AAM6020VI ADSL Wireless Modem Router Quick Installation Guide

Page 1

Quick Installation Guide

ASUS®AAM6020VI

ADSL Wireless Modem Router

¾Do not open the housing!

¾Use only the power supply provided with this device.

¾Use only the cables provided with this device and do

not perform any modification on them.

Rev 1.0

Nov, 23, 2004

P/N: 15-0680980F0

AAM6020VI ADSL Wireless Modem Router Quick Installation Guide

Page 2

Before you begin

Before installing your ADSL wireless modem router, please carefully check the following

requirements with your computer. This ADSL wireless modem router is equipped with four

10/100Mbps RJ-45 Ethernet switch ports and 802.11g wireless Access Point. You can connect to the

modem by Ethernet or wireless interface.

Unpacking and Inspection

Verify following items came with your ADSL Modem:

AAM6020VI unit

RJ-11 ADSL phone cable

RJ-45 UTP cable

Quick Installation Guide

Power adapter and splitter

Note: If any items are missing or damaged, please contact your local Sales Office for service.

System Requirements

IBM compatible, Macintosh or other OS-independent workstation supports TCP/IP.

An Ethernet port supports 10Mbps or 10/100Mbps TCP/IP connection on your PC.

For system configuration using the supplied web-based program: a web browser such

as Internet Explorer v5.5 or later

A wireless interface has installed properly on your PC, and it must support IEEE

802.11b or 802.11g wireless standard interface.

You can connect any one of modem four switch ports on the rear panel to PC NIC

Ethernet port. If you want to allow multiple computers (more than four PCs) to enjoy

internet through ADSL Modem, please purchase a hub/switch to link directly to

Ethernet port. You can contact your internet service provider to get more information

on this.

Caution:

1. If you want to use private Ethernet UTP cable linking between wireless modem

router with PC, please make sure that cable quality must conform to Cat.5

upward and cable’s length can’t exceed over 100 meters.

2. Please make sure that wireless modem router’s wireless signal could be accessed

by wireless interface on PC, and without any interference by electromagnetic

wave device or obstacle around the corner.

AAM6020VI ADSL Wireless Modem Router Quick Installation Guide

Page 3

Getting Started

Hardware Installation

Please follow the steps in the sequence outlined below. Fail to do so could result in damage of

your ADSL wireless modem.

Step 1: Connect a RJ-11 cable from wall phone jack to the connector “LINE” on the back of

the modem.

Step 2: Connect the AC adapter to the modem by inserting the barrel-shaped connector into the

mating power connector on the back of the modem, and plug in the adapter to a wall outlet

or a power strip.

Step 3: Connect any LAN port on the back of the modem with a UTP cable, and other end of

UTP cable directly link to RJ-45 port of your PC’s network card.

Step 4: Power on your PC and modem, now you are ready to configure PC.

Note: You can also use wireless interface to configure your modem, then please

directly proceed step 4 and make sure your wireless card driver has been installed

properly.

Caution: Please do not power on your PC and modem before connecting

steps are finished as mentioned above.

AAM6020VI ADSL Wireless Modem Router Quick Installation Guide

Page 4

1. Configuring Your Computers

1.1 Using Wired or Wireless Network Interface Card

Before you start to access AAM6020VI via Ethernet or Wireless, please configure your PC’s

TCP/IP address to be 192.168.1.x, where x could be any number between 2 to 254, subnet mask is

255.255.255.0, and Default gateway is 192.168.1.1 which is default IP address of ADSL modem.

Note:

By default, the router of modem’s DHCP server is enabled, you can obtain an IP address

automatically once you’ve configured your PC to “obtain an IP address automatically”.

If you have configured PC’s to DHCP client, it is not necessary to input IP address manually. But

you must make sure without two DHCP servers existing in the same LAN before your PC receive

IP.

Windows® XP PCs:

1. In the Windows task bar, click the Start button, and then click Control Panel.

2. Double-click the Network Connections icon.

3. In the LAN or High-Speed Internet window, right-click on icon corresponding to your network interface card

(NIC) and select Properties. (Often this icon is labeled Local Area Connection). The Local Area Connection

dialog box displays with a list of currently installed network items.

4. Ensure that the check box to the left of the item labeled Internet Protocol (TCP/IP) is checked, and click

AAM6020VI ADSL Wireless Modem Router Quick Installation Guide

Page 5

5. In the Internet Protocol (TCP/IP) Properties dialog box, click the radio button labeled Use the following IP

address and type 192.168.1.x (192.168.1.20 is shown below as an example), 255.255.255.0 and 192.168.1.1 in

the IP address field, Subnet Mask field and Default gateway, respectively.

TCP/IP Property @ Windows XP

6. Click twice to confirm your changes, and close the Control Panel.

Windows® 2000 PCs:

1. In the Windows task bar, click the Start button, point to Settings, and then click Control Panel.

2. Double-click the Network and Dial-up Connections icon.

3. In the Network and Dial-up Connections window, right-click the Local Area Connection icon,andthen

select Properties.

The Local Area Connection Properties dialog box displays with a list of currently installed network

components. If the list includes Internet Protocol (TCP/IP), the protocol has already been enabled, please skip

to step 10 directly.

4. If Internet Protocol (TCP/IP) does not display as an installed component, click .

5. In the Select Network Component Type dialog box, select Protocol, and then click .

6. Select Internet Protocol (TCP/IP) in the Network Protocols list, and then click .

You may be prompted to install files from your Windows 2000 installation CD or other media. Follow the

instructions to install the files.

7. If prompted, click to restart your computer with the new settings.

AAM6020VI ADSL Wireless Modem Router Quick Installation Guide

Page 6

8. After restarting your PC, double-click the Network and Dial-up Connections icon in the Control Panel.

9. In Network and Dial-up Connections window, right-click the Local Area Connection icon, and then select

Properties.

10. In the Local Area Connection Properties dialog box, select Internet Protocol (TCP/IP), and then click

11. In the Internet Protocol (TCP/IP) Properties dialog box, click the radio button labeled Use the following IP

address and type 192.168.1.x, 255.255.255.0 and 192.168.1.1 in the IP address field, Subnet Mask field and

Default gateway, respectively.

12. Click twice to confirm and save your changes, and then close the Control Panel.

Windows® Me PCs

1. In the Windows task bar, click the Start button, point to Settings, and then click Control Panel.

2. Double-click the Network and Dial-up Connections icon.

3. In the Network and Dial-up Connections window, right-click the Network icon, and then select Properties.

The Network Properties dialog box displays with a list of currently installed network components. If the list

includes Internet Protocol (TCP/IP), the protocol has already been enabled, please skip to step 11 directly.

4. If Internet Protocol (TCP/IP) does not display as an installed component, click .

5. In the Select Network Component Type dialog box, select Protocol, and then click .

6. Select Microsoft in the Manufacturers box.

7. Select Internet Protocol (TCP/IP) in the Network Protocols list, and then click .

You may be prompted to install files from your Windows Me installation CD or other media. Follow the

instructions to install the files.

8. If prompted, click to restart your computer with the new settings.

9. After restarting your PC, double-click the Network and Dial-up Connections icon in the Control Panel.

10. In Network and Dial-up Connections window, right-click the Network icon, and then select Properties.

11. In the Network Properties dialog box, select TCP/IP, and then click .

12. In the TCP/IP Settings dialog box, click the radio button labeled Use the following IP address and type

192.168.1.x, 255.255.255.0 and 192.168.1.1 in the IP address field, Subnet Mask field and Default gateway,

respectively.

13. Click twice to confirm and save your changes, and then close the Control Panel.

Windows® 95, 98 PCs:

1. In the Windows task bar, click the Start button, point to Settings, and then click Control Panel.

AAM6020VI ADSL Wireless Modem Router Quick Installation Guide

Page 7

2. Double-click the Network icon.

The Network dialog box displays with a list of currently installed network components. If the list includes

TCP/IP, the protocol has already been enabled. Please skip to step 9 directly.

3. If TCP/IP does not display as an installed component, click . Then Select Network Component

Type dialog box will display.

4. Select Protocol, and then click .

The Select Network Protocol dialog box displays.

5. Click on Microsoft in the Manufacturers list box, and then click TCP/IP in the Network Protocols list box.

6. Click to return to the Network dialog box, and then click again.

You may be prompted to install files from your Windows 95/98 installation CD. Follow the instructions to install

the files.

7. Click to restart the PC and complete the TCP/IP installation.

8. After restarting your PC, open the Control Panel window, and then click the Network icon.

9. Select the network component labeled TCP/IP, and then click .

If you have multiple TCP/IP listings, select the listing associated with your network card or adapter.

10. In the TCP/IP Properties dialog box, click the IP Address tab.

11. Click the radio button labeled Use the following IP address and type 192.168.1.x,255.255.255.0 and

192.168.1.1 in the IP address field, Subnet Mask field and Default gateway, respectively.

12. Click twice to confirm and save your changes. You will be prompted to restart Windows. Please

click and restart your PC again.

Windows® NT 4.0 workstations:

1. In the Windows NT task bar, click the Start button, point to Settings, and then click Control Panel.

2. In the Control Panel window, double click the Network icon.

3. In the Network dialog box, click the Protocols tab.

The Protocols tab displays a list of currently installed network protocols. If the list includes TCP/IP, the protocol

has already been enabled. Please skip to step 9 directly.

4. If TCP/IP does not display as an installed component, click .

5. In the Select Network Protocol dialog box, select TCP/IP, and then click .

You may be prompted to install files from your Windows NT installation CD or other media. Follow the

instructions to install the files.

After all files are installed, a window displays to inform you that a TCP/IP service called DHCP can be set up to

dynamically assign IP information.

AAM6020VI ADSL Wireless Modem Router Quick Installation Guide

Page 8

6. Click to continue, and then click if prompted to restart your computer.

7. After restarting your PC, open the Control Panel window, and then double-click the Network icon.

8. In the Network dialog box, click the Protocols tab.

9. In the Protocols tab, select TCP/IP, and then click .

10. In the Microsoft TCP/IP Properties dialog box, click the radio button labeled Use the following IP address and

type 192.168.1.x, 255.255.255.0 and 192.168.1.1 in the IP address field, Subnet Mask field and Default gateway,

respectively.

11. Click twice to confirm and save your changes, and then close the Control Panel.

1.2 Building Wireless Connection Using A Wireless Interface

Most steps for accessing the modem are very similar to configure the wired NIC. Only difference

with wired NIC is that your wireless card has built wireless connection with modem already. We

will describe detailed linking and configuring steps, and take ASUS WL-100G 802.11G wireless

card for example as below.

1. Please make sure that you have well-installed wireless card driver and utility into your PC.

2. Run ASUS WLAN Control Center, you will find ASUS WLAN Setting screen.

3. Click Survey icon on left column of Setting screen, you will find ADSL_Wireless - modem default SSID setting to

be showed on Available Network. Select ADSL_Wireless , than click Connect.

AAM6020VI ADSL Wireless Modem Router Quick Installation Guide

Page 9

4. Click Status icon, then click IP Config to check IP address among 2~254 range. If it is true, then click Ping tab

and run ping to do connection test between modem with your PC.

AAM6020VI ADSL Wireless Modem Router Quick Installation Guide

Page 10

After finishing above steps, you are ready to login and start to configure modem now.

Table des matières

Autres manuels Asus Routeur réseau

Asus

Asus RT-AC1200HP Manuel utilisateur

Asus

Asus AX5400 Manuel utilisateur

Asus

Asus AiMesh-AC1750 Manuel utilisateur

Asus

Asus RX3042H Manuel utilisateur

Asus

Asus ExpertWiFi EBR63 Manuel utilisateur

Asus

Asus ROG Strix GS-AX5400 Manuel utilisateur

Asus

Asus BLUE CAVE AC2600 Manuel utilisateur

Asus

Asus FX-D1161 Manuel utilisateur

Asus

Asus WL-AM604 Manuel utilisateur

Asus

Asus RT-AC58U V3 Manuel utilisateur

Asus

Asus BLUE CAVE Manuel utilisateur

Asus

Asus RT-AC66U Manuel utilisateur

Asus

Asus TUF-AX5400 Manuel utilisateur

Asus

Asus RT-AC86U Manuel utilisateur

Asus

Asus DSL-AC68U Manuel utilisateur

Asus

Asus RT-AC2600 Manuel utilisateur

Asus

Asus 4G-N12 B1 Manuel utilisateur

Asus

Asus RT-AC54U Manuel utilisateur

Asus

Asus WL-500gP V2 Manuel utilisateur

Asus

Asus RT-AC87U Dual Band Manuel utilisateur

Asus

Asus DSL-AC51 Manuel utilisateur

Asus

Asus Republic of Gamers Rapture GT-AX11000 Manuel utilisateur

Asus

Asus RT-AC66W Manuel utilisateur

Asus

Asus ROG Strix GS-AX5400 Manuel utilisateur

Manuels Routeur réseau populaires d'autres marques

Allnet

Allnet ALL0333AU Manuel utilisateur

HomeSeer

HomeSeer HT-SEL Manuel utilisateur

Sercomm

Sercomm Genesis OC3505D Manuel utilisateur

Billion

Billion BIPAC 5102 Series Manuel utilisateur

TP-Link

TP-Link TD-8817 Manuel utilisateur

Motorola

Motorola MR1900 Manuel utilisateur

Digi

Digi IX14 Manuel utilisateur

Cisco

Cisco NCS 540 Manuel

XAVi

XAVi X8821e Manuel utilisateur

BEC

BEC 6200WZL Manuel utilisateur

MikroTik

MikroTik hAP ac3 Series Manuel utilisateur

Korenix

Korenix JetNet 5428G Series Manuel utilisateur

NETGEAR

NETGEAR FS526T - Switch Manuel utilisateur

Korenix

Korenix JetNet 5710G Series Manuel utilisateur

Automated Logic

Automated Logic ZN551 Manuel du propriétaire

Cisco

Cisco ASR 1000 Series Manuel de l'opérateur

EnGenius

EnGenius ESR-9710 Manuel utilisateur

Cisco

Cisco 805 Series Instructions d'utilisation et de sécurité
