is designed for domestic household use and for

the cooking of domestic foodstuffs.

oIMPORTANT: The adjacent furniture and all materials used in

the installation must be able to withstand a minimum

temperature of 85°C above the ambient temperature of the

room it is located in, whilst in use.

oCertain types of vinyl or laminate kitchen furniture are

particularly prone to heat damage or discolouration at

temperatures below the guidelines given above.

oAny damage caused by the appliance being installed in

contravention of this temperature limit will be the liability of

the owner.

oFor use in leisure accommodation vehicles, please refer to

the appropriate information given in the installation instructions

for this appliance.

oIMPORTANT: Baumatic Ltd. DO NOT recommend that this

appliance is installed on any type of marine vessel.

oThe use of this appliance for any other purpose or in any other

environment without the express agreement of Baumatic Ltd.

will invalidate any warranty or liability claim.

oYour new appliance is guaranteed against electrical or

mechanical defects, subject to certain exclusions that are noted

in Baumatic’s Conditions Of Guarantee. The foregoing does not

affect your statutory rights.

oRepairs may only be carried out by Baumatic Service

Engineers or their authorised service agent.

Warning and safety instructions

oThis appliance complies with all current European safety

legislation. Baumatic do wish to emphasise that this compliance

does not remove the fact that the appliance surfaces will

become hot during use and retain heat after operation.

Child Safety

oBaumatic strongly recommend that babies and young children

are prevented from being near to the appliance and not allowed

to touch the appliance at any time. During and after use, all

surfaces will become hot.

oIf it is necessary for younger family members to be in the

kitchen, please ensure that they are kept under close supervision

at all times.

General Safety

Make sure that you understand the controls before using the

appliance.

Check that all of the controls on the appliance are turned off

after use.

Always stand back when opening the oven door, this will allow

heat to disperse.

Take care when removing items from the oven, as the contents

may be hot.

Always keep the oven doors closed when the oven is not in use.

Always follow the basic principles of food handling and hygiene,

this will prevent the possibility of bacterial growth.

Always keep ventilation slots clear of obstructions.

Keep fingers away from the hinge areas when closing the door,

otherwise you may trap them.

Oven gloves should be used when placing food in the oven cavity

and when removing it. Care should be taken to avoid direct

contact with any of the elements in the appliance.

oDO NOT LEAVE THE APPLIANCE UNATTENDED WHILST IN

USE.

oDo not place heavy objects on the oven door or lean on the

oven door when it is open, as this can cause damage to the oven

door hinges. Nobody should be allowed to sit or stand on any

part of the cooker.

oDo not store chemicals, food stuffs, pressurised containers in or

on the cooker or in cabinets immediately above or next to the

cooker.

oDo not heat up unopened food containers, as pressure can build

up which may cause the container to burst.

oDo not place flammable or plastic items on or near the hob

burners, these types of materials should also not be placed in

the oven or the compartment below the oven.

oDo not leave heated oil or fat unattended, as this is a fire risk.

You should not fill a deep fat frying pan more than one third full

of fat or oil, you should also not use a lid.

oDo not allow fat or oil to build up in the oven trays, grill pan or

oven base.

oDo not place pans or baking trays directly on the base of the

oven cavity, or line it with aluminium foil.

oDo not grill food containing fat without using the grill trivet. The

grill trivet should never be covered with aluminium foil.

oDo not place hot enamel parts in water, leave them to cool first.

oDo not allow vinegar, coffee, milk, saltwater, lemon, tomato

juice or any liquid with high sugar content to remain in contact

with the enamel parts of the appliance. Spillages should be

wiped up immediately.

oDo not allow electrical fittings or cables to come into contact

with areas on the appliance that get hot.

oDo not use the appliance to heat the room it is located in or to

dry clothing. No clothing should be placed over or near to the

hob burners or oven door.

oDo not install the appliance next to curtains or soft furnishings.

oDo not attempt to lift or move cooking appliances by using the

oven door or handle, as this may cause damage to the appliance

or result in injury to the person lifting the appliance.

Cleaning

oCleaning of the oven should be carried out on a regular basis.

oGreat care should be taken whilst using this appliance and when

following the cleaning procedure.

oIMPORTANT: The appliance must be disconnected from the

mains before following the cleaning procedure.

Installation

This appliance must be correctly installed by a

suitably qualified person, strictly in accordance

with the manufacturer’s instructions. Please see

the specific section of this booklet that refers to

installation.

oBaumatic Ltd. declines any responsibility for injury or

damage, to person or property, as a result of improper

use or installation of this appliance.

oHeat, steam and moisture will be created during use of the

appliance, take care to avoid injury and ensure that the room is

adequately ventilated. If the appliance is going to be used for

prolonged periods of time, then additional ventilation may be

required.

oPlease consult with your qualified installer if you are in any doubt

about the amount of ventilation that you will require.

Declaration of conformity

This appliance complies with the following European Standards:

-EN 30-1-1, EN 30-2-1 and EN 437 plus subsequent amendments

(gas).

-EN 60 335-1 and EN 60 335-2-6 (electrical) plus relative

amendments.

This appliance complies with the prescriptions of the following

European Directives:

-2006/95 EC concerning electrical safety (BT).

-89/336 + 92/31 + 93/68 EC concerning electromagnetic

compatibility (EMC).

-90/396 + 93/68 EC concerning gas safety.

Oven accessories that could come into contact with foodstuffs are

made with materials that comply with the provisions of the 89/109 EC

directive dated 21/12/88.

oThe manufacturer declares that the oven is built using certified

materials and requires the appliance to be installed in

accordance with the standards currently in force. This appliance

must be used by a trained person for domestic purposes only.

Specifications

Product dimensions:

Height: 900 mm

Width: 600 mm

Depth: 600 mm

Product specifications:

o4 burner gas hob:

o1 x 3.0 kW rapid burner

o2 x 1.8 kW semi-rapid burner

o1 x 1.0 kW auxiliary burner

oCast iron pan stands

oUnderknob auto-ignition

oFan oven (main oven cavity)

oConventional oven and grill (secondary oven cavity)

oOven energy efficiency class: A

oMain oven capacity: 57 litres

oSecondary oven capacity: 30 litres

oLED fully programmable timer

oCooling fan

oThermostatically controlled grill

oDouble glazed removable doors

oAdjustable feet
