aventon POWER SHARE CTS36ABU1 Guide de l'utilisateur
Original Instruction Manual
ＥＬＥＣＴＲＩＣ ＫＩＣＫ ＳＣＯＯＴＥＲ
Ｍｏｄｅｌ Ｎｕｍｂｅｒ：ＣＴＳ３６ＡＢＵ１，ＣＴＳ３６ＡＢＵ２ …
ＣＴＳ３６ＡＢＵ１０
IMPORTANT! Read this manual instruction carefully and keep it for future reference.
CONTENTS
1. SAFETY WARNINGS
2. SCOOTER WALKAROUND
3. DASHBOARD
4. ASSEMBLY
5. CHARGING
6. HOW TO RIDE
7. FOLDING AND CARRYING
8. MAINTENANCE
9 . SPECIFICATIONS
10. CONTACT
1. SAFETY WARNINGS
Do not ride over speed bumps, thresholds, or other bumps
at High Speed.
Watch your head when passing through
doorways.
Do not press the
throttle when walking with the scooter.
Do not ride in the snow, in the rain, or
on roads which are wet, muddy, icy,
or that are slippery for any reason.
WARNING!
Whenever you ride your scooter, you risk injury or death from loss of control, collisions, and falls.
The manufacturer recommends riders be 14+ years old. Read and understand all safety warnings listed on the
product label. Always follow these safety instructions.
People who should NOT ride this product include:
•Those with heart conditions, pregnant women, or persons with head, back, or neck ailments that limit their
ability to ride safely.
•Anyone under the influence of alcohol or drugs.
•Persons with any mental or physical conditions that may make them susceptible to injury or impair their
physical dexterity or mental capabilities to recognize, understand, and perform all of the safety instructions and
to be able to assume the hazards inherent with this product.
Comply with local laws and regulations when riding this product. Do not ride where prohibited by local law.
When braking rapidly you risk serious injury due to loss of traction and falls. Watch your speed when traveling
downhill. Apply brakes when traveling at high speeds. If brakes are loose, tighten to increase braking strength.
Ride safely to avoid falls or collisions.
Always wear a helmet while riding. A helmet is recommended, unless required by law.
Do not ride in the snow, in the rain, or on roads which are wet, muddy, icy, or that are slippery for any reason. Do not
ride over obstacles. Doing so could result in loss of balance or traction and could cause a fall. Whenever you ride
your vehicle you risk injury or death from loss of control, collisions, and falls. Be sure to read the User Manual.
Do not use the scooter for racing, stunt riding, or other maneuvers, which may cause loss of control, or may cause
uncontrolled operator actions.
Avoid contact with moving parts. Ensure hands, feet, hair, clothing, and other body parts stay clear of moving parts
like the motor or rear wheel.
ALWAYS keep both hands on the handlebar when riding.
Do not ride over speed bumps, thresholds, or other bumps
at High Speed.
Do not carry heavy objects on the
handlebar or exceed maximum
weight of 220lbs.
Keep both feet firmly on the scooter.
DO NOT ride with one foot only.
Comply with local laws and regulations when
riding this product. DO NOT ride on sidewalks,
motorways, or highways.
Avoid The Following Actions
When braking rapidly you risk serious
injury due to loss of traction and falls.
Watch your speed when traveling
downhill. Apply brakes when traveling at
high speeds.
DO NOT rotate the handlebars suddenly
while driving at high speeds.
Avoid all obstacles to avoid falls or
collisions.
WARNING
!
You are responsible for monitoring the condition of your scooter, maintaining the components and using only authorized
replacement parts.
If you check your scooter and identify any component that is not functioning properly, notice damage or
excessive wear and tear, or you encounter an error code, do not ride your scooter and please contact
Customer Support.
Do not modify the scooter. Doing so will void any applicable warranties and may put you at increased risk of serious
injury or death.
DO NOT ride up and down stairs. DO NOT use a mobile device or wear
earphones while riding.
Avoid contact with moving parts. Ensure
hands, feet, hair, clothing, and other body
parts stay clear of moving parts like the motor
or rear wheel.
DO NOT take your hands from the
handlebars while riding. ALWAYS
keep both hands on the handlebar.
DO NOT ride with more than one rider.
DO NOT ride the scooter in the rain or
on wet ground.
2. SCOOTER WALKAROUND
What's Included
Dual Power Share Charger
Hex Wrench
Extension Hose
Before assembling your new scooter, please verify that the above items are included. If any components are missing,
please contact customer service. After verifying all components are present and in good condition, you can assemble.
CAUTION: Remember to power off your scooter and remove the batteries before assembling, mounting accessories or
cleaning.
Power Share Batteries
Dual Charger
Power Share Batteries Battery Compartment Key
3.DASHBOARD
Headlight
When the light is on, the icon will be illuminated green
SpeeG
When ULGLQJ, the speed will be displayed on the control
panel.
(
Ifthe riding speed exceedVthe top speed, the display will IODVK and beep
as speed warning.)
Mode
The scooter has 3 speed modes. To change modes, press the
power button twice.
ECO: Max speed of 6 MPH
D
(Drive): Max speed of 9 MPH
S (Sport): Max speed of 15 MPH
Mi/h
Battery Level
The battery charge level is indicated by the 5 bars on the
display.
Error Codes
Motor Failure
Error code "E1" will flash from the speed display.
Brake Failure
Error code "E2" will flash from the speed display.
Accelerator Failure
Error code "E3" will flash from the speed display.
Controller Failure
Error code "E4" will flash from the speed display.
Power Button
The power button is used to turn ON/OFF the scooter and
configure.
Turn ON/OFF: Press & hold for 2 seconds
Headlight / Rear Light - Quick press 1 time to turn on and off the
lights
Mode Selection: Quick press 2 times to select the riding mode
4.ASSEMBLY
1.
Remove the scooter from the packaging box.
Move the kickstand out. With one hand on the pole and
one hand on the deck, place the scooter on the ground.
It should stand on its own with the kickstand out.
2.
Unfold the pole and push it until you hear a click.
Confirm that it is fully locked into place and the safety
lock pin is secured completely.
3. Firmly connect the wires inside the handlebar and the
pole. Slide the handlebar onto the pole. Be aware of the
correct orientation.
4. Tightly install the 4 screws with the included hex wrench.
5. Unlock the battery compartment underneath the deck
with the key provided.
6. After fully charging your Power Share batteries, insert
both batteries into the battery compartment.
Safety Lock Pin
WARNING!
Keep plastic covering away from children to avoid suffocation.
5.CHARGING
We recommend charging the batteries indoors, in moderate temperature conditions.
WARNING: read the supplied user manual for both the Power Share batteries and dual charger before use.
It is recommended to fully charge both batteries before use.
INDICATOR LIGHTS
RED
WARNING
!
Do not charge or use your battery if it is damaged or see trace of water.
Always power off your Electric Kick Scooter before removing the batteries.
6.HOW TO RIDE
WARNING
Always wear protective gear such as a helmet,
knee pads, and elbow pads.
Mi/h
How to Charge:
1. Connect the dual charger to a power supply
2. Push the battery onto the charger
Solid Red
Flashing Red
Solid Green
Flashing Green
1. Press and hold the power button for 2 seconds
to power on the scooter. Check the battery level
indicator. It is recommended to fully charge the
batteries before use.
2. Adjust the speed setting to be your desired
speed by pressing the power button twice to
choose your preferred mode.
3. Place one foot on the deck and kick with the other to
propel forward. Press the throttle to accelerate.
NOTE
: The electric scooter will not accelerate until
you manually reach a speed of approx. 1.5 MPH, for
your safety.
4. Slow down by releasing the throttle and brake
by squeezing the brake lever.
5. Tilt your body and slowly turn the handlebar to steer.
Always be aware of your surroundings before
turning.
6. Always release the kickstand and turn OFF the scooter
when not riding. Do not leave the scooter outside when it
is raining or snowing.
