DSR® x02x/x03x Switches

Firmware Release Notes

Version 3.7.0.13

Oct 28, 2008

This document outlines:

1. Update Instructions

2. Appliance Firmware Version and Language Support Information

3. Enhancements

4. Fixes

5. Known Issues

6. Flash Update Failure Recovery

=============================================================

Update Instructions

=============================================================

Please refer to your user manual for detailed instructions to update the

appliance.

Important Note:

1. If the appliance currently has a firmware version earlier than 3.2.0.17 (or

3.6.2.17 for DSR 1020, DSR 2020, or DSR 4020 switches) then the

appliance must first be upgraded to 3.2.0.17 (or 3.6.2.17 for DSR 1020,

DSR 2020, or DSR 4020 switches) before it can be updated with this

newest version.

2. Attaching the DSRIQ-VMC module to a Windows target may require the

USB CCID driver to be installed. If the user is prompted by the Windows

‘New Hardware Wizard’ the ‘Next’ button should be pressed.

3. For Avocent Power Management Distribution Units (PM™ 2003, 2006,

2024, 3003, 3006, and 3024 PDUs), PDU v110 firmware or higher is

required to be able to manage the PDU from a DSR switch.

=============================================================

Appliance Firmware Version and Language Support Information

=============================================================

The following DSR switches are supported with this update:

Switch English Spanish French German Italian

DSR 1021

DSR 1022

DSR1021

_3.7.0.13_en.fl DSR1021 _3.

7.0.13_sp.fl DSR1021 _3.

7.0.13_fr.fl DSR1021 _3.

7.0.13_de.fl DSR1021 _3.

7.0.13_it.fl

DSR 1024 DSR1024_3.

7.0.13.fl N/A N/A N/A N/A

DSR 1031 DSR1031 _3.

7.0.13_en.fl DSR1031

_37.0.13_sp.fl DSR1031

_3.7.0.13_fr.fl DSR1031 _3.

7.0.13_de.fl DSR1031 _3.

7.0.13_it.fl

DSR 1020

DSR 2020

DSR 4020

DSR4020 _3.

7.0.13_en.fl DSR4020 _3.

7.0.13_sp.fl DSR4020 _3.

7.0.13_fr.fl DSR4020 _3.

7.0.13_de.fl DSR4020 _3.

7.0.13_it.fl

DSR 8020 DSR8020 _3.

7.0.13_en.fl DSR8020 _3.

7.0.13_sp.fl DSR8020 _3.

7.0.13_fr.fl DSR8020 _3.

7.0.13_de.fl DSR8020 _3.

7.0.13_it.fl

DSR 1030

DSR 2030

DSR 4030

DSR 8030

DSRx030 _3.

7.0.13_en.fl DSRx030 _3.

7.0.13_sp.fl DSRx030 _3.

7.0.13_fr.fl DSRx030 _3.

7.0.13_de.fl DSRx030 _3.

7.0.13_it.fl

DSR 2035

DSR 8035

DSRx035 _3.

7.0.13_en.fl DSRx035 _3.

7.0.13_sp.fl DSRx035 _3.

7.0.13_fr.fl DSRx035 _3.

7.0.13_de.fl DSRx035 _3.

7.0.13_it.fl

=============================================================

Enhancements

=============================================================

This release contains the following enhancements:

1. Added support for USB CCID Generic Smart Card Reader – attached at the

client PC and at the local port of the DSR switch via DSRIQ-VMC module.

2. Added support for the DSRIQ-VMC RIP module.

3. Added support for the following High Density PM PDU devices:

•PM 2000 PDU horizontal 3 & 6 outlet and vertical 24 outlet – metered

•PM 3000 PDU horizontal 3 & 6 outlet and vertical 24 outlet – switched &

metered

(PM PDU models supported: 2003, 2006, 2024, 3003, 3006, 3024)

Management and measurement at the PM unit, segment, phase and socket

levels are available via the OBWI and DSView® 3 management software

(DSR plug-in) interfaces.

4. Added support for alarm threshold per segment for Cyclades PM PDU models

that supports two segments:

=============================================================

Fixes

=============================================================

This release contains the following fixes:

1. Fixed missing links from the side menu (Power Units) on OBWI

2. Fixed extra characters in the PMD Socket screen on OBWI

=============================================================

Known Issues

=============================================================

This release contains no known issues.

=============================================================

FLASH Update Failure Recovery

=============================================================

If the green power LED on the front and back panel of the DSR switch blinks

continuously, the switch is in recovery mode. Use the following steps to recover

from a failed FLASH upgrade:

1. Set up the TFTP server with server IP address 10.0.0.3.

2. Rename the flash update file to the appropriate filename from the following list

and place it into the appropriate directory on the TFTP server.

Switch Filename

DSR 1021, DSR 1022 DSR1021.fl

DSR 1024 DSR1024.fl

DSR 1031 DSR1031.fl

DSR 1020, DSR 2020, DSR 4020 DSRxx20.fl

DSR 8020 DSR8020.fl

DSR 1030, DSR 2030, DSR 4030, DSR 8030 DSRxx30.fl

DSR 2035, DSR 8035 DSR8035.fl

3. If the DSR switch is not on, turn it on now.

4. The recovery process will start automatically.

NOTE: If you do not have a TFTP server, there are several shareware and

freeware programs on the Internet that you can download and install.
