Avalue Technology EMS-CDV Manuel utilisateur

Part No. E20178201A0R

EMS-CDV

Fanless Intel® Atom™ D2550 Rugged Embedded

System with Intel® NM10 Express Chipset

Quick Reference Guide

1st Ed –27 November 2012

This datasheet has been downloaded fromhttp://www.digchip.com at this page

EMS-CDV

2 EMS-CDV Quick Reference Guide

FCC Statement

THIS DEVICE COMPLIES WITH PART 15 FCC RULES. OPERATION IS

SUBJECT TO THE FOLLOWING TWO CONDITIONS:

(1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE.

(2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED INCLUDING

INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.

THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO COMPLY WITH THE LIMITS

FOR A CLASS "A" DIGITAL DEVICE, PURSUANT TO PART 15 OF THE FCC RULES.

THESE LIMITS ARE DESIGNED TO PROVIDE REASONABLE PROTECTION AGAINST

HARMFUL INTERFERENCE WHEN THE EQUIPMENT IS OPERATED IN A

COMMERCIAL ENVIRONMENT. THIS EQUIPMENT GENERATES, USES, AND CAN

RADIATE RADIO FREQUENCY ENERGY AND, IF NOT INSTALLED AND USED IN

ACCORDANCE WITH THE INSTRUCTION MANUAL, MAY CAUSE HARMFUL

INTERFERENCE TO RADIO COMMUNICATIONS.

OPERATION OF THIS EQUIPMENT IN A RESIDENTIAL AREA IS LIKELY TO CAUSE

HARMFUL INTERFERENCE IN WHICH CASE THE USER WILL BE REQUIRED TO

CORRECT THE INTERFERENCE AT HIS OWN EXPENSE.

No part of this document may be reproduced, copied, translated, or transmitted in any form

or by any means, electronic or mechanical, for any purpose, without the prior written

permission of the original manufacturer.

Disclaimer

Avalue Technology Inc. reserves the right to make changes, without notice, to any product,

including circuits and/or software described or contained in this manual in order to improve

design and/or performance. Avalue Technology assumes no responsibility or liability for the

use of the described product(s), conveys no license or title under any patent, copyright, or

masks work rights to these products, and makes no representations or warranties that

these products are free from patent, copyright, or mask work right infringement, unless

otherwise specified. Applications that are described in this manual are for illustration

purposes only. Avalue Technology Inc. makes no representation or warranty that such

application will be suitable for the specified use without further testing or modification.

Quick Reference Guide

EMS-CDV Quick Reference Guide

1. Getting Started

1.1 Safety Precautions

Warning!

Always completely disconnect the power cord from your

chassis whenever you work with the hardware. Do not

make connections while the power is on. Sensitive

electronic components can be damaged by sudden power

surges. Only experienced electronics personnel should

open the PC chassis.

Caution!

Always ground yourself to remove any static charge before

touching the CPU card. Modern electronic devices are very

sensitive to static electric charges. As a safety precaution,

use a grounding wrist strap at all times. Place all electronic

components in a static-dissipative surface or static-shielded

bag when they are not in the chassis.

1.2 Packing List

1 x EMS-CDV Fanless Intel® Atom™ D2550 Rugged Embedded

System with Intel® NM10 Express Chipset

1 x Quick Reference Guide

1 x DVD-ROM contains the followings:

—User’s Manual (this manual in PDF file)

—Ethernet driver and utilities

—VGA drivers and utilities

—Audio drivers and utilities

Other major components include the followings:

—44 Pin Multi I/O Cable

—Wall Mount Kit

—Adapter

—Power Cord

EMS-CDV

4 EMS-CDV Quick Reference Guide

1.3 System Specifications

System

CPU

Intel® D2550 1.86GHz CPU

BIOS

AMI uEFI BIOS, 16Mbit SPI Flash ROM

System Chipset

Intel NM10

I/O Chip

Nuvoton W83627DHG-P

System Memory

1 x 204-pin SODIMM Up to 4GB DDR3 1066 SDRAM

Stroage

Front Access Swappable 2.5” Drive Bay and mSATA on 2nd Mini

PCIe Socket

Watchdog Timer

Reset: 1sec. ~ 65535sec./min. and 1sec. or 1min./step

H/W Status

Monitor

Monitoring System Temperature and Voltage with Auto Throtting

Control

TPM

Nuvoton NPCT420AA0WX

Bettery

Horziontal battery socket for CR-2032

Expansion

MI/Oe interface(1 x DP, 4 x PCIex1, 3 x USB, 1 x LPC, 1 x

Line-Out(R/L), 1 x SMBus)

2 x mini-PCIe

External I/O

Front Side External I/O

Connector

1 x Swappable 2.5” Drive Bay and SIM Card

1 x USB 2.0

1 x Power on/off Button with LED indicator

1 x Reset button

1 x Green LED for Data Access Indication

1 x Green LED for LAN Active

1 x Dual Color LED for LAN Speed/Link Indication

Rear Side External I/O

Connector

1 x Lockable Jack for DC Power Input

1 x VGA

1 x COM1 supports RS-232/422/485 selected by BIOS

1 x RJ45 for GbE

2 x USB 2.0

1 x Multi-Function Port for the following I/Os:

COM2 supports RS-232/422/485 selected by BIOS

PS/2 for KB and MS

SMBus

12-Bit GPIO

Line-In, Line-Out, Mic-In

2 x Knockouts for Antenna Mounting

PCIe Switch

Quick Reference Guide

EMS-CDV Quick Reference Guide

Chipset

IDT IDT89HPES5T5ZBBCG PCIe switch

Interface

5-Port/5-lane(for MI/Oe)

Display

Chipset

Cedarview integrated

Resolution

VGA: 1920x1200

Ethernet

Chipset

1 x Intel 82574L GbE controller

Ethernet Interface

10/100/1000 Base-Tx GbE compatible

Audio

Chipset

Realtek ALC892 HD codec

Audio Interface

Mic-In, Line-Inand Line-Out

Mechanical & Environmental

Power Requirement

+12 ~ +28Vdc

ACPI

Single Power ATX Support S0, S3, S4, S5

ACPI 3.0 Compliant

Power Mode

AT/ATX (ATX is The Default Setting)

Operating Temp.

-10°C ~ 60°C (w/ mSATA and 2.5”SSD), Ambient w/ Air Flow

Storage Temp.

-40°C ~ 75°C (-40 ~ 167°F)

Relative Humidity

0% ~ 90% Relative Humidity, Non-condensing

Vibration Protection

With mSATA/ SSD : 5Grms, IEC 60068-2-64, Random, 10 ~ 500Hz,

1hr/axis

Shock Protection

With mSATA/ SDD : 50G, IEC 60068-2-27, Half Sine, 11ms

Certification

CE, FCC Class B

Dimension (W x H x D)

240mm x 170mm x 45mm

Weight

4.4 lbs (2 Kgs)

EMS-CDV

6 EMS-CDV Quick Reference Guide

1.4 System Overview

1.4.1 Front & Top View

EMS-CDV-255-A1-1R

Quick Reference Guide

EMS-CDV Quick Reference Guide

EMS-CDV-255-A1-2R/3R

1.4.2 Front View

EMS-CDV

8 EMS-CDV Quick Reference Guide

1.4.3 Rear View

EMS-CDV-255-A1-1R

EMS-CDV-255-A1-2R

EMS-CDV-255-A1-3R

Quick Reference Guide

EMS-CDV Quick Reference Guide

EMS-CDV-255-A1-1R

Connectors

Label

Function

Note

COM1

Serial port connector 1

DC-IN

DC power-in connector

LAN1

RJ-45 Ethernet 1

Multi-function port

Multi-Function Port combined COM2,

2 PS/2, Audio, GPIO and SMBus

USB1~3

USB connector 1~3

VGA

VGA connector

Swappable Drawer

2.5” Driver Bay and SIM Card

EMS-CDV-255-A1-2R

Connectors

Label

Function

Note

COM1

Serial port connector 1

COM3~6

Serial port connector3~6

DC-IN

DC power-in connector

LAN1

RJ-45 Ethernet 1

Multi-function port

Multi-Function Port combined COM2,

2 PS/2, Audio, GPIO and SMBus

USB1~5

USB connector 1~5

VGA

VGA connector

Swappable Drawer

2.5” Driver Bay and SIM Card

EMS-CDV-255-A1-3R

Connectors

Label

Function

Note

COM1

Serial port connector1

DC-IN

DC power-in connector

LAN1~5

RJ-45 Ethernet 1~5

Multi-function port

Multi-Function Port combined COM2,

2 PS/2, Audio, GPIO and SMBus

USB1~5

USB connector 1~5

VGA

VGA connector

Swappable Drawer

2.5” Driver Bay and SIM Card

EMS-CDV

10 EMS-CDV Quick Reference Guide

2.Hardware

Configuration

Jumper and Connector Setting, Driver and BIOS Installing

For advanced information, please refer to:

1- EBM-CDVS, AUX-M01 and AUX-M02 included in this manual.

Note: If you need more information, please visit our website:

http://www.avalue.com.tw
