AAM6030BI CPE User Manual

AAM6030BI

UserManual

Rev. 1.00

Version date: Oct. 20, 2004

AAM6030BI User Manual

Table of Contents

1. Introduction 4

1.1 Features & System Requirements 4

2. Your CPE at a glance 5

2.1 Ports and buttons (Back panel) 5

2.2 LED description (Front panel) 5

2.3 LED table & parts list 5

3. Getting Start 7

3.1 Connecting the Hardware 7

3.1.1 Connect the ADSL line 7

3.1.2 Connect the computers or a LAN 7

3.1.3 Attach the power adapter 7

3.1.4 Turn on your computer 7

3.2 Configuring Your PC 8

3.2.1 Windows XP: 8

3.2.2 Windows 2000: 8

3.2.3 Windows Me: 9

3.2.4 Windows 95, 98: 10

3.2.5 Windows NT 4.0: 11

3.2.6 Assigning IP to your PC automatically by DHCP 11

4. Setting up your CPE 12

4.1 Log into your CPE 12

4.2 Home screen 12

4.3 Setup 13

4.3.1 Wide Area Network connection 14

4.3.2 Local Area Network connection 14

4.4 Configuring the WAN 14

4.4.1 New Connection 14

4.4.2 Modify an Existing Connection 19

4.4.3 Modem setup 19

4.5 Configuring the LAN 20

4.5.1 Enable/Disable DHCP 20

4.5.2 Changing the CPEs IP address 21

4.5.3 Firewall/NAT Services 22

4.6 Advanced 22

4.6.1 UPnP 23

4.6.2 Port Forwarding 24

4.6.3 IP QoS/IP filters 25

4.6.4 Access Control 26

4.6.5 LAN clients 26

4.6.6 Bridge Filters 26

4.6.7 Multicast/IGMP Snooping 28

4.6.8 Static Routing 29

4.6.9 Dynamic Routing 30

4.6.10 VLAN 31

4.7 Tools 32

2 2

AAM6030BI User Manual

4.7.1 System Commands 32

4.7.2 Remote Log 32

4.7.3 User Management 32

4.7.4 Update Gateway 33

4.7.5 Ping Test 33

4.7.6 Modem Test 34

4.8 Status 34

4.8.1 Network Statistics 34

4.8.2 Connection Status 34

4.8.3 DHCP Clients 34

4.8.4 Modem Status 34

4.8.5 Product Information 34

4.8.6 System Log 35

5. Appendix A: Troubleshooting 36

5.1 The CPE is not functional 36

5.2 I can’t connect to the CPE. 36

5.3 The LEDs blink in a sequential pattern. 36

5.4 The DSL Link LED continues to blink but does not go solid 37

5.5 The DSL Link LED is always off 37

6. Router terms 38

3 3

AAM6030BI User Manual

1. Introduction

Congratulations on becoming the owner of a AAM6030BI CPE (Customer Premises Equipment). Your

LAN (Local Area Network) will now be able to access the Internet via the CPE’s ADSL connection.

This User Manual will show you how to set up the AAM6030BI CPE, and how to customize its configuration to

get the most out of this product.

1.1 Features & System Requirements

zFeatures

•Equipped with a 4 Port 10/100 Ethernet

•Connects multiple PCs to the Internet with just one WAN IP Address (when configured in router

mode with NAT enabled)

•Configurable through user-friendly web pages

•Supports Single-Session IPSec and PPTP Pass-Through for Virtual Private Network (VPN)

•Several popular games are already pre configured. Just enable the game and the port settings are

automatically configured.

•Configurable as a DHCP Server on Your Network

•Compatible with virtually all standard Internet applications

•Industry standard and interoperable DSL interface

•Simple web based status page displays a snapshot of your system configuration, and links to the

configuration pages

•Downloadable flash software upgrades

•Support for up to 8 Permanent Virtual Circuits (PVC)

•Support for up to 8 PPPOE sessions

•Layer 2 Ether switch (not a hub)

•Allow PVC assignment to the individual Ethernet Ports (i.e 0,35 -> Ethernet Port 1, 0,36 ->

Ethernet Port 2, etc)

oThe modem must support the ability to map PVC’s to physical Ethernet ports. This will

likely be implemented via VLAN to associate the Port to the PVC. The VLAN would

then be only locally significant, i.e it is untagged in both directions and does not exist in

the DSLAM realm or in the customer network realm. The most important thing is to

prevent multicast and broadcast traffic that hits any given port from being broadcast to all

ports. A clean approach to achieve this is to segregate each VLAN into a separate bridge

table. This restricts all flooding to the bridge group.

•PVC assignment must be operational in bridged mode (RFC 1483/2684)

•Wall mounted/hanged support.

zSystem Requirements

In order to use the AAM6030BI CPE for Internet access, you must have the following:

fADSL service subscription from your ISP.

fOne computer containing an Ethernet 10BaseT/100BaseT network interface card (NIC).

f(Optional) An Ethernet hub/switch, if you are connecting the device to several computers on an

Ethernet network.

fFor system monitoring or configuration using the supplied web-based program: a web browser such as

Internet Explorer Version 5.5 or later.

4 4

AAM6030BI User Manual

2. Your CPE at a glance

Your CPE has many ports, switches and LEDs. Let’s take a look at the different options. Depending upon

your model of CPE, your CPE may have some or all of the features listed below

2.1 Ports and buttons (Back panel)

zPower is where you connect the power.

zLAN 1~4 (local area network) port: connect to Ethernet network devices, such as a PC, hub,

switch, or router. Some CPEs come with a single LAN connection and some come with four

LAN connections. Depending on the connection, you may need a cross over cable or a strait

through cable.

zReset Button: The reset button is used to reset the CPE to default setting. You may need to

reset the CPE if you loose network connectivity or you loose the ability to interface to the CPE

via the web interface. To reset the CPE, simply press the reset button for about 5-10 seconds

and release. After about 30 seconds the CPE will become operational.

zDSL (Line) port: This is the WAN interface which connects directly to your phone line.

2.2 LED description (Front panel)

zPower LED: On indicates that the power is supplied to the CPE

zStatus LED: The Status LED serves two purposes. If the LED is continuously lit, the DSL

interface is successfully connected to a device through the WAN port. If the LED is flickering,

it is an indication that the modem is training.

zActivity LED: The Activity LED flash during ADSL data transfer.

zLAN 1~4 LED: The LAN’s LED serves two purposes. If the LED is continuously lit, the

Ethernet interface is successfully connected to a device through the LAN port. If the LED is

flickering, it is an indication of any network activity.

2.3 LED table & parts list

zLED Table

The LEDs can help diagnose problems. If you are using an AAM6030BI CPE, you will have

the LEDs shown in Table 1

Label Color Function

POWER Green

On: Unit is powered on

Off: Unit is powered off

STATUS Green On: ADSL link is established and active

Flashing: Trying to create an ADSL connection

Off: No ADSL link

ACTIVITY Green Flashing: ADSL data transfer

LAN 1~4 Green On: LAN link is established

Flashing: Data transfer at LAN connection

Off: No LAN link

Table 1 (Front Panel & LEDs)

5 5

AAM6030BI User Manual

zParts List

In addition to this document, your AAM6030BI should come with the

following:

fAAM6030BI ADSL 4 Port Router

fPower adapter

fEthernet cable (RJ45), Phone cable (RJ-11)

fUser Manual CD

6 6

AAM6030BI User Manual

3. Getting Start

This chapter provides basic instructions for connecting the CPE to a computer or a LAN and to the Internet

via ADSL.

fPart 1 provides instructions to set up the hardware.

fPart 2 describes how to configure Internet properties on your computer(s).

fPart 3 shows you how to access your CPE.

It is assumed that you have already subscribed to ADSL service with your telephone company or other

Internet service provider (ISP). These instructions provide a basic configuration that should be compatible

with your home or small office network setup. Refer to the subsequent chapters for additional configuration

instructions.

3.1 Connecting the Hardware

In 3.1, you should connect the device to an ADSL line, the power outlet, and your computer or network.

3.1.1 Connect the ADSL line

Connect your ADSL line to the port labeled LINE on the rear panel of the device, and connect the other end

of the line to the wall phone jack directly or to an optional POTS splitter. If you use a POTS splitter to

connect a telephone to the same wall jack as the CPE, follow the instructions that came with the splitter.

3.1.2 Connect the computers or a LAN

You can use the included Ethernet cable to connect your computer directly to the CPE. Attach one end of the

Ethernet cable to the port labeled LAN on the rear panel of the device and connect the other end to the Ethernet

port of your computer.

If your LAN has more than one computer, you can attach one end of an Ethernet cable to a hub or a switch and

the other to the port labeled LAN on the CPE.

Note that either a crossover or a straight-through Ethernet cable can be used. The CPE determines and adjusts to

the type of signal required.

3.1.3 Attach the power adapter

The supplied power adapter may look different than the one illustrated here.

Connect the cylindrical power plug into the POWER connector on the back of the device.

•If you have a wall-mount adapter, plug the AC adapter into a wall outlet or a power strip.

•If you have a table-top adapter, use the AC power cord to connect the adapter to a wall outlet or

power strip.

3.1.4 Turn on your computer

Turn on and boot up your computer and any other LAN devices, such as hubs or switches.

7 7

AAM6030BI User Manual

3.2 Configuring Your PC

Before you start to access the CPE via Ethernet, you must configure your PC’s TCP/IP address to be 192.168.1.x,

where xis any number between 2 and 254. The subnet mask must be 255.255.255.0. Your CPE’s default IP

address is 192.168.1.1.

If you use Ethernet cable to connect your AAM6030BI and PC, you don’t need any specific driver installation.

3.2.1 Windows XP:

1. In the Windows task bar, click on the Start button, and then click on Control Panel.

2. Double-click on the Network Connections icon.

3. In the LAN or High-Speed Internet window, right-click on the icon corresponding to your network

interface card (NIC) and select Properties. (Often this icon is labeled Local Area Connection).

The Local Area Connection dialog box is displayed with a list of currently installed network

items.

4. Ensure that the check box to the left of the item labeled Internet Protocol (TCP/IP) is checked,

and click on .

Figure 3.7 Network

Connections in

Windows XP

Figure 3.8 Local Area Connection Properties in Windows XP

5. In the Internet Protocol (TCP/IP) Properties dialog box, click in the radio button labeled Use

the following IP address and type 192.168.1.x (where xis any number between 2 and 254) and

255.255.255.0 in the IP address field and Subnet Mask field, respectively.

3.2.2 Windows 2000:

1. In the Windows task bar, click on the Start button, point to Settings, and then select Control

Panel.

2. Double-click on the Network and Dial-up Connections icon.

3. In the Network and Dial-up Connections window, right-click on the Local Area Connection

icon, and then select Properties.

8 8

AAM6030BI User Manual

The Local Area Connection Properties dialog box is displayed with a list of currently installed

network components. If the list includes Internet Protocol (TCP/IP), the protocol has already

been enabled, in which case you can skip to Step 10.

4. If Internet Protocol (TCP/IP) does not appear as an installed component, click on

5. In the Select Network Component Type dialog box, select Protocol, and then click on

6. Select Internet Protocol (TCP/IP) in the Network Protocols list, and then click on

You may be prompted to install files from your Windows 2000 installation CD or other media. Follow

the instructions to install the files.

7. If prompted, click on to restart your computer with the new settings.

8. After restarting your PC, double-click on the Network and Dial-up Connections icon in the

Control Panel.

9. In Network and Dial-up Connections window, right-click on the Local Area Connection icon,

and then select Properties.

10. In the Local Area Connection Properties dialog box, select Internet Protocol (TCP/IP), and

then click on .

11. In the Internet Protocol (TCP/IP) Properties dialog box, click in the radio button labeled Use

the following IP address and type 192.168.1.x (where xis any number between 2 and 254) and

255.255.255.0 in the IP address field and Subnet Mask field, respectively.

12. Click on twice to confirm and save your changes, and then close the Control Panel.

3.2.3 Windows Me:

1. In the Windows task bar, click on the Start button, point to Settings, and then click Control

Panel.

2. Double-click on the Network and Dial-up Connections icon.

3. In the Network and Dial-up Connections window, right-click on the Network icon, and then

select Properties.

The Network Properties dialog box is displayed with a list of currently installed network

components. If the list includes Internet Protocol (TCP/IP), the protocol has already been

enabled, in which case you can skip to Step 11.

4. If Internet Protocol (TCP/IP) does not appear as an installed component, click on .

5. In the Select Network Component Type dialog box, select Protocol, and then click

6. Select Microsoft in the Manufacturers box.

7. Select Internet Protocol (TCP/IP) in the Network Protocols list, and then click on .

You may be prompted to install files from your Windows Me installation CD or other media. Follow

the instructions to install the files.

9 9

AAM6030BI User Manual

8. If prompted, click on to restart your computer with the new settings.

9. After restarting your PC, double-click on the Network and Dial-up Connections icon in the

Control Panel.

10. In Network and Dial-up Connections window, right-click on the Network icon, and then select

Properties.

11. In the Network Properties dialog box, select TCP/IP, and then click on .

12. In the TCP/IP Settings dialog box, click in the radio button labeled Use the following IP address

and type 192.168.1.x (where xis any number between 2 and 254) and 255.255.255.0 in the IP

address field and Subnet Mask field, respectively.

13. Click on twice to confirm and save your changes, and then close the Control Panel.

3.2.4 Windows 95, 98:

1. In the Windows task bar, click on the Start button, point to Settings, and then click Control

Panel.

2. Double-click on the Network icon.

The Network dialog box is displayed with a list of currently installed network components. If the list

includes TCP/IP, the protocol has already been enabled, in which case you can skip to Step 9.

3. If TCP/IP does not appear as an installed component, click on . The Select

Network Component Type dialog box appears.

4. Select Protocol, and then click .

The Select Network Protocol dialog box appears.

5. Click on Microsoft in the Manufacturers list box, and then click TCP/IP in the Network Protocols

list box.

6. Click to return to the Network dialog box, and then click again.

You may be prompted to install files from your Windows 95/98 installation CD. Follow the

instructions to install the files.

7. Click on to restart the PC and complete the TCP/IP installation.

8. After restarting your PC, open the Control Panel window, and then click on the Network icon.

9. Select the network component labeled TCP/IP, and then click on .

If you have multiple TCP/IP listings, select the listing associated with your network card or adapter.

10. In the TCP/IP Properties dialog box, click on the IP Address tab.

11. Click in the radio button labeled Use the following IP address and type 192.168.1.x (where xis

any number between 2 and 254) and 255.255.255.0 in the IP address field and Subnet Mask field,

respectively.

12. Click on twice to confirm and save your changes. You will be prompted to restart

Windows. Please click on and restart your PC again.

10 10

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Asus Routeur réseau

Asus

Asus RT-ACRH13 Manuel utilisateur

Asus

Asus RTN10UB Manuel utilisateur

Asus

Asus RTAXI600 Manuel utilisateur

Asus

Asus XD4R Manuel utilisateur

Asus

Asus RT-N66U Dark Knight Manuel utilisateur

Asus

Asus ISDNLink INET-800 Manuel utilisateur

Asus

Asus RT-AC87U Dual Band Manuel utilisateur

Asus

Asus WL-500W SuperSpeed N Manuel utilisateur

Asus

Asus AX5400 Manuel utilisateur

Asus

Asus RT-AX86U Manuel utilisateur

Asus

Asus RT-AX88U Manuel utilisateur

Asus

Asus RX3041 Manuel utilisateur

Asus

Asus RT-AC56U Manuel utilisateur

Asus

Asus ZenWiFi Pro ET12 Manuel utilisateur

Asus

Asus GIGAX 1005B Manuel utilisateur

Asus

Asus AAM6000EV Manuel

Asus

Asus RT-AX86U Manuel utilisateur

Asus

Asus DSL-AC750 Manuel utilisateur

Asus

Asus DSL-AC68VG Manuel utilisateur

Asus

Asus RT-AX95U Manuel utilisateur

Asus

Asus RT-AC1300G PLUS Manuel utilisateur

Asus

Asus RT-AX86U Manuel utilisateur

Asus

Asus SP-AC2015 Wi-Fi Connect Manuel utilisateur

Asus

Asus RT-AC68U V4 Manuel utilisateur

Manuels Routeur réseau populaires d'autres marques

Allnet

Allnet ALL0333AU Manuel utilisateur

HomeSeer

HomeSeer HT-SEL Manuel utilisateur

Sercomm

Sercomm Genesis OC3505D Manuel utilisateur

Billion

Billion BIPAC 5102 Series Manuel utilisateur

TP-Link

TP-Link TD-8817 Manuel utilisateur

Motorola

Motorola MR1900 Manuel utilisateur

Digi

Digi IX14 Manuel utilisateur

Cisco

Cisco NCS 540 Manuel

XAVi

XAVi X8821e Manuel utilisateur

BEC

BEC 6200WZL Manuel utilisateur

MikroTik

MikroTik hAP ac3 Series Manuel utilisateur

Korenix

Korenix JetNet 5428G Series Manuel utilisateur

NETGEAR

NETGEAR FS526T - Switch Manuel utilisateur

Korenix

Korenix JetNet 5710G Series Manuel utilisateur

Automated Logic

Automated Logic ZN551 Manuel du propriétaire

Cisco

Cisco ASR 1000 Series Manuel de l'opérateur

EnGenius

EnGenius ESR-9710 Manuel utilisateur

Cisco

Cisco 805 Series Instructions d'utilisation et de sécurité
