Easy Start

Page 1 of 15

HL100E HomePlug Ethernet Adaptor

Easy Start

Version 1.0

CONTENTS

1 Introduction to HL100E HomePlug Ethernet Adaptor . .……. 2

1.1 Package Contents……. . . . .. . . . . . . . . . . . . . . . . . . . . . . . 2

1.2 Important Safety Instructions. . . . . . . . . . . . . . . . . . . . . . . . 3

2 Installation and Connection . . . . . . . . . . . . . . . . . . . . . . . . . . 4

2.1 System Requirements . . . . .. . . . . . . . . . . . . . . . . . . . . . . . .4

2.2 Installation and Uninstallation of Configuration Utility . . .……4

2.3 Connection and Light indicators . . . . . . . . . . . . . . . . . . . . . . .5

3 All about the Home Network . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

3.1 Configuring the Computer . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

3.2 Examples of Applications . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

3.3 Care Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10

3.4 Frequently Asked Questions . . . . . . . . . . . . . . . . . . . . . . . . . .10

4 Configuration Utility User Guide . . . . . . . . . . . . . . . . . . . . . . . .11

5 Technical Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15

Product warranty does not apply to damage caused by lightning, power surges or wrong voltage usage.

Easy Start

Page 2 of 15

1 Introduction to HL100E HomePlug Ethernet Adaptor

One of the major drawbacks in setting up home network is the absence of required wiring inside the

house to interconnect networked computers. In recent years several technologies have attempted

to address the issue. The most prominent technology so far is the family of WIFI (802.11 X)

products. Recently, however, another technology called HomePlug has come forth. It uses

electrical grids, already available inside walls to transmit data from computer to computer.

HomePlug technology modulates computer data in a way to enable them use power grid as a

medium of transmission from point to point. Using this technology, two computers have a virtual

Ethernet connection without the need to be physically connected to each other.

The HL100E HomePlug Ethernet Adaptor has 3 indicator lights (LEDs) and an Ethernet port. The

LEDs depict the connection status, as well as other information, enabling detailed diagnosis of

system malfunction. The Ethernet port is to connect to a device in the home network. The HL100E

HomePlug Ethernet Adaptor has a standard power plug for connection to a power outlet. There are

three main kinds of power plugs:

• HL100E (UK) – 3 pins UK plug with integrated 230V AC power supply.

• HL100E (EUR) – 2 pins Euro plug with integrated 230V AC power supply.

• HL100E (US) – 2 pins US plug with integrated 120V AC power supply.

Computer networking in the office or at home has the following advantages:

1. Share centrally stored data

2. Share one printer

3. Multi-access to one Internet connection

4. Multi-user games over the network.

1.1 Package Contents

Make sure that you have the following items. If any of the items is damaged or missing, please

contact your dealer immediately.

HL100E HomePlug Ethernet Adaptor (Qty:2) Easy Start (Qty:1)

Configuration Utility Installation CD (Qty:1) CAT-5 UTP Straight Ethernet Network

cable (RJ-45) (Qty:2)

Easy Start

Page 3 of 15

1.2 Important Safety Instructions

Please read these instructions carefully:

1. Unplug the HL100E HomePlug Ethernet Adaptor from the wall outlet before cleaning. Do not use

liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning.

2. Do not use the HL100E HomePlug Ethernet Adaptor near water.

3. The HL100E HomePlug Ethernet Adaptor should never be placed near or over a radiator or heat

4. The HL100E HomePlug Ethernet Adaptor should be operated from the type of power indicated

on the marking label. If you are not sure of the type of power available, consult your dealer or

local power company.

5. The HL100E HomePlug Ethernet Adaptor relies on the building’s electrical installation for

short-circuit (over current) protection. Ensure that a fuse or circuit breaker no larger than 120

VAC or 230 VAC (depends on the power supply type in your country) is used on the phase

conductors (all current-carrying conductors).

6. Plug the HL100E HomePlug Ethernet Adaptor directly into a 120V AC or 230V AC (depends on

the power supply type in your country) wall outlet. Do not use an extension cord between the

adapter and the AC power source.

7. Do not attempt to service the HL100E HomePlug Ethernet Adaptor yourself, as opening or

removing covers may expose you to dangerous voltage points or other risks as well as ruin

product warranty. Refer all servicing to qualified service personnel.

8. Unplug the HL100E HomePlug Ethernet Adaptor from the wall outlet and refer the product to

qualified service personnel for the following conditions:

- If liquid has been spilled into the product.

- If the product has been exposed to rain or water.

- If the product does not operate normally when the operating instructions are followed.

- If the product exhibits a distinct change in performance.

Easy Start

Page 4 of 15

2 Installation and Connection

2.1 System Requirements

HL100E HomePlug Ethernet Adaptor is applicable with all TCP/IP operating systems with Ethernet

port. Drivers are not required for this adapter. But the supplied Configuration Utility software to

assign the network password operates only with Windows operating systems.

Your computer must meet the following requirements in order to use the HL100E HomePlug

Ethernet Adaptor Configuration Utility:

Operating systems:

• Windows 98SE, Windows Me, Windows 2000 or Windows XP with Ethernet connection

• Pentium II 300 MHz MMX-Compatible PC or greater

• At least 64MB hard disk space and memory

• CD-ROM drive

Note: Your computer or the device to which you want to connect the HL100E HomePlug

Ethernet Adaptor must have an Ethernet port, i.e. a network card or a network adaptor.

2.2 Installation and Uninstallation of Configuration Utility

Simple Installation:

1. Connect the HL100E HomePlug Ethernet Adaptor to the computer or the device with the

Ethernet cable.

2. Connect the HL100E HomePlug Ethernet Adaptor to the Power Outlet.

3. Install the Configuration Utility. The Configuration Utility Installation CD has auto run

feature. If the Configuration Utility Installation CD auto run fails, please run the Setup.exe file

in the CD.

4. Follow the on screen instructions to install the Configuration Utility.

Please refer to Page 11 for the Configuration Utility User Guide.

Note: 1) Before connecting the HL100E HomePlug Ethernet Adaptor, please note its

Security ID / Device Password and keep it available for configuration of the

network.

2) No drivers are required for installation of the HL100E HomePlug Ethernet Adaptor.

Uninstallation:

1. To uninstall the Configuration Utility, go to the Control Panel of your system.

2. Open the Add/Remove Programs.

3. Select and double click on the PowerPacket Utilities in the Add/Remove Programs

Properties.

4. Follow the on screen instructions to uninstallation the Configuration Utility.

Easy Start

Page 5 of 15

2.3 Connection and Indicator Lights

The HL100E HomePlug Ethernet Adaptor has three lights indicator (LEDs) and an Ethernet

port:

PWR: Lights up when connected to AC power supply.

PL-LINK: Lights up when detected and connected with another HomePlug adaptor

within the network.

ETH-LINK/ACT: Lights up when connected to the Ethernet port of the computer or other

Ethernet devices.

Flashes during data transfer.

ETHERNET: This is the connection point for connecting it to a computer or other devices with

Ethernet port.

Easy Start

Page 6 of 15

3 All about the Home Network

This chapter contains important and useful information on networks—from the configuration of your

computer to examples of applications to general tips.

3.1 Configuring the Computer

Now that you have successfully connected and installed your HL100E HomePlug Ethernet

Adaptor, we show you how to configure your computer correctly and how to check existing settings.

3.1.1 Windows 98 and Windows Me

1. Open the properties of the LAN connection on the connected computers by selecting

Start Settings Control Panel Network

2. Click the entry for the TCP/IP protocol of the network adaptor and on Properties. Enable the

option 'Obtain an IP address automatically'. You can ignore all other options: they either

remain empty or retain their default settings. Close the dialogs with OK.

Note: If you cannot find an entry similar to 'TCP/IP' or 'TCP/IP -> Network Adaptor Name' or

'Internet Protocol (TCP/IP)', you must install the TCP/IP protocol. Under Add select 'Protocol' and

click Add again. In the next dialog box under 'Manufacturer' select 'Microsoft' and under 'Network

Protocol' select 'TCP/ IP'.

3. If you use a router for Internet access, you will still need to configure it, because the router

dials into the Internet, not the computer.

Under Start Settings Control/Panel Internet Option select the

‘Connections’ tab and enable the 'Never dial a connection' option. Close the dialogs with OK.

3.1.2 Windows 2000

1. Open the properties of the LAN connection on the connected computers by selecting

Start Settings Control Panel Network and Dial-up Connections. Click with

the right mouse button on the corresponding LAN connection and select 'Properties'.

2. Click the entry for the TCP/IP protocol of the network adaptor and on Properties. Enable the

option 'Obtain an IP address automatically'. You can ignore all other options: they either

remain empty or retain their default settings. Close the dialogs with OK.

Easy Start

Page 7 of 15

Note: If you cannot find an entry similar to 'TCP/IP' or 'TCP/IP -> Network Adaptor Name' or

'Internet Protocol (TCP/IP)', you must install the TCP/IP protocol. Under Install select

'Protocol' and click Add. In the next dialog box select 'Internet Protocol (TCP/IP)' and confirm

with OK.

3. If you use a router for Internet access, you will still need to configure it, because the router

dials into the Internet, not the computer.

Under Start Settings Control Panel Network and Dial-up Connections,

and enable the 'Never dial a connection' option. Close the dialogs with OK.

3.1.3 Windows XP

The Windows XP start menu can be configured in different ways. See the Windows XP

documentation for more information.

1. Open the properties of the LAN connection on the connected computers.

Select Start Control Panel Network and Internet Connections. Click with

the right mouse button on the corresponding LAN connection and select 'Properties'.

2. Click the entry for the TCP/IP protocol of the network adaptor and on Properties. Enable

the option 'Obtain an IP address automatically'. You can ignore all other options: they

either remain empty or retain their default settings. Close the dialogs with OK.

Note: If you cannot find an entry similar to 'TCP/IP' or 'TCP/IP -> Network Adaptor Name' or

'Internet Protocol (TCP/IP)', you must install the TCP/IP protocol. Under Install select

'Protocol' and click Add. In the next dialog box select 'Internet Protocol (TCP/IP)' and confirm

with OK.

3. If you use a router for Internet access, you will still need to configure it, because the router

dials into the Internet, not the computer.

Under Start Settings Control/Panel Internet Options, select the

'Connections' tab and enable the 'Never dial a connection' option. Close the dialogs with

OK.

Note: Other Internet applications such as e-mail clients may also need this information. This

generally involves changing a setting with a name like 'Connect to' or similar to 'LAN'.

Easy Start

Page 8 of 15

3.2 Examples of Applications

This section demonstrates some of the application scenarios.

3.2.1 Home Networking-option 1

Workstation with Internet connection over an ADSL/Cable modem

3.2.4 Home Networking—option 2

Networking for Online Gaming.

Easy Start

Page 9 of 15

3.2.3 Home Networking—option 3

Networking for several workstations with one Internet connection over an ADSL/Cable modem

router.

3.2.2 Home Networking-option 4

Networking for several workstations with one Internet connection over an ADSL/Cable router

and an ADSL/Cable modem.

Easy Start

Page 10 of 15

3.3 Care Instructions

Network Volume

The maximum number of HomePlug adaptors in a single-family house is theoretically 253

connections, but in practice no more than 10 devices should be transferring data

simultaneously.

Network Security

Normally the electric meter forms a physical barrier, i.e. only devices connected to this meter

can be part of the network and benefit from the phase coupling. We strongly recommend that

you use the HL100E HomePlug Ethernet Adaptor internal device encryption. It is configured

with the HL100E HomePlug Ethernet Adaptor Configuration Utility (refer to the Appendix on

Page 11).

How to Use Passwords Correctly

You can improve your security substantially by following some important rules regarding the

use of passwords.

• Keep your passwords as secret as possible.

• Never write a password down. Popular, but completely unsuitable storage options include

notebooks, wallets and text files in computers.

• Do not pass on your password unnecessarily.

• Select a random password. Use random strings of letters and numbers. Passwords from

common language usage are not secure.

• Change the password regularly or immediately if you feel it has been compromised.

• Passwords should be changed as frequently as possible. This requires a little effort, but

increases your security considerably. Even if only the slightest indication of a leak exists,

the password should be changed.

Note: Always use the internal device encryption (the network password) for security. It can be

configured using the HL100E HomePlug Configuration Utility (please refer to Page 11 for the

Configuration Utility User Guide).

3.3 Frequently Asked Questions

Please refer to the FAQ.html file located in the \Manuals folder on the Configuration Utility

Installation CD for the HL100E HomePlug Ethernet Adaptor frequently asked questions

(FAQ).

Table des matières

Autres manuels Aztech Adaptateur

Aztech

Aztech 200Mbps HomePlug AV Ethernet Adaptor Manuel utilisateur

Aztech

Aztech WL578USB Instructions d'utilisation

Aztech

Aztech WL552USB Manuel utilisateur

Aztech

Aztech HL113EP Instructions d'utilisation

Aztech

Aztech WL230USB Wireless B+G Manuel utilisateur

Aztech

Aztech WL230USB Wireless B+G Instructions d'utilisation

Aztech

Aztech HL110E Instructions d'utilisation

Aztech

Aztech WL562 Manuel utilisateur

Aztech

Aztech WL562USB Manuel utilisateur

Aztech

Aztech WL950USB Mode d’emploi

Aztech

Aztech WL558USB Manuel utilisateur

Aztech

Aztech HL117 E Manuel utilisateur

Aztech

Aztech HL110E Manuel utilisateur

Aztech

Aztech HomePlug Mediaxtream Ethernet Adapter Manuel utilisateur

Aztech

Aztech WL568USB Manuel utilisateur

Aztech

Aztech WL590E Manuel utilisateur

Aztech

Aztech 500Mbps HomePlug AV Manuel utilisateur

Aztech

Aztech HL117E Instructions d'utilisation

Aztech

Aztech WL630USB Manuel utilisateur

Aztech

Aztech WL230USB Wireless B+G Manuel utilisateur

Aztech

Aztech WL635USB Manuel utilisateur

Aztech

Aztech HL115EP Instructions d'utilisation

Aztech

Aztech 500Mbps 4-Port HomePlugAV Ethernet Adaptor Manuel utilisateur

Aztech

Aztech HL129EP Instructions d'utilisation

Manuels Adaptateur populaires d'autres marques

PCB Piezotronics

PCB Piezotronics 090B274 Manuel utilisateur

Auvidea

Auvidea J20 Manuel du produit

Gossen MetraWatt

Gossen MetraWatt AT3-III E Manuel utilisateur

Akribis

Akribis ITF-21-BISS-MIT Manuel utilisateur

Tenda

Tenda W54U Manuel utilisateur

ROHO

ROHO AGILITY Manuel utilisateur

PROLiNK

PROLiNK WN2001 Manuel utilisateur

Hawking

Hawking HUF2 Manuel utilisateur

Airlink101

Airlink101 AWLC4030 Manuel utilisateur

NETGEAR

NETGEAR XAV101v1 - Powerline AV Ethernet Adapter Manuel utilisateur

Philips

Philips SWA4554S/10 Manuel utilisateur

JVC

JVC TS-C9D2B Manuel d'instructions

NETGEAR

NETGEAR A6100 Manuel utilisateur

D-Link

D-Link DWA-121 Manuel utilisateur

Philips

Philips SWA2037 Manuel utilisateur

Basalte

Basalte 0610-20 Manuel utilisateur

Yealink

Yealink EHS40 Manuel utilisateur

Balluff

Balluff BIC 1B0-IT1A7-Q40KFU-SM4A4A Manuel utilisateur
