Asus Pro B760M-C Manuel utilisateur

Motherboard

Pro B760M-C

E21337

First Edition

November 2022

No part of this manual, including the products and software described in it, may be reproduced,

transmitted, transcribed, stored in a retrieval system, or translated into any language in any form or by any

means, except documentation kept by the purchaser for backup purposes, without the express written

permission of ASUSTeK COMPUTER INC. (“ASUS”).

Product warranty or service will not be extended if: (1) the product is repaired, modied or altered, unless

such repair, modication of alteration is authorized in writing by ASUS; or (2) the serial number of the

product is defaced or missing.

ASUS PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS

OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OR CONDITIONS OF

MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. IN NO EVENT SHALL ASUS, ITS

DIRECTORS, OFFICERS, EMPLOYEES OR AGENTS BE LIABLE FOR ANY INDIRECT, SPECIAL,

INCIDENTAL, OR CONSEQUENTIAL DAMAGES (INCLUDING DAMAGES FOR LOSS OF PROFITS,

LOSS OF BUSINESS, LOSS OF USE OR DATA, INTERRUPTION OF BUSINESS AND THE LIKE),

EVEN IF ASUS HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES ARISING FROM ANY

DEFECT OR ERROR IN THIS MANUAL OR PRODUCT.

SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUAL ARE FURNISHED FOR

INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGE AT ANY TIME WITHOUT NOTICE,

AND SHOULD NOT BE CONSTRUED AS A COMMITMENT BY ASUS. ASUS ASSUMES NO

RESPONSIBILITY OR LIABILITY FOR ANY ERRORS OR INACCURACIES THAT MAY APPEAR IN THIS

MANUAL, INCLUDING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT.

Products and corporate names appearing in this manual may or may not be registered trademarks or

copyrights of their respective companies, and are used only for identication or explanation and to the

owners’ benet, without intent to infringe.

iii

Contents

Safety information...................................................................................................... iv

About this guide.......................................................................................................... v

Package contents....................................................................................................... vi

Pro B760M-C specications summary..................................................................... vi

Chapter 1： Product Introduction

1.1 Before you proceed...................................................................................... 1-1

1.2 Motherboard overview ................................................................................. 1-2

1.3 Central Processing Unit (CPU).................................................................... 1-9

1.4 System memory.......................................................................................... 1-11

Chapter 2： BIOS and RAID Support

2.1 BIOS Setup program .................................................................................... 2-1

2.2 BIOS menu screen........................................................................................ 2-2

2.3 Event Log ...................................................................................................... 2-3

2.4 Exit menu ...................................................................................................... 2-4

2.5 RAID congurations..................................................................................... 2-5

Appendix

Notices ..................................................................................................................... A-1

Warranty................................................................................................................... A-6

ASUS contact information...................................................................................... A-8

Service and Support ............................................................................................... A-8

Safety information

Electrical safety

• To prevent electrical shock hazard, disconnect the power cable from the electrical

outlet before relocating the system.

• When adding or removing devices to or from the system, ensure that the power cables

for the devices are unplugged before the signal cables are connected. If possible,

disconnect all power cables from the existing system before you add a device.

• Before connecting or removing signal cables from the motherboard, ensure that all

power cables are unplugged.

• Seek professional assistance before using an adapter or extension cord. These

devices could interrupt the grounding circuit.

• Ensure that your power supply is set to the correct voltage in your area. If you are not

sure about the voltage of the electrical outlet you are using, contact your local power

company.

• If the power supply is broken, do not try to fix it by yourself. Contact a qualified service

technician or your retailer.

Operation safety

• Before installing the motherboard and adding devices on it, carefully read all the

manuals that came with the package.

• Before using the product, ensure all cables are correctly connected and the power

cables are not damaged. If you detect any damage, contact your dealer immediately.

• To avoid short circuits, keep paper clips, screws, and staples away from connectors,

slots, sockets and circuitry.

• Avoid dust, humidity, and temperature extremes. Do not place the product in any area

where it may become wet.

• Place the product on a stable surface.

• If you encounter technical problems with the product, contact a qualified service

technician or your retailer.

• Your motherboard should only be used in environments with ambient temperatures

between 0°C and 40°C.

Button/Coin Batteries Safety Information

WARNING

KEEP OUT OF REACH OF CHILDREN

Swallowing can lead to chemical burns,

perforation of soft tissue, and death. Severe

burns can occur within 2 hours of ingestion.

Seek medical attention immediately.

About this guide

This user guide contains the information you need when installing and configuring the

motherboard.

How this guide is organized

This guide contains the following parts:

• Chapter 1: Product Introduction

This chapter describes the features of the motherboard and the new technology it

supports. It includes description of the switches, jumpers, and connectors on the

motherboard.

• Chapter 2: BIOS and RAID Support

This chapter tells how to boot into the BIOS, upgrade BIOS using the EZ Flash Utility

and support on RAID.

Where to find more information

Refer to the following sources for additional information and for product and software

updates.

1. ASUS website

The ASUS website (www.asus.com) provides updated information on ASUS hardware

and software products.

2. Optional documentation

Your product package may include optional documentation, such as warranty flyers,

that may have been added by your dealer. These documents are not part of the

standard package.

Conventions used in this guide

To ensure that you perform certain tasks properly, take note of the following symbols used

throughout this user guide.

CAUTION: Information to prevent damage to the components and injuries to

yourself when trying to complete a task.

IMPORTANT: Instructions that you MUST follow to complete a task.

NOTE: Tips and additional information to help you complete a task.

Pro B760M-C specications summary

CPU

Intel®Socket LGA1700 for 13th Gen Intel®Core™ & 12th Gen Intel®Core™,

Pentium®Gold and Celeron®Processors*

Supports Intel®Turbo Boost Technology 2.0 and Intel®Turbo Boost Max

Technology 3.0**

* Refer to www.asus.com for CPU support list.

** Intel®Turbo Boost Max Technology 3.0 support depends on the CPU types.

Chipset Intel®B760 Chipset

Memory

4 x DIMM, Max. 128GB, DDR5 Non-ECC, Un-buffered Memory*

Dual Channel Memory Architecture

Supports Intel® Extreme Memory Prole (XMP)

Optimem II

* Supported memory types, data rate (speed), and number of DRAM modules vary

depending on the CPU and memory conguration, for more information please refer

to CPU/Memory Support under the Support tab or visit

https://www.asus.com/support/.

* Non-ECC, un-buffered DDR5 memory supports On-Die ECC function.

Graphics

2 x DisplayPorts**

1 x VGA port

1 x HDMI® port***

Graphics specications may vary between CPU types. Please refer to

www.intel.com for any updates.

** Support max. 4K@60Hz as specied in DisplayPort 1.4.

*** Supports 4K@60Hz as specied in HDMI

2.1.

Expansion Slots Intel®13th & 12th Gen Processors

1 x PCIe 4.0/3.0 x16 slot

Intel®B760 Chipset

2 x PCIe 3.0 x1 slots

Note: To ensure compatibility of the device installed, please refer to

https://www.asus.com/support/ for the list of supported peripherals.

(continued on the next page)

Package contents

Check your motherboard package for the following items.

Motherboard 1 x Pro B760M-C motherboard

Cables 2 x SATA 6Gb/s cables

Miscellaneous

1 x I/O Shield

1 x Screw package for M.2 SSD

1 x Screw package for M.2 Key E

Documentation 1 x ACC Express Activation Key Card

1 x User guide

If any of the above items is damaged or missing, contact your retailer.

vii

Pro B760M-C specications summary

Storage

Total supports 2 x M.2 slots and 4 x SATA 6Gb/s ports*

Intel®13th & 12th Gen Processors

M.2_1 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode)

Intel®B760 Chipset

M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode)

4 x SATA 6Gb/s ports

* Intel®Rapid Storage Technology supports SATA RAID 0/1/5/10.

Ethernet 1 x Intel®1Gb Ethernet

ASUS LANGuard

Wireless &

Bluetooth®

M.2 slot only (Key E, CNVi & PCIe)*

* Wi-Fi module is sold separately.

USB

Rear USB (Total 4 ports)

2 x USB 3.2 Gen 1 ports (2 x Type-A)

2 x USB 2.0 ports (2 x Type-A)

Front USB (Total 7 ports)

1 x USB 3.2 Gen 1 connector (supports USB Type-C®)

1 x USB 3.2 Gen 1 header supports 2 additional USB 3.2 Gen 1 ports

2 x USB 2.0 headers support 4 additional USB 2.0 ports

Audio

Realtek 7.1 Surround Sound High Denition Audio CODEC*

- Supports: Jack detection, Front Panel Jack-retasking

- Supports up to 24-Bit/192kHz playback

* A chassis with an HD audio module in the front panel is required to support 7.1

Surround Sound audio output.

Back Panel I/O Ports

2 x USB 3.2 Gen 1 ports (2 x Type-A)

2 x USB 2.0 ports (2 x Type-A)

2 x DisplayPorts

1 x HDMI®port

1 x VGA port

1 x Intel®1Gb Ethernet

3 x Audio jacks

1 x PS/2 keyboard (purple) port

1 x PS/2 mouse (green) port

Internal I/O

Connectors

Fan and Cooling related

1 x 4-pin CPU Fan header

2 x 4-pin Chassis Fan headers

Power related

1 x 24-pin Main Power connector

1 x 8-pin +12V Power connector

Storage related

2 x M.2 slots (Key M)

4 x SATA 6Gb/s ports

(continued on the next page)

viii

Pro B760M-C specications summary

Internal I/O

Connectors

USB

1 x USB 3.2 Gen 1 connector (supports USB Type-C®)

1 x USB 3.2 Gen 1 header supports 2 additional USB 3.2 Gen 1 ports

2 x USB 2.0 headers support 4 additional USB 2.0 ports

Miscellaneous

1 x Clear CMOS header

1 x Chassis Intrude header

2 x COM Port headers

1 x Front Panel Audio header (AAFP)

1 x COM Debug header

1 x LPT header

1 x Mono-out header (with Amp IC)

1 x M.2 slot (Key E)

1 x SMBUS header

1 x Speaker header

1 x 10-1 pin System Panel header

Special Features

ASUS Q-Design

- Q-DIMM

- Q-LED Core

- Q-Slot

ASUS EZ DIYS

- Box Headers

Bespoke Motherboard Design & Business Focused Features

- ASUS Self Recovering BIOS

- ASUS Event Log

- ASUS Commercial BIOS kit*

- Anti-Moisture Coating

- 24/7 Reliability

- Overcurrent Protection

* Please contact the local FAE for the commercial BIOS kit.

Software Features

ASUS Exclusive Software

IT Management software supported

- ASUS Control Center Express (ACCE)

BIOS 128Mb Flash ROM

Manageability WOL by PME, PXE

Operating System Windows®11, Windows®10 64 - bit

Form Factor mATX Form Factor

9.6 inch x 9.6 inch (24.4 cm x 24.4 cm)

• Specifications are subject to change without notice. Please refer to the ASUS website

for the latest specifications.

• For more information on downloading and installing drivers and utilities for your

motherboard, please scan the QR code below:

Autres manuels pour Pro B760M-C

Table des matières

Autres manuels Asus Carte mère

Asus

Asus M4A78-E - Motherboard - ATX Manuel utilisateur

Asus

Asus P4SP-MX SE Manuel utilisateur

Asus

Asus Q370M-IM-A Manuel utilisateur

Asus

Asus H81M-V PLUS Manuel utilisateur

Asus

Asus P8Z77-V LE PLUS Manuel utilisateur

Asus

Asus PRIME H310M-F R2.0 Manuel utilisateur

Asus

Asus AAEON UP Squared V2 Manuel utilisateur

Asus

Asus PRIME Z790-P WIFI Manuel utilisateur

Asus

Asus Q87M-E Manuel utilisateur

Asus

Asus P5B VM - AiLifestyle Series Motherboard Manuel utilisateur

Asus

Asus Maximus V Extreme Manuel utilisateur

Asus

Asus M2N-MX SE PLUS Manuel utilisateur

Asus

Asus P8H77-M Manuel utilisateur

Asus

Asus TUF Z370-PRO GAMING Manuel utilisateur

Asus

Asus A7V266-E AA Manuel utilisateur

Asus

Asus P11C-E/4L Manuel utilisateur

Asus

Asus Prime Z370-P II Manuel utilisateur

Asus

Asus H110S1/CSM Manuel utilisateur

Asus

Asus H61M-E Manuel utilisateur

Asus

Asus TUF Z270 Mark 1 Manuel utilisateur

Asus

Asus EX-B660M-V5 D4 Manuel utilisateur

Asus

Asus ROG CROSSHAIR VIII EXTREME Manuel utilisateur

Asus

Asus P5KPL SE Manuel utilisateur

Asus

Asus F1A75 Manuel utilisateur

Manuels Carte mère populaires d'autres marques

DFI

DFI SD170 Manuel utilisateur

ASROCK

ASROCK ROMED8-2T Manuel utilisateur

Winmate

Winmate IC70 Manuel utilisateur

Grantech

Grantech SYS8F377VGGA-3OMN Manuel utilisateur

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Manuel utilisateur

Gigabyte

Gigabyte GA-9IVDT Manuel utilisateur

Texas Instruments

Texas Instruments ADS8372EVM Manuel utilisateur

Commell

Commell MS-C73 Manuel utilisateur

IBT Technologies

IBT Technologies MB860 Manuel utilisateur

Nvidia

Nvidia TEGRA DG-04927-001_V01 Manuel utilisateur

Biostar

Biostar M7VIT Bravo Instructions d'utilisation et d'installation

Intel

Intel D33217CK Manuel utilisateur

EPC

EPC EPC9147C Manuel utilisateur

EPOX

EPOX MU-8KHA0010 Manuel utilisateur

Ski-Doo

Ski-Doo Bombardier MPEM 219 700 090 Manuel utilisateur

Epson

Epson S5U13700P00C000 Manuel utilisateur

Gigabyte

Gigabyte GA-K8N Ultra-SLI Manuel utilisateur

Albatron

Albatron PX925XE Series Manuel utilisateur
