AT97SC3205T-SDK2

AT97SC3205P-SDK2

Atmel TPM I2C/SPI Development Kit

USER GUIDE

Atmel I2C/SPI Demonstration Kit

Introduction

The Atmel®TPM™ Development Kit includes examples of how to use the Trusted Platform Module

(TPM) in an embedded and PC application. Source code is provided to enable an embedded designer to

make quick progress in understanding and utilizing the TPM.

The TPM Development Kits are based on the Atmel SAM4S ARM®with an added I2C or SPI TPM

device. The TPM demonstration code and evaluation software are included on a USB flash drive which

comes with the kits. The board includes a SPI or I2C TPM, a SAMS4 processor, a board reset button, a

JTAG connector, and detachable segments to allow for engineering system integration as shown in

Figure 1.

Complete SAM4S ARM documentation can be found on the Atmel web site at the following link:

http://www.atmel.com/Images/Atmel_11100_32-bit-Cortex-M4-Microcontroller_SAM4S_Datasheet.pdf

This TPM Development Kit User Guide documents the features specific to the TPM and references the

SAM4S ARM documentation where appropriate.

Atmel-8528D-TPM-I2C-SPI-Development-Kit-UserGuide_052014

AT97SC3205T/3205P-SDK2 TPM I2C/SPI Development Kiti [USER GUIDE]

Atmel-8528D-TPM-I2C-SPI-Development-Kit-UserGuide_052014

Features

The TPM kit is a custom board containing an I2C TPM or SPI TPM and related circuitry connected to the

SAM4S ARM board. Interface signals on the board are:

•Power

•Ground

•PIRQ

•Chip Select (CS)

•MISO

•SDA

•SCL

•SCLK

•MOSI

•RST

•GND

•VCC

The following functional sections are provided on the Embedded TPM kit:

•AT97SC3205 I2C or SPI Atmel TPM

•TPM Reset Switch

•RC Reset Delay

•Decoupling Capacitors

•Pull-Up and Pull-Down Resistors

•Test Points

USB Drive

The included USB drive includes the following:

•User Guide

•Source Code of the Demo

•Hex Images for Reloading the Demo (If Necessary)

•Kit Schematics

Figure 1. Atmel I2C/SPI Demonstration Kit

JTAG ConnectorSAMS4 ARM Reset Button TPM

Mini JTAG Connector

Detachable Segments

AT97SC3205T/3205P-SDK2 TPM I2C/SPI Development Kiti [USER GUIDE]

Atmel-8528D-TPM-I2C-SPI-Development-Kit-UserGuide_052014

Table of Contents

TPM Overview ..................................................................................................................... 4

Power.............................................................................................................................................................4

Reset Button ..................................................................................................................................................4

In-System Programming ................................................................................................................................4

Debugging......................................................................................................................................................4

Demonstration Software .................................................................................................... 5

Initial One-Time Setup ...................................................................................................................................6

Demo Menu Commands ................................................................................................................................6

Selection 1 - TPM_Startup (ST_CLEAR) ..............................................................................................6

Selection 2 - TPM_ContinueSelfTest ....................................................................................................7

Selection 3 - TPM_CreateEKPair..........................................................................................................7

Selection 4 - TPM_TakeOwnerShip (Sequence) ..................................................................................7

Selection 5 - TPM_CreateWrapKey (Sequence)...................................................................................8

Selection 6 - TPM_Loadkey (Sequence) ..............................................................................................8

Selection 7 - TPM_Seal (Sequence).....................................................................................................9

Selection a - TPM_UnSeal (Sequence) ..............................................................................................10

Selection b - TPM_Sign (Sequence)...................................................................................................10

Selection c - TPM_VerifySign (Sequence).......................................................................................... 11

Selection d - TPM_GetPubKey (Sequence)........................................................................................11

Selection t - getCapability_versionVal.................................................................................................12

Selection u - TPM_Reset (Clears authSessions)................................................................................12

Selection v - TPM_FlushSpecific (keyHandle) ....................................................................................12

Selection w - TPM_ForceClear (Sequence)........................................................................................12

Selection x - Enable/Activate TPM (Sequence) ..................................................................................13

Selection y - Disable/Deactivate TPM (Sequence) .............................................................................13

Selection z - Display Known Keys.......................................................................................................13

Technical Support ............................................................................................................ 13

Hardware Reference Design ............................................................................................ 13

Schematics ..................................................................................................................................................13

Revision History ............................................................................................................... 14

AT97SC3205T/3205P-SDK2 TPM I2C/SPI Development Kiti [USER GUIDE]

Atmel-8528D-TPM-I2C-SPI-Development-Kit-UserGuide_052014

TPM Overview

Power

The TPM receives power from the SAM4S ARM through the interface headers. During normal use, the

SAM4S ARM is powered through the USB device connection, which doubles as both a power source

and communication interface to the SAM4S ARM. The SAM4S ARM provides 5V to 3.3V regulated

power for the TPM.

Reset Button

The reset button resets the TPM. Pressing the reset button will only send a Power-On-Reset (POR)

signal to the TPM.

In-System Programming

The SAM4S ARM provided with the TPM differs from a standard SAM4S ARM in that the

pre-programmed application software loaded in Flash memory is the TPM demonstration software, not

the SAM4S ARM demonstration software.

The USB bootloader remains pre-programmed in ROM memory. This bootloader may be used to either

reload the TPM demonstration software images or to load the SAM4S ARM demonstration software.

The kit has a JTAG connector that can be detached from the kit and connected to the mini JTAG

connector on the board. This will allow the reprogramming of the SAM4S ARM.

The TPM demonstration software must remain loaded in Flash memory in order to execute

the I2C TPM demo.

Instructions on how to utilize the FLexible In-system Programmer (“FLIP”) software in tandem with the

USB bootloader to load SPI, I2C, or additional application software can be found in the SAM4S ARM

Datasheet. A copy of the FLIP installer is downloadable from www.atmel.com.

For more advanced in-system programming techniques, the In-System Programmer SAM JTAG ICE

combined with Atmel Studio®can be utilized over the provided JTAG interface port to exercise complete

programming control over the processor.

If a software update is required on the TPM, and the customer does not have a SAM-ICE JAG, the

SAM-BA tool can be downloaded using the following Atmel link:

http://www.atmel.com/tools/atmelsam-bain-systemprogrammer.aspx

Contact crypto@atmel.com for software update instructions.

Debugging

For more advanced development and debugging techniques, the Atmel In-System Programmer

SAM-ICE JTAG combined with the Atmel Studio and the Atmel Studio GCC C Complier can be utilized

over the provided JTAG interface port to exercise complete development and debugging control over

the SAM4S processor.

AT97SC3205T/3205P-SDK2 TPM I2C/SPI Development Kiti [USER GUIDE]

Atmel-8528D-TPM-I2C-SPI-Development-Kit-UserGuide_052014

Demonstration Software

To start the demonstration software, follow the below steps:

1. Connect the TPM Demo Kit to an available USB port:

a. Insert the USB drive into the computer, and allow Windows to recognize the drive.

b. Install the Atmel_devices_cdc.inf file from the USB drive. The steps include the following:

•Open Device Manager.

•Select CDC unknown device.

•From the Device Manager main menu, select Action > Update Driver Software….

•Select Browse my computer for Driver Software…button.

•Browse to the .inf file folder on the USB drive.

c. Install the TPM Demo Kit driver software. The TPM Demo Kit device should show as a COM

PORT in the Device Manager.

2. Launch a terminal emulation software of your choice. The serial default connection default

settings are:

– Baud rate: 9,600

– Data: 8 bit

– Stop: 1 bit

– Parity: None

– Flow control: None

– Echo Type Characters locally (if available).

3. Associate the terminal emulation software with the virtual COM port established by connecting the

TPM Demo Kit to the system.

4. Activate the demonstration software by pressing any key while in the active terminal emulation

software window. The below demonstration selection menu should appear.

Demonstration Menu Selections

Available commands:

1) TPM_Startup(ST_CLEAR)

2) TPM_ContinueSelfTest

3) TPM_CreateEKPair

4) TPM_TakeOwnerShip (sequence)

5) TPM_CreateWrapKey

6) TPM_Loadkey

7) TPM_Seal (sequence)

a) TPM_UnSeal (sequence)

b) TPM_Sign (sequence)

c) TPM_VerifySign

d) TPM_GetPubKey

t) TPM_GetCapability(versionVal)

u) TPM_Reset (clears authSessions)

v) TPM_FlushSpecifc - keyHandle

w) TPM_ForceClear (sequence)

x) enable/activate TPM (sequence)

y) disable/deactivate TPM (sequence)

z) display known keys

Please pick a command:

AT97SC3205T/3205P-SDK2 TPM I2C/SPI Development Kiti [USER GUIDE]

Atmel-8528D-TPM-I2C-SPI-Development-Kit-UserGuide_052014

Pressing the indicated numeral or letter beside each menu selection initiates transmission of a TPM

command or command sequence to the TPM and reception of the TPM command response or

responses back.

Details regarding these Trusted Computed Group (“TCG”) TPM Commands can be found in the “TPM

Main Part 3 Commands” specification, located at: https://www.trustedcomputinggroup.org/specs/TPM/

and on the USB drive located in the TCG Docs folder.

Initial One-Time Setup

To ensure the TPM is in a know state, the below sequence is recommended. This sequence will clear

any data that may have been loaded during manufacturing and testing of the kit. It will allow the user to

complete the first steps that would have been completed during the initial manufacturing process of a

TPM device.

1. Selection 1 - TPM_Startup (ST_CLEAR)

2. Selection w - TPM_ForceClear (Sequence)

3. Selection x - Enable/Activate TPM (Sequence)

4. Selection 3 - TPM_TakeOwnership (Sequence)

It is important that these four demo commands be executed in the order listed above. See Section,

“Demo Menu Commands” below, for additional details on each command.

The kits are shipped with a pre-generated Endorsement Key which includes an X.509

certificate.

Only one Endorsement Key can be created during the lifetime of a TPM. Attempting to execute

Seletction 3 - TPM_CreateEKPair command will respond with TPM_DISABLED_CMD

return code of 0x00000008 indicating that an Endorsement Key already resides on the

TPM.

After TPM_TakeOwnership, the user should create and load keys that will enable the user to sign,

verify signatures, seal and unseal data, along with exploring other demo functionality. See section,

“Demo Menu Commands” below for more detailed information regarding the available options.

Demo Menu Commands

Selection 1 - TPM_Startup (ST_CLEAR)

The TPM_Startup command initiates a startup on the TPM. This is the first command that must be

executed after a TPM is powered-up or reset. In this case, the demo provided version of

TPM_Startup is TPM_ST_CLEAR.

TPM_Startup(TPM_ST_CLEAR) does not actually clear the TPM. It is a fresh start where all

variables go back to their default or non-volatile state.

TPM_Startup can only be executed once after the TPM is powered-up or reset, returning a

TPM_SUCCESS return code of 0x00000000. If TPM_Startup is executed again, it will return a

TPM_INVALID_POSTINIT return code of 0x00000026. Any attempt to execute other commands

prior to the TPM_Startup command will also return the error code TPM_INVALID_POSTINIT.

AT97SC3205T/3205P-SDK2 TPM I2C/SPI Development Kiti [USER GUIDE]

Atmel-8528D-TPM-I2C-SPI-Development-Kit-UserGuide_052014

Selection 2 - TPM_ContinueSelfTest

The TPM_ContinueSelfTest command requests the TPM to complete the self-test of all TPM

cryptographic resources when convenient (i.e. when no other commands are being issued to the TPM).

This command is not required on the I2C TPM since the I2C TPM automatically completes all self-test

functions on a power-up or reset.

This command is required after a TPM_Startup on the SPI Interface TPM and is provided in the demo

as an example of how to execute it on the TPM.

The expected return code after executing the TPM_ContinueSelfTest command is

TPM_SUCCESS 0x00000000.

Selection 3 - TPM_CreateEKPair

The TPM_CreateEndorsementKeyPair command self-generates the Endorsement Key Pair

(EK) on the TPM.

While the EK is being generated, the message waiting for TPM response... is displayed. Although

normally only a few seconds, since key generation is non-deterministic, EK generation can take up to

five minutes.

The first time TPM_CreateEndorsementKeyPair is executed, resulting in the generation of an

Endorsement Key Pair, the TPM will return a TPM_SUCCESS return code of 0x00000000.

Subsequent executions of TPM_CreateEndorsementKeyPair will return a

TPM_DISABLED_CMD return code of 0x00000008. The inclusion of this command sequence is to

demonstrate and verify that an Endorsement Key is present on the TPM.

Selection 4 - TPM_TakeOwnerShip (Sequence)

The TPM_TakeOwnership command takes or establishes the owner of the TPM, generating a new

Storage Root Key (SRK). The demo command, TPM_TakeOwnerShip, is a sequence comprised of

the following:

1. A check is made to ensure the EK has been generated on the TPM. If not, then

TPM_CreateEndorsementKeyPair is executed first.

2. The TPM_GetCapability command is executed to ensure that an owner is not currently

present on the TPM.

3. Enter a value for the Owner authorization at the prompt enter owner Auth:. Choose a

passphrase of up to 40 characters.

4. The TPM_BindV20 command is utilized to encrypt the Owner Auth.

5. Enter a value for the SRK authorization at the prompt enter SRK Auth:. Choose a passphrase of

up to 40 characters.

6. The TPM_BindV20 command is utilized to encrypt the SRK Auth.

7. A TPM_OIAP command is executed to establish an authorization session.

8. The TPM_TakeOwnership command is executed.

9. While the SRK is being generated, the message Please wait. Generating SRK... is displayed.

Since key generation is non-deterministic, SRK generation can take seconds or up to five

minutes.

10. If TPM_TakeOwnership is successful, the TPM responds back with the public portion of the

SRK and a TPM_SUCCESS return code of 0x00000000.

TPM_TakeOwnerShip cannot be successfully executed again unless the owner has been cleared by

the TPM_ForceClear command.

AT97SC3205T/3205P-SDK2 TPM I2C/SPI Development Kiti [USER GUIDE]

Atmel-8528D-TPM-I2C-SPI-Development-Kit-UserGuide_052014

Selection 5 - TPM_CreateWrapKey (Sequence)

The TPM_CreateWrapKey command generates a RSA Key pair. Ownership must be taken or

established on the TPM before TPM_CreateWrapKey can generate a RSA Key pair.

The demo command, TPM_CreateWrapKey, is a sequence comprised of the following:

1. If no keys are loaded on the TPM, the TPM_CreateWrapKey automatically uses the SRK as

the parent key. If keys are loaded on the TPM, then choose either a previously loaded key or the

SRK as the parent key.

Make the selection at the prompt:

known keyHandles:

1: XX XX XX XX

2: XX XX XX XX

X: XX XX XX XX

pick a parent key (0=SRK):

2. A TPM_OSAP command is executed to establish an authorization session.

3. Enter a value for the key migration Auth at the prompt enter key migration Auth:. Choose a

passphrase of up to 40 characters.

4. Enter a value for the key usage Auth at the prompt enter key usage Auth:. Choose a passphrase

of up to 40 characters.

5. Choose a type for the key, storage, or signing, at the prompt please pick a key type:.

6. Choose whether the key is migrateable or non-migrateable, at the prompt please pick a key

option:.

7. Choose whether the key’s authDataUsage is TPM_AUTH_ALWAYS or TPM_AUTH_NEVER, at

the prompt please pick a key option:.

8. While the key is being generated, the message waiting for TPM response... is displayed. Since

key generation is non-deterministic, key generation can take seconds or up to five minutes.

9. If the TPM_CreateWrapKey command is successful, the TPM responds back with the public

portion of the key, the encrypted private portion of the key, and a TPM_SUCCESS return code of

0x00000000.

10. The key is now generated, but must be stored so it can be later loaded by TPM_LoadKey2.

The demo supports five cache slots 1 thru 5 in the SAM4S FLASH memory for the temporary

storage of keys or other data. Choose a cache slot for storage of the key at the prompt store key

in which cacheSlot (1-5)?.

These five cache slots are Last In First Out (“LIFI”) and may be overwritten when the stored data

is no longer needed.

Selection 6 - TPM_Loadkey (Sequence)

The TPM_LoadKey2 command loads a previously created key into the TPM for further use. The demo

command, TPM_Loadkey, is a sequence comprised of the following:

1. Choose a cache slot from which to load the key at the prompt load key from which cacheSlot

(1-5)?.

2. A TPM_OIAP command is executed to establish an authorization session.

AT97SC3205T/3205P-SDK2 TPM I2C/SPI Development Kiti [USER GUIDE]

Atmel-8528D-TPM-I2C-SPI-Development-Kit-UserGuide_052014

3. If no keys are loaded on the TPM, TPM_LoadKey2 automatically uses the SRK as the parent

key. If keys are loaded on the TPM, then choose either a previously loaded key or the SRK as the

parent key.

Make the selection at the prompt:

known keyHandles:

1: XX XX XX XX

2: XX XX XX XX

X: XX XX XX XX

pick a parent key (0=SRK):

Selecting the incorrect parent key will result in a TPM_LoadKey2 failure, and the TPM will return

a TPM_DECRYPT_ERROR return code of 0x00000021.

4. The key is then loaded from the selected cache slot.

5. A successful execution of TPM_LoadKey2 returns a TPM_SUCCESS return code of

0x00000000, along with the TPM_KEY_HANDLE.

Selection 7 - TPM_Seal (Sequence)

The TPM_Seal command encrypts private objects that can only be decrypted on the current platform

by using the TPM_Unseal command. Optional current or future configuration information indicated by

the PCR registers can be included in the Seal operation. PCR configuration included in the Seal process

is presently not supported in this demo. The demo command, TPM_Seal, is a sequence comprised of

the following:

1. If no keys are loaded on the TPM, TPM_Seal automatically uses the SRK as the sealing key. If

keys are loaded on the TPM, then choose either a previously loaded key or the SRK as the sealing

key.

Make the selection at the prompt:

known keyHandles:

1: XX XX XX XX

2: XX XX XX XX

X: XX XX XX XX

pick a sealing key (0=SRK):

The only allowed sealing keys are non-migrate able storage keys. Selecting a non-storage key as

a sealing key will result in a TPM_Seal failure, and the TPM will return a

TPM_INVALID_KEYUSAGE return code of 0x00000024.

2. A TPM_OSAP command is executed to establish an authorization session.

3. Enter an authorization value for the sealed blob at the prompt enter auth value for sealed blob:.

Choose a passphrase of up to 40 characters.

4. Enter the data to seal at the prompt enter data to seal (40 chars max):. Choose data to seal of

up to 40 characters.

5. A successful execution of the TPM_Seal command returns a TPM_SUCCESS return code of

0x00000000, along with the encrypted data blob.

6. The encrypted data blob must be stored so it can be later decrypted by the TPM_Unseal

command. The demo supports five cache slots 0 thru 4 in SAM4S FLASH memory for the

temporary storage of keys or other data. Choose a cache slot for storage of the data blob at the

prompt store data blob in which cacheSlot (1-5)?. These five cache slots are LIFI (Last In First

Out) and may be overwritten when the stored data is no longer needed.

AT97SC3205T/3205P-SDK2 TPM I2C/SPI Development Kiti [USER GUIDE]

Atmel-8528D-TPM-I2C-SPI-Development-Kit-UserGuide_052014

Selection a - TPM_UnSeal (Sequence)

The TPM_Unseal command decrypts private objects which been encrypted on the current platform by

TPM_Seal. If optional current or future configuration information indicated by the PCR registers were

included in the Seal operation, then there must be a match with the present PCR values in order for the

TPM_Unseal command to succeed. The demo command, TPM_UnSeal, is a sequence comprised of

the following:

1. If no keys are loaded on the TPM, TPM_Unseal automatically uses the SRK as the sealing key.

If keys are loaded on the TPM, then choose either the previously loaded storage key or the SRK

that was used to seal the data blob as the sealing key.

Make the selection at the prompt:

known keyHandles:

1: XX XX XX XX

2: XX XX XX XX

X: XX XX XX XX

pick a sealing key (0=SRK):

2. A TPM_OIAP command is executed to establish an authorization session.

3. A TPM_OIAP command is executed to establish an authorization session.

4. Enter an Auth value for the sealed blob at the prompt enter auth value for sealed blob:. This

must be the same passphrase of up to 40 characters used to seal the blob.

5. Choose a cache slot from which to load the data blob to unseal at the prompt unseal blob from

which Slot (1-5)?.

6. A successful execution of the TPM_Unseal command returns a TPM_SUCCESS return code of

0x00000000, along with the unsealed data. An unsuccessful decryption of the data blob returns

a TPM_DECRYPT_ERROR return code of 0x00000021.

Selection b - TPM_Sign (Sequence)

The TPM_Sign command signs an input digest and returns the resulting digital signature. The demo

command, TPM_Sign, is a sequence comprised of the following:

1. A TPM_OIAP command is executed to establish an authorization session.

2. TPM_Sign requires a signing key be created with the TPM_CreateWrapKey command and

loaded on the TPM with TPM_LoadKey2 before a digest can be signed. Choose a previously

loaded signing key.

Make the selection at the prompt:

known keyHandles:

1: XX XX XX XX

2: XX XX XX XX

X: XX XX XX XX

pick a signing key:

The only allowed keys for signing are signing keys. Selecting a non-signing key as a signing key

will result in a TPM_Sign failure, and the TPM will return a TPM_INVALID_KEYUSAGE return

code of 0x00000024.

3. Enter the digest to sign at the prompt enter data to sign (40 chars max):. Choose data to sign of

up to 40 characters.

4. A successful execution of TPM_Sign returns a TPM_SUCCESS return code of 0x00000000,

along with the digital signature.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Atmel Microcontrôleur

Atmel

Atmel AT01607 Instructions d'installation et d'utilisation

Atmel

Atmel SAM HA1G16A Xplained Pro Manuel utilisateur

Atmel

Atmel AVR1909 Manuel d'installation

Atmel

Atmel STK200 Manuel utilisateur

Atmel

Atmel AT32UC3 Series Instructions d'installation et d'utilisation

Atmel

Atmel ARIS+ AT88SC-ADK2 Manuel utilisateur

Atmel

Atmel ATAB5749 Instructions d'installation et d'utilisation

Atmel

Atmel ATZB-EVB-24-SMA Manuel utilisateur

Atmel

Atmel AVR2052 Manuel utilisateur

Atmel

Atmel AVR ATtiny15L Manuel utilisateur

Atmel

Atmel AT89C5131A-L Manuel utilisateur

Atmel

Atmel AVR STK100 Manuel utilisateur

Atmel

Atmel ATtiny13A Manuel utilisateur

Atmel

Atmel SAM D09 Instructions d'installation et d'utilisation

Atmel

Atmel AT90S4433-8AC Manuel utilisateur

Atmel

Atmel SAM4SD32B Mode d’emploi

Atmel

Atmel AVR943 Manuel utilisateur

Atmel

Atmel ATmega8 Manuel utilisateur

Atmel

Atmel 8051 Manuel utilisateur

Atmel

Atmel AVR2131 Manuel utilisateur

Atmel

Atmel AT90S1200 Manuel utilisateur

Atmel

Atmel AT91FR40162S Manuel utilisateur

Atmel

Atmel AT90USB162 Manuel utilisateur

Atmel

Atmel AVR1306 Manuel utilisateur

Manuels Microcontrôleur populaires d'autres marques

AMS

AMS AS7261 Demo Kit Manuel utilisateur

Novatek

Novatek NT6861 Manuel utilisateur

Espressif Systems

Espressif Systems ESP8266 SDK Guide de configuration

Nuvoton

Nuvoton ISD61S00 ChipCorder Mode d’emploi

STMicrolectronics

STMicrolectronics ST7 Assembler Linker Manuel utilisateur

Texas Instruments

Texas Instruments Chipcon CC2420DK Manuel utilisateur

Lantronix

Lantronix Intrinsyc Open-Q 865XR SOM Manuel utilisateur

NEC

NEC 78GK0S/K 1+ Series Instructions d'installation et d'utilisation

Mikroe

Mikroe SEMITECH N-PLC Click Instructions d'installation et d'utilisation

Intel

Intel Agilex Manuel utilisateur

Cypress

Cypress CY4607 HX2VL Manuel utilisateur

DIGITAL-LOGIC

DIGITAL-LOGIC MICROSPACE Manuel utilisateur

Texas Instruments

Texas Instruments TMS320F2837 D Series Manuel utilisateur

CYPRES

CYPRES CY14NVSRAMKIT-001 Manuel utilisateur

Texas Instruments

Texas Instruments INA-DUAL-2AMP-EVM Manuel utilisateur

Espressif Systems

Espressif Systems ESP8266EX Mode d'emploi

Abov

Abov AC33M8128L Manuel utilisateur

Laird

Laird BL654PA Manuel utilisateur
