Audiovox D1917ES Manuel utilisateur

D1917ES

PORTABLE 9" LCD MONITOR, DVD PLAYER AND

EXTRAMONITOR

AnLCDpanel and/or videomonitor maybeinstalled in amotor

vehicle and visible to thedriver iftheLCDpanelor video monitor

is used for vehicle information, system control, rear or side

observationor navigation. Ifthe LCD panelorvideomonitoris

used fortelevision reception, video or DVD play, theLCDpanel or

video monitor must be installed sothat these featureswill only

function when the vehicleisin park”or when the vehicle’spark-

ing brake isapplied.

AnLCD panel orvideomonitor usedfor television reception, video

or DVD playthat operates when the vehicleisingear or when the

parkingbrake is notappliedmust be installedto therearof the

driver’sseat where it willnot bevisible, directly or indirectly, to the

operatorof themotor vehicle.

Notice:

This Product incorporatescopyrightprotectiontechnologythatis

protectedby methodclaims of certainU.S. Patents andotherintel-

lectual propertyrightsownedbyMacrovisionCorporation and other

rights owners. Use of this copyrightprotection technologymust be

authorizedby Macrovision Corporation, andis intendedforhome

andother limitedviewing uses only unlessotherwise authorizedby

MacrovisionCorporation. Reverseengineering ordisassembly is

prohibited.

Content

A.Introduction............................................................................ 4

B.Cautionsand Warnings........................................................ 4

C.Contents ............................................................................... 6

D.PoweringandInstallation ..................................................... 6

E.Vehicle Installation.....................................................8

F.Controls,Indicatorsand Connectors................................... 10

G. Loadingand PlayingaDisc ................................................. 12

H.BasicOperation......................................................................13

I. Menu .................................................................... 14

J.Display...................................................................................14

K.PlayingAudio CDS................................................................ 17

L. Playing MP3 Discs ..........................................................18

M.ConnectingtoOtherElectronicEquipment.........................20

N.PlayingJPEGFiles........................................................... .21

O.Connecting the Monitorto aGame orCamcorder.............. 22

P.Setup....................................................................................23

Q. Specifications ...................................................................... 26

R.Rechargeable BatteryInstallation andUse ......................... 26

S. Troubleshooting ................................................................. 29

A.Introduction

Thankyoufor choosing the D1917ESportableDVD playerand extra

monitor.Themain features include two 9" DigitalScreen(16:9 As-

pect Ratio) Liquid Crystal Display (LCD) monitors and aDVDplayer.

The unitalso containsa3in 1cardreaderand aUSB port. The unitis

designed forusewithSD/MMC,MSmemory cardsand USB memory

devices.The unit appliesthelatest state of theart electronics and is

designed foruse inhotels, officesor your home. The unitiscon-

structedto provide years ofreliable, trouble-free service and is com-

pactsothatyoucantakeit with you anywhereandis designedfor

quickandeasy installation.Please readtheentire instructionmanual

supplied with thisproduct prior to using. The documentation will as-

sist you inusing the system properly to obtainthe best equipment

performance. Please save this manual for lateruse.

B. Cautions and Warnings

1. Placement

Toprevent fireor electric shock, donot expose this unit to rainor

moisture. Keep the unit away from strong magnets, heat sources,

directsunlight, excessivedust. Ifthe unitis brought directly from a

coldto a warmlocation,moisture maycondense inside the unit.

When you move the unit fromacold toawarm location, waitfor

about one hour before operating the unit, or remove the disc and

leavethe unitturned on until themoistureevaporates.

2. Installation

Ensurethatthe 9”portableDVD player andextramonitorareused

inaccordancewith theinstructionsandillustrationsprovidedinthis

manual.

3. Caution

Donotpushobjectsof anykindintothe unitthroughopenings;do

not spill or sprayliquid ofanykind on or in the unit (thismay

result in a fireor electricshock). Donot place anything heavyon

the unit. To ensure proper ventilation and proper operation, never

coverorblocktheslotsandopenings withaclothorothermaterial.

Keep theunit away fromanopenflamesuch as fire, candle etc.

Replacing the batteryincorrectly ishazardous. Replacethe bat-

teryonly with the same or equivalent type. In ordertoprotect the

environment, pleasedispose the batteryproperly. Do notuse the

unit intemperatures higher than95 degrees Fahrenheit or35 de-

grees Celsius.

4.Disassembly

Do not attempt to disassemble the unit’scase. There is a risk of

electric shock and/orexposure toLaser Radiation.Contact quali-

fied service personnel if your system needs repair.

5.Cleaning Unit

Whencleaning,makesurethesystem isunplugged fromthepower

source. Donotuseliquid cleaners or aerosolcleaners. Usea cloth

lightly dampenedwith waterfor cleaningtheexterior ofthe system

only.

6. Disc

Do not use irregularlyshaped discs such asheart orstar-shaped

discs as theymay cause the unittomalfunction.Donotstickpaper,

tapeor glue on the disc. Do not expose thedisc to direct sunlight

or heat sources. Do not touchthe surface ofdisc. Handle thedisc

by itsedge. Cleanthedisc bywipingthedisc from the center out

with a clean cloth. Remove the disc from the unit and store it in its

case after playing. Some playback operations ofdiscsmaybe in-

tentionallyfixed by software producers. Since this unit plays discs

according to the disc contentsthesoftwareproducers designed,

some playbackfeatures maynot be available. Also referto the

instructionssuppliedwiththediscs.

7.RegionalCoding

Both theDVDplayer and disc are coded by region. These

regional codes must match inorder for thedisc toplay.Ifthe

codesdon’t match, the disc won’t play. This unit’s code is region

1. DVD’s with other regional codes cannot be played in thisunit

C. Contents

1. 1 x 9’’ LCDMonitor and DVDPlayer

2. 1x 9’’ LCDMonitor

3. 1 xRemote Control with battery(CR2025)

4. 1 x Audio/VideoAdapter Cable(One to ThreeFemale)

5. 1x Audio/VideoAdapter Cable(Oneto ThreeMale)

6. 1 xAC to DCAdapter

7. 1 x Y Type DC Power Adapter

8. 1x Instruction Manual

9. 1 xRechargeable Battery

10.1x Mounting BagWith Straps for theMonitor

11.1 xCarryBagWith Straps

D. Powering and Installation

1. Powering the system indoors (Refer to Figure 1)

Plug one end of theAC to DC adapterinto the DCinputjackon the

left side ofthe mainunit, then plugthe otherend intothe 110~240V

AC power receptacle.

Figure1

SingleMonitorMain Unit

Note: Unplugthe the unit from its power source and remove the

rechargeablebatteryif theunitis not goingto be used for a long

time.

2. Powering the system in a car (Refer to Figure 2)

Plugone end of the DC Power adapter into the DC input jackon

theunit, thenplugthe other endinto the vehicle power outlet.

Main Unit

RightSide

Monitor

Monitor Main Unit

Figure2

E. Vehicle Installation

Installing the DVD Player and monitor onto a car seat

(Refer to Figures 3 through 5)

1).Unfoldthe carrybagand place theDVDplayer onthebag

beneaththe elastic straps. Ensurethat the unit scornersare

secured bythe elasticstraps.

2).Securetheupper portion of the carry bag toheadrest support

barsusingthe headreststrap.Adjust the headreststrap untilthe

bag isfirmly secured.

3). Securethelowerportionofthecarry bagto the vehicleseat back

using the seatback strap.Adjust the seat back strap until the

bag isfirmly secured.

Figure3

Elastic

Straps

CarryBagClosed

VehicleSeat

Back

VehicleHeadrest

CarryBagOpened

Headrest

Strap

Seat Back

Strap

Installing the monitor

Option 1 Vehicle Headrest (Refer to Figure 4)

Figure4

Slidethe Monitor intothe pouch and attach theVelcro strapsto se-

cure the Monitorinthe pouch.Loopthe strap ofthe poucharoundthe

headrest andpullthe endofthe strapwhileholdingthe buckleto

secure the pouch to the headrest

Option 2 Flat Surface (Refer to Figure 5)

Figure5

Rotate the base of Monitor backwardandplace onaflat surface.

Adjust thescreen for a proper viewingangle. Thiscanbedonewith

the Monitor insideor outside the pouch.

F. Controls, Indicators and Connectors

1. LCD MonitorandDVD Player (Referto Figure6)

Figure 6

11) Charge Indicator

12)Headphone Jack 1*

13)HeadphoneJack 2

14) Volume Up/DownControl

15) Brightness Up/Down Control

16)LCD Panel Shut Off Switch

17) Wide Button

18) Previous/Next/Pause/Stop/Play

19)MenuButton

20) Up/Down/Left/Right/OK Button

78910

1) Battery Release Button

2) DC 9V InputJack

3)AVJack

4)AVIn/Out Switch

5) USB Port

6)Power ON/OFF Switch

7) SD/MMC/MSCard Slot

8)Power LED

9)Remote Control Sensor

10) Cover Open Switch

* Connectingto headphone jacknumber 1 will disable the

internal speakers
