Audio Technica ATCS-60 Manuel utilisateur

ATCS-M60a/ATCS-M65

ATCS-C60a

Voting module

ATCS-V60

MASTER CONTROL UNIT

ATCS-C60a

Conference Manager

V2.1

6.6. Setting method for MIX MODE switch (ATCS-M60a only)

6.7. All finish from chairperson’s microphone

7. Voting module

7.1.Part names and functions of voting module

8.1.

8.2.

8.3.

9.1.

9.2.

9.3.

10. How to Operate the Basic System

11.

12.1.

12.2.

12.3.

12.4.

12.

13.

13.1.

13.2.

13.3.

13.4.

13.5.

13.6.

13.7.

13.8.

13.9.

14.

14.1.

14.2.

6.2. Mounting and dismounting the microphone unit

(extended system)

Important information

Warning:

To prevent fire or shock hazard, do not expose this apparatus to rain or moisture.

Caution:

Do not expose this apparatus to drips or splashes.

To avoid electric shock, do not open the cabinet.

Refer servicing to qualified personnel only.

Do not expose this apparatus to excessive heat such as sunshine, fire

or the like.

Do not subject this apparatus to strong impact.

This apparatus should be located close enough to the AC outlet so

that you can easily grasp the power cord plug at any time.

In case of emergency, disconnect the power cord plug of this

apparatus quickly.

This apparatus should be located close enough to the AC outlet so

that you can easily grasp the AC adapter at any time.

In case of emergency, disconnect the AC adapter quickly.

Do not place any objects filled with liquids, such as vases, on this

apparatus.

To prevent fire, do not place any naked flame sources (such as lighted

candles) on this apparatus.

Do not install this apparatus in a confined space such as a bookcase or

similar unit.

Install this apparatus only in places where ventilation is good.

To prevent fire, do not cover the ventilation of this apparatus with

newspapers, tablecloths, curtains, etc.

This apparatus with Class I construction shall be connected to an AC

outlet with a protective grounding connection.

Batteries caution

Keep batteries out of the reach of children.

Observe correct polarity as marked.

Do not expose batteries to excessive heat, such as sunshine, fire or the like.

Always consider environmental issues and follow local regulations when

disposing of batteries.

Remove depleted battery immediately.

Danger of explosion if battery is incorrectly replaced. Replace only with the

same or equivalent type.

Do not use a leaking battery. If battery leakage occurs, avoid contact with skin.

If contact occurs, immediately wash skin thoroughly with soap and water.

If battery leakage comes into contact with your eyes, immediately flush them

with water and seek medical attention.

Important Safety Instructions

For customers in the USA/Canada

To prevent electric shock, do not remove the cover. There are

no user-serviceable parts inside. Internal adjustments are for qualified

professionals only. Refer all servicing to qualified service personnel.

Caution:

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

The lightning flash with arrowhead symbol within an

equilateral triangle is intended to alert the user to the

presence of uninsulated “dangerous voltage” within the

product enclosure that may be of sufficient magnitude to

constitute a risk of shock to persons.

The exclamation point within an equilateral triangle is

intended to alert the user to the presence of important

operating and maintenance (servicing) instructions in the

literature accompanying the product.

1) Read these instructions.

2) Keep these instructions.

3) Heed all warnings.

4) Follow all instructions.

5) Do not use this apparatus near water.

6) Clean only with dry cloth.

7) Do not block any ventilation openings. Install in accordance

with the manufacturer’s instructions.

8) Do not install near any heat sources such as radiators, heat

registers, stoves, or other apparatus (including amplifiers) that

produce heat.

9) Do not defeat the safety purpose of the polarized or grounding-type

plug. A polarized plug has two blades with one wider than

the other.

A grounding-type plug has two blades and a third grounding

prong.

The wide blade or the third prong are provided for your safety.

If the provided plug does not fit into your outlet, consult an

electrician for replacement of the obsolete outlet.

10) Protect the power cord from being walked on or pinched,

particularly at plugs, convenience receptacles, and the point

where they exit from the apparatus.

11) Only use attachments/accessories specified by the manufacturer.

12) Use only with the cart, stand, tripod, bracket, or table specified

by the manufacturer, or sold with the apparatus.

When a cart is used, use caution when moving the cart/apparatus combination

to avoid injury from tip-over.

13) Unplug this apparatus during lightning storms or when unused for long

periods of time.

14) Refer all servicing to qualified service personnel. Servicing is required when

the apparatus has been damaged in any way, such as power-supply

cord or plug is damaged; liquid has been spilled or objects have fallen into the

apparatus; the apparatus has been exposed to rain or moisture,

does not operate normally, or has been dropped.

FCC Notice

Warning:

Caution:

This device complies with Part 15 of the FCC Rules. Operation is subject to the

following two conditions: (1) This device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that

may cause undesired operation.

Note: This equipment has been tested and found to comply with the limits for a

Class B digital device, pursuant to part 15 of the FCC Rules.

These limits are designed to provide reasonable protection against harmful

interference in a residential installation. This equipment generates, uses and can

radiate radio frequency energy and, if not installed and used in accordance with

the instructions, may cause harmful interference to radio communications.

However, there is no guarantee that interference will not occur in a particular

installation. If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the equipment off and

on, the user is encouraged to try to correct the interference by one or more of

the following measures:

− Reorient or relocate the receiving antenna.

− Increase the separation between the equipment and receiver.

− Connect the equipment into an outlet on a circuit different from that to which

the receiver is connected.

− Consult the dealer or an experienced radio/TV technician for help.

You are cautioned that any changes or modifications not expressly approved in

this manual could void your authority to operate this equipment.

For customers in Canada

IC statement

CAN ICES-3 (B)/NMB-3(B)

Notes on use

■Microphone Unit

･To move the microphone unit, pick it up by its base; do not lift or pull on the

microphone.

･Slowly bend and straighten the flexible part of the microphone. Do not bend it

with excessive force.

･Do not drop the unit.

･Do not cover the infrared transmitting/receiving section.

･When the microphone units are too close together, high sound volume may

cause acoustic feedback.

In this case, increase the space between the microphone units or turn down

the volume.

･After installing a new battery, confirm that the power LED turns on.

■Installing

･Do not install the IR transmitter/receiver units or the microphone units near

infrared-emitting objects such as direct sunlight, incandescent lamps, halogen

lamps, inverter fluorescent lamps, or plasma displays.

･Noise may be generated by interference regardless of the operating distance

between the IR transmitter/receiver and the microphone unit; in this case,

move transmitter/receiver unit away from infrared-emitting objects.

■DVD-ROM (Conference Manager)

･Handle with care to keep fingerprints, dust, or water (or oil) drops off the

recording surface (blue side).

･Be careful to avoid scratching the recording surface (blue side).

･Use a felt-tip pen to write on the label. Do not use a pen with a hard tip, such

as a ballpoint pen.

■Battery charger

･If the charging terminal is dirty, poor contact will prevent the battery from being

charged properly. Periodically clean the charging terminals.

･The battery charger may become hot during charging.

Use it in a well-ventilated area.

･After the battery is fully charged, turn off the battery charger or remove the

batteries.

■Battery(optional)

･The newly purchased battery is not charged.

･If the battery is installed on the microphone unit and left with the power switch

ON for a long period, the battery may become over-discharged. IN such case,

charging the battery one time may be insufficient, so please charge it again.

･The battery is dedicated to the microphone unit (ATCS-M60a/ATCS-M65).

Do not use it for other applications.

･Dispose of used batteries properly as industrial waste, or contact our business

office in your area.

There is no need to wire the microphone units, allowing for easy layout changes in

conference rooms. In addition, there is no risk of interference or eavesdropping.

(supported by ATCS-M60a only)

Settings of the master control unit and the microphone unit allow speaking management as shown below.

Setting for number of speaking microphones

It is possible to set the number of microphones that are available for simultaneous use (number of

“speaking microphones”) in a range from 1 to 5. This can be set via the PRIORITY left switch on the

master control unit or through Conference Manager.

Setting for number of priority microphones

It is possible to set the number of microphones that can be used at any time (number of “priority

microphones”)in a range from 0 to 4. This can be set via the PRIORITY right switch on the

master control unit or through Conference Manager. When this is set, the speaking priority is

assigned to microphone unit IDs in order from the smallest to the largest number.

(Refer to

section 6.5 “Setting the ID switches”.)

Setting for number of non-priority microphones

This function sets the number of microphones other than priority microphones (number of “non-priority

microphones”), based on the number of speaking microphones and the number of priority microphones,

as shown in the table below.

・・・

Setting the master control unit

Number of speaking

microphones

(PRIORITY left switch)

Number of priority

microphones

(PRIORITY right switch)

Setting for number of

non-priority microphones

* Number of speaking microphones − number of priority microphones = number of non-priority microphones.

* It is not possible to set the number of priority microphones greater than the number of speaking microphones.

* For the setting method of the master control unit, refer to

section 10 “How to Operater the Basic System”

Autres manuels pour ATCS-60

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Audio Technica Système de microphone

Audio Technica

Audio Technica UniPak ATW-1661 Manuel du propriétaire

Audio Technica

Audio Technica AT895 Manuel du propriétaire

Audio Technica

Audio Technica ATW-A65 Manuel du propriétaire

Audio Technica

Audio Technica AT-ONE Manuel du propriétaire

Audio Technica

Audio Technica Artist Elite AEW-DA550C Manuel du propriétaire

Audio Technica

Audio Technica ATW-2110 Manuel du propriétaire

Audio Technica

Audio Technica Artist Elite 4000 Series Mode d'emploi

Audio Technica

Audio Technica PRO 88W Manuel utilisateur

Audio Technica

Audio Technica M2 Instruction manuelle

Audio Technica

Audio Technica 1200 Series Manuel utilisateur

Audio Technica

Audio Technica ATW-A10 Manuel du propriétaire

Audio Technica

Audio Technica ATW-A49 Manuel du propriétaire

Audio Technica

Audio Technica 200 Series Manuel du propriétaire

Audio Technica

Audio Technica ATW-1101 Manuel du propriétaire

Audio Technica

Audio Technica PRO 88W Manuel utilisateur

Audio Technica

Audio Technica ATW-DA600 Manuel d'utilisation

Audio Technica

Audio Technica ATW-BH1 Manuel du propriétaire

Audio Technica

Audio Technica ATW-1451 Manuel du propriétaire

Audio Technica

Audio Technica ATW-R1810 Manuel du propriétaire

Audio Technica

Audio Technica ATW-1235 Manuel du propriétaire

Audio Technica

Audio Technica ATW-3110 Manuel du propriétaire

Audio Technica

Audio Technica ATW-T3202 Manuel utilisateur

Audio Technica

Audio Technica ATW-0951 Manuel du propriétaire

Audio Technica

Audio Technica Professional 2000 Series Manuel utilisateur

Manuels Système de microphone populaires d'autres marques

Paso

Paso R824 Manuel utilisateur

Naxa

Naxa NAM-982 Manuel utilisateur

Motorola

Motorola PMNN4461 Manuel utilisateur

Xvive

Xvive U3 Manuel utilisateur

Tekon

Tekon DUOS Manuel utilisateur

Heyuan Intelligence

Heyuan Intelligence IOT-G2S-01 Manuel utilisateur

Devine

Devine WMD-IE Manuel utilisateur

LG LF-D7150 Manuel utilisateur

GE S768DAV Manuel utilisateur

LD U305 HBH 2 Manuel utilisateur

Chainway

Chainway URA8 Manuel utilisateur

ORATOR

ORATOR D860TD Manuel utilisateur

Sennheiser

Sennheiser Evolution Wireless Digital EW-DX EM 2 Manuel utilisateur

Alpha Technologies

Alpha Technologies RBMS Manuel utilisateur

SWIT Electronics Co.,LTD.

SWIT Electronics Co.,LTD. CW-S150 Manuel utilisateur

Shure

Shure UA844 Manuel utilisateur

Panasonic

Panasonic SHFX70 - DVD HOME THEATER WIRELESS SYSTEM Manuel utilisateur

Pyle

Pyle PDWM5000 Manuel utilisateur
