Avalue Technology LPC-08A1 Manuel utilisateur

Part No. E201708A1A1R

LPC-08 Series

8” Multi-functional Touch Panel PC

Quick Reference Guide

2nd Ed – May 2010

LPC-08 Series

2 LPC-08 Series Quick Reference Guide

Contents

1. Getting Started............................................................................................................3

1.1 Safety Precautions ................................................................................................3

1.2 Packing List...........................................................................................................3

1.3 System Specifications ...........................................................................................4

1.4 System Overview...................................................................................................6

1.4.1 Rear View..................................................................................................................................... 6

1.4.2 Right View.................................................................................................................................... 6

1.5 System Dimensions...............................................................................................7

1.5.1 LPC-08 Series.............................................................................................................................. 7

2. Hardware Configuration.............................................................................................8

2.1 Jumper and Connector Setting, Driver and BIOS Installing...................................8

2.2 Installing Memory ..................................................................................................9

2.3 Installing CF Card................................................................................................10

2.4 Installing Hard Disk..............................................................................................11

Quick Reference Guide

LPC-08 Series Quick Reference Guide 3

1. Getting Started

1.1 Safety Precautions

Warning!

Always completely disconnect the power cord from your

chassis whenever you work with the hardware. Do not

make connections while the power is on. Sensitive

electronic components can be damaged by sudden power

surges. Only experienced electronics personnel should

open the PC chassis.

Caution!

Always ground yourself to remove any static charge before

touching the CPU card. Modern electronic devices are very

sensitive to static electric charges. As a safety precaution,

use a grounding wrist strap at all times. Place all electronic

components in a static-dissipative surface or static-shielded

bag when they are not in the chassis.

1.2 Packing List

z1 x LPC-08 Series Panel PC

z1 x Quick Reference Guide

z1 x CD/DVD-ROM contains the followings:

—User’s Manual (this manual in PDF file)

—Ethernet driver and utilities

—VGA drivers and utilities

—Audio drivers and utilities

—WiFi drivers and utilities

—Touch controller drivers and utilities

z1 x Power Adapter

z4 x screws for VESA

LPC-08 Series

4 LPC-08 Series Quick Reference Guide

1.3 System Specifications

Panel

Specifications LPC-08A1 LPC-0803

LCD size 8"

Display type SVGA TFT

Resolution 800 x 600

Color 262K

Pixel pitch 0.2025mm(H) x 0.2025mm(V)

Luminance 400 cd/m²

Contrast ratio 500

Viewing angle 55(U), 65(D), 65(L), 65(R)

Response time 50 ms

Backlight LED

Touch Type 5-wire Resistive

Touch Light Transmission 80%

Touch Interface USB onboard touch interface USB

System

Board ECM-LX800D ECM-945GSE

CPU Onboard AMD Geode LX800 @ 0.9

W 500 MHz with 128K L2 cache

Intel® Atom processor N270 1.6GHz

CPU

Cooling Method Passive CPU heatsink

System Chipset AMD Geode LX800/CS5536 Intel® 945GSE / ICH7-M

I/O Chip Winbond W83627HG-AW ITE IT8712F

Memory Onboard 512MB DDR Memory

One 200-pin SODIMM socket

supports up to 2GB DDR2

400/533MHz SDRAM

SSD

One CF socket by IDE secondary slave channel

supports Type I / II Compact Flash Card

Optional one 2.5” HDD w/shock-resistant drive bay

WiFi Optional USB WiFi 802.11 b/g

(occupy one USB port) Optional USB WiFi 802.11 b/g

Quick Reference Guide

LPC-08 Series Quick Reference Guide 5

Rear Panel I/O

Serial Port 1 x RS-232, Optional 1 x RS-232/422/485

Ethernet Dual Realtek RTL8101L LAN Dual Marvell 88E8053 GigaLAN

VGA 1 x DB-15

Audio port 1 x Line out

USB 2 x USB 2.0 4 x USB 2.0

Mouse & KB 1 x PS/2 Keyboard connector N / A

Mechanical & Environmental

Color Front Silver and Back Black

Power Input 100~250 Vdc/ 47~63 Hz

Power Output +12 Vdc / 5 A (60W)

Operating Temperature -10°C to 60°C. 0°C to 40°C

Storage Temperature -20°C to 70°C. -10°C to 50°C

Relative Humidity 10% to 95% @ 40℃, non-condensing

Mounting Wall/Stand/VESA 75 mm X 75 mm

Dimensions 202.5 mm X 159.5 mm X 42.3 mm

(w/HDD 202.5 x 159.5 x 55 mm)

Weight 1.38 Kgs (w/HDD 1.68Kgs)

Note: 1. LPC-08A1 supports +10V~28V wide range power input.

2. Either RS-232 or RS-422/485 for COM2 only.

LPC-08 Series

6 LPC-08 Series Quick Reference Guide

1.4 System Overview

1.4.1 Rear View

1.4.2 Right View

Connectors

Label Function Note

CF Cover CompactFlash Type I/II socket with cover

COM Serial port 1 & 2

(Optional RS-422/485 for COM2) DB-9 male connector

DC in +12V DC-in power connector

(Optional industrial DC-in co-lay with COM2)

KB/MS/USB PS/2 keyboard & mouse connector

(LPC-08A1)

2 x USB connector (LPC-0803)

6-pin Mini DIN or dual USB

decks

LAN Ethernet connector RJ-45

LINE OUT Line-out audio jack

Power Power switch

USB USB 2.0 connector

VGA CRT connector DB-15 female connector

Note: The optional WiFi module will occupy one USB port for LPC-08A1.

Quick Reference Guide

LPC-08 Series Quick Reference Guide 7

1.5 System Dimensions

1.5.1 LPC-08 Series

LPC-08 Series

8 LPC-08 Series Quick Reference Guide

2.Hardware

Configuration

2.1 Jumper and Connector Setting, Driver and BIOS

Installing

zPlease refer to ECM-LX800D, ECM-945GSE Quick Installation Guide or

User’s Manual for further information.

Note: If you need more information, please visit our website:

http://www.avalue.com.tw

Quick Reference Guide

LPC-08 Series Quick Reference Guide 9

2.2 Installing Memory

Note: Memory installation is not for LPC-08A1 due to 512MB memory onboard.

Step 1. Unfasten 6 screws to remove the bottom chassis.

Step 2. Unlock 4 coppers from the rear I/O of VGA & COM ports.

Step 3. Release 4 screws to take off the board, and install the RAM module into the

memory slot.

Step 4. Assemble the board and bottom chassis back as step 3 to step 1.

LPC-08 Series

10 LPC-08 Series Quick Reference Guide

2.3 Installing CF Card

Step 1. Unlock 2 screws from the rear side of the panel PC as above.

Step 2. Put the CF card into the socket and fasten 2 screws back.
