Asus PRIME H770-PLUS D4 Manuel utilisateur

Motherboard

PRIME H770-PLUS D4

E20703

First Edition

September 2022

No part of this manual, including the products and software described in it, may be reproduced,

transmitted, transcribed, stored in a retrieval system, or translated into any language in any form or by any

means, except documentation kept by the purchaser for backup purposes, without the express written

permission of ASUSTeK COMPUTER INC. (“ASUS”).

Product warranty or service will not be extended if: (1) the product is repaired, modied or altered, unless

such repair, modication of alteration is authorized in writing by ASUS; or (2) the serial number of the

product is defaced or missing.

ASUS PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS

OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OR CONDITIONS OF

MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. IN NO EVENT SHALL ASUS, ITS

DIRECTORS, OFFICERS, EMPLOYEES OR AGENTS BE LIABLE FOR ANY INDIRECT, SPECIAL,

INCIDENTAL, OR CONSEQUENTIAL DAMAGES (INCLUDING DAMAGES FOR LOSS OF PROFITS,

LOSS OF BUSINESS, LOSS OF USE OR DATA, INTERRUPTION OF BUSINESS AND THE LIKE),

EVEN IF ASUS HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES ARISING FROM ANY

DEFECT OR ERROR IN THIS MANUAL OR PRODUCT.

SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUAL ARE FURNISHED FOR

INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGE AT ANY TIME WITHOUT NOTICE,

AND SHOULD NOT BE CONSTRUED AS A COMMITMENT BY ASUS. ASUS ASSUMES NO

RESPONSIBILITY OR LIABILITY FOR ANY ERRORS OR INACCURACIES THAT MAY APPEAR IN THIS

MANUAL, INCLUDING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT.

Products and corporate names appearing in this manual may or may not be registered trademarks or

copyrights of their respective companies, and are used only for identication or explanation and to the

owners’ benet, without intent to infringe.

iii

Contents

Safety information...................................................................................................... iv

About this guide.......................................................................................................... v

Package contents....................................................................................................... vi

PRIME H770-PLUS D4 specifications summary...................................................... vi

Chapter 1: Product Introduction

1.1 Before you proceed...................................................................................... 1-1

1.2 Motherboard overview .................................................................................1-2

1.3 Central Processing Unit (CPU).................................................................... 1-9

1.4 System memory.......................................................................................... 1-11

1.5 M.2 installation............................................................................................1-13

Chapter 2: BIOS and RAID Support

2.1 Knowing BIOS...............................................................................................2-1

2.2 BIOS Setup program ....................................................................................2-2

2.3 ASUS EZ Flash 3...........................................................................................2-3

2.4 ASUS CrashFree BIOS 3.............................................................................. 2-4

2.5 RAID configurations..................................................................................... 2-5

Appendix

Notices ..................................................................................................................... A-1

Warranty................................................................................................................... A-6

ASUS contact information...................................................................................... A-8

Service and Support ............................................................................................... A-8

Safety information

Electrical safety

• To prevent electrical shock hazard, disconnect the power cable from the electrical outlet

before relocating the system.

• When adding or removing devices to or from the system, ensure that the power cables

for the devices are unplugged before the signal cables are connected. If possible,

disconnect all power cables from the existing system before you add a device.

• Before connecting or removing signal cables from the motherboard, ensure that all power

cables are unplugged.

• Seek professional assistance before using an adapter or extension cord. These devices

could interrupt the grounding circuit.

• Ensure that your power supply is set to the correct voltage in your area. If you are not

sure about the voltage of the electrical outlet you are using, contact your local power

company.

• If the power supply is broken, do not try to x it by yourself. Contact a qualied service

technician or your retailer.

Operation safety

• Before installing the motherboard and adding components, carefully read all the manuals

that came with the package.

• Before using the product, ensure all cables are correctly connected and the power cables

are not damaged. If you detect any damage, contact your dealer immediately.

• To avoid short circuits, keep paper clips, screws, and staples away from connectors,

slots, sockets and circuitry.

• Avoid dust, humidity, and temperature extremes. Do not place the product in any area

where it may become wet.

• Place the product on a stable surface.

• If you encounter technical problems with the product, contact a qualied service

technician or your retailer.

• Your motherboard should only be used in environments with ambient temperatures

between 0°C and 40°C.

Button/Coin Batteries Safety Information

WARNING

KEEP OUT OF REACH OF CHILDREN

Swallowing can lead to chemical burns,

perforation of soft tissue, and death.

Severe burns can occur within 2 hours

of ingestion. Seek medical attention

immediately.

About this guide

This user guide contains the information you need when installing and conguring the

motherboard.

How this guide is organized

This guide contains the following parts:

• Chapter 1: Product Introduction

This chapter describes the features of the motherboard and the new technology it

supports. It includes descriptions of the switches, jumpers, and connectors on the

motherboard.

• Chapter 2: BIOS and RAID Support

This chapter tells how to boot into the BIOS, upgrade BIOS using the EZ Flash Utility

and support on RAID.

Where to find more information

Refer to the following sources for additional information and for product and software

updates.

1. ASUS website

The ASUS website (www.asus.com) provides updated information on ASUS hardware

and software products.

2. Optional documentation

Your product package may include optional documentation, such as warranty flyers,

that may have been added by your dealer. These documents are not part of the

standard package.

Conventions used in this guide

To ensure that you perform certain tasks properly, take note of the following symbols used

throughout this user guide.

CAUTION: Information to prevent damage to the components and injuries to

yourself when trying to complete a task.

IMPORTANT: Instructions that you MUST follow to complete a task.

NOTE: Tips and additional information to help you complete a task.

PRIME H770-PLUS D4 specifications summary

CPU

Intel®Socket LGA1700 for 13th Gen Intel®Core™ Processors & 12th Gen

Intel®Core™, Pentium®Gold and Celeron®Processors*

Supports Intel®Turbo Boost Technology 2.0 and Intel®Turbo Boost Max

Technology 3.0**

* Refer to www.asus.com for CPU support list.

** Intel®Turbo Boost Max Technology 3.0 support depends on the CPU types.

Chipset Intel®H770 Chipset

Memory

4 x DIMM, Max. 128GB, 5066(OC)/5000(OC)/4800(OC)/4600(OC)/

4400(OC)/4266(OC)/4000(OC)/3733(OC)/3600(OC)/3466(OC)/

3400(OC)/3333(OC)/3200/3000/2933/2800/2666/2400/2133 Non-ECC,

Un-buffered Memory*

Dual Channel Memory Architecture

Supports Intel® Extreme Memory Prole (XMP)

OptiMem

* Supported memory types, data rate(Speed), and number of DRAM modules vary

depending on the CPU and memory configuration, for more information refer to

www.asus.com for memory support list.

Graphics

1 x DisplayPort**

1 x HDMI®port***

Graphics specifications may vary between CPU types.

Please refer to

www.intel.com for any updates.

** Supports max. 4K@60Hz as specified in DisplayPort 1.4.

***Supports 4K@60Hz as specified in HDMI

2.1.

Expansion Slots

Intel®13th &12th Gen Processors*

1 x PCIe 5.0 x16 slot

Intel®H770 Chipset

2 x PCIe 4.0 x16 slots (support x4 mode)

2 x PCIe 3.0 x1 slots

* Please check the PCIe bifurcation table on the support site

(https://www.asus.com/support/FAQ/1037507/).

Note: To ensure compatibility of the device installed, please refer to

https://www.asus.com/support/ for the list of supported peripherals.

(continued on the next page)

Package contents

Check your motherboard package for the following items.

Motherboard 1 x PRIME H770-PLUS D4 motherboard

Cables 2 x SATA 6Gb/s cables

Miscellaneous

1 x I/O Shield

1 x M.2 Rubber Package

2 x Screw Packages for M.2 SSD

Documentation 1 x User guide

If any of the above items is damaged or missing, contact your retailer.

vii

PRIME H770-PLUS D4 specifications summary

Storage

Total supports 3 x M.2 slots and 4 x SATA 6Gb/s ports*

Intel®13th &12th Gen Processors

M.2_1 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode)

Intel®H770 Chipset

M.2_2 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 4.0 x4

mode)

M.2_3 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 & SATA

modes)

4 x SATA 6Gb/s ports

* Intel®Rapid Storage Technology supports PCIe RAID 0/1/5/10, SATA RAID

0/1/5/10.

Ethernet 1 x Realtek 2.5Gb Ethernet

Wireless & Bluetooth®Vertical M.2 slot only (Key E, CNVi & PCIe)*

* Wi-Fi module is sold separately.

USB

Rear USB (Total 8 ports)

3 x USB 3.2 Gen 2 ports (2 x Type-A + 1 x USB Type-C®)

3 x USB 3.2 Gen 1 ports (3 x Type-A)

2 x USB 2.0 ports (2 x Type-A)

Front USB (Total 7 ports)

2 x USB 3.2 Gen 1 headers support 4 additional USB 3.2 Gen 1 ports

2 x USB 2.0 headers support 3 additional USB 2.0 ports

Audio

Realtek 7.1 Surround Sound High Denition Audio CODEC*

- Supports: Jack detection, Multi-streaming, Front Panel Jack-retasking

- Supports up to 24-Bit/192kHz playback

Audio Features

- Audio Shielding

- Premium audio capacitors

- Dedicated audio PCB layers

* A chassis with an HD audio module in the front panel is required to support

7.1 Surround Sound audio output.

Back Panel I/O Ports

3 x USB 3.2 Gen 2 ports (2 x Type-A + 1 x USB Type-C®)

3 x USB 3.2 Gen 1 ports (3 x Type-A)

2 x USB 2.0 ports (2 x Type-A)

1 x DisplayPort

1 x HDMI®port

1 x Vertical M.2 slot (Key E)

1 x Realtek 2.5Gb Ethernet port

3 x Audio jacks

(continued on the next page)

viii

PRIME H770-PLUS D4 specifications summary

Internal I/O Connectors

Fan and Cooling related

1 x 4-pin CPU Fan header

1 x 4-pin AIO Pump header

3 x 4-pin Chassis Fan headers

Power related

1 x 24-pin Main Power connector

1 x 8-pin +12V Power connector

Storage related

3 x M.2 slots (Key M)

4 x SATA 6Gb/s ports

USB

2 x USB 3.2 Gen 1 headers support 4 additional USB 3.2 Gen 1 ports

2 x USB 2.0 headers support 3 additional USB 2.0 ports

Miscellaneous

3 x Addressable Gen 2 headers

2 x Aura RGB headers

1 x Clear CMOS header

1 x COM Port header

1 x Front Panel Audio header (AAFP)

1 x S/PDIF Out header

1 x SPI TPM header (14-1pin)

1 x 20-3 pin System Panel header with Chassis intrude function

1 x Thunderbolt™ (USB4®) header

Special Features

ASUS 5X PROTECTION III

- DIGI+ VRM

- LANGuard

- Overvoltage Protection

- SafeSlot Core+

- Stainless-Steel Back I/O

ASUS Q-Design

- Q-DIMM

- Q-LED Core

- Q-Slot

ASUS Thermal Solution

- M.2 heatsink

- VRM heatsink design

ASUS EZ DIY

- ProCool

Aura Sync

- Aura RGB headers

- Addressable Gen 2 headers

(continued on the next page)

PRIME H770-PLUS D4 specifications summary

Software Features

ASUS Exclusive Software

Armoury Crate

- Aura Creator

- Aura Sync

- Fan Xpert 2+

- Power Saving

AI Suite 3

- DIGI+ VRM

- PC Cleaner

ASUS CPU-Z

Norton 360 Deluxe (60 Days Free Trial)

WinRAR

UEFI BIOS

ASUS EZ DIY

- ASUS CrashFree BIOS 3

- ASUS EZ Flash 3

- ASUS UEFI BIOS EZ Mode

BIOS 192 (128+64) Mb Flash ROM, UEFI AMI BIOS

Manageability WOL by PME, PXE

Operating System Windows®11, Windows®10 64-bit

Form Factor ATX Form Factor

12 inch x 9.6 inch (30.5 cm x 24.4 cm)

Specications are subject to change without notice. Refer to the ASUS website for the

latest specications.

Autres manuels pour PRIME H770-PLUS D4

Table des matières

Autres manuels Asus Carte mère

Asus

Asus M4N78 - PRO w/ Athlon II X2 240 Manuel utilisateur

Asus

Asus Pro B650M-CT Manuel utilisateur

Asus

Asus P5N32-E SLI Instructions d'utilisation

Asus

Asus Motherboard A8N-SLI Premium Manuel utilisateur

Asus

Asus P4BP-MX Manuel utilisateur

Asus

Asus P5KEPU - Motherboard - ATX Manuel utilisateur

Asus

Asus Pro B760M-C Manuel utilisateur

Asus

Asus TUF Z270 Mark 1 Manuel utilisateur

Asus

Asus SP97-XV Manuel utilisateur

Asus

Asus PRIME B660M-K D4 Manuel utilisateur

Asus

Asus P7F7-E WS SUPERCOMPUTER Manuel utilisateur

Asus

Asus Prime B660M-AJ D4 Manuel utilisateur

Asus

Asus ROG STRIX X370-F GAMING Manuel utilisateur

Asus

Asus TUF B450M-PLUS GAMING Manuel utilisateur

Asus

Asus SK8V Manuel utilisateur

Asus

Asus Sabertooth X99 Manuel utilisateur

Asus

Asus Z8NA-D6 - Motherboard - ATX Manuel utilisateur

Asus

Asus P8Z77-V LE PLUS Manuel utilisateur

Asus

Asus ProArt B760-CREATOR D4 Manuel utilisateur

Asus

Asus P5E WS PROFESSIONAL Manuel utilisateur

Asus

Asus P5-99B Manuel utilisateur

Asus

Asus Z97I-PLUS Manuel utilisateur

Asus

Asus F2A55 Manuel utilisateur

Asus

Asus PCI I-486SP3G Manuel utilisateur

Manuels Carte mère populaires d'autres marques

DFI

DFI SD170 Manuel utilisateur

ASROCK

ASROCK ROMED8-2T Manuel utilisateur

Winmate

Winmate IC70 Manuel utilisateur

Grantech

Grantech SYS8F377VGGA-3OMN Manuel utilisateur

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Manuel utilisateur

Gigabyte

Gigabyte GA-9IVDT Manuel utilisateur

Texas Instruments

Texas Instruments ADS8372EVM Manuel utilisateur

Commell

Commell MS-C73 Manuel utilisateur

IBT Technologies

IBT Technologies MB860 Manuel utilisateur

Nvidia

Nvidia TEGRA DG-04927-001_V01 Manuel utilisateur

Biostar

Biostar M7VIT Bravo Instructions d'utilisation et d'installation

Intel

Intel D33217CK Manuel utilisateur

EPC

EPC EPC9147C Manuel utilisateur

EPOX

EPOX MU-8KHA0010 Manuel utilisateur

Ski-Doo

Ski-Doo Bombardier MPEM 219 700 090 Manuel utilisateur

Epson

Epson S5U13700P00C000 Manuel utilisateur

Gigabyte

Gigabyte GA-K8N Ultra-SLI Manuel utilisateur

Albatron

Albatron PX925XE Series Manuel utilisateur
