orKan 1D CMOS
Bluetooth mobile terminal
Embedded display for instant data treatment
Comes with 4 pre-loaded applications
1D Laser, 1D CMOS & 2D Full Imager versions
Withstands several 2 meter drops onto concrete
IP54
Bluetooth Class 1 (100m)
Heavy duty removable battery
RFID version (coming soon)
Transport & Delivery
Inventory Management
Picking & Order Preparation
Goods in / Goods out
Access Control
www.baracoda.com
www.baracoda.com
Electronics Characteristics
CPU ARM9
Memory SDRAM 128 Mbits - NAND Flash 64 MBytes
Display characteristics Graphic monochrome (white & deep blue) - OLED Technology - Diagonal: 1.54 In
Display comments Up to status bar - capability to display :
5 lines of 21 characters (small font)
4 lines of 16 characters (big font)
Scan Engine
Reference (manufacturer) EV10 (Intermec)
Reading technology CMOS
Light source 617 nm
Reading distance 4 to 50 cm (for 40mil barcode)
Scan rate 200 scans/second
Scan angle 40°
Light 0 to 100 000 Lux
Power Energy
Battery type Removable battery pack - Lithium Polymer
Battery capacity 2100 mAh
Battery dimension 64.5 x 36 x 12 mm
Charging time With provided PSU or cradle : 4 hours
Back up battery
User Environment
Operating temperature -10°C - +40°C
Storage temparature -20°C - +50°C
Humidity 5 - 95 % (non-condensing)
Shocks Multiple 2m / 6.6ft drops onto concrete (with protective boot)
IP rate IP 54
Specifications
Communication Interfaces
Radio frequence Bluetooth 2.0 + EDR (SPP profile)
Radio range Class 1 (100m)
USB USB v2.0 (micro USB)
Cradle Depending on cradle version
Supported Barcode Symbologies
Linear Barcodes
Code 2 of 5 standard - Interleaved 2 of 5 - Matrix 2 of 5 - Codabar/Monarch - Code 11 - Code 128 - GS-128 (UCC/EAN-128)
Code 39 - Italian PharmaCode - Code 93 - UPC-A - UPC-E - EAN 8 / EAN 13 - JAN 8 & JAN 13 - ISSN / ISBN - MSI
GS1 DataBar Omnidirectionnal (RSS-14) - GS1 DataBar Limited (RSS-14 Limited)
Physical Characteristics
Length 134.3 mm
Width 57.1 mm
Height 36.9 mm
Weight ~175 g
Reading Modes
Trigger
Aiming
Laser beam ON via Bluetooth
Auto-scan (no duplicate scan)
Manual auto-scan
Depth of Field
5 Mil 3.5 to 7.5 In
10 Mil 2 to 11 In
100% UPC/EAN 2 to 11.5 In
20 Mil 1.5 to 14 In
40 Mil 3 to 20 In
v1.2 - July 2011
orKan Accessories
Cradle
Protective boot
External battery
Box content
1 orKan terminal with rechargeable battery
1 charger - 1 universal charging adaptor (AUS/EU/US/UK)
1 CD with software and documentation
User Interfaces Supported Interfaces Using Modes
Buzzer 106 db(A) Standard dongle Real time (raw)
LED 2x tricolor (green, orange, red) USB Plug&Scan Real time with No Data Loss with buffer
Vibrator yes RS232 Plug&Scan Batch
BOK-L
Real Time Clock (RTC) for timestamp
