Aztech WL578USB Instructions d'utilisation
Easy Start Guide
WL578USB
WL578USBWL578USB
WL578USB
High Speed Wireless
High Speed WirelessHigh Speed Wireless
High Speed Wireless-
--
-N
NN
N
USB 2.0 Adapter
USB 2.0 AdapterUSB 2.0 Adapter
USB 2.0 Adapter
uick Installation Guide
Page 2 of 24
User Manual
Page 3 of 24
2011 © All rights reserved. Version 1.0
No part of this document may be reproduced, republished, or retransmitted in any form or by any means
whatsoever, whether electronically or mechanically, including, but not limited to, by way of photocopying,
recording, information recording, or through retrieval systems without the express written permission. We
reserve the right to revise this document at any time without the obligation to notify any person and/or
entity. All other company or product names mentioned are used for identification purposes only and may
be trademarks of their respective owners.
LIMITATION OF LIABILITY AND DAMAGES
THE PRODUCT AND THE SOFTWARES WITHIN ARE PROVIDED "AS IS," BASIS. THE MANUFACTURER AND
MANUFACTURER’S RESELLERS (COLLECTIVELY REFERRED TO AS “THE SELLERS”) DISCLAIM ALL WARRANTIES,
EXPRESS, IMPLIED OR STATUTORY, INCLUDING WITHOUT LIMITATION THE IMPLIED WARRANTIES OF NON-
INFRINGEMENT, MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, OR ANY WARRANTIES
ARISING FROM COURSE OF DEALING, COURSE OF PERFORMANCE, OR USAGE OF TRADE. IN NO EVENT WILL
THE SELLERS BE LIABLE FOR DAMAGES OR LOSS, INCLUDING BUT NOT LIMITED TO DIRECT, INDIRECT,
SPECIAL WILLFUL, PUNITIVE, INCIDENTAL, EXEMPLARY, OR CONSE UENTIAL, DAMAGES, DAMAGES FOR
LOSS OF BUSINESS PROFITS, OR DAMAGES FOR LOSS OF BUSINESS OF ANY CUSTOMER OR ANY THIRD
PARTY ARISING OUT OF THE USE OR THE INABILITY TO USE THE PRODUCT OR THE SOFTWARES, INCLUDING
BUT NOT LIMITED TO THOSE RESULTING FROM DEFECTS IN THE PRODUCT OR SOFTWARE OR
DOCUMENTATION, OR LOSS OR INACCURACY OF DATA OF ANY KIND, WHETHER BASED ON CONTRACT,
TORT OR ANY OTHER LEGAL THEORY, EVEN IF THE PARTIES HAVE BEEN ADVISED OF THE POSSIBILITY OF
SUCH DAMAGES. THE ENTIRE RISK AS TO THE RESULTS AND PERFORMANCE OF THE PRODUCT OR ITS
SOFTWARE IS ASSUMED BY CUSTOMER. BECAUSE SOME STATES DO NOT ALLOW THE EXCLUSION OR
LIMITATION OF LIABILITY FOR DAMAGES, THE ABOVE LIMITATION MAY NOT APPLY TO THE PARTIES. IN NO
EVENT WILL THE SELLERS’ TOTAL CUMULATIVE LIABILITY OF EACH AND EVERY KIND IN RELATION TO THE
PRODUCT OR ITS SOFTWARE EXCEED THE AMOUNT PAID BY CUSTOMER FOR THE PRODUCT.
uick Installation Guide
Page 4 of 24
Contents
About the Product ...................................................................................................... 5
Getting Started ........................................................................................................... 6
Check Package Contents .............................................................................. 7
Device Overview ....................................................................................................... 7
Remove or Disable Conflicts ........................................................................ 7
Internet Sharing, Proxy, and Security Applications................................................. 8
Configuring Internet Properties ............................................................................... 8
Removing Temporary Internet Files ........................................................................ 8
nstallation ................................................................................................................. 9
Connecting to wireless AP ........................................................................................ 10
Settings and Options ................................................................................................ 14
Use as an Access Point .............................................................................................. 17
Use as Virtual Wifi .................................................................................................... 20
User Manual
Page 5 of 24
About the Product
WL578USB provides wireless connectivity to desktop and notebook computers. The
device performs the function of a radio broadcaster and receiver to communicate with a
wireless network. This gives the computer connected with WL578USB the capability to
communicate with other devices and use the Internet service available in the wireless
network.
WL578USB is capable of connecting with wireless networks that utilize the Wireless N
protocol. This device also supports connection to other wireless network standards like
Wireless G or Wireless B. WL578USB is easy to setup - install the necessary driver
software, connect it to an available USB slot, and then connect to a wireless network. The
device comes with Windows-based software called “REALTEK 11n USB Wireless LAN
Utility” that can be used to connect to wireless networks and create profiles which
remembers the configuration details for a wireless network.
Note:
Note:Note:
Note: Wireless connection speed is not correlated to Internet access speed. Internet
access speed from popular broadband DSL or cable Internet services normally
provides up to 3 Mbps connection, which can be easily handled even by the slower
Wireless B protocol.
uick Installation Guide
Page 6 of 24
Getting Started
Setting up the device is easy. The flowchart below provides an outline of the steps
needed to complete the installation. Brief descriptions appear beside each step. Detailed
instructions are provided in the subsequent pages.
Remove/Disable
Conflicts
Check Package
Contents
Install the Device
The package includes the Wireless
N USB Adapter, Easy Start Guide,
Resource CD and USB Cable.
Check proxy application, TCP/IP
Settings, Internet Properties, and
remove temporary Internet files.
Install the device and then connect
to a wireless network.
Ready to Use
User Manual
Page 7 of 24
Check Package Contents
Make sure that you have the following items. If any of the items is damaged or missing,
please contact your dealer immediately.
WL578USB
Easy Start Guide
Resource CD – contains WL568USB Utility installer
Device Overview
Remove or Disable Conflicts
To make sure the device installation moves on smoothly, you need to remove or disable
conflicts that may interfere the installation. Probable conflicts may include:
Internet sharing applications
Proxy software
Security software
Internet properties
Temporary Internet files
WPS
Butto
n
uick Installation Guide
Page 8 of 24
Internet Sharing, Proxy, and Security Applications
Internet sharing, proxy software, and firewall applications may interfere with the
installation. These should be removed or disabled before start the installation.
If you have any of the following or similar applications installed on your computer,
remove or disable them according to the manufacturer’s instructions.
Internet Sharing Applications
Internet Sharing ApplicationsInternet Sharing Applications
Internet Sharing Applications
Proxy Software
Proxy SoftwareProxy Software
Proxy Software
Security Software
Security SoftwareSecurity Software
Security Software
Microsoft Internet Sharing WinGate Symantec
WinProxy Zone Alarm
Configuring Internet Properties
To set the nternet Properties:
1. Click the Start button, and then click Run. This opens the Run dialog box.
2. Type control inetcpl.cpl, and then click OK. This opens Internet Properties.
3. Click Connections tab.
4. In Dial-up and Virtual Private Network settings, check Never dial a connection.
5. To close Internet Properties, click OK.
Removing Temporary Internet Files
Temporary Internet files are files from Web sites that are stored in your computer. Delete
these files to clean the cache and remove footprints left by the Web pages you visited.
To remove temporary nternet files:
1. Click the Start button, and then click Run. This opens the Run dialog box.
2. Type control, and then click OK. This opens Control Panel.
3. Double-click Internet Options. This opens Internet Options.
4. In the Temporary Internet Files pane, click Delete Cookies.
5. Click Delete Files.
6. To close Internet Properties, click OK.
User Manual
Page 9 of 24
nstallation
Here are the instructions on how to install the driver software for Windows XP, Vista and
Windows 7.
1. Connect the Aztech WL578USB to Computer’s USB port.
2. Install the Driver found in the Resource CD on the computer where you wish to
use Aztech WL578USB.
a. a. Open Resource CD from your CD Rom Drive and select the folder for your
operating system
b. Open folder
"RTLWlanU_WindowsDriver_1015.6.0210.2012_UI_1.00.0187.b2_CU.L"
c. Double click on Setup.exe icon and follow installation procedure then
restart the computer
WL578USB
WL578USBWL578USB
WL578USB
uick Installation Guide
Page 10 of 24
Connecting to wireless AP
1. Double click on “REALTEK 11n USB Wireless LAN Utility” found on the desktop after
installing the CD.
