Atmel AT88CK109BK8 Manuel d'installation

8742A–CRYPTO–3/11

Atmel CryptoAuthentication Starter Kit

Atmel AT88CK109BK8

Hardware User Guide

Features

Two 8-lead SOIC sockets

Supports the Atmel ATSHA204 CryptoAuthentication IC

Supports communication protocols

-I2C

-SWI (Single wire interface)

Power LEDs

Contents

Atmel AT88CK109BK8 daughterboard

1. Introduction

Atmel®AT88CK101BK8 is a daughterboard that interfaces with a mcu board via a 10-pin header. The

daughterboard has two 8-pin SOIC sockets which can support HOST and CLIENT development with an

Atmel ATSHA204 device. This kit uses a modular approach, enabling the daughterboard to connect

directly to an STK series AVR development platform to easily add security to applications. An optional

adapter kit is also available when the 10-pin header on the daughterboard requires a different pinout. The

AT88CK109BK8 is sold with the Atmel AT88Microbase to form the Atmel AT88CK109STK8 starter kit. The

AT88Microbase AVR base board comes with a USB interface that lets designers learn and experiment on

their PCs.

Figure 1-1. Atmel AT88CK109BK8 daughterboard

Pin 1 indicator

Standoff hole

2Atmel AT88CK109BK8 Hardware User Guide

8742A–CRYPTO–3/11

1.2. Atmel AT88CK109STK8 starter kit

The AT88CK109BK8 is sold with the AT88Microbase to form the AT88CK109STK8 starter kit. For

additional information on the AT88Microbase, see Atmel doc8723A, AT88Microbase Hardware User Guide.

Figure 1-2. The AT88CK109BK8 adaptor board with the Atmel AT88Microbase

2. Board configuration

2.1. 10-pin interface header

Table 2-1. 10-pin interface header

P10

VCC

GND

SDA

SCL

Note: I2C Pins: SCL, SDA

2.2. Supports 8-lead SOIC interface with the following pinout

Figure 2-1. Pinout configuration

GND

8-lead SOIC VCC

SCL

SDA

Atmel AT88CK109BK8 Hardware User Guide 3

8742A–CRYPTO–3/11

2.3. AT88CK301ADP adapter kit

An optional adapter kit is also available when the 10-pin header on the daughterboard requires a different

pinout.

Figure 2-2. Atmel AT88CK301ADP adapter kit

Table 2-2. 10-pin squid cable

10-pin squid cable

P10

black

white

gray

purple

blue

green

yellow

orange

red

brown

4Atmel AT88CK109BK8 Hardware User Guide

8742A–CRYPTO–3/11

3. References and further information

Schematics, Gerber files, bill of materials (BOM), development and demonstration software are

conveniently downloadable from the Atmel website at www.atmel.com/cryptokits.

4. EVALUATION BOARD/KIT IMPORTANT NOTICE

This evaluation board/kit is intended for ENGINEERING, DEVELOPMENT, DEMONSTRATION or

EVALUATION PURPOSE ONLY. It is not a finished product and may not (yet) comply with some or

any technical or legal requirements that are applicable to finished products, including, without limitations,

directives regarding electromagnetic compatibility, recycling (WEEE), FCC, CE or UL (except as may be

otherwise noted on the board/kit). Atmel®supplied this board/kit “AS IS,” without any warranties, with

all faults, at the buyer’s and further users’ sole risk. The user assumes all responsibly and liability for

proper and safe handling of goods. Further, the user indemnifies Atmel from claims arising from the

handling or use of goods. Due to open construction of the product, it is the user’s responsibility to take

any and all appropriate precautions with regard to electrostatic discharge and any other technical or legal

concerns.

EXCEPT TO THE EXTENT OF INDEMNITY SET FORTH ABOVE, NEITHER USER NOR ATMEL SHALL BE

LIABLE TO EACH OTHER FOR ANY INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES.

No license is granted under any patent right or other intellectual property right of Atmel covering or

relating to any machine, process, or combination in which such Atmel product or services might be or are

used.
