Aztech WL552USB Manuel utilisateur

Wireless N USB Adapter

User Manual

Page 2 of 43

No part of this document may be reproduced, republished, or retransmitted in any form or by any means

whatsoever, whether electronically or mechanically, including, but not limited to, by way of photocopying,

recording, information recording, or through retrieval systems without the express written permission We

reserve the right to revise this document at any time without the obligation to notify any person and/or

entity All other company or product names mentioned are used for identification purposes only and may

be trademarks of their respective owners

LIMITATION OF LIABILITY AND DAMAGES

THE PRODUCT AND THE SOFTWARES WITHIN ARE PROVIDED "AS IS," BASIS THE MANUFACTURER AND

MANUFACTURER’S RESELLERS (COLLECTIVELY REFERRED TO AS “THE SELLERS”) DISCLAIM ALL WARRANTIES,

EXPRESS, IMPLIED OR STATUTORY, INCLUDING WITHOUT LIMITATION THE IMPLIED WARRANTIES OF NON-

INFRINGEMENT, MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, OR ANY WARRANTIES

ARISING FROM COURSE OF DEALING, COURSE OF PERFORMANCE, OR USAGE OF TRADE IN NO EVENT WILL

THE SELLERS BE LIABLE FOR DAMAGES OR LOSS, INCLUDING BUT NOT LIMITED TO DIRECT, INDIRECT,

SPECIAL WILLFUL, PUNITIVE, INCIDENTAL, EXEMPLARY, OR CONSEQUENTIAL, DAMAGES, DAMAGES FOR

LOSS OF BUSINESS PROFITS, OR DAMAGES FOR LOSS OF BUSINESS OF ANY CUSTOMER OR ANY THIRD

PARTY ARISING OUT OF THE USE OR THE INABILITY TO USE THE PRODUCT OR THE SOFTWARES, INCLUDING

BUT NOT LIMITED TO THOSE RESULTING FROM DEFECTS IN THE PRODUCT OR SOFTWARE OR

DOCUMENTATION, OR LOSS OR INACCURACY OF DATA OF ANY KIND, WHETHER BASED ON CONTRACT,

TORT OR ANY OTHER LEGAL THEORY, EVEN IF THE PARTIES HAVE BEEN ADVISED OF THE POSSIBILITY OF

SUCH DAMAGES THE ENTIRE RISK AS TO THE RESULTS AND PERFORMANCE OF THE PRODUCT OR ITS

SOFTWARE IS ASSUMED BY CUSTOMER BECAUSE SOME STATES DO NOT ALLOW THE EXCLUSION OR

LIMITATION OF LIABILITY FOR DAMAGES, THE ABOVE LIMITATION MAY NOT APPLY TO THE PARTIES IN NO

EVENT WILL THE SELLERS’ TOTAL CUMULATIVE LIABILITY OF EACH AND EVERY KIND IN RELATION TO THE

PRODUCT OR ITS SOFTWARE EXCEED THE AMOUNT PAID BY CUSTOMER FOR THE PRODUCT

User Manual

Page 3 of 43

Contents

About the Product ...................................................................................................... 5

Getting Started........................................................................................................... 6

Check Package Contents.............................................................................. 7

Using the USB Extension 7

Remove or Disable Conflicts ........................................................................ 7

Internet Sharing, Proxy, and Security Applications 8

Configuring Internet Properties 8

Removing Temporary Internet Files 8

nstallation ................................................................................................................. 9

Configuration ........................................................................................................... 15

Connecting to non-Secured Wireless AP .................................................... 15

Connecting to WEP-Secured Wireless AP ................................................... 16

Connecting to WPA-PSK-Secured Wireless AP............................................ 17

About WL552USB Utility ........................................................................................... 18

Network Tab.............................................................................................. 18

Button Section 19

Function Section 19

Profile........................................................................................................ 22

Definition of each field: 22

Icons and buttons: 23

Add/Edit Profile 23

Network .................................................................................................... 27

Definition of each field 28

Icons and buttons 28

Connected network 29

Advanced................................................................................................... 30

Definition of each field 31

Link Status................................................................................................. 31

Throughput 32

Statistics 32

Transmit Statistics 33

User Manual

Page 4 of 43

Received Statistics 34

WPS ........................................................................................................... 34

Definition of each field 35

Security...................................................................................................... 37

Auth /Encry Setting - WEP/TKIP/AES 37

802 1x Setting 38

User Manual

Page 5 of 43

About the Product

WL552USB provides wireless connectivity to desktop and notebook computers The

device performs the function of a radio broadcaster and receiver to communicate with a

wireless network This gives the computer connected with WL552USB the capability to

communicate with other devices and use the Internet service available in the wireless

network

WL552USB is capable of connecting with wireless networks that utilize the Wireless N

protocol This device also supports connection to other wireless network standards like

Wireless G or Wireless B WL552USB is easy to setup - install the necessary driver

software, connect it to an available USB slot, and then connect to a wireless network The

device comes with a Windows-based software called WL552USB Utility that can be used

to connect to wireless networks and create profiles which remembers the configuration

details for a wireless network

Note:

Note:Note:

Note: Wireless connection speed is not correlated to Internet access speed Internet

access speed from popular broadband DSL or cable Internet services normally

provides up to 3 Mbps connection, which can be easily handled even by the slower

Wireless B protocol

User Manual

Page 6 of 43

Getting Started

Setting up the device is easy The flowchart below provides an outline of the steps

needed to complete the installation Brief descriptions appear beside each step Detailed

instructions are provided in the subsequent pages

Remove/Disable

Conflicts

Check Package

Contents

Install the Device

The package includes the Wireless

N USB Adapter, Easy Start Guide,

Resource CD and USB Extension

Check proxy application, TCP/IP

Settings, Internet Properties, and

remove temporary Internet files

Install the device and then connect

to a wireless network

Ready to Use

User Manual

Page 7 of 43

Check Package Contents

Make sure that you have the following items If any of the items is damaged or missing,

please contact your dealer immediately

 WL552USB

 Easy Start Guide

 Resource CD – contains WL552 Utility installer, and User Manual

 USB Cable

Using the USB Extension

The USB Extension helps you place the device to a more prominent location and to

achieve a better reception of the wireless network It is most useful for desktop

computers with USB 2 0 ports placed behind the computer casing USB ports placed in the

front of the computer are usually the slower USB 1 0 variant

To use the USB Extension, connect one end to a USB 2 0 port in your computer, and then

attach the WL552USB at the other end

Remove or Disable Conflicts

To make sure the device installation moves on smoothly, you need to remove or disable

conflicts that may interfere the installation Probable conflicts may include:

 Internet sharing applications

 Proxy software

 Security software

 Internet properties

 Temporary Internet files

User Manual

Page 8 of 43

Internet Sharing, Proxy, and Security Applications

Internet sharing, proxy software, and firewall applications may interfere with the

installation These should be removed or disabled before start the installation

If you have any of the following or similar applications installed on your computer,

remove or disable them according to the manufacturer’s instructions

Internet Sharing Applications

Internet Sharing ApplicationsInternet Sharing Applications

Internet Sharing Applications

Proxy Software

Proxy SoftwareProxy Software

Proxy Software

Security Software

Security SoftwareSecurity Software

Security Software

Microsoft Internet Sharing WinGate Symantec

WinProxy Zone Alarm

Configuring Internet Properties

To set the nternet Properties:

1 Click the Start button, and then click Run This opens the Run dialog box

2 Type control inetcpl cpl, and then click OK This opens Internet Properties

3 Click Connections tab

4 In Dial-up and Virtual Private Network settings, check Never dial a connection

5 To close Internet Properties, click OK

Removing Temporary Internet Files

Temporary Internet files are files from Web sites that are stored in your computer Delete

these files to clean the cache and remove footprints left by the Web pages you visited

To remove temporary nternet files:

1 Click the Start button, and then click Run This opens the Run dialog box

2 Type control, and then click OK This opens Control Panel

3 Double-click Internet Options This opens Internet Options

4 In the Temporary Internet Files pane, click Delete Cookies

5 Click Delete Files

6 To close Internet Properties, click OK

User Manual

Page 9 of 43

nstallation

Here are the instructions on how to install the driver software for Windows 2000, XP, and

Vista

Note:

Note: Note:

Note: Do not connect the device until the Utility is completely installed

To install the driver software:

1 Insert the Resource CD to the CD-ROM This opens the WL552USB Utility Setup If

the Utility does not open automatically, click the Start button, and then click Run

Enter d:\setup exe, where d is the CD-ROM drive

2 Wizard will now move to next step for license agreement, check the option ‘I

accept the terms of the license agreement’

User Manual

Page 10 of 43

3 Click Next

4 Select either of the options available:

a Install driver and Ralink WLAN Utility, this will install driver for the adaptor, and

the wireless utility

b Install driver only, this will install only the driver for the adaptor
