Avalue Technology REN-WHLPC Manuel utilisateur

Part No. E2017LAM0A0R

REN-WHLPC

8th Gen Intel Embedded Box System for Renity Air

Quick Reference Guide

1st Ed –03 March 2021

REN-WHLPC

2 REN-WHLPC Quick Reference Guide

FCC Statement

THIS DEVICE COMPLIES WITH PART 15 FCC RULES. OPERATION IS

SUBJECT TO THE FOLLOWING TWO CONDITIONS:

(1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE.

(2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED INCLUDING

INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.

THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO COMPLY WITH THE LIMITS

FOR A CLASS "B" DIGITAL DEVICE, PURSUANT TO PART 15 OF THE FCC RULES.

THESE LIMITS ARE DESIGNED TO PROVIDE REASONABLE PROTECTION AGAINST

HARMFUL INTERFERENCE WHEN THE EQUIPMENT IS OPERATED IN A

COMMERCIAL ENVIRONMENT. THIS EQUIPMENT GENERATES, USES, AND CAN

RADIATE RADIO FREQUENCY ENERGY AND, IF NOT INSTATLLED AND USED IN

ACCORDANCE WITH THE INSTRUCTION MANUAL, MAY CAUSE HARMFUL

INTERFERENCE TO RADIO COMMUNICATIONS.

OPERATION OF THIS EQUIPMENT IN A RESIDENTIAL AREA IS LIKELY TO CAUSE

HARMFUL INTERFERENCE IN WHICH CASE THE USER WILL BE REQUIRED TO

CORRECT THE INTERFERENCE AT HIS OWN EXPENSE.

A Message to the Customer

Avalue Customer Services

Each and every Avalue’s product is built to the most exacting specifications to ensure

reliable performance in the harsh and demanding conditions typical of industrial

environments. Whether your new Avalue device is destined for the laboratory or the factory

floor, you can be assured that your product will provide the reliability and ease of operation

for which the name Avalue has come to be known.

Your satisfaction is our primary concern. Here is a guide to Avalue’s customer services. To

ensure you get the full benefit of our services, please follow the instructions below carefully.

Technical Support

We want you to get the maximum performance from your products. So if you run into

technical difficulties, we are here to help. For the most frequently asked questions, you can

easily find answers in your product documentation. These answers are normally a lot more

detailed than the ones we can give over the phone. So please consult the user’s manual

first.

To receive the latest version of the user’s manual; please visit our Web site at:

http://www.avalue.com.tw/

Quick Reference Guide

REN-WHLPC Quick Reference Guide

Content

1. Getting Started ........................................................................................................4

1.1 Safety Precautions....................................................................................................4

1.2 Packing List...............................................................................................................4

1.3 System Specifications...............................................................................................5

1.4 System Overview......................................................................................................7

1.4.1 Top View.................................................................................................................................. 7

1.4.2 Side View................................................................................................................................. 7

1.5 System Dimensions ..................................................................................................9

2. Hardware Configuration .......................................................................................10

2.1 Installing Light Bar...................................................................................................11

2.2 Installing Power Cord..............................................................................................13

2.3 Installing Touch Monitor (Factory Option)...............................................................14

REN-WHLPC

4 REN-WHLPC Quick Reference Guide

1. Getting Started

1.1 Safety Precautions

Warning!

Always completely disconnect the power cord from your

chassis whenever you work with the hardware. Do not make

connections while the power is on. Sensitive electronic

components can be damaged by sudden power surges.

Only experienced electronics personnel should open the PC

chassis.

Caution!

Always ground yourself to remove any static charge before

touching the CPU card. Modern electronic devices are very

sensitive to static electric charges. As a safety precaution,

use a grounding wrist strap at all times. Place all electronic

components in a static-dissipative surface or static-shielded

bag when they are not in the chassis.

Risk of Explosion if Battery is replaced by an Incorrect Type.

Dispose of Used Batteries According to the Instructions.

Français:

Attention!

Débranchez le câble d'alimentation de votre châssis chaque

fois que vous travaillez avec le matériel. Ne faites pas de

connexion lorsque le système est allumé. Les composants

électroniques sensibles peuvent être endommagés par les

surtensions soudaines. Seule les personnels expérimentés

de l'électronique peuvent ouvrir le châssis du PC.

Précaution!

Il faut toujours mettre à la masse pour éliminer l’électricité

statique avant de toucher la carte CPU. Les appareils

électroniques modernes sont très sensibles aux électricité

statique. Pour des raisons de sécurité, utilisez un bracelet

électrostatique. Placez tous les composants électroniques

sur une surface antistatique ou dans un sac antistatique

quand ils ne sont pas dans le châssis.

Risque d'explosion si la batterie est remplacée par un type

incorrect. Jetez les piles usagées selon les instructions

1.2 Packing List

1 x REN-WHLPC Intel® Core® Soc Processor Box PC

1 set of Screw kit/Power Cord/Light Bar/Printer Bracket

2 sets of HDMI cable, USB cable and DC-in plug pre-install in BOX PC

Quick Reference Guide

REN-WHLPC Quick Reference Guide

1.3 System Specifications

System

Mother Board

ECM-WHL SBC

CPU

Intel® Core™ i7-8665U Processor (8M Cache, up to 4.80 GHz)

CPU Cooler (Type)

CPU Cooler

Memory

8GB DDR4 2400Mhz

Power Supply

150W/12V

Audio

Realtek ALC892/ALC888S

Camera

FHD 5MP Auto-Focus Web Camera

Operating System

Win10

Expansion Card

1-M.2 Key-B (2242/3042), 1-M.2 Key-E

Storage

Solid State Drive

M.2 SSD

External I/O

Serial Port

4-RS232

USB Port

4-USB3.1 (Gen2,10Gbps), 5-USB2.0

HDMI Port

2-HDMI

Audio Port

1-Mic-in, 1-Line-out

LAN Port

2-RJ45

Power Switch

1-Power on/off button

Light Power Switch

1-Light on/off button

Power Connector

Type

AC Inlet

LED Light Bar

CCT

5700K (±10%)

CRI

>70

Beam Angle

120。

Luminous Flux

500 (lm)

Mechanical

Power Type

100~240 VAC ± 10%, 50~60Hz

Dimension

285*368*280mm (11.22*14.49*11.02)

Weight

4.5kg

Color

White

OS Support

Win10

Note: Specifications are subject to change without notice.

REN-WHLPC

6 REN-WHLPC Quick Reference Guide

Suggested Specification for Factory Option items

1.) Touch monitor：Please note the specification is must.

Screen Diagonal

18.5 Inch

15.6 Inch

Resolution

1920x1080 (FHD)

1366x768 (HD)

Contrast Ratio

1000:1

500:1

Touch Type

PCAP

Brightness

500nits Above

300nits Above

Display Input

HDMI

Power Input

12VDC

Weight (Net)

2.94KG (≦3KG)

3.3KG (≦3.5KG)

2.) Touch monitor ARM：

Providing 2 mounting space in coordination with VESA standard:75mm x

75mm and 100mm x100mm.

Bearing weight should more than 4KG.

The angle of view should be designed adjustable for clear vision.

Drawing Demonstration:

Quick Reference Guide

REN-WHLPC Quick Reference Guide

1.4 System Overview

1.4.1 Top View

1.4.2 Side View

Connectors

Label

Function

Note

Light Bar Power Switch

Light on/off switch

AC Inlet

For AC power cord

REN-WHLPC

8 REN-WHLPC Quick Reference Guide

Power Button

Power on/off button

USB 2.0

USB 2.0 connector

Quick Reference Guide

REN-WHLPC Quick Reference Guide

1.5 System Dimensions

(Unit: mm)

REN-WHLPC

10 REN-WHLPC Quick Reference Guide

2.Hardware

Configuration

For advanced information, please refer to:

1- ECM-WHL User’s Manual

Note: If you need more information, please visit our website:

http://www.avalue.com.tw
