Avision AV630CS Manuel utilisateur

AV630CS

Color

Image Scanner

User's Manual

Version 1.0

(Doc. No. 250-0115-E)

 AVISION INC. 1997

Trademarks

Microsoft is a U.S. registered trademark of Microsoft Corporation.

Windows and MS-DOS are trademarks of Microsoft Corporation.

IBM, PC, AT, XT are registered trademarks of International Business

Machines Corp.

Other brands and product names herein are trademarks or registered

trademarks of their respective holders.

transmitted, transcribed, stored in a retrieval system, or translated into any

language or computer language, in any form or by any means, electronic,

mechanical, magnetic, optical, chemical, manual, or otherwise, without the

prior written permission of Avision Inc.

Material scanned by this product may be protected by governmental laws

and other regulations, such as copyright laws, the customer is solely

responsible for complying with all such laws and regulations.

iii

Warranty

The information contained in this document is subject to change without

notice.

Avision makes no warranty of any kind with regard to this material, including,

but not limited to, the implied warranties of fitness for a particular purpose.

Avision shall not be liable for errors contained herein or for incidental or

consequential damages in connection with the furnishing, performance, or

use of this material.

FCC Radio Frequency Interference Statement

This equipment has been tested and found to comply with the limits for a

class B digital device, pursuant to Part 15 of the FCC rules. These limits

are designed to provide reasonable protection against harmful interference

in a residential installation. This equipment generates, uses, and can

radiate radio frequency energy and, if not installed and used in

accordance with the instruction manual, may cause harmful interference

to radio communication. However, there is no guarantee that interference

will not occur in a particular installation. If this equipment does cause

harmful interference to radio or television reception, which can be

determined by turning the equipment off and on, the user is encouraged to

try to correct the interference by one or more of the following measures:

* Reorient or relocate the receiving antenna.

* Increase the separation between the equipment and receiver.

* Connect the equipment into an outlet on a circuit different from that to

which the receiver is connected.

* Consult the dealer or an experienced radio/TV technician for

help.

CAUTION: Any changes or modifications not expressly approved by the

manufacture of this device could void the user's authority to operate the

equipment.

Table of Contents

Chapter 1 INTRODUCTION

Chapter 2 SCANNER INSTALLATION

2.1 Installation of the Scanner............................................................. 2-1

2.2 Unlocking the Scanner................................................................... 2-2

2.3 Installation of the SCSI card.......................................................... 2-3

2.4 Connecting the Cable..................................................................... 2-5

2.5 Document Placement..................................................................... 2-9

Chapter 3 SCANNER DRIVER INSTALLATION

Chapter 4 SCANNER OPERATION

4.1 IMAGE TYPE.....................................................................................4-2

4.2 RESOLUTION CONTROL................................................................... 4-3

4.3 IMAGE CONTROL ............................................................................ 4-6

4.4 SCANNING .................................................................................... 4-7

Chapter 5 MAINTENANCE

Chapter 6 TROUBLESHOOTING

6.1 Q&A ............................................................................................. 6-2

6.2 Technical Service .......................................................................... 6-3

Chapter 7 SPECIFICATIONS

Model: AV630CS................................................................................ 7-1

Appendix Detailed Procedure for installing SCSI Driver

1-1

Chapter 1 Introduction

Congratulations on your purchase of Avision AV630CS color image scanner.

Avision Inc. is one of the leading companies in the world to develop high

performance scanners.

Before you install and operate the new scanner, please take a few minutes to

read through this manual. It provides you with the proper instructions on

how to unpack, install, operate and maintain the scanner.

Figure 1-1 shows how the scanner is packed. Please check all the items

against your checklist. If you do not receive all the items, please contact

your authorized local dealer immediately.

1-2

1. Manual, Driver kit CD, AC power cord, D25P cable, etc.

2. Scanner 3. Cushion 4. Carton

Figure 1-1 Scanner packing

2-1

Chapter 2 Scanner Installation

Precautions

*Keep the scanner out of direct sunlight. Direct exposure to the sun or

excessive heat may cause damage to the unit.

*Do not install the scanner in a humid or dusty place.

*Be sure to use the proper AC power source.

*Place the scanner securely on an even, flat surface. Tilted or uneven

surfaces may cause mechanical problem.

*Keep the scanner box and packing materials in case you may need to ship

the scanner back in good condition.

2.1 Installation of the Scanner

Please unpack the scanner box carefully, and check the items against

the checklist. If any item missing or damaged, please contact your

dealer immediately.

2-2

2.2 Unlocking the Scanner

As shown below, unlock the scanner by turning the scanner lock to the

“Use” position.

1. "Shipping" position 2. "Use" position

Figure 2-1 Unlocking the Scanner

2-3

2.3 Installation of the SCSI Card

Hardware Installation

1) Power off your computer.

2) Plug the SCSI card in an available slot of your computer.

Be sure to screw it firmly.

3) Power on your computer.

Software Installation

In Windows 3.1

1) If your SCSI card is bundled with Avision AV630CS,

then installing the scanner driver will at the same time

complete the installation of the SCSI card driver.

2) If your SCSI card is not bundled with Avision

AV630CS, then please follow the installation sheet

contained in your SCSI card.

In Windows 95

1) Press Start Setting Control Panel. And then double

click "Add New Hardware". Select SCSI Adapter.

2) Choose Have disk and type "d:\DTCSCSI"(d means the letter

indicating your current CD-ROM drive)

3) Choose Finish and restart Windows 95.
