AXIOMTEK SBC84833 Series Manuel utilisateur
SBC84833 Series
Intel®Atom™Processor N270
Capa Board with LVDS
User’s Manual
II
Disclaimers
This manual has been carefully checked and believed to contain
accurate information. Axiomtek Co., Ltd. assumes no responsibility for
any infringements of patents or any third party’s rights, and any
liability arising from such use.
Axiomtek does not warrant or assume any legal liability or
responsibility for the accuracy, completeness or usefulness of any
information in this document. Axiomtek does not make any
commitment to update the information in this manual.
Axiomtek reserves the right to change or revise this document and/or
product at any time without notice.
No part of this document may be reproduced, stored in a retrieval
system, or transmitted, in any form or by any means, electronic,
mechanical, photocopying, recording, or otherwise, without the prior
written permission of Axiomtek Co., Ltd.
Caution
If you replace wrong batteries, it causes the danger of explosion. It is
recommended by the manufacturer that you follow the manufacturer’s
instructions to only replace the same or equivalent type of battery,
and dispose of used ones.
©Copyright 2011 Axiomtek Co., Ltd.
All Rights Reserved
April 2011, Version A4
Printed in Taiwan
III
ESD Precautions
Computer boards have integrated circuits sensitive to static electricity.
To prevent chipsets from electrostatic discharge damage, please take
care of the following jobs with precautions:
Do not remove boards or integrated circuits from their anti-static
packaging until you are ready to install them.
Before holding the board or integrated circuit, touch an unpainted
portion of the system unit chassis for a few seconds. It
discharges static electricity from your body.
Wear a wrist-grounding strap, available from most electronic
component stores, when handling boards and components.
Trademarks Acknowledgments
Axiomtek is a trademark of Axiomtek Co., Ltd.
Windows®is a trademark of Microsoft Corporation.
AMI®is a registered trademark of American Megatrends Inc.
IBM, PC/AT, PS/2, VGA are trademarks of International Business
Machines Corporation.
Intel®and Atom™ are trademarks of Intel Corporation.
Winbond is a trademark of Winbond Electronics Corp.
Other brand names and trademarks are the properties and registered
brands of their respective owners.
IV
Table of Contents
Disclaimers ................................................................................. II
ESD Precautions........................................................................ III
CHAPTER 1..............................................................................................1
INTRODUCTION....................................................................................1
1.1Specifications............................................................ 2
1.2Utilities Supported.................................................... 4
CHAPTER 2 ...............................................................................................5
JUMPERS AND CONNECTORS..........................................................5
2.1Board Dimensions and Fixing Holes...................... 5
2.2Board Layout............................................................. 7
2.3Jumper Settings........................................................ 9
2.3.1LCD Voltage Slection Jumper (JP1)......................... 10
2.3.2Audio Output Jumper (JP2)...................................... 10
2.3.3CompactFlash™ Voltage Jumper (JP3)...................11
2.3.4CMOS Clear Jumper (JP4).......................................12
2.3.5Auto Power On Jumper (JP5)................................... 13
2.3.6COM1 Mode Select Jumpers (JP6, JP7, JP8) ......... 14
2.3.7COM2 Mode Selection Jumper (JP9).......................15
2.3.8COM1 Mode Selection Jumper (JP10).....................16
2.3.9COM3 Mode Selection Jumper (JP11).....................17
2.3.10COM4 Mode Selection Jumper (JP12) .................... 18
2.3.11 CRT Always On Jumper (JP13).............................. 19
2.4Connectors.............................................................. 20
2.4.1ATX 4 Pin 12V Connector (ATX1)............................21
2.4.2LVDS Backlight Connector (CN1) ............................ 21
2.4.3Audio Phone Jack Connector (CN2) ........................ 21
2.4.4LVDS Flat Panel Connector (CN3)........................... 22
2.4.5Flat Panel Bezel Connector (CN4) ........................... 23
2.4.6Digital I/O Port Connector (CN6)..............................25
2.4.7 Mini PCI-Express Card Connector (CN7).................. 25
2.4.8SMBus Connector (CN9).......................................... 27
2.4.9Serial Port3 & Serial Port4 (CN10)...........................28
2.4.10 Keyboard and PS/2 Mouse Connector (CN11)........ 29
2.4.11 VGA Connector (CN13) ...........................................29
2.4.12 Serial Port1 Connector (COM1)............................... 30
V
2.4.13Serial Port 2 Connectors (CN15)................. 30
2.4.14Power output Connector (CN8) ................... 31
2.4.15Ethernet Connectors (LAN1) ........................ 31
2.4.16SATA Connectors (SATA1, SATA2)............. 31
2.4.17USB Port Connector (USB3) ....................... 32
2.4.18Internal USB Connector (USB1)..................32
2.4.19Internal USB Connector (USB4)................... 33
2.4.20Internal USB Connector (USB2)..................33
2.4.21CompactFlash™ Socket (SCF1) .................. 34
CHAPTER 3 .............................................................................................36
HARDWARE DESCRIPTION.............................................................36
3.1Microprocessors..................................................... 36
3.2BIOS ......................................................................... 36
3.3System Memory ...................................................... 36
3.4I/O Port Address Map ............................................. 37
3.5Interrupt Controller................................................. 39
CHAPTER 4 .............................................................................................40
AMI BIOS SETUP UTILITY.................................................................40
4.1Starting .................................................................... 40
4.2Navigation Keys...................................................... 40
4.3Main Menu ............................................................... 42
4.4Advanced Menu ...................................................... 43
4.5Boot Menu ............................................................... 59
4.6Security Menu ......................................................... 62
4.7Chipset Menu .......................................................... 63
4.8Exit Menu................................................................. 67
APPENDIX A...........................................................................................69
WATCHDOG TIMER............................................................................69
What is Watchdog Timer ......................................................... 69
How to Use the Watchdog Timer............................................ 69
APPENDIX B...........................................................................................72
DIGITAL I/O...........................................................................................72
Digital I/O Software Programming.......................................... 73
SBC84833 Series All-In-One Capa Board User’s Manual
INTRODUCTION 1
CHAPTER 1
INTRODUCTION
The SBC84833, a Capa board, supports Intel® Atom™processor
N270, at FSB 533 MHz. The board integrates chipsets Intel®945GSE
and ICH7M that deliver outstanding system performance through high-
bandwidth interfaces, multiple I/O functions for interactive applications
and various embedded computing solutions. There is one 200-pin
unbuffered SO-DIMM sockets for singe channel DDR2-400/533 MHz
memory, maximum memory capacity up to 2GB. It also features one
Gigabit/Fast Ethernet, two serial ATA channels for total two Serial ATA
hard drives at maximum transfer rate up to 150MB/sec, seven USB 2.0
high speed compliant, built-in HD audio codec that can achieve the
best stability and reliability for industrial applications. Additionally, it
provides you with unique embedded features, such as 4 serial ports
and 3.5” form factor that applies an extensive array of PC peripherals.
SBC84833 Series All-In-One Capa Board User’s Manual
INTRODUCTION
2
1.1 Specifications
zCPU
Intel®AtomTM processor N270
zSystem Chipset
Intel®945GSE & ICH7M
zFront-Side Bus
533 MHz
zBIOS
American Megatrends Inc. BIOS.
8Mbit SPI Flash, DMI, Plug and Play
“Load Optimized Default” to backup customized Setting in
the BIOS flash chip to prevent from CMOS battery fail
zSystem Memory
One 200-pin unbuffered DDR2 SO-DIMM sockets
Maximum to 2GB DDR2 400/533 MHz memory
SBC84833 Series All-In-One Capa Board User’s Manual
INTRODUCTION 3
zOnboard Multi I/O
Controller: Winbond W83627UHG
Serial Ports: One port for RS-232/422/485 and three ports
for RS-232
Two SATA-150 connectors
zCompactFlash™Socket
One CompactFlash™ Type II Socket
zUSB Interface
Seven USB ports with fuse protection and complies with USB
Spec. Rev. 2.0
zDisplay
CRT connector
One 40-pin connector for 18 single channel LVDS and one 7-
pin inverter connector
One 40-pin 24-bit single/dual channel LVDS via Chrontel
CH7308B from SDVO as EFP port and one 7-pin inverter
connector
zWatchdog Timer
1~255 seconds; up to 255 levels
zEthernet
One port with RTL8111DL for Gigabit/Fast Ethernet
zAudio
HD Audio compliant (with Speaker/line-out & MIC-in) via
ALC662
Internal Audio features for speaker-out & MIC-in & Line-in via
Box Header connector
zPower Management
ACPI (Advanced Configuration and Power Interface)
zForm Factor
3.5” form factor
NOTE All specifications and images are subject to change
without notice.
SBC84833 Series All-In-One Capa Board User’s Manual
INTRODUCTION
4
1.2 Utilities Supported
zChipset Driver
zEthernet Driver
zGraphic Driver
zAudio Driver
