Audi TT COUPE Manuel utilisateur
Audi TT Coupé
Quick reference guide
Fuel
(see sticker)
Tyre pressures
(see sticker on door pillar
on driver side)
Fuel tank flap
To open:
Press the switch on
the driver’s door.
To close:
Press the tank flap until you
hear it click into place.
Engine oil
The correct oil
specifications and
engine oil capacity are
listed in the
Performance, weights
and dimensions
section of the
Owner’s Manual.
Warning triangle
The compartment for the
warning triangle is located in
the luggage compartment.
Welcome
Dear Audi Driver,
This quick reference guide gives you an
overview of the main features and
controls of your vehicle. However, it
cannot replace the detailed Owner’s
Manual which contains important
information and safety warnings.
Please refer to your Owner's Manual for
detailed information on your vehicle.
You will find everything you need to
know about the radio, CD, navigation,
TV and telephone functions in the
Operating Manual for your sound system
or navigation system.
We wish you safe and enjoyable
motoring with your new Audi.
AUDI AG
Controls and
displays
Unlock switches for:
Tailgate
Tank flap
Electric windows
To set the desired position:
Press/pull to the first stop
and hold.
"One-touch" function:
Press/pull briefly to the
second stop.
Adjuster for exterior
mirrors
Turn the adjuster for:
Left exterior mirror
Exterior mirror heating
Right exterior mirror
3
2
1
7
10 12
9 9
8
11
14
3
2
4
5
6
1
13
Exterior mirror
retraction
Press the adjuster to move
the mirror glass in the desi-
red direction
Bonnet lock release
Door handle and central
locking switch
Lock
Unlock
Light switch
Headlight range control
and daytime running lights
Cruise control system
Controls on multi-function
steering wheel
9
8
7
6
5
4
Overview
Ashtray
Buttons for:
Audi magnetic ride
Electronic stabilisation
program
Hazard warning lights
Rear spoiler
Activating tyre
pressure monitoring
Handbrake
21
22
ESP
OFF
23
15
16
17
19 18
20
21
22
23
Turn signal and main beam
lever
Instruments and
warning/indicator lamps
Windscreen wipers/washer
and buttons for on-board
computer
Ignition lock
Steering wheel position
adjuster
14
13
12
11
10 Navigation system or
sound system
Warning lamp for front
passenger's airbag
Air conditioner
Front passenger’s
seat heating
Driver’s seat heating
Gear lever or selector lever
for automatic gearbox
20
15
18
16
17
19
8
7
6
4
123
5
Manual seat adjustment
To move seat backwards
or forwards:
Lift the lever and move the seat.
Then release the lever and move the
seat further until the catch engages.
To adjust lumbar support:
Press the appropriate part of
the switch.
To adjust seat height:
Pull up or press down the
lever repeatedly.
To adjust backrest:
Take your weight off the backrest
and turn the knob.
Easy entry function:
Pull the lever upwards and fold the
backrest forwards.
5
8
7
6
4
Adjusting head restraints
Take hold of the sides of the head
restraint with both hands and move
it up as required. The top of the
head restraint should be at eye level
or higher.
Seat adjustment
Electric seat adjustment
To adjust lumbar support:
Press the appropriate part of the switch.
To adjust seat height and move seat
backwards or forwards:
Front of seat cushion up/down
Rear of seat cushion up/down
Seat up/down
Seat forwards/backwards
To adjust backrest:
Backrest further
upright/further
reclined
1
3
2
Sitting position
Sit in a normal upright position and
do not sit too close to the steering
wheel. If necessary, also adjust the
position of the steering wheel.
min.
25 cm
Automatic gearbox
Selector lever positions
PParking lock
RReverse gear
NNeutral
DDrive (forwards)
SSport position
To release the selector lever and engage a gear:
Switch on the ignition, press the brake pedal, and
press the interlock button on the selector lever.
Move the selector lever to Dor Sto start
driving forwards.
tiptronic: To switch to manual gear
selection mode, push the selector
lever from position Dto the right.
The gears are shown on the driver
information system.
To shift up or down a gear: Briefly push
the selector lever forwards or backwards.
First steps
Starting the engine
Switching on the ignition/starting the engine
Insert the key into the ignition lock.
To switch on the ignition: Turn the key
to position .
To start the engine (on vehicles with
manual gearbox): Press the clutch and turn
the key to position until the engine
starts.
To start the engine (on vehicles with
automatic gearbox): Move the selector lever
to position Por N, press the brake pedal,
and turn the key to position until the
engine starts.
To switch off the engine: Turn the key to position .
1
0
2
2
Switches for air conditioner
Control on left: Temperature selection
Control in middle: Switching air conditioner on/off
and regulating blower speed
Control on right: Air distribution
Automatic mode
Set the desired temperature and
press the button.
Air recirculation
Circulates and filters the air in the interior
of the vehicle
Switching air cooling system on/off
Defrosting windscreen and side windows
Rear window heating
AC
AUTO
Air conditioner
Audi magnetic ride
Two suspension systems in one vehicle
Normal driving mode: Comfort-oriented suspension
Sport driving mode: Performance-oriented suspension
Press the switch to activate/deactivate.
Technology
When the system is switched on, the indicator
lamp appears in the instrument cluster.
To switch on/off: Pull/press lever .
To set speed: Press button .
To adjust stored speed: Press lever up (faster)
or down (slower).
1
2
Cruise control system
2
1
Rear spoiler
To increase stability
The down force of the rear axle
increases when the rear
spoiler is extended.
Automatic mode:
The rear spoiler extends at
speeds above 120 km/h and
retracts at speeds below
80 km/h.
Manual mode:
Briefly press the button to extend the rear spoiler.
Briefly press the button again (while driving between
20 km/h and 120 km/h) to retract the rear spoiler again.
Press and hold the button (while driving below
20 km/h) to retract the rear spoiler.
1
2
2
Audi Navigation System plus
Components
Driver information system
Multi-function steering wheel
Scroll the left thumbwheel to select a menu item in the
driver information system. Press the thumbwheel to
confirm the selection.
Press the MODE button to switch between the active audio
source and the navigation and telephone functions.
Briefly press the button to switch on the speech
dialogue system.
Speak after the <beep>, e.g. say <Help> to call up the pos-
sible operating commands.
Press and hold the talk button to switch off the speech
dialogue system.
Scroll the right thumbwheel to adjust the volume.
If you press the right thumbwheel, the last navigation
cue will be repeated.
2
1
