Avalue Technology UB-A200 Manuel utilisateur

Part No. E2017UBA2A0R

UB-A200

ARTEMIS Anchor

Quick Reference Guide

1st Ed –11 January 2022

UB-A200

2 UB-A200 Quick Reference Guide

FCC Statement

THIS DEVICE COMPLIES WITH PART 15 FCC RULES. OPERATION IS

SUBJECT TO THE FOLLOWING TWO CONDITIONS:

(1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE.

(2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED INCLUDING

INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.

THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO COMPLY WITH THE LIMITS

FOR A CLASS "A" DIGITAL DEVICE, PURSUANT TO PART 15 OF THE FCC RULES.

THESE LIMITS ARE DESIGNED TO PROVIDE REASONABLE PROTECTION AGAINST

HARMFUL INTERFERENCE WHEN THE EQUIPMENT IS OPERATED IN A

COMMERCIAL ENVIRONMENT. THIS EQUIPMENT GENERATES, USES, AND CAN

RADIATE RADIO FREQUENCY ENERGY AND, IF NOT INSTATLLED AND USED IN

ACCORDANCE WITH THE INSTRUCTION MANUAL, MAY CAUSE HARMFUL

INTERFERENCE TO RADIO COMMUNICATIONS.

OPERATION OF THIS EQUIPMENT IN A RESIDENTIAL AREA IS LIKELY TO CAUSE

HARMFUL INTERFERENCE IN WHICH CASE THE USER WILL BE REQUIRED TO

CORRECT THE INTERFERENCE AT HIS OWN EXPENSE.

A Message to the Customer

Avalue Customer Services

Each and every Avalue’s product is built to the most exacting specifications to ensure

reliable performance in the harsh and demanding conditions typical of industrial

environments. Whether your new Avalue device is destined for the laboratory or the factory

floor, you can be assured that your product will provide the reliability and ease of operation

for which the name Avalue has come to be known.

Your satisfaction is our primary concern. Here is a guide to Avalue’s customer services. To

ensure you get the full benefit of our services, please follow the instructions below carefully.

Technical Support

We want you to get the maximum performance from your products. So if you run into

technical difficulties, we are here to help. For the most frequently asked questions, you can

easily find answers in your product documentation. These answers are normally a lot more

detailed than the ones we can give over the phone. So please consult the user’s manual

first.

To receive the latest version of the user’s manual; please visit our Web site at:

http://www.avalue.com.tw/

Quick Reference Guide

UB-A200 Quick Reference Guide

Content

1. Getting Started..........................................................................................................4

1.1 Safety Precautions....................................................................................................4

1.2 Packing List...............................................................................................................4

1.3 System Specifications...............................................................................................5

1.4 System Overview......................................................................................................8

1.4.1 Rear View................................................................................................................................ 8

1.4.2 Rear/Top View......................................................................................................................... 8

1.5 System Dimensions ..................................................................................................9

UB-A200

4 UB-A200 Quick Reference Guide

1. Getting Started

1.1 Safety Precautions

Warning!

Always completely disconnect the power cord from your

chassis whenever you work with the hardware. Do not

make connections while the power is on. Sensitive

electronic components can be damaged by sudden power

surges. Only experienced electronics personnel should

open the PC chassis.

Caution!

Always ground yourself to remove any static charge before

touching the CPU card. Modern electronic devices are very

sensitive to static electric charges. As a safety precaution,

use a grounding wrist strap at all times. Place all electronic

components in a static-dissipative surface or static-shielded

bag when they are not in the chassis.

1.2 Packing List

1 x UB-A200

1 x Bracket

Quick Reference Guide

UB-A200 Quick Reference Guide

1.3 System Specifications

Component

Mother Board

Leverage PCBA of UB-A100 (E9697UBA1E0R)

MCU

ARM® Cortex® -M4 32-bit RISC core, 168 MHz (STM32F407VGT6)

UWB RF Specifications

Chip

DECAWAVE DW1000

Frequency

Channel 1 : 3.25~3.75 GHz for USA

Channel 2 : 3.75~4.25 GHz for USA, Europe

Channel 3 : 4.25~4.75 GHz for USA, Europe, Taiwan

Channel 5 : 6.25~6.75 GHz for China

Physical rate

110K bps

850K bps

6.8 Mbps

Power output (25℃)

-41.3 dBm

Antenna peak gain

5dBi

2.4 Wi-Fi RF Specifications

Chip

AI7688H

Protocol

802.11b/g/n

Antenna

1.5dBi

Software

UWB operating mode

TDoA

Network mode

Bridge mode

WLAN operating mode

Station

AP + Station

Protocol

DHCP

Security

WPA

WPA2

External I/O

LAN Port

1 x RJ-45 (10/100Mbps), support Powered LAN (802.3af/at)

Indicator Light

All LEDs color is GREEN

Power

When power on, LED indicator remains lit.

LAN

When the data of Ethernet is transmitted, the LED indicator flashes.

UWB

When UWB work normally, the LED indicator flashes.

UB-A200

6 UB-A200 Quick Reference Guide

Wi-Fi

When the data is transmitted, the LED indicator flashes.

Others

1 x Reboot button

1 x Function button

Mechanical

Power Type

AT (*whcih means no power switch or button on chassis)

Power Connector Type

1 x DC-in

Power Requirement

+12V DC-in or Powered LAN (802.3af/at)

Mounting

Wall mount

Dimension

182 x 182 x 38mm

Weight

0.4kg

Color

White

Reliability

EMI Test

CE/FCC ClassB

Safety

UL/CB design compatible

Vibration Test

Random Vibration Operation

1 Test PSD : 0.00454G²/Hz , 1.5 Grms

2 System condition : operation mode

3 Test frequency : 5~500 Hz

4 Test axis : X,Y and Z axis

5 Test time : 30 minutes per each axis

6 IEC60068-2-64 Test Fh

Sine Vibration test (Non-operation)

1 Test Acceleration : 2G

2 Test frequency : 5~500 Hz

3 Sweep：1 Oct/ per one minute. (logarithmic)

4 Test Axis : X,Y and Z axis

5 Test time :30 min. each axis

6 System condition : Non-Operating mode

7. Reference IEC 60068-2-6 Testing procedures

Package Vibration Test

1 Test PSD : 0.026G²/Hz , 2.16 Grms

2 Test frequency : 5~500 Hz

3 Test axis : X,Y and Z axis

4 Test time : 30 minutes per each axis

5 IEC 60068-2-64 Test Fh

Mechanical Shock Test

1. Wave form：Half Sine wave

2. Acceleration Rate：10g for operation mode

Quick Reference Guide

UB-A200 Quick Reference Guide

3. Duration Time：11ms

4. No. of Shock：Z axis 300 times

5. Test Axis: Z axis

6. Operation mode

7 Reference IEC 60068-2-27 testing procedures

Test Eb : Shock Test

Drop Test

Packing Drop

Reference ISTA 2A, Method : IEC-60068-2-32 Test:Ed Test Ea : Drop

Test

1 One corner, three edges, six faces

2 ISTA 2A, IEC-60068-2-32 Test:Ed

Operating Temperature

0℃~ 55℃

Operating Humidity

40°C @ 95% Relative Humidity, Non-condensing

Storage Temperature

-40 ~ 75°C

Note: Specifications are subject to change without notice.

UB-A200

8 UB-A200 Quick Reference Guide

1.4 System Overview

1.4.1 Rear View

1.4.2 Rear/Top View

Connector

Label

Function

PWR

DC-IN +12V

ETH

RJ-45 Ethernet (10/100 Mbps)

USB

USB 2.0 connector (for reload firmware only)

RST 1/2

RST1：Reboot button

RST2：Combined with RST1 to form a multi-function button

Quick Reference Guide

UB-A200 Quick Reference Guide

1.5 System Dimensions

(Unit: mm)
