Asus RT-ACRH13 Manuel utilisateur

User Guide

RT-ACRH13

Wireless-AC1300 Dual Band Gigabit Router

No part of this manual, including the products and software described

in it, may be reproduced, transmitted, transcribed, stored in a retrieval

system, or translated into any language in any form or by any means, except

documentation kept by the purchaser for backup purposes, without the

express written permission of ASUSTeK Computer Inc. (“ASUS”).

Product warranty or service will not be extended if: (1) the product is repaired,

modied or altered, unless such repair, modication of alteration is authorized

in writing by ASUS; or (2) the serial number of the product is defaced or

missing.

ASUS PROVIDES THIS MANUAL “AS IS”WITHOUT WARRANTY OF ANY KIND,

EITHER EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED

WARRANTIES OR CONDITIONS OF MERCHANTABILITY OR FITNESS FOR A

PARTICULAR PURPOSE. IN NO EVENT SHALL ASUS, ITS DIRECTORS, OFFICERS,

EMPLOYEES OR AGENTS BE LIABLE FOR ANY INDIRECT, SPECIAL, INCIDENTAL,

OR CONSEQUENTIAL DAMAGES (INCLUDING DAMAGES FOR LOSS OF PROFITS,

LOSS OF BUSINESS, LOSS OF USE OR DATA, INTERRUPTION OF BUSINESS

AND THE LIKE), EVEN IF ASUS HAS BEEN ADVISED OF THE POSSIBILITY OF

SUCH DAMAGES ARISING FROM ANY DEFECT OR ERROR IN THIS MANUAL OR

PRODUCT.

SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUAL ARE

FURNISHED FOR INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGE

AT ANY TIME WITHOUT NOTICE, AND SHOULD NOT BE CONSTRUED AS A

COMMITMENT BY ASUS. ASUS ASSUMES NO RESPONSIBILITY OR LIABILITY

FOR ANY ERRORS OR INACCURACIES THAT MAY APPEAR IN THIS MANUAL,

INCLUDING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT.

Products and corporate names appearing in this manual may or may not be

registered trademarks or copyrights of their respective companies, and are used

only for identication or explanation and to the owners’benet, without intent

to infringe.

E11649

Revised Edition V2

June 2016

Table of contents

1 Getting to know your wireless router

1.1 Welcome! ........................................................................................6

1.2 Package contents.........................................................................6

1.3 Your wireless router.....................................................................7

1.4 Positioning your router..............................................................9

1.5 Setup Requirements ................................................................ 10

1.6 Router Setup............................................................................... 11

1.6.1 Wired connection..................................................................11

1.6.2 Wireless connection.............................................................12

2 Getting started

2.1 Logging into the Web GUI ..................................................... 14

2.2 Quick Internet Setup (QIS) with Auto-detection ........... 15

2.3 Connecting to your wireless network................................ 18

3 Conguring the General settings

3.1 Using the Network Map ......................................................... 19

3.1.1 Setting up the wireless security settings......................20

3.1.2 Managing your network clients.......................................21

3.1.3 Monitoring your USB device.............................................22

3.2 Creating a Guest Network...................................................... 25

3.3 Using the Trac Manager ...................................................... 27

3.3.1 Managing QoS (Quality of Service) Bandwidth..........27

3.3.2 Monitoring Trac .................................................................30

3.4 Setting up Parental Control................................................... 31

3.5 Using the USB Application..................................................... 32

3.5.1 Using AiDisk ............................................................................32

3.5.2 Using Servers Center............................................................34

3.5.3 3G/4G ........................................................................................39

Table of contents

3.6 Using AiCloud............................................................................. 41

3.6.1 Cloud Disk................................................................................42

3.6.2 Smart Access...........................................................................44

3.6.3 Smart Sync...............................................................................45

4 Conguring the Advanced Settings

4.1 Wireless......................................................................................... 46

4.1.1 General......................................................................................46

4.1.2 WPS ............................................................................................49

4.1.3 Wireless MAC Filter...............................................................51

4.1.4 RADIUS Setting ......................................................................52

4.1.5 Professional.............................................................................53

4.2 LAN................................................................................................. 55

4.2.1 LAN IP ........................................................................................55

4.2.2 DHCP Server............................................................................56

4.2.3 Route .........................................................................................58

4.2.4 IPTV ............................................................................................59

4.3 WAN ............................................................................................... 60

4.3.1 Internet Connection.............................................................60

4.3.2 Port Trigger..............................................................................63

4.3.3 Virtual Server/Port Forwarding........................................64

4.3.4 DMZ............................................................................................68

4.3.5 DDNS .........................................................................................69

4.3.6 NAT Passthrough...................................................................70

4.4 IPv6................................................................................................. 71

4.5 Firewall.......................................................................................... 72

4.5.1 General......................................................................................72

4.5.2 URL Filter ..................................................................................72

4.5.3 Keyword lter .........................................................................73

4.5.4 Network Services Filter .......................................................74

Table of contents

4.6 Administration ........................................................................... 76

4.6.1 Operation Mode ....................................................................76

4.6.2 System.......................................................................................77

4.6.3 Firmware Upgrade................................................................78

4.6.4 Restore/Save/Upload Setting ...........................................78

4.7 System Log .................................................................................. 79

5 Utilities

5.1 Device Discovery....................................................................... 80

5.2 Firmware Restoration .............................................................. 81

5.3 Setting up your printer server .............................................. 82

5.3.1 ASUS EZ Printer Sharing .....................................................82

5.3.2 Using LPR to Share Printer .................................................86

5.4 Download Master...................................................................... 91

5.4.1 Conguring Bit Torrent download settings.................92

5.4.2 NZB settings............................................................................93

6 Troubleshooting

6.1 Basic Troubleshooting............................................................. 94

6.2 Frequently Asked Questions (FAQs) .................................. 97

Appendices

Notices .....................................................................................................106

ASUS Contact information..................................................................120

Networks Global Hotline Information.............................................121

1 Getting to know your wireless

router

NOTES:

• Ifanyoftheitemsaredamagedormissing,contactASUSfor

technical inquiries and support, Refer to the ASUS Support Hotline

list at the back of this user manual.

• Keeptheoriginalpackagingmaterialincaseyouwouldneedfuture

warranty services such as repair or replacement.

Network cable (RJ-45)

Quick Start Guide

RT-ACRH13 Wireless Router

Power adapter

Support CD (User Manual)

1.1 Welcome!

Thank you for purchasing an ASUS RT-ACRH13 Wireless Router!

The ultra-thin and stylish RT-ACRH13 features both 2.4GHz and

5GHz dual bands which delivers super fast gigabit wireless-AC

speeds up to 867 Mbps on the 5 GHz band & 300 Mbps on the 2.5

GHz band concurrently.

1.2 Package contents

1.3 Your wireless router

1Power LED

O: No power.

On: Device is ready.

Flashing slow: Rescue mode

Flashing quick:WPS is processing.

2WAN (Internet) LED

O: No power or no physical connection.

On: Has physical connection to a wide area network (WAN).

32.4GHz LED / 5GHz LED

O: No 2.4 GHz or 5 GHz signal.

On:Wireless system is ready.

Flashing:Transmitting or receiving data via wireless connection.

4USB LED

O: No power or no physical connection.

On: Has physical connection to USB device.

5USB 3.0 port

Insert a USB device such as USB hard disk or USB flash drive into the port.

Insert your iPad’s USB cable into the port to charge your iPad.

6LAN LED

O: No power or no physical connection.

On: Has physical connection to a local area network (LAN).

NOTES:

• Useonlytheadapterthatcamewithyourpackage.Usingother

adapters may damage the device.

•Specications:

DC Power adapter DC Output: +12V with max 1.5A current;

Operating

Temperature 0~40oCStorage 0~70oC

Operating Humidity 50~90% Storage 20~90%

7Reset button

This button resets or restores the system to its factory default settings.

8Power button

Press this button to power on or off the system.

9Power (DC-IN) port

Insert the bundled AC adapter into this port and connect your router to a power source.

10 LAN 1 ~ 4 ports

Connect network cables into these ports to establish LAN connection.

11 WAN (Internet) port

Connect a network cable into this port to establish WAN connection.

12 WPS button

This button launches the WPS Wizard.

1.4 Positioning your router

For the best wireless signal transmission between the wireless

router and the network devices connected to it, ensure that you:

• Placethewirelessrouterinacentralizedareaforamaximum

wireless coverage for the network devices.

• Keepthedeviceawayfrommetalobstructionsandawayfrom

direct sunlight.

• Keepthedeviceawayfrom802.11b/gor20MHzonlyWi-Fi

devices, 2.4GHz computer peripherals, Bluetooth devices,

cordlessphones,transformers,heavy-dutymotors,fluorescent

lights, microwave ovens, refrigerators, and other industrial

equipment to prevent signal interference or loss.

• Alwaysupdatetothelatestfirmware.VisittheASUSwebsiteat

http://www.asus.com to get the latest firmware updates.

• Toensurethebestwirelesssignal,orientthefourantennasas

shown in the drawing below.

45°45°

1.5 Setup Requirements

To set up your wireless network, you need a computer that meets

the following system requirements:

• EthernetRJ-45(LAN)port(10Base-T/100Base-TX/1000Base-

TX)

• IEEE802.11a/b/g/n/acwirelesscapability

• AninstalledTCP/IPservice

• WebbrowsersuchasInternetExplorer,Firefox,Safari,or

Google Chrome

NOTES:

• Ifyourcomputerdoesnothavebuilt-inwirelesscapabilities,youmay

install an IEEE 802.11a/b/g/n/ac WLAN adapter to your computer to

connect to the network.

• Withitsdualbandtechnology,yourwirelessroutersupports2.4GHz

and 5GHz wireless signals simultaneously. This allows you to do

Internet-related activities such as Internet surng or reading/writing

e-mail messages using the 2.4GHz band while simultaneously

streaming high-denition audio/video les such as movies or music

using the 5GHz band.

• SomeIEEE802.11ndevicesthatyouwanttoconnecttoyournetwork

may or may not support 5GHz band. Refer to the device's manual for

specications.

• TheEthernetRJ-45cablesthatwillbeusedtoconnectthenetwork

devices should not exceed 100 meters.

Autres manuels pour RT-ACRH13

Table des matières

Autres manuels Asus Routeur réseau

Asus

Asus DSL-X11 Manuel utilisateur

Asus

Asus DSL-AC88U Manuel utilisateur

Asus

Asus Republic of Gamers Rapture GT-AX11000 Manuel utilisateur

Asus

Asus WL-500gP V2 Manuel utilisateur

Asus

Asus RT-AC57U Manuel utilisateur

Asus

Asus DSL-N55U Manuel d'instructions

Asus

Asus RT-N65U Manuel utilisateur

Asus

Asus RT-AX86U Manuel utilisateur

Asus

Asus RT-AC68W Manuel utilisateur

Asus

Asus AAM6030EV Manuel

Asus

Asus RT-AC2600 Manuel utilisateur

Asus

Asus ROG STRIX GS-AX3000 Manuel utilisateur

Asus

Asus RT-AC88U Manuel utilisateur

Asus

Asus ZenWiFi XD5 Manuel utilisateur

Asus

Asus WL-500gP Manuel utilisateur

Asus

Asus WL-530G Manuel utilisateur

Asus

Asus RT-AC55U Manuel utilisateur

Asus

Asus TUF Gaming AX4200 Manuel utilisateur

Asus

Asus ROG Rapture GT-BE98 Pro Manuel utilisateur

Asus

Asus RT-AC1900P Manuel utilisateur

Asus

Asus RT-AC1200GE Manuel utilisateur

Asus

Asus Wireless-N300 Manuel utilisateur

Asus

Asus RT-AC66U Manuel utilisateur

Asus

Asus 90IG0560-MO3G10 Manuel utilisateur

Manuels Routeur réseau populaires d'autres marques

Allnet

Allnet ALL0333AU Manuel utilisateur

HomeSeer

HomeSeer HT-SEL Manuel utilisateur

Sercomm

Sercomm Genesis OC3505D Manuel utilisateur

Billion

Billion BIPAC 5102 Series Manuel utilisateur

TP-Link

TP-Link TD-8817 Manuel utilisateur

Motorola

Motorola MR1900 Manuel utilisateur

Digi

Digi IX14 Manuel utilisateur

Cisco

Cisco NCS 540 Manuel

XAVi

XAVi X8821e Manuel utilisateur

BEC

BEC 6200WZL Manuel utilisateur

MikroTik

MikroTik hAP ac3 Series Manuel utilisateur

Korenix

Korenix JetNet 5428G Series Manuel utilisateur

NETGEAR

NETGEAR FS526T - Switch Manuel utilisateur

Korenix

Korenix JetNet 5710G Series Manuel utilisateur

Automated Logic

Automated Logic ZN551 Manuel du propriétaire

Cisco

Cisco ASR 1000 Series Manuel de l'opérateur

EnGenius

EnGenius ESR-9710 Manuel utilisateur

Cisco

Cisco 805 Series Instructions d'utilisation et de sécurité
