Avision BF-1102S Manuel utilisateur

Color Image Scanner

User’s Manual

Regulatory model: BF-1102S

manual-en-250-0949-E -FB1200Plusv2

Avision Inc.

in any forms or by any means without prior written permission of

Avision Inc.

Trademark

All brands and product names mentioned in this document are

trademarks of their respective holders.

Warranty

The information contained in this document is subject to change

without notice.

Avision makes no warranty of any kind with regard to this

material, including, but not limited to, the implied warranties of

fitness for a particular purpose.

User’s Manual

iii

FCC Radio Frequency Interference Statement

This product has been tested and found to comply with the

limits for a class B digital device, pursuant to Part 15 of the

FCC rules. Operation is subject to the following two

conditions: (1) this device may not cause harmful

interference, and (2) this device must accept any

interference received, including interference that may cause

undesired operation. The FCC Class B limits are designed

to provide reasonable protection against harmful interference

in a residential installation. This equipment generates, uses,

and can radiate radio frequency energy and, if not installed

and used in accordance with the instructions, may cause

harmful interference to radio communications. However,

there is no guarantee that interference will not occur in a

particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be

determined by turning the equipment off and on, the user is

encouraged to try to correct the interference by one or more

of the following measures:

Reorient or relocate the receiving antenna.

Increase the separation between the equipment and

receiver.

Connect the equipment into an outlet on a circuit different

from that to which the receiver is connected.

Consult your point of purchase or service representative

for additional suggestions.

European Union Regulatory Notice

Products bearing the CE marking comply with the following EU

Directives:

Low Voltage Directive 2006/95/EC

EMC Directive 2004/108/EC

CE compliance of this product is valid if powered with the correct

CE-marked AC adapter provide by Avision.

This product satisfies the Class B limits of EN55022, EN55024 and

safety requirements of EN 60950.

User’s Manual

Disposal of Waste Equipment by Users in Private Union

This symbol on the product or on its packaging indicates that the

product can not be disposed of with your other household waste.

Instead it should be sent to appropriate facilities for recovery and

recycling in an effort to protect human health and the

environment. Fore more information about where you can drop

off your waste equipment for recycling, please contact your local

city office, your household waste disposal service or the shop

where you purchased the product.

*This machine is certified as Class 1 LED product. This means

that this machine does not produce hazardous laser radiation.

System Requirements

IBM compatible PC 586, Pentium or higher

Microsoft Windows 2000, Windows XP SP3, Windows

Vista/Windows 7

USB port 2.0 (compatible with USB 1.1)

At least 100 MB of free hard disk space (500 MB is

recommended)

At least 128 MB of system memory (512 MB of RAM is

recommended)

At least 1 GB of RAM for Windows Vista/7

A CD-ROM drive

User’s Manual

vii

Table of Contents

1. Installing the Scanner..............................................1-1

1.1 Preinstallation Information..................................1-1

1.2 Checking the Package Contents...........................1-2

1.3 Installation.......................................................1-3

1.3.1 Connecting to power...............................1-3

1.3.2 Installing the scanner driver ....................1-4

1.3.3 Connecting to computer ..........................1-4

2. Completing Your First Scan......................................2-1

2.1 Placing Your Original..........................................2-1

2.2 Verifying Your Scanner Installation ......................2-2

2.3 A Glance of the User Interface ............................2-6

3. Using the Scanner Properties Dialog Box .................3-1

3.1 Buttons on the Scanner Properties Dialog Box .......3-2

3.2 The Image Tab .................................................3-4

3.2.1 The Image Selection Box.........................3-5

3.2.2 Other Image Options ..............................3-8

3.2.3 Scanning color images ..........................3-19

3.2.4 Scanning grayscale images....................3-19

3.2.5 Scanning B&W images ..........................3-19

3.2.6 Editing Profiles.....................................3-20

3.3 The Compression Tab ......................................3-23

3.4 The Color Dropout Tab.....................................3-25

3.4.1 Color Dropout Selection.........................3-25

3.4.2 Other Color Dropout Options..................3-27

3.5 The Paper Tab ................................................3-29

3.5.1 Cropping.............................................3-30

3.5.2 Other Paper Selection ...........................3-35

3.6 The Multi-Feed Detection Tab............................3-37

3.7 The Preview Tab .............................................3-45

viii

3.8 The Options Tab..............................................3-46

3.9 The Setting Tab ..............................................3-54

3.10 The Imprinter Tab......................................3-57

3.11 The Information Tab...................................3-61

4. ISIS Interface Operation..........................................4-1

5. Maintaining Your Scanner ........................................5-1

5.1 Cleaning the Glass.............................................5-1

5.2 Frequently Asked Questions................................5-2

5.3 Technical Service ..............................................5-3

6. Specifications...........................................................6-1

Index................................................................................... a

User’s Manual

1-1

1. Installing the Scanner

1.1 Preinstallation Information

Keep the scanner out of direct sunlight. Direct exposure to

the sun or excessive heat may cause damage to the unit.

Do not install the scanner in a humid or dusty place.

Be sure to use the proper AC power source.

Only use the AC adapter (HEG42-120130-7L made by Hitron

or WA-18H12 made by APD) included in the machine. Using

other AC adapters may damage the machine and void the

warranty.

Place the scanner securely on an even, flat surface. Tilted or

uneven surfaces may cause mechanical problems.

1-2

1.2 Checking the Package Contents

Gently open your box and check the package contents. If there

is anything missing or damaged, please call your dealer.

1. Scanner main unit

2. USB cable

3. Power Adapter/Power Cable

4. Software CD/Quick guide

Note:

Please keep all the packing material in case you may have to

return the scanner for repair.

1 2

3 4
