Asus FX-D1162 Manuel utilisateur
English
First Edition / May 2009
Copyright © 2009 ASUSTeK COMPUTER INC. All Rights Reserved.
E4581
FX-D1162
16-Port 10/100Mbps Switch
Quick Start Guide
®
Book FX-D1162.indb 1 5/8/09 6:26:10 PM
ASUS REACH
Complying with the REACH (Registration, Evaluation, Authorisation, and
Restriction of Chemicals) regulatory framework, we published the chemical
substances in our products at ASUS REACH website at http://green.asus.com/
english/REACH.htm.
Federal Communications Commission Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference that
may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class A
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference when the equipment
is operated in a commercial environment. This equipment generates, uses,
and can radiate radio frequency energy, and if it is not installed and used in
accordance with the instruction manual, it may cause harmful interference to
radio communications. Operation of this equipment in a residential area is likely to
cause harmful interference, in which case the user will be required to correct the
interference at his own expense.
CE Mark Warning
This is a Class A product, in a domestic environment, this product may cause radio
interference, in which case the user may be required to take adequate measures.
Notices
Book FX-D1162.indb 2 5/8/09 6:26:10 PM
English
Index
1. English..................................................................1
2. Български ...............................................................9
3. Česky..................................................................14
4. Nederlands .........................................................19
5. Eesti....................................................................24
6. Français..............................................................29
7. Suomi .................................................................34
8. Deutsch ..............................................................39
9. Ελληνικά............................................................44
10. Magyar................................................................49
11. Italiano ................................................................54
11. Latviski................................................................59
12. Lietuvių ...............................................................64
13. Bahasa Malaysia ................................................69
14. Polski .................................................................74
15. Português ...........................................................79
16. Русский ...............................................................84
17. Română..............................................................89
18. Slovenščina ........................................................94
19. Español...............................................................99
20. Українська ..........................................................104
Book FX-D1162.indb 3 5/8/09 6:26:10 PM
4Quick Start Guide
English
Knowing your switch
Package contents
ASUS FX-D1162 x 1
Power adapter x 1
Quick Start Guide x 1
VIP Member card x 1
If any of the items is damaged or missing, contact your retailer.
Features
16 10/100Mbps auto-detect half/Full duplex switch ports
LAN1 & LAN2 default VIP, top priority ports
Up to 200Mbps for all ports in full duplex mode
Plug-and-play: Auto MDI/MDX and auto-sensing for speed and duplex mode
on all ports
Flow control schemes (802.3x in full duplex mode) to support zero loss under
temporary network congestion
4K MAC address learning and aging
Support Store and Forward architecture
Buffer memory: 203KB
Switch Fabric: 3.2Gbps
Pack Forwarding (10Mbps port): 14,880 packets/sec
(100Mbps port): 148,880 packets/sec
Green Network Technology: advanced power saving function
Technical specications
Dimension (approximate) 185 x 124 x 45 mm(L x W x H)
Net Weight (approximate) 772 g
Power Supply DC 12V 1A Switching adaptor
Temperature Operating: 0°C to 40°C (32°F to 104ºF)
Storage: 0° to 70° C (32°F to 158°F)
Humidity Operating: 10% to 90% RH (Non-condensing)
Storage: 5% to 95% RH (Non-condensing)
Certication CE / FCC / LVD
•
•
•
•
•
•
•
•
•
•
•
Book FX-D1162.indb 4 5/8/09 6:26:11 PM
Quick Start Guide 5
English
Front panel features
The front panel includes the LED indicators that show the real-time status of the
switch.
LED indicators
Item LED Status Description
Power Green ON The switch is ON.
OFF The switch is OFF.
Status Green ON A valid link is established.
Blinking Receiving or transmitting data packets.
Rear panel features
The rear panel includes Ethernet ports and the DC In input port.
Book FX-D1162.indb 5 5/8/09 6:26:13 PM
6Quick Start Guide
English
The mounting brackets, screws, and rack mount screws are purchased separately.
Getting started
Placement options
• DO NOT place any device on top of the switch.
• Leave enough space around the switch for adequate ventilation. Ensure that the switch
isplacedinalocationthatmeetstheenvironmentalspecications.RefertoTechnical
specications on page 2 for more details.
Desktop placement
Puttheswitchonaatandstablesurface.
Mounting the switch on a rack
To mount the switch on a rack:
1. Locate the four screw holes on both sides of the switch.
2. Align the mounting brackets with the switch screw holes.
3. Secure the mounting brackets with screws.
4. Place the switch in the rack, then secure both sides with rack mount screws.
Book FX-D1162.indb 6 5/8/09 6:26:15 PM
Quick Start Guide 7
English
Connecting network devices
To connect network devices to the switch:
1. Connect one end of the Ethernet cable to an Ethernet port on the switch
front panel. Connect the other end to the Ethernet port of the network device.
Repeat this step to connect additional network devices.
2. Connect one end of the power cable to the power connector on the switch rear
panel, then connect the other end to a power outlet.
The Power LED and LAN LED indicators for active Ethernet ports light up when
the switch is powered on and active nodes are connected to the LAN ports.
• Use Category 5 Ethernet straight-through cables to ensure proper connections between
the switch and other network devices.
• You can use either cross-over or straight-through cables to connect other network
devices such as bridges, switches, hubs, and repeaters.
Notebook
1 2
Desktop Router
Server
R
AX112W
VOIP Router
Book FX-D1162.indb 7 5/8/09 6:26:18 PM
8Quick Start Guide
English
Problem Solution
The POWER LED does not light up. Check if the power cable is properly
connected to the switch and to a power
outlet with a correct voltage output.
The STATUS LED does not light
up even after a network device is
connected to the port.
Check if the Ethernet cable is properly
connected to the switch and to the
network device.
Ensure that the switch and your network
device are powered on.
Check if the Ethernet cable meets your
network requirements. To connect a
gigabit switch port, you need a Category
5 cable to get gigabit transfer speed.
Troubleshooting
Book FX-D1162.indb 8 5/8/09 6:26:18 PM
Кратко упътване за бърз старт
Български
Съдържание на пакета
• ASUS FX-D1162 x 1
• Токов адаптер x 1
• Кратко упътване за бърз старт x 1
• Карта за VIP членство x 1
Свържете се с Вашия търговски представител ако някое от тези неща липсва или е
повредено.
Характеристики
• 16 10/100Mbps, автоматично откриване, портове на суича с полудуплекс/пълен дуплекс
• LAN1 & LAN2 default VIP, портове с висок приоритет
• Plug-and-play (Включване на устройство в системата, при което тя автоматично
го разпознава и конфигурира): Автоматични настройки MDI/MDIX и автоматично
разпознаване за всички портове при скоростен режим и режим дуплекс .
• Схеми за контролиране на потока от данни (802.3x при режим на пълен достъп) за
нулеви загуби при временно претоварване на системата.
• Поддържа 4K MAC Address Learning & Aging
• Поддържа архитектура за съхраняване и препращане
• Памет на буфера: 203KB
• Switch Fabric: 3.2Gbps
• Препращане на пакети (порт 10Mbps): 14,880 пакета/сек
(порт 100Mbps): 14,8880 пакета/сек
• Технология Green Network (Зелена мрежа): разширена енергоспестяваща функция
Технически характеристики
Размери
(приблизителни)185 x 124 x 45 mm(L x W x H)
Нетно тегло
(приблизително) 772 g
Адаптер DC 12V 1A превключващ адаптер
Температура Работна:От 0°C до 40°C (от 32°F до 104°F)
Съхранение: От 0°C до 70°C (от 32°F до 158°F)
Влажност От 10% до 0% относителна влажност (Без кондензация)
Сертификати CE/FCC/LVD
Запознаване със суича
Book FX-D1162.indb 9 5/8/09 6:26:19 PM
10 Кратко упътване за бърз старт
Български
Хардуер
Преден панел
Предният панел има индикатори, които показват статуса в реално време на суича.
Индикатори
Индикатори Цвят Статус Описание
ЗАХРАНВАНЕ Зелено ВКЛ. Суичът е ВКЛЮЧЕН.
ИЗКЛЮЧЕН Суичът е ИЗКЛЮЧЕН.
Статус Зелено ВКЛ. Установена е валидна връзка.
Мига Получава и предава пакети с данни.
Заден панел
Задният панел има Ethernet портове и DC IN вход
Book FX-D1162.indb 10 5/8/09 6:26:20 PM
