Shenzhen AtomStack Technologies Co., Ltd.
www.atomstack3d.com
Table of Contents
1. Precautions and Disclaimer........................3
2. Device introduction....................................4
3. Tools and accessories..............................5
4. Pre-assembly inspection..........................6
5. Structure assembling...............................7
5.1 Step1: Z-Axis assembling.............................7
5.2 Step2: LCD screen assembling.......................8
5.3 Step3: Material bracket assembling................9
5.4 Step4: Handle assembling...........................10
5.5 Step5: Cable connectivity ...........................11
6. Printing extruder replacement method..12
7. LCD interface introduction......................13
8. Software configuration...........................14
8.1 Software installation.................................14
8.2 Step1: Printer configuration..................15~16
8.3 Step2: Material configuration......................17
8.4 Step3: Slice files configuration.....................18
9. Printing File Preparation ................................19
9.1 Slice files parameter introduction.......................19
9.2 Creating the Slice files....................................20
10. Inspection of Structure..............................21
10.1 Printer inspection before printing........................21
10.2 Scroll wheel inspection ...................................22
10.3 Transmission belt Inspection .............................23
10.4 Extruder nozzle cleaning..................................24
10.5 Levelling adjustment......................................25
11. Material preparation.....................................26
11.1 Prepare to load the material..............................26
11.2 Loading the material ......................................27
12. Start printing................................................28
13. Finish printing...............................................29
1.Precautions and Disclaimer
1.Astomstack 3D printer has two types of voltage mode, AC 115V & AC 230V, please switch to the suitable voltage to your electric circuit by manual to prevent the damage
of equipment. Must use with the ground wire power source.
2.Do not place the printer where there are flammable and explosive materials. Make sure that there is no other vibration source where the printer is located to ensure the
stability of the printer. The ambient temperature is 25℃, and the relative humidity is 20%RH~50%RH
3.For your safty, please DO NOT touch any part of the printer during building prevent from harmful by hit or pinch.Temperature at the nozzle could 250℃ and the head
bed could be 90℃, please stay away from them during printing.
4.Please clean the extruder and nozzle after each printing, caution because the nozzle could be very hot. Make sure it is power off before cleaning, please clean by the tools privided with the printer.
Please clean the printer with dry clean rag.
5. This product is not a toy, nor is it suitable for people under 15 years of age. Do not allow children to touch the printer. Please be careful when performing scene
operations with children. Be careful not to pinch your hands during installation and use. Any pinch will not be held responsible. Before using this product, please read this
document carefully to understand Your legal rights, responsibilities and safety instructions; otherwise it may cause property damage, safety accidents and personal safety
hazards. Once you use this product, you should be deemed to have understood, accepted and accepted all the terms and contents of this document. The user is
responsible for his or her actions and all consequences arising therefrom. The user agrees to use the product for legitimate purposes only, and agrees to all the terms and
contents of this document and any related policies or guidelines that AtomStack may establish. Shenzhen AtomStack Technology Co., Ltd. reserves the right to update this
disclaimer and safety operation guide. AtomStack is not responsible for any and all losses caused by the user’s failure to use this product due to the user’s use of this
product. AtomStack has the final right to interpret the documents and comply with legal requirements. AtomStack reserves the right to update, modify or terminate the
terms without prior notice.
2.Device introduction
X-Axis belt adjustment knob
Extruder
（Pre-set E285 extruder）
Y-Axis belt adjustment
knob
Y-Axis Eccentric nut
X-Axis Eccentric nut
TF card slot
at LCD
Switch
Levelling adjustment
wheel
Support bracket
AtomStack
Material
bracket
Loading Handle
TF card slot
at machine USB port
Nozzle
LCD
Handle
Heating bed
Introduction
Printer
volume
235*235*250mm
Power
supply
AC100~240V 50/60HZ
Operation
Software
Ultimaker Cura
Support OS
macOS、Windows&Linux
Material
bracket
3.Tools and accessories
Shovel
Socket wrench for
replacement of
nozzle
hexagonal wrench
for assembling
Wrench for the
levelling adjustment
TF memory card
including the printer object
file and configuration
instructioin video etc.
TF card reader
reading file
Through needle
for cleaning of nozzle
E175printing extruder
1.75mmfilament，0.4mm
nozzle.For PLA,PETG printing
Cutting pliers
for filament
E285 printing extruder
for 2.855mm filament,0.4mm
nozzle.For TPR printing
screwdriver used for
disassembling
FFC cable plug
1.The power switch of 3D printer has two types of voltage mode,
AC 115V & AC 230V, please switch to the suitable voltage to your
electric circuit by manual at the bottom .
4. Pre-assembly inspection
Bottom of printer Switch of voltage
2.we will set the positioning pin in order to keep the Z-axis part with the firm
position before package at the Z-axis.Please remove the position pin before
assembling
Z-axis parts
Pos it i o n P I N
Z - ax i s ( l e f t ) Z - ax i s ( r i g h t )
Z轴(左）
Pos it i o n P i n
Re move t h e
po si t i on P I N
Instruction
1.Put the Z-axis vertical into the groove at the base
2.Use 4pcs M5*44 screw to fasten from the bottom of base
with the Z-axis
1
2
G ro o ve
3
1 . Z - a x i s p a r t ( w i t h E 2 8 5 ) 2 . B a s e 3 . M 5 * 4 4 s c r e w *4 P C S
Assembling parts
5. Structure assembling
5.1 Step1 Z-Axis assembling
Fasten the LCD at the right of base with the screw
5*14
1
2
Assembling Parts
1 . L C D * 1 P C S 2 . M 5 * 1 4 s c r e w * 2 P C S
Instruction
5.2 Step2: LCD screen assembling
Fasten the brack on the beam with M5*14 screw*2PCS
2
Assembling Parts
1 . b r a c k e t * 1 P C S 2 . M 5 * 1 4 s c r e w * 2 P C S
Instruction
1
5.3 Step3 Material bracket
assembling
Fasten the handle on the beam with the screws of
M5*2pcs
Instruction
Assembling Parts
1 . h a n d l e * 1 P C S 2 . M 5 * 2 5 s c r e w * 2 P C S
2
1
5.4 Step4: Handle assembling
