ABS10H / ABS12H

OWNER’S MANUAL

To bring the product to market that excites the consumer through sound and

vision from an orientation of integrity and customer service. We make you look as

good as you sound. We strive to take car audio to an extreme the world has never

seen, and a world that never stops evolving.

Audiobahn was established in 1997 with one long-term goal in mind, “Build

it Bigger, Badder, & Better, and the people will take notice!” We back this statement

with an engineering team that has brought home several Innovations, Design &

Engineering Showcase Awards, and a marketing team from around the world that

spends countless hours developing our no compromise products to satisfy the most

discriminating enthusiasts.

Our global manufacturing facilities feature ISO9002 ratings (the highest level

of quality control awarded in the electronics manufacturing industry), fully robotic as-

sembly lines and a state of the art, California based R & D laboratory.

Our Technical Department and entire staff look to strive above and beyond

the rest of the pack by going that extra mile to help you out. Whether you happen to

be a veteran competitor, or a beginner car audio enthusiast who does not know a

voice coil from a spider. We are all her to help you get the best system you can with

what you have.

Judge for yourself, and remember what it’s all about, “If it’s not Bigger, Bad-

der & Better, it’s not Audiobahn.” If audio is your life, Audiobahn is the brand for you!

We make you look as good as you sound. People never stop trying to get the best

product, so we will never stop making it.

The Audiobahn Way

Introduction___________________________________________________ 3

Features and Specications______________________________________ 4

Terminals_____________________________________________________ 5

Mounting_____________________________________________________ 6

Troubleshooting________________________________________________ 7

Warning and Disclaimer__________________________________________ 8

Warranty______________________________________________________ 9

Notes_________________________________________________________ 10

Getting Started

Welcome to Audiobahn Inc.. This manual has been designed to provide information for

the owner, salesperson, and installer. For those of you who want quick information on

how to install this product, please turn to the installation section of this manual. Other in-

formation can be located by using the table of contents. We at Audiobahn have worked

very hard to make sure that all of the information in this manual is current, but, as we

are constantly nding new ways to improve our product, this information is subject to

change without notice. All updated information can be found on our web page in the

technical support section.

TABLE OF CONTENTS

Dear Customer,

Congratulations on your purchase of the worlds nest brand of car audio products. Here at

Audiobahn Inc. we are devoted to making our musical reproduction the vert best, and we

are pleased you have chosen our product. Through years of engineering expertise, hand

craftsmanship, and critical testing procedures, we have created a wide range of products

that reproduce music with all the clarity and richness you deserve.

For maximum performance we recommend you have your Audiobahn product installed by

an Authorized Audiobahn Dealer, as we provide specialized training through our Audiobahn

Installer Training Programs. Please read your warranty, keep your receipt, and original

carton for possible future use.

To get a free brochure on Audiobahn products in the US call (714) 452-1476 or e-mail us at

[email protected].

WARNING

Continuous exposure to sound pressure levels over 100dB may cause permanent

hearing loss. High powered autosound systems may produce sound pressure levels

well over 135dB. Need we say more! Use common sense.

If after reading this manual you still have questions regarding your product, we recom-

mend that you see your nearest Audiobahn Dealer. A list of Authorized Audiobahn

Dealers can be found on our web page. If you need further assistance, feel free to call

us at (714) 452-1476 and ask for the Technical Department. Be sure to have the model

number, date of purchase, and invoice number available when you call.

The model number can be located on the outside of the carton. Record this in the space

provided below along with the date of purchase. It is a good idea to keep your receipt

with this as you will need it in the case of needing a warranty, repair service or ex-

change.

Date of Purchase: _____________________Model Number:___________________

INTRODUCTION

Features and Specifications

ABS10H

• Sealed Enclosure

• High Quality MDF Construction

• Impedance: 4 Ohm Mono

• 40oz. Magnet

• 2” Voice Coil

• One Piece Aluminium Cone

• 400 Watts RMS

• Sensitivity: 92dB

• Freq. Response: 33 - 1500Hz.

• Bumped Back Plate

• Gold Binding Post Terminals

• Enclosure Dimensions:

12.48” (H) x 18” (W) x

4” top - 6.22” bottom (D)

317mm(H) x 458mm(W) x

104mm top - 158mm bottom (D)

(H)=Height

(W)=Width

(D)=Depth

ABS12H

• Sealed Enclosure

• High Quality MDF Construction

• Impedance: 4 Ohm Mono

• 40oz. Magnet

• 2” Voice Coil

• One Piece Aluminium Cone

• 600 Watts RMS

• Sensitivity: 93dB

• Freq. Response: 30 - 1500Hz

• Bumped Back Plate

• Gold Binding Post Terminals

• Enclosure Dimensions:

14.73” (H) x 21.7” (W) x

4.8” top - 7.72” bottom (D)

374mm(H) x 551mm(W) x

122mm top - 196mm bottom (D)

(H)=Height

(W)=Width

(D)=Depth

TERMINALS

The box can be wired in 1) a stereo conguration (each sub wired to a different channel)

or 2) a mono conguration (both subs wired together to a single channel of an amp(applies

only to multiple enclosures), or two bridged channels of an amp). Looking at the back of the

box you will see each side’s terminals. The left terminal is negative (-) and the right terminal

is positive (+) for each terminal. For more information please visit the Tech Tips section at

www.audiobahn.com.

MOUNTING

After determining the best mounting position, check carefully in the areas where

you have positioned the enclosure. Make sure that you position the enclosure in

an area where you will be able to mount the unit. If there are no supplied hard-

ware available, please use some other means of mounting the enclosure to the

vehicle.

TRUNK MOUNTING

Mounting the enclosure in the trunk provides a good overall performance.

Facing the enclosure towards a wall will increase the low frequency sounds.

WARNING

TO AVOID POTENTIAL INJURY FROM MOVEMENT OF THE ENCLOSURE

DURING AGGRESSIVE VEHICLE MANEUVERS (ACCELERATION, STOPS

AND ACCIDENTS), THE ENCLOSURE MUST BE PROPERLY INSTALLED AND

SECURELY FASTENED TO THE VEHICLE.

Troubleshooting

If you start having problems with distorted sound or loss of performance after installing your box in your

empty enclosure, you can follow the instructions below to try and locate what is causing the problem.

1) If you have any distorted sound, loss of performance, or rattling from your subs after you install

your box, check the connections running from your amplier or other processor to the box. You

will also want to check the connections inside the box to make sure no wires have become un

hooked or are loose.

2) If the above does not solve the problem, check your enclosure thoroughly to see if there are any

leaks, cracks, or broken pieces. Make sure the plexiglass is securely fastened. Any loss of struc-

tural

integrity of your enclosure can cause signicant performance loss and distortion.

3) The next step you can take is to remove the subs and look for any burned wire leads or separated

components. Sometimes when you play subs too hard for too long, they will start to heat up.

4) If none of the above steps solve the problem, you will want to start looking at the other components

in the vehicle. Start by checking all connections to and from the box, amplier, source unit, or any

other processors you may be using. You will need to reference to that particular manufacturer for

any setting congurations or troubleshooting.

Warning And Disclaimer

Investigate the layout of your automobile thoroughly before drilling or cutting any holes. Take care

when you work near gas tanks, gas lines, hydraulic lines, and electrical wiring. Do not use the power ampli-

er unmounted. Attach the system securely to the automobile to prevent damage, particularly in the event of

an accident. Do not mount the system so that the wire connections are unprotected or are subject to pinching

or damage from nearby objects.

The +12V DC power wire must be fused at the battery positive terminal connection. Before making or break-

ing power connections at the system power terminals, disconnect the +12V wire at the battery end. Con-

rm your radio/head unit and/or other equipment is turned off while connecting the input jacks and speaker

terminals. If you need to replace the power fuse, replace it only with a fuse identical to that supplied with the

system. Using a fuse of a different type or rating may result in damage to this system which is not covered by

the warranty.

Disclaimer

Specications are subject to change without notice.

For the most updated Specications call Audiobahn,

your local Authorized Audiobahn Dealer,

or check the Audiobahn web site.

www.audiobahn.com

Warranty

Audiobahn Consumer

Product Warranty Policy

Audiobahn products are manufactured with the highest quality components and some of the most advanced

technology available. Because of this we recommend that you have your new products installed by an Au-

thorized Audiobahn Dealer. (A list of Authorized Audiobahn Dealers can be found on our web page).

Warranty Period: One year from the original date of purchase.

Warranty Coverage: This warranty covers manufacturer defects only. The warranty is applicable to the

original purchaser, and is non-transferable. You must provide a receipt from an Authorized Audiobahn

Dealer that shows the location of purchase, price paid, and date of purchase.

(Products purchased by consumers from an Authorized Audiobahn Dealer outside the United States are

covered only by the Distributor of that specic country and are not covered by Audiobahn).

NOTES:

Complete subwoofer enclosures (Audiobahn will replace defective subwoofers, plexiglass, or neon only. Do

not send the entire enclosure, unless the enclosure is defective itself. You must receive prior authorization

and an RA# before sending in any complete enclosure).

AUDIOBAHN DOES NOT WARRANTY ANY PRODUCTS NOT PURCHASED THROUGH AN AUTHO-

RIZED DEALER.

(A list of Authorized Audiobahn Dealers can be found on our web page).

AUDIOBAHN WARRANTIES DO NOT COVER THE FOLLOWING:

• Any product not purchased from an Authorized Audiobahn Dealer (including Internet dealers)

• Damage caused by abuse, misuse, accident, water / ood, or theft (including any cosmetic damage to

the body of the product)

• Damage caused by improper installation

• Any cost or expense related to removal or reinstallation

• Any unauthorized services

• Any product that has the serial number removed, altered, or defaced

• Subsequent damage to any other components

• Pinched, cut, or stripped wires / terminals

• Any product that is new, and/or found to be in working condition

• L.E.D. indicators on electronics (Audiobahn will only replace L.E.D.(s) found to be defective at the time

of purchase)
