Audiovox VOD1022 Manuel utilisateur

128-7094

1 of 31

VOD705

ELECTRONICS CORP.

VOD1022

DVD PLAYER

WITH

DROP-DOWN

VIDEO

TV/MONITOR

128-7094

ReleaseDate6/28/04

128-7094

2 of 31

-2-

Warnings

Donotuseanysolventsorcleaningmaterialswhencleaningthevideomonitor.Useonlyalightlydampenedlintfreeclothtowipe

the screen if it is dirty. Lock the LCD screen in the fully closed position when not in use.

Rememberto leave thedome light switchin the offor auto positionswhen the vehicleis unattended, asthe dome lights,if left on,

candrainthe vehicle’s battery. Television Reception

Thisentertainmentsystemisdesignedprimarilyforviewingprerecordedmoviesorplayingvideogames. Televisionreceptionina

movingvehiclewillbelimitedandinsomeareaswillnotbepossibleduetoweakandvariablesignalstrength. Televisionviewingin

astationary vehicle will resultinanimprovement,butmaystillbe marginal due tosignalstrength. Thequalityofthepicturewillnot

be consistent with home TV reception. Reception may be affected by weather and distance fromTV station. Aweak signal may

cause the picture to roll, be snowy, or cause some color loss.

Licensedunder one ormore of the followingpatents,

PatentNOS. 5,775,762 and5,927,784

Important Notice

AnLCDpaneland/orvideomonitormaybeinstalledina motorvehicleandvisibletothedriveriftheLCDpanelorvideo monitoris

used for vehicle information, system control, rear or side observation or navigation. If the LCD panel or video monitor is used for

television reception, video or DVD play, the LCD panel or video monitor must be installed so that these features will only function

whenthevehicle is in“park” orwhenthe vehicle’s parking brakeisapplied.

AnLCDpanel or videomonitor usedfortelevisionreception, video orDVD playthatoperateswhen the vehicleis ingearorwhen

theparkingbrakeisnotappliedmustbeinstalledtotherearofthedriver’sseatwhereitwillnotbevisible,directlyorindirectly,tothe

operatorofthemotorvehicle.Itisunlawfulinmostjurisdictionsforapersontodriveamotorvehiclewhichisequippedwithascreen

that is located in the motor vehicle at any point forward of the back of the driver’s seat, or that is visible, directly or indirectly, to the

driverwhileoperatingthevehicle. Intheinterestofsafety,theVOD1022shouldneverbeinstalledwhereitwillbevisible,directlyor

indirectly, bythe operator of the motor vehicle.

128-7094

3 of 31

-3-

Congratulations on your purchase of the Audiovox

VOD1022DVDPlayerwithDrop-DownVideomonitor/

TV. The VOD1022 has been designed to give you

and your family many years of video entertainment in

the mobile environment. Please read the directions

that follow to familiarize yourself with the product and

to ensure that you obtain the best results from your

equipment.

Please note: Installation options vary, see the

individual owner’s manuals for each component in

your system to obtain a full understanding of each

component’s operation.

Safety Precaution

For safety reasons, when changing video media it is

recommended that the vehicle is not in motion, and

that you do not allow children to unfasten seat-belts

to change video media or make any adjustments to

the system. System adjustments can be

accomplished using the remote control unit, while

seat-belts remain fastened. Enjoy your Audiovox

entertainment system but remember-safety of all

passengers remains the number one priority.

Features

••

•10.2” TFT Active Matrix Color LCD Monitor

••

•Built-In DVD Player

••

•DVD/CD/MP3 compatible

••

•On Screen Display

••

•16:9 and 4:3 Screen Mode (switchable)

••

•IR Remote Repeater for AV1 Inputs

••

•Dual IR Sensors

••

•Remote Control

••

•Four Source Selection (DVD/TV/AV1/AUX)

••

•AUX Input for Game or Camcorder

••

•6 Frequency FM Modulator

(Remote Control Accessible)

••

•Dual Headphone Jacks

••

•Built-In TV Tuner

••

•Built-In Dual IR Transmitter

••

•Built-In Dome Lights with Switch

••

•Last position memory for DVD

128-7094

4 of 31

-4-

Controls and Indicators Diagram

128-7094

5 of 31

-5-

Main Function Descriptions

1. DVD Disc insertion slot – For loading Disc.

2. POWER Button – Bright red when system is on dim when

off.

3. EJECT ( ) Button – For ejecting discs from the disc

compartment.

4. PLAY ( ) Button – This button is used to enter the play

mode.

5. STOP ( ) Button – To stop playback.

6. Infrared Transmitter and Sensor – Use to transmit audio

to wireless headphones. Also allows the remote control to

operate the VOD1022 and to control other accessories in

the system.

7. VOD1022 Ventilation Opening.

8. Dome Lights –Provide additional interior illumination.

9. SOURCE Select – Used to select one of the four sources

(TV,AV1,AUX,DVD).

10. CHANNEL ( ) Button –Use this button to decrease the

channel number to the desired number. Note : When TV

function is selected.

11. AUTO PROGRAM Button –Allows the user to scan and

store active TV stations into memory.

12. CHANNEL( )Button – Use this button to increase the

channel number to the desired number. Note : When TV

function is selected.

13. Side Remote Sensor Eye – Allows the remote control to

operatethe VOD1022,control volume towired headphone

jacks and control the other accessories.

14. AUX Input (Use with supplied A/V adapter)

••

•AuxiliaryAudio RightInput.

••

•AuxiliaryAudio LeftInput.

••

•AuxiliaryVideo Input.

15. Drop Down LCD Panel.

16. Headphone Jack – Allow the use of wired headphones

witha 1/8” plug forlistening to video programaudio.

17. Screen release –Movesin direction ofthe arrowto release

thedrop down screen.

18. VOLUME ( ) Button – Use this button to decrease the

volumelevel of the wired headphonejacks. It is also used

to make picture adjustments in the picture select mode.

128-7094

6 of 31

-6-

19. FM Select Button – Each time this button is pressed the

FMModulator will cyclethrough the following options:(FM

OFF – POD AUDIO – SAT AUDIO) The frequency of the

FMmodulator will remain same.

20. VOLUME( )Button –Use thisbutton toraise thevolume

levelof the wiredheadphone jacks. It isalso used tomake

picture adjustments in the picture select mode. Note :

Audiovox recommends the use of the Audiovox HP275

Headphoneswhenusing wiredheadphones.

21. Three position Dome Light Switch

• Auto – Automatically switches on the dome lights in

conjunctionwith the vehicle’s interiorillumination.

• Off – The dome lights will not turn on in this position.

• On – Turns on the dome lights.

Note:Thevolume buttonswillnoteffectthevolumeofthe wireless

headphonesorthe wiredFM modulator. Whenusing these

devices the volume must be adjusted with the wireless

headphonevolumecontrolorwithyourradio’svolumecontrol

(see page 15, Wireless Headphones, or page 16, Wired

FMModulator).

128-7094

7 of 31

-7-

Remote Control Operation

POWER

SOURCE

RETURN

SETUP

PIX

Enter

ERASE/

WRITE

SKIP/

AUTO

MEMORY

VOL

–+

MUTE

REPEAT

23 24

EJECT

Battery Installation

Before attempting to operate your Remote Control, install the

batteriesas described below.

1) Turn the Remote Control face down. Using a fingernail,

liftthe battery cover off.

2) Install two “AAA” batteries as shown. Make sure that

properpolarity (+ or -)is observed.

3) Align the cover tabs with the remote control and press

down until the cover clicks.

Theremote control willoperate the VOD1022and mostAudiovox

VCP’s. It is not a universal remote control and will not control

equipmentfrom othermanufacturers.

128-7094

8 of 31

-8-

Remote Control Function Descriptions

*Function control is available on the unit and the remote control.

1. POWER Button*

Press this button to turn the VOD1022 on. Press the button again to turn the VOD1022 off.

2. SOURCE Button*

Video signals from video equipment connected to the audio / video inputs can be displayed on the monitor by

pressing this button. Each time the button is pressed, the audio / video source will change sources in the

followingorder: DVD, AV1,AV2andAUX.

3. AUTO MEMORY Button (AUTO PROGRAM Button)*

When the AUTO MEMORY button is pressed, all channels are searched and channels that are detected with

signals of sufficent levels are automatically stored.

4. SKIP/SEARCH Button

This button selects betweeen SKIP and SEARCH mode. In “SKIP mode” the TV tuner will tune and stop on

channels that are programmed into memory when the CHANNEL UP/DOWN buttons are used. When in the

SEARCH mode, the TV will stop on all active channels.

5. ERASE/WRITE Button

While tuned to a channel, pressing this button will either store or erase the channel from memory. The stored

channel numbers are displayed in “GREEN” on the LCD display screen, and the erased channel numbers are

displayed in “RED”.

128-7094

9 of 31

-9-

6. Channel Up ( ) Button*

Use this button to increase the channel number to the desired channel and to scroll upward in menu options.

7. MUTE Button

Press this button to mute the audio.

Pressing the button again restores the sound to the previously set level.

8. ENTER Button

Used to confirm a selected setting or option.

9. LEFT ( ) Button

Allows the user to shift left in the menu options.

10. MENU Button

Allows the user to access the DVD (DVD MODE) main menu and monitor menu (TV MODE).

11. RETURN Button

Allows the user to return to the menu while PBC on.

Note:Thisfunction only present onVCD2.0.

12. TV Mode Select Button

Switches certain function keys on the remote control for TV functions.

128-7094

10 of 31

-10-

13. DISPLAY Button

Press to display DVD Disc current information.

Press DISPLAY button DVD Player Perform

Once Display current TITLE & CHAPTER

Twice Display current SUBTITLE

3 times DisplaycurrentAUDIO language& channel

4 times DisplaycurrentANGLE

5 times DisplayA-B current status

6 times Display REPEAT current status

7 times Display is turn off

ForTitle&Chapter,use cursor buttonsto do title/chapter selection,then press Enter buttonto implement the selection.

ForSubtitle,Audio,Angle, A to B&Repeat, press the Enterkeyrepeatedly to change the options.Theseoptions may vary

fromdisc to disc.

14. PAUSE ( ) Button*

Allows the user to pause playback.

15. PREVIOUS ( ) Button

Allows the user to return to the previous chapter or track.

16. NEXT ( ) Button

Allows the user to skip to the next chapter or track.
