Autonics TK4S Manuel utilisateur

User Manual

Preface

Thank you for purchasing an Autonics product.

Please familiarize yourself with the information contained in the Safety Precautions

section before using this product.

This user manual contains information about the product and its proper use, and should

be kept in a place where it will be easy to access.

User Manual Guide

iv © Copyright Reserved Autonics Co., Ltd.

User Manual Guide

This user manual contains information about the product and its proper use, it should be

kept in a place where it will be easy to access.

Please familiarize yourself with the information in this manual before using the

product.

This manual provides detailed information on the product's features. It does not offer

any guarantee concerning matters beyond the scope of this manual.

This manual may not be edited or reproduced in either part or whole without

permission.

A user manual is not provided as part of the product package.

Please visit www.autonics.com to download a copy.

The manual's content may vary depending on changes to the product's software and

other unforeseen developments within Autonics, therefore, the contents of this

manual is subject to change without prior notice.

User Manual Symbols

Symbol Description

Supplementary information for a particular feature.

Failure to follow instructions can result in serious injury or death.

Failure to follow instructions can lead to a minor injury or product damage.

An example of the concerned feature's use.

※1 Annotation mark.

Safety Precautions

vi © Copyright Reserved Autonics Co., Ltd.

Safety Precautions

Following these safety precautions will ensure the safe and proper use of the product

and help prevent accidents, as well as minimizing possible hazards.

Safety precautions are categorized as Warnings and Cautions, as defined below:

Warning Failure to follow the instructions may lead to a serious injury

or accident.

Caution Failure to follow the instructions may lead to a minor injury

or accident.

If using the product to control machines or devices having serious impact potential on

lives and/or property (applications in nuclear power plants, medical equipment,

vehicles, trains, aviations, combustion systems, entertainment devices, safety devices,

etc.), Always use in conjunction with redundant failsafe systems in place.

It may cause fire, personal injury, and/or property loss if not followed.

Always install the unit on a panel.

It may cause an electric shock if not followed.

Never wire, repair, or inspect the unit while electricity is flowing through it.

It may cause an electric shock if not followed.

Check the input power specifications and terminal polarity before connecting the

wires.

It may cause a fire if not followed.

Only an Autonics technician is authorized to service or modify the product.

It may cause an electric shock or fire if not followed.

Do not use outdoors.

It may shorten the life of the product and/or cause an electric shock if not followed.

Always use AWG 20 (0.5 mm2) or higher when wiring to the relay's output terminals.

It may pose a fire risk if not followed.

Always use within the range of rated specifications and performance.

Safety Precautions

It may shorten the lifespan of the product and/or pose a fire risk if not followed.

Do not allow loads in excess of the rated switching capacity on relay contacts.

It may damage the insulation, relay contacts and/or cause a fire or faulty connection if

not followed.

Do not use water or an oil-based solvent to clean the product. Use a dry towel instead.

It may pose an electric shock or fire risk if not followed.

Do not use the product in a place where it is exposed to flammable or explosive

gases, humidity, direct light, radiant heat, vibration, or impact.

It may pose a fire or an explosion risk if not followed.

Do not allow dust or wiring fragments to get inside the product.

It may pose a fire or a malfunction risk if not followed.

Check the terminal's polarity first to properly wire the temperature sensor.

It may pose a fire or an explosion risk if not followed.

◈Handling Precautions

These handling precautions address issues that can potentially cause the product to

malfunction.

Power & Usage Environment

Use the rated power only.

Maintain the controller's ambient temperature between -10℃ and 50℃.

Turn the power on and allow the temperature controller to warm-up for twenty

minutes before use.

A power switch or a circuit-breaker is necessary to supply and cut off power to the

product.

Install the switch or circuit-breaker in the vicinity of the product to facilitate easy

access.

Use the product in a well-ventilated environment. Otherwise, arrange for ventilation if

necessary.

Recommended usage conditions are as follows:

Indoors

Under 2,000 m altitude

Safety Precautions

viii © Copyright Reserved Autonics Co., Ltd.

Pollution Degree 2

Installation Category II

Sensor Input

If using in an environment where the margin of sensor error cannot be avoided, use

the Input Bias feature to minimize the error margin.

If using a thermocouple sensor, make sure to use prescribed compensation wire as

extension wire. Failure to do so will produce temperature distortion at the junction

between the thermocouple and the extension wire.

If using a resistance temperature detector (RTD) sensor, always make connection

with three-wire configuration. In addition, only use three wires of identical material,

thickness and length if you need to extend the line. Variance in wire resistance will

lead to temperature distortion.

When changing an input sensor, first disconnect power to the product and then

connect the new sensor. Restore power to the product and update the related

parameters either directly from the product or using the PC loader program.

Always use a line filter on the controller's power line. Also, use shielded wire for the

input signal line, provided it is necessary the power line and the input signal line must

remain close to one another.

Noise Effect

Isolate the product's wiring from high-voltage lines and power lines to prevent impulse

noise.

Avoid using the product in the vicinity of high-frequency noise generating devices.

Such as: welding machines, sewing machines, high-capacity SCR controllers, and

high-capacity motors.

Avoid using the product in the vicinity of radio, television, and wireless devices that

may cause high-frequency interference.

Communication

Only use twisted pair wires for the communication lines. Attach round ferrules at the

ends of the lines to reduce the impact of external noise.

Do not have the communication lines in close proximity to the AC power line.

If possible, use a separate power source (24 VDC) for the communication converter

(SCM-38I, sold separately).

Table of Contents

Preface .............................................................................................................................iii

User Manual Guide ......................................................................................................... iv

User Manual Symbols ...................................................................................................... v

Safety Precautions .......................................................................................................... vi

Table of Contents ............................................................................................................ ix

1Product Introduction.................................................................................13

1.1 Features.............................................................................................................13

1.2 Components and Accessories ...........................................................................14

1.3 Model Lineup .....................................................................................................17

1.4 Parts and Features: Displays and Controls.......................................................18

2Specifications............................................................................................21

2.1 Ratings...............................................................................................................21

2.2 Input Type ..........................................................................................................23

3Dimensions................................................................................................25

3.1 Installation..........................................................................................................27

4Wiring Diagrams .......................................................................................30

4.1 TK4S-Series.......................................................................................................30

4.2 TK4SP-Series ....................................................................................................30

4.3 TK4M-Series......................................................................................................31

4.4 TK4W, TK4H, TK4L-Series................................................................................31

4.5 Wiring Precautions.............................................................................................32

4.5.1 Sensor Connection..................................................................................... 32

4.5.2 Communication Line Wiring ....................................................................... 33

5Preparation and Startup ...........................................................................34

5.1 Powering On and Initial Display.........................................................................34

5.2 Input Selection Switch .......................................................................................34

5.3 Basic Controls....................................................................................................35

5.3.1 Parameter Setting Sequence ..................................................................... 35

5.3.2 SV Settings................................................................................................. 35

Table of Contents

x © Copyright Reserved Autonics Co., Ltd.

5.3.3 Changing Parameter Settings .................................................................... 36

5.3.4 MV Monitoring and Manual Control Setting ............................................... 36

5.4 Parameter Reference Chart ..............................................................................38

5.5 Parameter Setting Groups.................................................................................40

5.5.1 Parameter 1 Setting Group [PAR1] ............................................................ 40

5.5.2 Parameter 2 Setting Group [PAR2] ............................................................ 41

5.5.3 Parameter 3 Setting Group [PAR3] ............................................................ 43

5.5.4 Parameter 4 Setting Group [PAR4] ............................................................ 45

5.5.5 Parameter 5 Setting Group [PAR5] ............................................................ 47

6Parameter Settings and Functions ..........................................................49

6.1 Input ...................................................................................................................49

6.1.1 Input Types and Temperature Ranges ....................................................... 49

6.1.2 Input Type Settings [PAR3 → IN-T]........................................................... 51

6.1.3 Temperature Unit Settings for Input Temperature Sensor [PAR3 → UNIT]51

6.1.4 Analog Input/Scale Settings ....................................................................... 52

6.1.5 Input Bias Adjustments [PAR3 → IN-B] ..................................................... 54

6.1.6 Input Digital Filter [PAR3 → MAV.F] ............................................................ 54

6.1.7 High and Low-limit of SV (Setting Value) [PAR3 → H-SV/L-SV] ............... 55

6.2 Control Output ...................................................................................................56

6.2.1 Control Output Mode [PAR3 → O-FT] ........................................................ 56

6.2.2 MV High / Low-limit Settings [PAR2 → H-MV / L-MV] ................................. 62

6.2.3 Ramp Settings [PAR2 → RAMU/ RAMD/ rUNT]............................................ 63

6.2.4 Auto/Manual Control Settings .................................................................... 64

6.2.5 Output Settings........................................................................................... 67

6.3 Temperature Control..........................................................................................69

6.3.1 Temperature Control Mode [PAR3 → C-MD]............................................... 69

6.3.2 On/Off Control [PAR3 → C-MD → ONOF] .................................................... 70

6.3.3 PID Control [PAR3 → C-MD → PID]........................................................... 71

6.3.4 Auto-tuning ................................................................................................. 75

6.4 Alarm Output......................................................................................................77

6.4.1 Alarm Output Mode [PAR4 → AL-1/AL-2] ................................................. 77

6.4.2 Alarm Output Options [PAR4 → AL!T/AL@T]............................................. 79

6.4.3 Alarm SV Settings [PAR1 → AL!L/AL!H/AL@L/AL@H] .............................. 80

6.4.4 Alarm Output Hysteresis [PAR4 → A!HY/A@HY] ........................................ 80

6.4.5 Alarm Output Mode Selection [PAR4 → A!N/A@N]..................................... 81

6.4.6 Alarm Output Delay Settings [PAR4 → A!ON / A!OF/ A@ON / A@OF] ......... 81

6.4.7 Loop Break Alarm [PAR4 → AL-1/AL-2 → LBA] ....................................... 83

6.4.8 Sensor Break Alarm [PAR4 → AL-1/AL-2 → SBA].................................... 85

6.4.9 Heater Burnout Alarm [PAR4 → AL-1/AL-2 → HBA] ................................. 85

6.4.10 Alarm Output Deactivation [PAR5 → DI-K→ AL.RE] ................................. 87

6.4.11 Alarm Output Examples ............................................................................. 88

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Autonics Régulateurs de température

Autonics

Autonics TK Series Manuel utilisateur

Autonics

Autonics TX4S Series Manuel utilisateur

Autonics

Autonics KPN Series Manuel d'utilisation et d'entretien

Autonics

Autonics TK Series Manuel utilisateur

Autonics

Autonics TS4M Manuel utilisateur

Autonics

Autonics TS4 Series Manuel utilisateur

Autonics

Autonics TH4M Series Manuel utilisateur

Autonics

Autonics TK4N Manuel utilisateur

Autonics

Autonics TZ4H Series Manuel utilisateur

Autonics

Autonics TK Series Manuel d'utilisation et d'entretien

Autonics

Autonics TN Series Manuel utilisateur

Autonics

Autonics TM Series Manuel d'utilisation et d'entretien

Autonics

Autonics TC Series Manuel utilisateur

Autonics

Autonics TK4N Manuel utilisateur

Autonics

Autonics T3 Series Manuel utilisateur

Autonics

Autonics TX Series Manuel d'utilisation et d'entretien

Autonics

Autonics TN Series Manuel utilisateur

Autonics

Autonics TM Series Manuel utilisateur

Autonics

Autonics TMH Series Manuel utilisateur

Autonics

Autonics TC Series Manuel utilisateur

Autonics

Autonics TM Series Manuel utilisateur

Autonics

Autonics TCN4S Series Manuel utilisateur

Autonics

Autonics TC3YF Series Manuel utilisateur

Autonics

Autonics TZN4M Manuel utilisateur

Manuels Régulateurs de température populaires d'autres marques

Swegon

Swegon LUNAd MB Manuel utilisateur

Lucky Reptile

Lucky Reptile Thermo Control II Manuel utilisateur

SENSORMETRIX

SENSORMETRIX Argon 100 Manuel utilisateur

Fuji Electric

Fuji Electric PXE4 Manuel utilisateur

Yuyao gongyi

Yuyao gongyi XMT-808 series Manuel utilisateur

Selec

Selec TC544C Manuel utilisateur

P.W. KEY

P.W. KEY rt-208gt Manuel utilisateur

Future Design

Future Design FDC-9200 Manuel utilisateur

BH Thermal

BH Thermal BriskONE Manuel utilisateur

Omron

Omron E5EX-H Manuel utilisateur

West Control Solutions

West Control Solutions KS 45 Guide de démarrage rapide

MCS

MCS RITC-15B Manuel utilisateur

SMC Networks

SMC Networks Thermo-con INR-244-639 Manuel utilisateur

eltherm

eltherm Ex-TC It Series Manuel utilisateur

Omron

Omron C200H-TV Series Manuel utilisateur

industrie technik

industrie technik CA1 Manuel utilisateur

KRAL

KRAL EET 32 Manuel utilisateur

dixell

dixell XR420C Schéma de câblage
