Avalue Technology PPC-1501 Manuel utilisateur

Part No. E2017PPC0A3R

PPC 15”~22”W Series

15”/17”/18”W/21”W/22”W Plastic Touch Panel PC

Quick Reference Guide

4th– 03 March, 2011

PPC 15”~22”W Series

2 PPC 15”~22”W Series Quick Reference Guide

Contents

1.1 Safety Precautions ................................................................................................3

1.2 Packing List...........................................................................................................3

1.3 System Specifications ...........................................................................................4

1.4 System Overview.................................................................................................14

1.4.1 Front View.................................................................................................................................. 14

1.4.1.1 Front View for PPC-21W05.............................................................................................................................14

1.4.2 Rear View................................................................................................................................... 15

1.5 System Dimensions.............................................................................................16

1.5.1 PPC 15” Series.......................................................................................................................... 16

1.5.2 PPC 17” Series.......................................................................................................................... 17

1.5.3 PPC 18” Widescreen Series...................................................................................................... 18

1.5.4 PPC 21” Widescreen Series...................................................................................................... 19

1.5.5 PPC 22” Widescreen Series...................................................................................................... 20

2.1 Jumper and Connector Setting, Driver and BIOS Installing.................................21

2.2 Installing Hard Disk & Memory ............................................................................22

2.2.1 Install 2.5” HDD.......................................................................................................................... 22

2.3 Installing Panel PC Stand....................................................................................25

2.4 Installing Optional MSR Module ..........................................................................26

Quick Reference Guide

PPC 15”~22”W Series Quick Reference Guide 3

1. Getting Started

1.1 Safety Precautions

Warning!

Always completely disconnect the power cord from your

chassis whenever you work with the hardware. Do not

make connections while the power is on. Sensitive

electronic components can be damaged by sudden power

surges. Only experienced electronics personnel should

open the PC chassis.

Caution!

Always ground yourself to remove any static charge before

touching the CPU card. Modern electronic devices are very

sensitive to static electric charges. As a safety precaution,

use a grounding wrist strap at all times. Place all electronic

components in a static-dissipative surface or static-shielded

bag when they are not in the chassis.

1.2 Packing List

z1 x PPC 15”/17”/18”W/21”W/22”W Series Panel PC

z1 x CD/DVD-ROM contains the followings:

—Quick Reference Guide (this manual in PDF file)

—Ethernet driver and utilities

—VGA drivers and utilities

—Audio drivers and utilities

—WiFi drivers and utilities

—Touch controller drivers and utilities

z1 x Power Adapter

z1 x Stand for Panel PC (with 6 screws & 5 rubber-foot)

z1 x MSR set with bracket (for optional MSR)

PPC 15”~22”W Series

4 PPC 15”~22”W Series Quick Reference Guide

1.3 System Specifications

Panel

Specifications PPC-1501 PPC-1701 PPC-22W01

LCD size 15", 4:3 17", 4:3 22", 16:10

Display type XGA TFT SXGA TFT WSXGA TFT

Resolution 1024 x 768 1280 x 1024 1680 x 1050

Color 16.7M 16.7M 16.7M

Pixel pitch 0.297mm(H) x

0.297mm(V)

0.264mm(H) x

0.264mm(V)

0.282mm(H) x

0.282mm(V)

Luminance 300 cd/m² 380 cd/m² 300 cd/m²

Contrast ratio 700 1000 700

Viewing angle 70(U), 70(D), 75(L),

75(R) 80(U), 80(D), 85(L), 85(R) 80(U), 80(D), 85(L),

85(R)

Response time 8 ms 5 ms 5 ms

Backlight 2 x CCFL 4 x CCFL 4 x CCFL

Touch Type 5 Wires resistive 5 Wires resistive 5 Wires resistive

Touch Light Transmission 80% 80% 80%

Touch Interface USB USB USB

System

Board EBM-CX700

CPU Onboard VIA Eden V4 ULV 1G (3.5W)

System Chipset VIA CX700M

I/O Chip VIA VT1211

Memory One 200-pin DDR2 SODIMM socket, supports up to 1GB DDR2 400/533

SDRAM

SSD One CF socket by IDE secondary slave channel supports Type I / II Compact

Flash Card

HDD Drive Bay One 2.5" SATA HDD or optional 44-pin enhanced IDE HDD

WiFi Optional USB WiFi 802.11b/g

Watchdog Timer Reset: 1 sec.~255 min. and 1 sec. or 1 min./step

H/W Status Monitor Monitoring system temperature and voltage.

Auto throttling control when CPU overheats

Expansion Slot 1 x Mini PCI

Quick Reference Guide

PPC 15”~22”W Series Quick Reference Guide 5

Rear Panel I/O

Serial Port 1 x RS-232

Ethernet 2 x RJ-45

VGA 1 x DB-15

Audio port 1 x Line out

USB 2 x USB 2.0

Speaker 2W x 2

Mechanical & Evironmental

System Fan Passive Heat Sink

Color Front & Rear panel Black (Plastics)

Mounting Wall/Stand/VESA 100 mm X 100 mm

Power Input 100~250 Vdc/ 47~63 Hz

Power Output +12 Vdc / 5 A (60W)

Operating Temperature 0 to 40°C (32 to 140°F )

Storage Temperature -10°C to 50°C

Relative Humidity 0%~90% relative humidity, non-condensing

Dimensions 340 x 285 x 53 mm 372 x 324 x 53 mm 510 x 352 x 55 mm

Weight 2.79 Kgs 3.79 Kgs 4.79 Kgs

PPC 15”~22”W Series

6 PPC 15”~22”W Series Quick Reference Guide

Panel

Specifications PPC-1503 PPC-1703

LCD size 15", 4:3 17", 4:3

Display type XGA TFT SXGA TFT

Resolution 1024 x 768 1280 x 1024

Color 16.7M 16.7M

Pixel pitch 0.297mm(H) x 0.297mm(V) 0.264mm(H) x 0.264mm(V)

Luminance 300 cd/m² 380 cd/m²

Contrast ratio 700 1000

Viewing angle 70(U), 70(D), 75(L), 75(R) 80(U), 80(D), 85(L), 85(R)

Response time 8 ms 5 ms

Backlight 2 x CCFL 4 x CCFL

Touch Type 5 Wires resistive 5 Wires resistive

Touch Light Transmission 80% 80%

Touch Interface USB USB

System

Board EBM-945GSE

CPU Onboard Intel N270 Atom processor 1.6GHz, (2.5W)

System Chipset Intel 945GSE + ICH7-M

I/O Chip ITE IT8712F/KX

Memory One 200-pin DDR2 SODIMM socket, supports up to 1 GB DDR2 400/533

SDRAM

SSD One CF socket by IDE secondary slave channel supports Type I / II Compact

Flash Card

HDD Drive Bay One 2.5" SATA HDD or optional 44-pin enhanced IDE HDD

WiFi Optional USB WiFi 802.11b/g

Watchdog Timer Reset: 1~65535 sec./min. and 1 min./step

H/W Status Monitor Monitoring system temperature and voltage. Auto throttling control when

CPU overheats

Expansion Slot One Mini PCI slot

Quick Reference Guide

PPC 15”~22”W Series Quick Reference Guide 7

Rear Panel I/O

Serial Port 1 x RS-232

Ethernet 1 x RJ-45

VGA 1 x DB-15

Audio port 1 x Line out

USB 2 x USB 2.0

Speaker 2W x 2

Mechanical & Evironmental

System Fan Passive Heat Sink

Color Front & Rear panel Black (Plastics)

Mounting Wall/Stand/VESA 100 mm X 100 mm

Power Input 100~250 Vdc/ 47~63 Hz

Power Output +12 Vdc / 5 A (60W)

Operating Temperature 0 to 40°C (32 to 140°F )

Storage Temperature -10°C to 50°C

Relative Humidity 0%~90% relative humidity, non-condensing

Dimensions 340 x 285 x 53 mm 372 x 324 x 53 mm

Weight 2.79 Kgs 3.79 Kgs

PPC 15”~22”W Series

8 PPC 15”~22”W Series Quick Reference Guide

Panel

Specifications PPC-18W03 PPC-22W03

LCD size 18.5", 16 : 9 22", 16:10

Display type WSGA TFT WSXGA TFT

Resolution 1366 x 768 1680 x 1050

Color 16.7M 16.7M

Pixel pitch 0.300mm(H) x 0.300mm(V) 0.282mm(H) x 0.282mm(V)

Luminance 300 cd/m² 300 cd/m²

Contrast ratio 300 700

Viewing angle 80(U), 80(D), 85(L), 85(R) 80(U), 80(D), 85(L), 85(R)

Response time 5 ms 5 ms

Backlight 2 x CCFL 4 x CCFL

Touch Type 5 Wires resistive 5 Wires resistive

Touch Light Transmission 80% 80%

Touch Interface USB USB

System

Board EBM-945GSE

CPU Onboard Intel N270 Atom processor 1.6GHz, (2.5W)

System Chipset Intel 945GSE + ICH7-M

I/O Chip ITE IT8712F/KX

Memory One 200-pin DDR2 SODIMM socket, supports up to 1 GB DDR2 400/533

SDRAM

SSD One CF socket by IDE secondary slave channel supports Type I / II Compact

Flash Card

HDD Drive Bay One 2.5" SATA HDD or optional 44-pin enhanced IDE HDD

WiFi Optional USB WiFi 802.11b/g

Watchdog Timer Reset: 1~65535 sec./min. and 1 min./step

H/W Status Monitor Monitoring system temperature and voltage. Auto throttling control when

CPU overheats

Expansion Slot One Mini PCI slot

Quick Reference Guide

PPC 15”~22”W Series Quick Reference Guide 9

Rear Panel I/O

Serial Port 1 x RS-232

Ethernet 1 x RJ-45

VGA 1 x DB-15

Audio port 1 x Line out

USB 2 x USB 2.0

Speaker 2W x 2

Mechanical & Evironmental

System Fan Passive Heat Sink

Color Front & Rear panel Black (Plastics)

Mounting Wall/Stand/VESA 100 mm X 100 mm

Power Input 100~250 Vdc/ 47~63 Hz

Power Output +12 Vdc / 5 A (60W)

Operating Temperature 0 to 40°C (32 to 140°F )

Storage Temperature -10°C to 50°C

Relative Humidity 0%~90% relative humidity, non-condensing

Dimensions 443 x 290 x 59.8 mm 510 x 352 x 55 mm

Weight 3.90 Kgs 4.79 Kgs

PPC 15”~22”W Series

10 PPC 15”~22”W Series Quick Reference Guide

Panel

Specifications PPC-1505 PPC-1705

LCD size 15", 4:3 17", 4:3

Display type XGA TFT SXGA TFT

Resolution 1024 x 768 1280 x 1024

Color 16.7M 16.7M

Pixel pitch 0.297mm(H) x 0.297mm(V) 0.264mm(H) x 0.264mm(V)

Luminance 300 cd/m² 380 cd/m²

Contrast ratio 700 1000

Viewing angle 70(U), 70(D), 75(L), 75(R) 80(U), 80(D), 85(L), 85(R)

Response time 8 ms 5 ms

Backlight 2 x CCFL 4 x CCFL

Touch Type 5 Wires resistive 5 Wires resistive

Touch Light Transmission 80% 80%

Touch Interface USB USB

System

Board EBM-PNV

CPU Onboard Intel® Atom™ D525 Dual-Core 1.8 GHz CPU

System Chipset Intel ICH8-M

I/O Chip Winbond W83627DHG

Memory Onboard 1 GB up to 2GB & one 204-pin SODIMM support up to 4 GB DDR3

800 SDRAM2

SSD One CF socket by IDE secondary slave channel supports Type I / II Compact

Flash Card

HDD Drive Bay One 2.5" SATA HDD

WiFi Optional USB or Mini PCIe WiFi module

Watchdog Timer Reset: 1 ~ 255min. and 1sec. or 1min./step

H/W Status Monitor Monitoring system temperature and voltage. Auto throttling control when

CPU overheats

Expansion Slot One Mini PCIe slot

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Avalue Technology Ordinateur de bureau

Avalue Technology

Avalue Technology ARC-1209 Manuel utilisateur

Avalue Technology

Avalue Technology EPC-BSW Manuel utilisateur

Avalue Technology

Avalue Technology SOPM-QM87 Manuel utilisateur

Avalue Technology

Avalue Technology EPC-CDV Manuel utilisateur

Avalue Technology

Avalue Technology HPS-SRSU4A Manuel utilisateur

Avalue Technology

Avalue Technology EMS-SKLU Series Manuel utilisateur

Avalue Technology

Avalue Technology EPS-ADS Manuel utilisateur

Avalue Technology

Avalue Technology BMX-T522-SK Manuel utilisateur

Avalue Technology

Avalue Technology BMX-T521-BSW Manuel utilisateur

Avalue Technology

Avalue Technology ERS-CDVE Manuel utilisateur

Avalue Technology

Avalue Technology EPC-WHL Manuel utilisateur

Avalue Technology

Avalue Technology EPC Series Manuel utilisateur

Avalue Technology

Avalue Technology EMS-TGL Series Manuel utilisateur

Avalue Technology

Avalue Technology OPC-15W6 Manuel utilisateur

Avalue Technology

Avalue Technology LPC-1207 Manuel utilisateur

Avalue Technology

Avalue Technology LPC-1009 Series Manuel utilisateur

Avalue Technology

Avalue Technology EPC-TGU Manuel utilisateur

Avalue Technology

Avalue Technology EPC-CDV Manuel utilisateur

Avalue Technology

Avalue Technology LPC-0833 Manuel utilisateur

Avalue Technology

Avalue Technology ERS-A50M Manuel utilisateur

Avalue Technology

Avalue Technology BMX-T524 Manuel utilisateur

Avalue Technology

Avalue Technology EPC-3711 Manuel utilisateur

Avalue Technology

Avalue Technology ECS-BSW Manuel utilisateur

Avalue Technology

Avalue Technology UB-A200 Manuel utilisateur

Manuels Ordinateur de bureau populaires d'autres marques

HP m9060n - Pavilion - Elite Fiche technique

Asus

Asus E210 Series Manuel utilisateur

Dell

Dell Inspiron 600m Manuel utilisateur

Dell

Dell Inspiron 3662 Manuel utilisateur

TotalFlow

TotalFlow uFLO Manuel utilisateur

HP Presario SV7000 - Desktop PC Manuel utilisateur

HP ProDesk 400 G5 Manuel

Logitech

Logitech MK320 Manuel utilisateur

Dell

Dell XPS 730 H2C Manuel utilisateur

Sony

Sony Vaio Series Manuel utilisateur

Sony

Sony VGC-LT32E - Vaio All-in-one Desktop Computer Manuel utilisateur

Alto

Alto MD 250 Manuel utilisateur

Lenovo

Lenovo ThinkCentre Edge 72 Manuel

Lenovo

Lenovo ThinkStation D20 Manuel

Arbor Technology

Arbor Technology FPC-7800 Series Manuel utilisateur

Sony

Sony VAIO VGX-TP1 Series Manuel utilisateur

Asus

Asus Eee Box B204 Manuel utilisateur

Dell

Dell Optiplex 9010 All In One Manuel utilisateur
