Asus P5G-TVM Manuel utilisateur

Motherboard

P5G-TVM

No part of this manual, including the products and software described in it, may be reproduced,

transmitted, transcribed, stored in a retrieval system, or translated into any language in any form

or by any means, except documentation kept by the purchaser for backup purposes, without the

express written permission of ASUSTeK COMPUTER INC. (“ASUS”).

Product warranty or service will not be extended if: (1) the product is repaired, modiﬁed or

altered, unless such repair, modiﬁcation of alteration is authorized in writing by ASUS; or (2)

the serial number of the product is defaced or missing.

ASUS PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER

EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES

OR CONDITIONS OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.

IN NO EVENT SHALL ASUS, ITS DIRECTORS, OFFICERS, EMPLOYEES OR AGENTS BE

LIABLE FOR ANY INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES

(INCLUDING DAMAGES FOR LOSS OF PROFITS, LOSS OF BUSINESS, LOSS OF USE

OR DATA, INTERRUPTION OF BUSINESS AND THE LIKE), EVEN IF ASUS HAS BEEN

ADVISED OF THE POSSIBILITY OF SUCH DAMAGES ARISING FROM ANY DEFECT OR

ERROR IN THIS MANUAL OR PRODUCT.

SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUAL ARE FURNISHED

FOR INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGE AT ANY TIME

WITHOUT NOTICE, AND SHOULD NOT BE CONSTRUED AS A COMMITMENT BY

ASUS. ASUS ASSUMES NO RESPONSIBILITY OR LIABILITY FOR ANY ERRORS OR

INACCURACIES THAT MAY APPEAR IN THIS MANUAL, INCLUDING THE PRODUCTS

AND SOFTWARE DESCRIBED IN IT.

Products and corporate names appearing in this manual may or may not be registered

trademarks or copyrights of their respective companies, and are used only for identiﬁcation or

explanation and to the ownersʼ beneﬁt, without intent to infringe.

E1960

First Edition V1

February 2005

iii

Contents

Notices ................................................................................................. v

Safety information .............................................................................. vi

P5G-TVM speciﬁcations summary ...................................................... vii

Chapter 1: Product introduction

1.1 Before you proceed .............................................................. 1-2

1.2 Motherboard overview .......................................................... 1-3

1.2.1 Placement direction ................................................ 1-3

1.2.2 Screw holes ............................................................. 1-3

1.2.3 Motherboard layout ................................................ 1-4

1.2.4 Layout contents ..................................................... 1-5

1.3 Central Processing Unit (CPU) .............................................. 1-7

1.3.1 Installing the CPU .................................................... 1-7

1.3.2 Installing the CPU heatsink and fan ....................... 1-10

1.3.3 Uninstalling the CPU heatsink and fan ................... 1-12

1.4 System memory .................................................................. 1-14

1.4.1 DIMM sockets location .......................................... 1-14

1.4.2 Memory Conﬁgurations ......................................... 1-14

1.4.3 Installing a DIMM ................................................... 1-16

1.4.4 Removing a DIMM .................................................. 1-16

1.5 Expansion slots ................................................................... 1-17

1.5.1 Installing an expansion card .................................. 1-17

1.5.2 Conﬁguring an expansion card .............................. 1-17

1.5.3 Interrupt assignments ........................................... 1-18

1.5.4 PCI slots ................................................................ 1-19

1.5.5 PCI Express x16 slot ............................................. 1-19

1.6 Jumpers .............................................................................. 1-20

1.7 Connectors ......................................................................... 1-22

1.7.1 Rear panel connectors .......................................... 1-22

1.7.2 Internal connectors ............................................... 1-24

Chapter 2: BIOS Setup

2.1 BIOS setup program .............................................................. 2-2

2.2 BIOS menu screen ................................................................. 2-3

2.2.1 Menu bar ................................................................. 2-3

2.2.2 Legend bar .............................................................. 2-4

Contents

2.2.3 Menu items .............................................................. 2-4

2.2.4 Sub-menu items ...................................................... 2-4

2.2.5 Conﬁguration ﬁelds ................................................. 2-4

2.2.6 Pop-up window ........................................................ 2-5

2.2.7 General help ............................................................ 2-5

2.3 Main menu ............................................................................. 2-6

2.3.1 System Time ............................................................ 2-6

2.3.2 System Date ............................................................ 2-6

2.3.3 Legacy Diskette A ................................................... 2-6

2.3.4 Primary and Secondary IDE Master/Slave ................ 2-7

2.3.5 HDD SMART Monitoring ........................................... 2-8

2.3.6 Installed Memory ...................................................... 2-8

2.3.7 Usable Memory ........................................................ 2-8

2.4 Advanced Menu .................................................................... 2-9

2.4.1 CPU Conﬁguration .................................................... 2-9

2.4.2 Memory Conﬁguration ............................................ 2-11

2.4.3 Chipset ................................................................... 2-12

2.4.4 PCIPnP .................................................................... 2-13

2.4.5 Onboard Device Conﬁguration ............................... 2-14

2.4.6 USB Conﬁguration .................................................. 2-16

2.5 Power menu ........................................................................ 2-17

2.5.1 ACPI Suspend Type ................................................ 2-17

2.5.2 ACPI APCI Support ................................................. 2-17

2.5.3 APM Conﬁguration .................................................. 2-18

2.5.4 Hardware Monitor ................................................... 2-20

2.6 Boot menu .......................................................................... 2-21

2.6.1 Boot Device Priority ............................................... 2-22

2.6.2 Removable Drives ................................................... 2-23

2.6.3 Hard Disk Drives ..................................................... 2-23

2.6.4 Network Boot Priority ............................................ 2-24

2.6.5 Boot Settings Conﬁguration ................................... 2-24

2.6.6 Security .................................................................. 2-26

2.7 Exit menu ............................................................................ 2-28

Notices

Federal Communications Commission Statement

This device complies with Part 15 of the FCC Rules. Operation is subject to

the following two conditions:

•

This device may not cause harmful interference, and

•

This device must accept any interference received including

interference that may cause undesired operation.

This equipment has been tested and found to comply with the limits for a

Class B digital device, pursuant to Part 15 of the FCC Rules. These limits

are designed to provide reasonable protection against harmful interference

in a residential installation. This equipment generates, uses and can radiate

radio frequency energy and, if not installed and used in accordance with

manufacturerʼs instructions, may cause harmful interference to radio

communications. However, there is no guarantee that interference will

not occur in a particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be determined by

turning the equipment off and on, the user is encouraged to try to correct

the interference by one or more of the following measures:

•

Reorient or relocate the receiving antenna.

•

Increase the separation between the equipment and receiver.

•

Connect the equipment to an outlet on a circuit different from that to

which the receiver is connected.

•

Consult the dealer or an experienced radio/TV technician for help.

Canadian Department of Communications Statement

This digital apparatus does not exceed the Class B limits for radio noise

emissions from digital apparatus set out in the Radio Interference

Regulations of the Canadian Department of Communications.

This class B digital apparatus complies with Canadian

ICES-003.

The use of shielded cables for connection of the monitor to the graphics

card is required to assure compliance with FCC regulations. Changes

or modiﬁcations to this unit not expressly approved by the party

responsible for compliance could void the userʼs authority to operate

this equipment.

Safety information

Electrical safety

•

To prevent electrical shock hazard, disconnect the power cable from

the electrical outlet before relocating the system.

•

When adding or removing devices to or from the system, ensure that

the power cables for the devices are unplugged before the signal

cables are connected. If possible, disconnect all power cables from the

existing system before you add a device.

•

Before connecting or removing signal cables from the motherboard,

ensure that all power cables are unplugged.

•

Seek professional assistance before using an adapter or extension

cord. These devices could interrupt the grounding circuit.

•

Make sure that your power supply is set to the correct voltage in your

area. If you are not sure about the voltage of the electrical outlet you

are using, contact your local power company.

•

If the power supply is broken, do not try to fix it by yourself. Contact

a qualified service technician or your retailer.

Operation safety

•

Before installing the motherboard and adding devices on it, carefully

read all the manuals that came with the package.

•

Before using the product, make sure all cables are correctly connected

and the power cables are not damaged. If you detect any damage,

contact your dealer immediately.

•

To avoid short circuits, keep paper clips, screws, and staples away from

connectors, slots, sockets and circuitry.

•

Avoid dust, humidity, and temperature extremes. Do not place the

product in any area where it may become wet.

•

Place the product on a stable surface.

•

If you encounter technical problems with the product, contact a

qualified service technician or your retailer.

vii

P5G-TVM speciﬁcations summary

(continued on the next page)

CPU

Chipset

Front Side Bus

Memory

Expansion slots

Storage

Audio

LAN

USB

BIOS features

Rear panel

LGA775 socket for Intel® Pentium® 4/Celeron processor

Compatible with Intel® Mainstream/Value FMB

processors

Supports Intel® Hyper-Threading Technology

Northbridge: Intel® 915G Graphics Memory and

Controller Hub (GMCH)

Southbridge: Intel® 82801FB ICH6

800/533 MHz

4 x 184-pin DIMM sockets support unbufferred non-ECC

400/333 MHz DDR memory modules

1 x PCI Express™ x16 slot for discrete graphics card

3 x PCI slots

Intel® ICH6 Southbridge supports:

- 2 x Ultra ATA 100/66/33 hard disk drives

- 4 x Serial ATA hard disk drives

Realtek® ALC655 6-channel CODEC

Realtek® RTL 8110S Gigabit LAN controller

Supports up to 8 USB 2.0 ports

4 MB FWH, Phoenix Award, Green, PnP, DMI 2.3.4,

ACPI 1.0, SM BIOS 2.3

1 x PS/2 mouse port

1 x Parallel port

1 x LAN (RJ-45) port

6-channel audio ports (optional 8-channel audio ports)

4 x USB 2.0 ports

1 x VGA port

1 x Serial port

1 x PS/2 keyboard port

viii

1 x Floppy disk drive connector

1 x Primary IDE connector

4 x Serial ATA connectors

1 x CPU fan connector

1 x Chassis fan connector

4 x USB 2.0 connectors

1 x 24-pin ATX power connector

1 x 4-pin ATX 12 V power connector

1 x Front panel audio connector

1 x Chassis intrusion connector

1 x Infrared module connector(Optional)

1 x S/PDIF Out connector

1 x Power LED connector

ATX power supply (with 24-pin and 4-pin 12 V plugs)

ATX 12 V 2.0 compliant

Micro ATX form factor: 9.6 in x 9.6 in (24.5 cm x 24.5 cm)

P5G-TVM speciﬁcations summary

*Speciﬁcations are subject to change without notice.

Internal

connectors

Power

requirement

Form factor

1-1

ASUS P5G-TVM

Product

introduction

This chapter describes the motherboard

features and the new technologies

it supports.

1-2 Chapter 1: Hardware information

Onboard LED

The motherboard comes with a standby power LED that lights up to

indicate that the system is ON, in sleep mode, or in soft-off mode.

This is a reminder that you should shut down the system and unplug

the power cable before removing or plugging in any motherboard

component. The illustration below shows the location of the onboard

LED.

•

Unplug the power cord from the wall socket before touching any

component.

•

Use a grounded wrist strap or touch a safely grounded object or

a metal object, such as the power supply case, before handling

components to avoid damaging them due to static electricity.

•

Hold components by the edges to avoid touching the ICs on them.

•

Whenever you uninstall any component, place it on a grounded

antistatic pad or in the bag that came with the component.

•

Before you install or remove any component, ensure that the ATX

power supply is switched off or the power cord is detached from

the power supply. Failure to do so may cause severe damage to the

motherboard, peripherals, and/or components.

1.1 Before you proceed

Take note of the following precautions before you install components into

the system.

P5G-TVM

P5G-TVM Onboard LED

SB_PWR1

Standby

Power

OFF

Powered

Off

Autres manuels pour P5G-TVM

Table des matières

Autres manuels Asus Carte mère

Asus

Asus P5Q Premium - Motherboard - ATX Manuel utilisateur

Asus

Asus H170-PLUS D3 Manuel utilisateur

Asus

Asus P7H55-M BR Manuel utilisateur

Asus

Asus P5B VM - AiLifestyle Series Motherboard Manuel utilisateur

Asus

Asus P2B-N Manuel utilisateur

Asus

Asus DSBF-D12 - Motherboard - SSI EEB 3.61 Manuel utilisateur

Asus

Asus P65UP5-PKND Manuel utilisateur

Asus

Asus PRIME H410M-ACSM Manuel utilisateur

Asus

Asus PRIME Z370-A II Manuel utilisateur

Asus

Asus AAEON UP Squared Pro Manuel utilisateur

Asus

Asus P7P55D-E LX Manuel utilisateur

Asus

Asus P7P55-M Manuel utilisateur

Asus

Asus Dual TualatinTM Motherboard TRL-DLS Manuel utilisateur

Asus

Asus P5KPL/1600 Manuel utilisateur

Asus

Asus M5A99FX PRO R2.0 Manuel utilisateur

Asus

Asus H110M-A D3 Manuel utilisateur

Asus

Asus P6TD - Deluxe Motherboard - ATX Manuel utilisateur

Asus

Asus P8H61 R2.0 Series Manuel utilisateur

Asus

Asus P5VDC-X Manuel utilisateur

Asus

Asus Motherboard P5PL2 Guide de démarrage rapide

Asus

Asus AAEON UP Xtreme i11 Manuel utilisateur

Asus

Asus MES-VM Manuel utilisateur

Asus

Asus KFN4-D16 1U Manuel utilisateur

Asus

Asus Z97-K Manuel utilisateur

Manuels Carte mère populaires d'autres marques

DFI

DFI SD170 Manuel utilisateur

ASROCK

ASROCK ROMED8-2T Manuel utilisateur

Winmate

Winmate IC70 Manuel utilisateur

Grantech

Grantech SYS8F377VGGA-3OMN Manuel utilisateur

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Manuel utilisateur

Gigabyte

Gigabyte GA-9IVDT Manuel utilisateur

Texas Instruments

Texas Instruments ADS8372EVM Manuel utilisateur

Commell

Commell MS-C73 Manuel utilisateur

IBT Technologies

IBT Technologies MB860 Manuel utilisateur

Nvidia

Nvidia TEGRA DG-04927-001_V01 Manuel utilisateur

Biostar

Biostar M7VIT Bravo Instructions d'utilisation et d'installation

Intel

Intel D33217CK Manuel utilisateur

EPC

EPC EPC9147C Manuel utilisateur

EPOX

EPOX MU-8KHA0010 Manuel utilisateur

Ski-Doo

Ski-Doo Bombardier MPEM 219 700 090 Manuel utilisateur

Epson

Epson S5U13700P00C000 Manuel utilisateur

Gigabyte

Gigabyte GA-K8N Ultra-SLI Manuel utilisateur

Albatron

Albatron PX925XE Series Manuel utilisateur
