AXIOMTEK SBC82400 Manuel utilisateur

SBC82400

Single Chip Half Size

ISA CPU CARD

with CRT, Ethernet

User’s Manual

Disclaimers

The information in this manual has been carefully checked and is believed

to be accurate. AXIOMTEK Co., Ltd. assumes no responsibility for any

infringements of patents or other rights of third parties which may result

from its use.

AXIOMTEK assumes no responsibility for any inaccuracies that may be

contained in this document. AXIOMTEK makes no commitment to update

or to keep current the information contained in this manual.

AXIOMTEK reserves the right to make improvements to this document

and/or product at any time and without notice.

No part of this document may be reproduced, stored in a retrieval system,

or transmitted, in any form or by any means, electronic, mechanical,

photocopying, recording, or otherwise, without the prior written permission

of AXIOMTEK Co., Ltd.

June 2004, Version A1

Printed in Taiwan

iii

ESD Precautions

Integrated circuits on computer boards are sensitive to static

electricity. To avoid damaging chips from electrostatic

discharge, observe the following precautions:

 Do not remove boards or integrated circuits from their anti-static

packaging until you are ready to install them.

 Before handling a board or integrated circuit, touch an unpainted

portion of the system unit chassis for a few seconds. This helps to

discharge any static electricity on your body.

 Wear a wrist-grounding strap, available from most electronic

component stores, when handling boards and components.

Trademarks Acknowledgments

AXIOMTEK is a trademark of AXIOMTEK Co., Ltd.

IBM is a registered trademark of International Business

Machines Corporation.

MS-DOS, and Windows ’95/98/NT/2000 are trademarks of

Microsoft Corporation.

Award is a trademark of Award Software, Inc.

IBM, PC/AT, PS/2, VGA are trademarks of International

Business Machines Corporation.

Intel, Pentium, Pentium II, Pentium III and Celeron are

trademarks of Intel Corporation.

C&T is a trademark of Chips and Technologies, Inc.

Realtek RT8100C are registered trademark of Realtek

Semiconductor Corporation.

Other brand names and trademarks are the properties and

registered brands of their respective owners.

This page does not contain any information.

Table of Contents v

T a b l e o f C o n t e n t s

Chapter 1 Introduction............................................................1

1.1 General Description.......................................................1

1.2 Secpifications ................................................................2

Chapter 2 Jumpers and Connectors......................................5

2.1 Board Dimensions .........................................................6

2.2 Board Layout..................................................................7

2.3 Jumper Settings.............................................................8

2.3.1 CPU CLK SPEED: JP1, JP2, JP7, JP8 ..................................... 9

2.3.2 CPU is HCLK X1 or X2: JP3, JP12 .......................................... 9

2.3.3 COM2 Signal/+12V/+5V Selection: JP5 ................................ 9

2.3.4 COM1 Signal/+12V/+5V Selection: JP6 ................................ 9

2.3.5 COM2 RS-232/422/485 Selection: JP9, JP10, JP11............. 10

2.3.6 CMOS Clear Jumper: JP13........................................................ 10

2.3.7 Compact Flash Voltage Selection: JP14.................................. 10

2.3.8 Compact Flash Master/Slave Selection: JP15 ........................ 10

2.3.9 DiskOnChipMemory Segment Selection: JP17................. 11

2.3.10 Watchdog Trigger Mode Selection: JP18.............................. 11

2.4 Connectors...................................................................12

2.4.1 Flat Panel Bezel Connector: CN2 ............................................ 13

2.4.2 Mouse & Keyboard Connectors: CN4, CN5......................... 14

2.4.3 Keyboard & Mouse Connector: CN6 ..................................... 14

2.4.4 Power Connector: CN7 ............................................................. 15

2.4.5 ACPI Connector: CN8 .............................................................. 15

2.4.6 Compact Flash Connector: CN9.............................................. 16

2.4.7 Ethernet Connector: LAN1 ...................................................... 17

2.4.8 PC/104 Connectors: J1 and J2 ................................................. 18

2.4.9 Parallel Port Interface: LPT1 .................................................... 20

2.4.10 Serial Port Interface: COM1 and COM2.............................. 21

2.4.11 IrDA Connector: IR1............................................................... 22

2.4.12 Floppy Disk Controller: FDD1.............................................. 22

2.4.13 IDE Interface Connector: IDE1............................................ 23

Table of Contents

Chapter 3 Hardware Description........................................24

3.1 Microprocessors..........................................................24

3.2 CPU Bus Clock.............................................................24

3.3 BIOS ...........................................................................24

3.4 System Memory ...........................................................24

3.5 I/O Port Address Map ..................................................25

3.6 Interrupt Controller......................................................26

Chapter 4 Award BIOS Utility ............................................28

4.1 BIOS Introduction ........................................................28

4.2 BIOS Setup ...................................................................28

4.2.1 Standard CMOS Setup............................................................... 30

4.2.2 Advanced BIOS Features.......................................................... 34

4.2.3 Advanced Chipset Features....................................................... 39

4.2.4 Integrated Peripherals ................................................................ 41

4.2.5 Power Management Setup......................................................... 44

4.2.6 PNP/PCI Configuration ........................................................... 46

4.2.7 Set Password................................................................................ 48

4.2.8 Save & Exit Setup....................................................................... 49

4.2.9 Exit Without Saving ................................................................... 49

Appendix A Watchdog Timer .............................................50

SBC82400 ISA Half-Size CPU Board Series User’s Manual

Introduction 1

C h a p t e r 1

Introduction

1.1 General Description

The SBC82400 is the ultimate cost-effective solution of 486-level

embedded half card. The SBC82400 comes with an embedded high-

performance STPC Consumer-II microprocessor and 32MB SDRAM

onboard. For maximum performance, it also has one optional DIMM

socket that can support up to 128 MB memory.

Its major onboard features include a DOC®2000 socket, a

Compact Flash socket, an IDE interface, a parallel port, two

serial ports (RS-232 and RS-232/422/485) a RJ-45 for fast

Ethernet and a mini-DIN PS/2 connector for keyboard and

mouse. A SVGA display controller, which integrated in

Consumer-II microprocessor, allows the CRT display resolution

up to 1280 x 1024 @ 256 colors.

SBC82400 ISA Half-Size CPU Board Series User’s Manual

Introduction

1.2 Secpifications

 CPU

 Onboard STPC Consumer-II microprocessor

 System Chipset

 Integrated in Consumer-II

 Cache memory

 Integrated L1 8Kbyte write back cache

 System memory

 128MB maximum

 First bank: onboard 32MB

 Second bank: one 168-pin DIMM socket supporting

up to 128MB SDRAM

 BIOS

 AWARD BIOS, Plug-and-Play 2Mbit Flash ROM with

integrated Ethernet Novell RPL and Windows PXE Boot

ROM functions

 Onboard IDE

 1 channel up to 2 devices

 PIO Mode 0-4, DMA Mode 0-2

 Standard I/O:

 Two serial ports, including one RS-232 and one RS-

232/422/485

 One parallel port, SPP/EPP/ECP

 One HDD Interface

 One FDD Interface

 One PS/2 Keyboard & Mouse Interface

 One IrDA interface for wireless communication

 Watchdog Timer

 Generates a system reset or NMI by jumper

selectable

 Software programmable time interval

 64 levels, 0.5~8/5~80/50~800/100~1600 seconds

SBC82400 ISA Half-Size CPU Board Series User’s Manual

Introduction 3

 Ethernet

 Realtek 8100C PCI Bus 10/100M Base-T

 Power Management

 Supports Plug & Play, APM(ACPI support)

 Graphics

 Graphics function is integrated in Consumer-II

 Up to 4MB long linear frame buffer

 Supports CRT connector

 The CRT controller supports up to 1024 x 768 Display

resolutions at 75Hz

 SSD

 DiskOnChip: supports M-System DiskOnChip

 Compact Flash Type II

 Expansion Slots

 One 16-Bit PC/104 connector

 1 ISA golden finger

 Board ID:

 Dallas DS2401 Board unique ID support

 Operating system

 MS-DOS

 Windows 98, Windows NT 4.0, Windows CE

 Power supply voltage: +5 V (4.75 ~ 5.25 V)

 Power consumption:

 Maximum: +5 V @ 2 A

 Typical: +5 V @ 1.62 A

 Operating temperature: 0 ~ 60° C (32 ~ 140° F)

NOTE: Specifications are subject to change without notice.

SBC82400 ISA Half-Size CPU Board Series User’s Manual

Introduction

This page does not contain any information.
