AT91 Host Flash Loader

This application note describes the host Flash loader used to upload and program an

application in the Flash memory of a Flash-based AT91 microcontroller.

Flash-based AT91 devices are delivered by Atmel with resident boot software able to

upload program software into the Flash memory.

The following subjects are covered in this document:

• Flash requirements

• Host loader software

• Host configuration file

• Host loader software user notes

Package Contents

The file AT91Loader.zip contains all source and executable files for the computer. It

also contains AT91Loader8011.ini and AT91Loader16x4.ini files, configuration files for

the AT91Loader.exe file.

The file AT91Flash_uploader.zip contains all source, object and binary files for the

AT91 device. It enables the user to understand and modify (if necessary) the flash

uploader software. Note that fmu_flash.bin is the image of AT91 Flash production line

programming.

Definition of Terms

A Flash-based AT91 is a microcontroller containing an embedded AT91 ARM7TDMI™

microcontroller with a 16-bit Flash memory.

A host Flash loader is a PC running software under Windows®95/98.

USART is the universal synchronous/asynchronous receiver/transmitter, a serial com-

munication port compatible with the computer serial port.

Warranty

All delivered sources are free of charge and can be copied or modified without

authorization.

The software is delivered “AS IS” without warranty or condition of any kind, either

express, implied or statutory. This includes, without limitation, any warranty or condi-

tion with respect to merchantability or fitness for any particular purpose, or against the

infringements of intellectual property rights of others.

AT91 ARM®

Thumb®

Microcontrollers

Application

Note

Rev. 2640A–ATARM–08/02

2AT91 Host Flash Loader

2640A–ATARM–08/02

Host Loader Software The host loader software runs under Windows. The executable file AT91Loader.exe has

been generated with Microsoft®Visual Studio®6.0. Its main functionalities are:

• To read the configuration file (Loader.ini)

• To synchronize with the AT91 boot loader software on a Flash-based AT91 micro-

controller and adapt to the baud rate (defined in Loader.ini)

• To read and analyze the binary file

• To encode commands and transfer data

Configuration File The host flash loader supports different flash configurations described in the configura-

tion file. This file also describes additional initialization parameters for the transfer

configuration. These parameters are defined in four groups:

MODE: Work mode

COM: PC serial port definition

FILE: Name of binary file to download

FLASH: Target Flash description

MODE This field is used for the debug protocol. In general, two modes can be set, automatic

mode or manual mode.

• Manual = 0: Automatic mode. All commands and sequences are managed by the

PC Host Flash loader.

• Manual = 1: Manual mode. All commands can be sent in the menu “Send”. This

mode is used only for debugging the serial communication channel. If this field is

set, the following commands are accessible:

– Autosync: Autosynchronisation

– Synchro: Send the synchro command

– Speed: Send the speed command

– Erase sector: Select the sector to erase and send the erase sector

command

– Write: Select the address and send the write command

– Data: Send a block of 64 data words

– Read Data: Select the address and read a block of 64 data words

– Verify: Select the addresses (start and end) and the checksum and send the

verify command

– Upload: Not implemented

– ACK: Send the ack command

– Fill input buffer: Purge the communication port

COM This field is used to define the serial communication channel. It is divided into four fields:

• Name = COM1: Indicate the PC port connected to the target

• Synchronization = 1200: Indicate the initial connection speed. In this case the low

speed choice is used. The first action of the target is waiting for a character (0x80)

for baud rate measurement and to initiate the communication.

• Transfer_baud = 115200: Indicate data transfer connection speed. In general, a PC

cannot support a baud rate higher than 115200. If the user PC supports a higher

speed, the baud rate can be updated.

AT91 Host Flash Loader

2640A–ATARM–08/02

• Target_CD = 18: Indicate the target user CD value for data speed connection. This

value depends on the main target oscillator. The AT91 USART Speed Definition

table on page 8 can be used to choose the best CD value to optimize

communication quality. This value is sent to the target after synchronization and

when communication starts at the high speed data transfer rate.

FILE Name of binary file to download. This name must use the absolute path.

FLASH Target flash description. This field is used to define the embedded Flash. It is sub-

divided into six fields:

– Name = AT49BV8011. Indicate the Flash name. It is used only to provide the

information corresponding to the file definition. This field is not analysed.

– Type = 0x004A. Indicate the type of embedded Flash. This information is

available in the corresponding Flash datasheet in the device code field.

– Manufacturer = 0x001F. Indicate the type of embedded Flash. This

information is available in the corresponding Flash datasheet in the

manufacturer code field.

– base_address = 0x01000000. Indicate the first Flash sector. This value is

also defined in the target by the EBI setting.

– Load_address =0x01000000. Indicate the first address to be loaded.

Generally it is the same as the base address.

– Sector = 40. Indicate the sector number of the embedded Flash. This

information is defined in the features presented in the Flash datasheet .

– Sector_TypeX = and Size_TypeX =

These groups of two fields describe the Flash sector mapping. For example,

if a 16-megabit 1 M words/2 M bytes Flash is used, e.g. AT49BV1604, there

are forty sectors to map as shown in the following table:

For sector type 0, there are 8 sectors of 8 K bytes (Sector_Type0 = 8; Size_Type0 =8)

For sector type 1, there are 2 sectors of 32 K bytes

(Sector_Type1 = 2; Size_Type1 =32)

For sector type 2, there are 8 sectors of 8 K bytes

(Sector_Type2 = 40; Size_Type2 =64)

This information is available in the corresponding Flash datasheet in the Sector Address

Table field.

On page 4 and page 5, there are two examples of the LOADER.INI file, the first for the

embedded Flash AT49BV1604, the second for the AT49BV8011.

Sector No. Sector K bytes Sector_TypeX Size_TypeX X

SA0 to SA7 8 8 8 8 0

SA8 to SA9 2 32 2 32 1

SA10 to SA39 30 64 30 64 2

Total (AT49BV1604) 40 2048

4AT91 Host Flash Loader

2640A–ATARM–08/02

Example of Loader.ini

File for AT91F40416

The example file below is also valid for an AT91 with an embedded AT49BV16x4. The

file is provided by Atmel.

[MODE]

Manual=0 // automatic load, all commands are managed by HOST Loader

[COM]

Name=COM1 // COM1 serial port

Synchronization_baud=1200 // Synchronization baud rate

Transfer_baud=115200 // Transfer baud rate

Target_CD=18 // AT91 CD value for a baud rate of 115200

// Main Clock = 32.678MhZ => CD = 18

// Main Clock = 25Mhz => CD = 13

[FILE] // name of the binary file to download

Name=C:\At91\software\projects\led_blink_eb40\flash\led_blink.bin

[FLASH]

Name=AT49BV1604 // flash type is AT49BV1604

Type=0x00C0

Manufacturer=0x001F// ATMEL manufacturer Id

base_address=0x01000000 // base address of the flash

Load_address=0x01000000 // download address of the binary file

Sector=40 // number of sector of the flash

Sect_type0=8 // number of first sectors SA0 to SA7

Size_type0=8 // Size of the first sectors in K byte

Sect_type1=2 // number of next sectors SA8 and SA9

Size_type1=32 // Size of sectors in K byte

Sect_type2=30 // number of next sectors SA10 to SA39

Size_type2=64 // Size of sectors in K byte

[END_OF_FILE]

AT91 Host Flash Loader

2640A–ATARM–08/02

Example of Loader.ini

File for AT91FR4081

The example file is also valid for an AT91 with an embedded AT49BV8011. This file is

provided by Atmel.

[MODE]

Manual=0 // automatic load, all commands are managed by HOST Loader

[COM]

Name=COM1 // COM1 serial port

Synchronization_baud=1200 // Synchronization baud rate

Transfer_baud=115200 // Transfer baud rate

Target_CD=18 // AT91 CD value for a baud rate of 115200

// Main Clock = 32.678MhZ => CD = 18

// Main Clock = 25Mhz => CD = 13

[FILE] // name of the binary file to download

Name=C:\At91\software\projects\led_blink_eb40\flash\led_blink.bin

[FLASH]

Name=AT49BV8011 // flash type is AT49BV8011

Type=0x004A

Manufacturer=0x001F

base_address=0x01000000 // base address of the flash

Load_address=0x01000000 // download address of the binary file

Sector=22 // number of sector of the flash

Sect_type0=1 // number of first sectors SA0

Size_type0=16 // Size of the first sectors in K byte

Sect_type1=1 // number of next sectors SA1

Size_type1=32 // Size of sectors in K byte

Sect_type2=4 // number of next sectors SA2 to SA5

Size_type2=8 // Size of sectors in K byte

Sect_type3=1 // number of next sectors SA6

Size_type3=32 // Size of sectors in K byte

Sect_type4=1 // number of next sectors SA7

Size_type4=16 // Size of sectors in K byte

Sect_type5=14 // number of next sectors SA8 to SA21

Size_type5=64 // Size of sectors in K byte

[END_OF_FILE]

6AT91 Host Flash Loader

2640A–ATARM–08/02

Host Loader Software

User Notes

The download procedure is as follows:

1. If an AT91 with an AT49BV8011 Flash memory is used, copy Loader8011.ini to

Loader.ini.

If an AT91 with an AT4916x4 Flash memory is used, copy Loader16x4.ini to

Loader.ini.

2. Modify the [FILE] field. Set the name of the binary file as follows:

[FILE]

Name=C:\At91\software\projects\

"your project\your binary file name"

3. Connect the AT91-based system through a serial cable to the computer's COM1.

4. Power-up or reset the system to launch Flash_uploader.

5. Launch AT91Loader.exe on your computer.

The window below should appear:

When the computer's serial COM1 is synchronized with the USART of the AT91,

Flash programming begins.

If the download is successful, the following window appears:

If the download is unsuccessful, the following window appears:

AT91 Host Flash Loader

2640A–ATARM–08/02

Troubleshooting In case of failure, the following points should be verified:

• Hardware

– AT91 and Flash supplies are correctly connected

– NCS0 is connected to NCSF

– NWAIT is pulled-up and not driven always to 0

– NRST is connected to a reliable reset circuitry

– NRSTF is connected to a reliable reset circuitry (we suggest to connect it

directly to NRST)

– BMS is connected to 0

– NTRI is pulled-up

•Software

– Loader.ini contains the correct memory mapping

– Serial port selected is the one connected to serial cable (COM1 or COM2)

– File name path is correct

–Target_CD corresponds to CD chosen based on the table “AT91 USART

Speed Definition” on page 8

– Transfer_baud corresponds to Target_CD

– File downloaded is a pure binary image file (file extension .mem/ .rom/ .bin)

– The computer's serial port is not already being used

8AT91 Host Flash Loader

2640A–ATARM–08/02

AT91 USART Speed

Definition

The baud rate parameter is selected depending on microprocessor frequency. It is

entered as the value of target_CD in the loader.ini file.

The following table is used to select the most reliable baud rate according to the fre-

quency of the AT91-based system. Note that in asynchronous mode, maximum error

must not be greater than 5%.

USART Baud Rate = MCKI/CD x 16

MCKI (MHz) Baud Max (Bits/s) Standard (Bits/s) CD Real CD Choice Real (Bits/s) Error %

3 686 400 230 400 115 200 2.00 2 115 200.00 0.00%

4 915 200 307 200 115 200 2.67 3 102 400.00 12.50%

5 000 000 312 500 115 200 2.71 3 104 166.67 10.59%

6 000 000 375 000 115 200 3.26 3 125 000.00 7.84%

6 144 000 384 000 115 200 3.33 3 128 000.00 10.00%

7 372 800 460 800 115 200 4.00 4 115 200.00 0.00%

8 000 000 500 000 115 200 4.34 4 125 000.00 7.84%

10 738 635 671 165 115 200 5.83 6 111 860.78 2.99%

12 000 000 750 000 115 200 6.51 7 107 142.86 7.52%

12 288 000 768 000 115 200 6.67 7 109 714.29 5.00%

14 318 180 894 886 115 200 7.77 8 111 860.78 2.99%

14 745 600 921 600 115 200 8.00 8 115 200.00 0.00%

15 000 000 937 500 115 200 8.14 8 117 187.50 1.70%

18 432 000 1 152 000 115 200 10.00 10 115 200.00 0.00%

24 000 000 1 500 000 115 200 13.02 13 115 384.62 0.16%

24 576 000 1 536 000 115 200 13.33 13 118 153.85 2.50%

25 000 000 1 562 500 115 200 13.56 14 111 607.14 3.22%

32 000 000 2 000 000 115 200 17.36 17 117 647.06 2.08%

32 768 000 2 048 000 115 200 17.78 18 113 777.78 1.25%

40 000 000 2 500 000 115 200 21.70 22 113 636.36 1.38%

Printed on recycled paper.

Atmel Corporation makes no warranty for the use of its products, other than those expressly contained in the Company’s standard warranty

which is detailed in Atmel’s Terms and Conditions located on the Company’s web site. The Company assumes no responsibility for any errors

which may appear in this document, reserves the right to change devices or specifications detailed herein at any time without notice, and does

not make any commitment to update the information contained herein. No licenses to patents or other intellectual property of Atmel are granted

by the Company in connection with the sale of Atmel products, expressly or by implication. Atmel’s products are not authorized for use as critical

components in life support devices or systems.

Atmel Headquarters Atmel Operations

Corporate Headquarters

2325 Orchard Parkway

San Jose, CA 95131

TEL 1(408) 441-0311

FAX 1(408) 487-2600

Europe

Atmel Sarl

Route des Arsenaux 41

Case Postale 80

CH-1705 Fribourg

Switzerland

TEL (41) 26-426-5555

FAX (41) 26-426-5500

Asia

Room 1219

Chinachem Golden Plaza

77 Mody Road Tsimhatsui

East Kowloon

Hong Kong

TEL (852) 2721-9778

FAX (852) 2722-1369

Japan

9F, Tonetsu Shinkawa Bldg.

1-24-8 Shinkawa

Chuo-ku, Tokyo 104-0033

Japan

TEL (81) 3-3523-3551

FAX (81) 3-3523-7581

Memory

2325 Orchard Parkway

San Jose, CA 95131

TEL 1(408) 441-0311

FAX 1(408) 436-4314

Microcontrollers

2325 Orchard Parkway

San Jose, CA 95131

TEL 1(408) 441-0311

FAX 1(408) 436-4314

La Chantrerie

BP 70602

44306 Nantes Cedex 3, France

TEL (33) 2-40-18-18-18

FAX (33) 2-40-18-19-60

ASIC/ASSP/Smart Cards

Zone Industrielle

13106 Rousset Cedex, France

TEL (33) 4-42-53-60-00

FAX (33) 4-42-53-60-01

1150 East Cheyenne Mtn. Blvd.

Colorado Springs, CO 80906

TEL 1(719) 576-3300

FAX 1(719) 540-1759

Scottish Enterprise Technology Park

Maxwell Building

East Kilbride G75 0QR, Scotland

TEL (44) 1355-803-000

FAX (44) 1355-242-743

RF/Automotive

Theresienstrasse 2

Postfach 3535

74025 Heilbronn, Germany

TEL (49) 71-31-67-0

FAX (49) 71-31-67-2340

1150 East Cheyenne Mtn. Blvd.

Colorado Springs, CO 80906

TEL 1(719) 576-3300

FAX 1(719) 540-1759

Biometrics/Imaging/Hi-Rel MPU/

High Speed Converters/RF Datacom

Avenue de Rochepleine

BP 123

38521 Saint-Egreve Cedex, France

TEL (33) 4-76-58-30-00

FAX (33) 4-76-58-34-80

e-mail

literature@atmel.com

Web Site

http://www.atmel.com

2640A–ATARM–08/02 0M

AT M E L ®is the trademark of Atmel.

Windows®,Microsoft

®and Visual Studio®are the registered trademarks of Microsoft Corporation. ARM Pow-

ered is the registered trademark of ARM Ltd.; ARM7TDMI™is the trademark of ARM Ltd. Other terms and

product names may be the trademarks of others.

Autres manuels pour AT91 ARM Thumb

Table des matières

Autres manuels Atmel Microcontrôleur

Atmel

Atmel ARIS+ AT88SC-ADK2 Manuel utilisateur

Atmel

Atmel AT01607 Instructions d'installation et d'utilisation

Atmel

Atmel ATmega128 Manuel utilisateur

Atmel

Atmel AVR1014 Manuel utilisateur

Atmel

Atmel ATmega324PB Manuel utilisateur

Atmel

Atmel AT90PWM2 Manuel utilisateur

Atmel

Atmel AVR1019 Instructions d'installation et d'utilisation

Atmel

Atmel AVR943 Manuel utilisateur

Atmel

Atmel AVR XMEGA AU series Manuel utilisateur

Atmel

Atmel CAP AT91CAP7X-DK Manuel utilisateur

Atmel

Atmel ATmega328PB Xplained Mini Instructions d'installation et d'utilisation

Atmel

Atmel AT91 Series Manuel utilisateur

Atmel

Atmel AVR AT90S4434 Manuel utilisateur

Atmel

Atmel AVR1306 Manuel utilisateur

Atmel

Atmel 80C51 Instructions d'installation et d'utilisation

Atmel

Atmel AT91CAP9A-DK Manuel utilisateur

Atmel

Atmel AT89RFD-10/EVLB002 Manuel utilisateur

Atmel

Atmel megaAVR Manuel utilisateur

Atmel

Atmel AT89C51 Guide de l'utilisateur

Atmel

Atmel AT90S2313 Manuel utilisateur

Atmel

Atmel UC3-L0 Xplained Instructions d'installation et d'utilisation

Atmel

Atmel AT91 Series Instructions d'installation et d'utilisation

Atmel

Atmel AVR ATtiny10 Series Manuel utilisateur

Atmel

Atmel SAM L21 Xplained Pro Manuel utilisateur

Manuels Microcontrôleur populaires d'autres marques

AMS

AMS AS7261 Demo Kit Manuel utilisateur

Novatek

Novatek NT6861 Manuel utilisateur

Espressif Systems

Espressif Systems ESP8266 SDK Guide de configuration

Nuvoton

Nuvoton ISD61S00 ChipCorder Mode d’emploi

STMicrolectronics

STMicrolectronics ST7 Assembler Linker Manuel utilisateur

Texas Instruments

Texas Instruments Chipcon CC2420DK Manuel utilisateur

Lantronix

Lantronix Intrinsyc Open-Q 865XR SOM Manuel utilisateur

NEC

NEC 78GK0S/K 1+ Series Instructions d'installation et d'utilisation

Mikroe

Mikroe SEMITECH N-PLC Click Instructions d'installation et d'utilisation

Intel

Intel Agilex Manuel utilisateur

Cypress

Cypress CY4607 HX2VL Manuel utilisateur

DIGITAL-LOGIC

DIGITAL-LOGIC MICROSPACE Manuel utilisateur

Texas Instruments

Texas Instruments TMS320F2837 D Series Manuel utilisateur

CYPRES

CYPRES CY14NVSRAMKIT-001 Manuel utilisateur

Texas Instruments

Texas Instruments INA-DUAL-2AMP-EVM Manuel utilisateur

Espressif Systems

Espressif Systems ESP8266EX Mode d'emploi

Abov

Abov AC33M8128L Manuel utilisateur

Laird

Laird BL654PA Manuel utilisateur
