Asus BRT-AC828/M2 Manuel utilisateur

User Guide

BRT-AC828/M2

Wireless-AC2600 Dual WAN VPN Wireless Router

SSD

failover

No part of this manual, including the products and software described

in it, may be reproduced, transmitted, transcribed, stored in a retrieval

system, or translated into any language in any form or by any means, except

documentation kept by the purchaser for backup purposes, without the

express written permission of ASUSTeK Computer Inc. (“ASUS”).

Product warranty or service will not be extended if: (1) the product is repaired,

modied or altered, unless such repair, modication of alteration is authorized

in writing by ASUS; or (2) the serial number of the product is defaced or

missing.

ASUS PROVIDES THIS MANUAL “AS IS”WITHOUT WARRANTY OF ANY KIND,

EITHER EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED

WARRANTIES OR CONDITIONS OF MERCHANTABILITY OR FITNESS FOR A

PARTICULAR PURPOSE. IN NO EVENT SHALL ASUS, ITS DIRECTORS, OFFICERS,

EMPLOYEES OR AGENTS BE LIABLE FOR ANY INDIRECT, SPECIAL, INCIDENTAL,

OR CONSEQUENTIAL DAMAGES (INCLUDING DAMAGES FOR LOSS OF PROFITS,

LOSS OF BUSINESS, LOSS OF USE OR DATA, INTERRUPTION OF BUSINESS

AND THE LIKE), EVEN IF ASUS HAS BEEN ADVISED OF THE POSSIBILITY OF

SUCH DAMAGES ARISING FROM ANY DEFECT OR ERROR IN THIS MANUAL OR

PRODUCT.

SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUAL ARE

FURNISHED FOR INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGE

AT ANY TIME WITHOUT NOTICE, AND SHOULD NOT BE CONSTRUED AS A

COMMITMENT BY ASUS. ASUS ASSUMES NO RESPONSIBILITY OR LIABILITY

FOR ANY ERRORS OR INACCURACIES THAT MAY APPEAR IN THIS MANUAL,

INCLUDING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT.

Products and corporate names appearing in this manual may or may not be

registered trademarks or copyrights of their respective companies, and are used

only for identication or explanation and to the owners’benet, without intent

to infringe.

E11131

First Edition

November 2015

Table of contents

1 Getting to know your wireless router

1.1 Welcome! ........................................................................................6

1.2 Package contents.........................................................................6

1.3 Your wireless router.....................................................................7

1.4 Positioning your router..............................................................9

1.5 Setup Requirements ................................................................ 10

1.6 Router Setup............................................................................... 11

1.6.1 Wired connection..................................................................11

1.6.2 Wireless connection.............................................................12

2 Getting started

2.1 Logging into the Web GUI ..................................................... 14

2.2 Quick Internet Setup (QIS) with Auto-detection ........... 15

2.3 Connecting to your wireless network................................ 18

3 Conguring the General settings

3.1 Using the Network Map ......................................................... 19

3.1.1 Setting up the wireless security settings......................20

3.1.2 Managing your network clients.......................................22

3.1.3 Monitoring your USB device.............................................23

3.2 Creating a Guest Network...................................................... 26

3.3 Using the USB Application..................................................... 28

3.3.1 Using AiDisk ............................................................................28

3.3.2 Using Servers Center............................................................30

3.3.3 3G/4G ........................................................................................35

3.4 Using AiCloud 2.0...................................................................... 36

3.4.1 Cloud Disk................................................................................37

3.4.2 Smart Access...........................................................................39

3.4.3 Smart Sync...............................................................................40

Table of contents

4 Conguring the Advanced Settings

4.1 Wireless......................................................................................... 41

4.1.1 General......................................................................................41

4.1.2 WPS ............................................................................................43

4.1.3 WDS (Bridge)...........................................................................45

4.1.4 Wireless MAC Filter...............................................................47

4.1.5 RADIUS Setting ......................................................................48

4.1.6 Professional.............................................................................49

4.2 LAN................................................................................................. 51

4.2.1 LAN IP ........................................................................................51

4.2.2 DHCP Server............................................................................52

4.2.3 Route .........................................................................................54

4.2.4 IPTV ............................................................................................55

4.3 WAN ............................................................................................... 56

4.3.1 Internet Connection.............................................................56

4.3.2 Dual WAN .................................................................................59

4.3.3 Port Trigger..............................................................................60

4.3.4 Virtual Server/Port Forwarding........................................62

4.3.4 DMZ............................................................................................65

4.3.5 DDNS .........................................................................................66

4.3.6 NAT Passthrough...................................................................67

4.4 IPv6................................................................................................. 68

4.5 VPN Server................................................................................... 69

4.6 Firewall.......................................................................................... 70

4.6.1 General......................................................................................70

4.6.2 URL Filter ..................................................................................70

4.6.3 Keyword lter .........................................................................71

4.6.4 Network Services Filter .......................................................72

4.6.5 IPv6 Firewall ............................................................................73

Table of contents

4.7 Administration ........................................................................... 74

4.7.1 Operation Mode ....................................................................74

4.7.2 System.......................................................................................75

4.7.3 Firmware Upgrade................................................................76

4.7.4 Restore/Save/Upload Setting ...........................................77

4.8 System Log .................................................................................. 78

5 Utilities

5.1 Device Discovery....................................................................... 79

5.2 Firmware Restoration .............................................................. 80

5.3 Setting up your printer server .............................................. 81

5.3.1 ASUS EZ Printer Sharing .....................................................81

5.3.2 Using LPR to Share Printer .................................................85

5.4 Download Master...................................................................... 90

5.4.1 Conguring Bit Torrent download settings.................91

5.4.2 NZB settings............................................................................92

6 Troubleshooting

6.1 Basic Troubleshooting............................................................. 93

6.2 Frequently Asked Questions (FAQs) .................................. 95

Appendices

Notices .....................................................................................................104

ASUS Contact information..................................................................118

Networks Global Hotline Information.............................................119

1 Getting to know your wireless

router

1.1 Welcome!

Thank you for purchasing an ASUS BRT-AC828/M2 Wireless Router!

The ultra-thin and stylish BRT-AC828/M2 features 2.4GHz and

5GHz dual bands for an unmatched concurrent wireless HD

streaming; SMB server, UPnP AV server, and FTP server for 24/7

le sharing; a capability to handle 300,000 sessions; and the ASUS

Green Network Technology, which provides up to 70% power-

saving solution.

1.2 Package contents

NOTES:

• Ifanyoftheitemsisdamagedormissing,contactASUSfortechnical

inquiries and support, Refer to the ASUS Support Hotline list at the

back of this user manual.

• Keeptheoriginalpackagingmaterialincaseyouwouldneedfuture

warranty services such as repair or replacement.

BRT-AC828/M2 Wireless Router AC adapter

Network cable (RJ-45) Quick Start Guide

Support CD (Manual)

1.3 Your wireless router

Power LED

O: No power.

On: Device is ready.

Flashing slow: Rescue mode

LAN 1~8 LED

O: No power or no physical connection.

On: Has physical connection to a local area network (LAN).

2.4GHz LED

O: No 2.4GHz signal.

On:Wireless system is ready.

Flashing:Transmitting or receiving data via wireless connection.

5GHz LED

O: No 5GHz signal.

On:Wireless system is ready.

Flashing:Transmitting or receiving data via wireless connection.

WAN (Internet) LED

Red: No IP or no physical connection.

On: Has physical connection to a wide area network (WAN).

Failover LED

O: Failover feature is disabled.

On: Failover feature is enabled.

Flashing: Failover feature is functioning.

SSD LED

O: No SSD device connected.

Flashing: SSD devices are running.

USB LED

O: No USB device connected.

Flashing: USB devices are running.

NOTES:

• Useonlytheadapterthatcamewithyourpackage.Usingother

adapters may damage the device.

• Specications:

DC Power adapter DC Output: +19V with max 2.37A/3.42A current

Operating

Temperature 0~40oCStorage 0~70oC

Operating Humidity 50~90% Storage 20~90%

USB unmount button

Press this button to safely remove the USB device.

USB 3.0 port

Insert USB 3.0 devices such as USB hard disks or USB flash drives into this port.

WAN (Internet) ports

Connect a network cable into these ports to establish WAN connection.

WPS button

This button launches the WPS Wizard.

LAN 1 ~ 8 ports

Connect network cables into these ports to establish LAN connection.

Power button

Press this button to power on or off the system.

Power (DC-IN) port

Insert the bundled AC adapter into this port and connect your router to a power source.

1.4 Positioning your router

For the best wireless signal transmission between the wireless

router and the network devices connected to it, ensure that you:

• Placethewirelessrouterinacentralizedareaforamaximum

wireless coverage for the network devices.

• Keepthedeviceawayfrommetalobstructionsandawayfrom

direct sunlight.

• Keepthedeviceawayfrom802.11gor20MHzonlyWi-Fi

devices, 2.4GHz computer peripherals, Bluetooth devices,

cordlessphones,transformers,heavy-dutymotors,fluorescent

lights, microwave ovens, refrigerators, and other industrial

equipment to prevent signal interference or loss.

• Alwaysupdatetothelatestfirmware.VisittheASUSwebsiteat

http://www.asus.com to get the latest firmware updates.

• Toensurethebestwirelesssignal,orientthefourdetachable

antennas as shown in the drawing below.

45°45°

1.5 Setup Requirements

To set up your wireless network, you need a computer that meets

the following system requirements:

• EthernetRJ-45(LAN)port(10Base-T/100Base-TX/

1000BaseTX)

• IEEE802.11a/b/g/n/acwirelesscapability

• AninstalledTCP/IPservice

• WebbrowsersuchasInternetExplorer,Firefox,Safari,or

Google Chrome

NOTES:

• Ifyourcomputerdoesnothavebuilt-inwirelesscapabilities,youmay

install an IEEE 802.11a/b/g/n/ac WLAN adapter to your computer to

connect to the network.

• Withitsdualbandtechnology,yourwirelessroutersupports2.4GHz

and 5GHz wireless signals simultaneously. This allows you to do

Internet-related activities such as Internet surng or reading/writing

e-mail messages using the 2.4GHz band while simultaneously

streaming high-denition audio/video les such as movies or music

using the 5GHz band.

• SomeIEEE802.11ndevicesthatyouwanttoconnecttoyournetwork

may or may not support 5GHz band. Refer to the device's manual for

specications.

• TheEthernetRJ-45cablesthatwillbeusedtoconnectthenetwork

devices should not exceed 100 meters.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Asus Routeur réseau

Asus

Asus RT-N600RU Manuel utilisateur

Asus

Asus BRT-AC828 Manuel utilisateur

Asus

Asus XT8 Manuel utilisateur

Asus

Asus RT-AC66U Manuel utilisateur

Asus

Asus ZenWiFi AC CT8 Manuel utilisateur

Asus

Asus Zhone 6218-i3 Manuel utilisateur

Asus

Asus RT-AX92U/CA Manuel utilisateur

Asus

Asus 4G-N12 Manuel utilisateur

Asus

Asus RT-N10E EZ N Manuel utilisateur

Asus

Asus RT-AC1200 Manuel d'instructions

Asus

Asus RT-N66W Dual Band 3x3 Manuel utilisateur

Asus

Asus WL 520GU - Wireless Router Manuel utilisateur

Asus

Asus RT-AC68R Manuel utilisateur

Asus

Asus RT-N65U Manuel utilisateur

Asus

Asus RT-AC66U Manuel utilisateur

Asus

Asus RT-N18U Manuel utilisateur

Asus

Asus RT-AC85MR Manuel utilisateur

Asus

Asus BLUE CAVE AC2600 Manuel utilisateur

Asus

Asus RT-AX3000 V2 Manuel utilisateur

Asus

Asus TUF-AX3000 V2 Manuel utilisateur

Asus

Asus XD4S Manuel utilisateur

Asus

Asus Republic of Gamers Rapture GT-AX11000 Manuel utilisateur

Asus

Asus ROG Rapture GT-AC2900 Manuel utilisateur

Asus

Asus GT-AX11000 Pro Manuel utilisateur

Manuels Routeur réseau populaires d'autres marques

Allnet

Allnet ALL0333AU Manuel utilisateur

HomeSeer

HomeSeer HT-SEL Manuel utilisateur

Sercomm

Sercomm Genesis OC3505D Manuel utilisateur

Billion

Billion BIPAC 5102 Series Manuel utilisateur

TP-Link

TP-Link TD-8817 Manuel utilisateur

Motorola

Motorola MR1900 Manuel utilisateur

Digi

Digi IX14 Manuel utilisateur

Cisco

Cisco NCS 540 Manuel

XAVi

XAVi X8821e Manuel utilisateur

BEC

BEC 6200WZL Manuel utilisateur

MikroTik

MikroTik hAP ac3 Series Manuel utilisateur

Korenix

Korenix JetNet 5428G Series Manuel utilisateur

NETGEAR

NETGEAR FS526T - Switch Manuel utilisateur

Korenix

Korenix JetNet 5710G Series Manuel utilisateur

Automated Logic

Automated Logic ZN551 Manuel du propriétaire

Cisco

Cisco ASR 1000 Series Manuel de l'opérateur

EnGenius

EnGenius ESR-9710 Manuel utilisateur

Cisco

Cisco 805 Series Instructions d'utilisation et de sécurité
