Avision DF-1701B Manuel utilisateur

Color Image Scanner

User’s Manual

Regulatory model: DF-1701B/DF-1702B

Avision Inc.

User’s Manual

Trademarks

Microsoft is a U.S. registered trademark of Microsoft

Corporation.

Windows, Windows Vista, Windows 7, Windows 8 and Windows 10

are either registered trademarks or trademarks of Microsoft

Corporation in the United States and/or other countries.

IBM, IBM PC are registered trademarks of International Business

Machines Corp.

Other brands and product names herein are trademarks or

registered trademarks of their respective holders.

reproduced, transmitted, transcribed, stored in a retrieval

system, or translated into any language or computer language,

in any form or by any means, electronic, mechanical, magnetic,

optical, chemical, manual, or otherwise, without the prior

written permission of Avision Inc.

Material scanned by this product may be protected by

governmental laws and other regulations, such as copyright

laws, the customer is solely responsible for complying with all

such laws and regulations.

Warranty

The information contained in this document is subject to

change without notice.

Avision makes no warranty of any kind with regard to this

material, including, but not limited to, the implied warranties

of fitness for a particular purpose.

Avision shall not be liable for errors contained herein or for

incidental or consequential damages in connection with the

furnishing, performance, or use of this material.

User’s Manual

FCC Radio Frequency Interference Statement

This product has been tested and found to comply with the

limits for a class B digital device, pursuant to Part 15 of

the FCC rules. Operation is subject to the following two

conditions: (1) this device may not cause harmful

interference, and (2) this device must accept any

interference received, including interference that may

cause undesired operation. The FCC Class B limits are

designed to provide reasonable protection against harmful

interference in a residential installation. This equipment

generates, uses, and can radiate radio frequency energy

and, if not installed and used in accordance with the

instructions, may cause harmful interference to radio

communications. However, there is no guarantee that

interference will not occur in a particular installation. If this

equipment does cause harmful interference to radio or

television reception, which can be determined by turning

the equipment off and on, the user is encouraged to try to

correct the interference by one or more of the following

measures:

Reorient or relocate the receiving antenna.

Increase the separation between the equipment and

receiver.

Connect the equipment into an outlet on a circuit

different from that to which the receiver is connected.

Consult your point of purchase or service representative

for additional suggestions.

As an ENERGY STAR® Partner, Avision Inc. has

determined that this product meets the ENERGY

STAR guidelines for energy efficiency.

iii

User’s Manual

European Union Regulatory Notice

Products bearing the CE marking comply with the following EU

Directives:

Low Voltage Directive 2014/35/EC

EMC Directive 2014/30/EC

Restriction of the use of certain hazardous substances

(RoHS) Directive 2011/65/EU

CE compliance of this product is valid if powered with the

correct CE-marked AC adapter provided by Avision.

This product satisfies the Class B limits of EN55022, EN55024

and safety requirements of EN 60950.

*This machine is certified as Class 1 LED product. This means

that this machine does not produce hazardous laser radiation.

Disposal of Waste Equipment

This symbol on the product or on its packaging indicates that

the product can not be disposed of with your other household

waste. Instead it should be sent to appropriate facilities for

recovery and recycling in an effort to protect human health and

the environment. Fore more information about where you can

drop off your waste equipment for recycling, please contact

your local city office, your household waste disposal service or

the shop where you purchased the product.

User’s Manual

System Requirements

CPU:

Intel®Core™ 2 Duo or higher

Memory:

32 bit: 2 GB

64 bit: 4 GB

Optical Drive:

DVD-ROM Drive

USB Port:

USB port 2.0 (compatible with USB 1.1)

Compatible

Operating

System:

Microsoft Windows XP(SP3), Windows Vista,

Windows 7, Windows 8 (32 bits/64 bits),

Windows 10 (32 bits/64 bits)

User’s Manual

1. Introduction

Congratulations on your purchase of the color image

scanner. With this scanner, you can scan documents in a

rated speed to increase your productivity.

Before you install and operate the new scanner, please take

a few minutes to read through this manual. It provides

proper instructions for you to unpack, install, operate and

maintain the scanner.

The following figure indicates the package contents. Please

check all the items against your checklist. If you do not

receive all the items, please contact your authorized local

dealer immediately.

1 2

3 4

1. Scanner Main Unit

2. Software CD/Quick Guide

3. USB Cable

4. Power Adapter & Power Cord

1-1

User’s Manual

1-2

NOTE:

1. Only use the AC adapter (DA-48M24 made by APD)

included in the machine. Using other AC adapters may

damage the machine and void the warranty.

2. Please unpack the packing carefully, and check the contents

against the checklist. If any items are missing or damaged,

please contact your dealer immediately.

3. To access more service supports, visit www.avision.com to

User’s Manual

2. Scanner Installation

Precautions

Keep the scanner out of direct sunlight. Direct

exposure to the sun or excessive heat may cause

damage to the unit.

Do not install the scanner in a humid or dusty place.

Be sure to use the proper AC power source.

Place the scanner securely on an even, flat surface.

Tilted or uneven surfaces may cause mechanical or

paper-feeding problems.

Retain the scanner box and packing materials for

shipping purposes.

2-1

User’s Manual

2.1 Installing the Scanner Driver and Cables

NOTE:

1). The Windows system CD may be required when installing

on some PC’s.

2). To ensure your computer can identify the USB scanner,

please install scanner driver first before connecting the

scanner to your computer.

3). The scanner driver contains TWAIN, ISIS and WIA driver.

If you are running Windows Me, Windows XP, or Windows

Vista, after the installation of scanner driver is completed,

this scanner allows you to scan via a TWAIN, ISIS, or a

WIA interface. Start your TWAIN-compliant image editing

software application to select a TWAIN or WIA user

interface or your ISIS software to select an ISIS user

interface. You may also launch Microsoft’s Scanner and

Camera Wizard to scan via a WIA user interface.

2.1.1 Connecting to Power

Plug the small end of the power adaptor into the power jack of

your scanner. Insert the other end to an appropriate power

outlet.

2-2

User’s Manual

2.1.2 Turning on the Scanner

Press the Power Switch button on the front panel, the Power

LED will be lit. To turn off the scanner, press the Power

Switch button for about 3 seconds, the Power LED will be off.

2.1.3 Installing the Scanner Driver

1. Place the supplied CD-ROM onto your CD-ROM drive.

2. The software installation graphic appears. If not, run

“setup.exe”.

2-3
