AXIOMTEK TBOX324-894 Manuel utilisateur

4 9416N324000E

Ver ion A1 September 2017

Printed in Taiwan

DRAM Installation

Step 1 Make sure system power is off, and then loosen the lateral

cover screws as shown.

Step 2 Loosen the lateral screws as shown.

Step 3 Pull out the front bezel and internal bracket as shown.

Step 4 Remove cover to install DRAM and stick thermal pad on it.

Step 5 Secure DRAM cover and install the internal bracket, front

bezel. Follow by fastening the lateral screws as shown to

complete the installation.

tBOX324-894 Quick Installation Guide

9416N324000E 1

Ver ion A1 September 2017

Printed in Taiwan

Checklist



tBOX324

894

system u

nit



HDD/SSD

(

ptional)

Quick installation guide x 1

CD x 1 (for Driver & Manual)



Foot Pad x 4



Mini

PCIe c

ard

odule

(optional)



Remote Switch cable (optional)



M12 LAN cable(s) (optional)



Screws pack



Wireless modu

le (optional)



Wallmount

Bracket

x 1



Key x 2



Power terminal block or M12

power cable

(optional)

DIO (6x2) x1 and COM (5x2) x 2

terminal block

(optional)

Note: Please contact your local suppliers if any damaged or missing items.

Dimensions

tBOX324-894

tBOX324-894 Transportation Fanless Em edded System

2 9416N324000E

Ver ion A1 September 2017

Printed in Taiwan

I/O Outlets

Front View

Rear View

9416N324000E 3

Ver ion A1 September 2017

Printed in Taiwan

Hardware Installtion

SATA drive and CFast Installation

Step 1 Make sure system power is off, and then loosen the screw at

HDD tray as shown.

Step 2 Slide HDD into the cover as picture shown. Insert screws into

each side of the SATA drive through the corresponding holes.

Step 3 Install CFast and SATA drive to the slot.

Step 4 Secure CFast and SATA drive to complete the installation.

Mini PCIe module and SIM card Installation

Step 1 Make sure system power is off, and then loosen the lateral

cover screws as shown.

Step 2 Install the module card and fasten screw, notice the signal

support at mini card slot. Fasten screws.
