Asus MES-VM Manuel utilisateur

MES-VM

Socket 370 microATX Motherboard

USER’S MANUAL

2ASUS MES-VM User’s Manual

USER'S NOTICE

Product Name: ASUS MES-VM

Manual Revision: 1.02 E339

Release Date: March 1999

No part of this manual, including the products and software described in it, may be repro-

duced, transmitted, transcribed, stored in a retrieval system, or translated into any language in

any form or by any means, except documentation kept by the purchaser for backup purposes,

without the express written permission of ASUSTeK COMPUTER INC. (“ASUS”).

ASUS PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY OF ANY KIND,

EITHER EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED

WARRANTIES OR CONDITIONS OF MERCHANTABILITYOR FITNESS FORAPAR-

TICULAR PURPOSE. IN NO EVENT SHALL ASUS, ITS DIRECTORS, OFFICERS,

EMPLOYEES OR AGENTS BE LIABLE FOR ANY INDIRECT, SPECIAL, INCIDEN-

TAL, OR CONSEQUENTIAL DAMAGES (INCLUDING DAMAGES FOR LOSS OF

PROFITS, LOSS OF BUSINESS, LOSS OF USE OR DATA, INTERRUPTION OF BUSI-

NESS AND THE LIKE), EVEN IF ASUS HAS BEEN ADVISED OF THE POSSIBILITY

OF SUCH DAMAGES ARISING FROM ANY DEFECT OR ERROR IN THIS MANUAL

OR PRODUCT.

Product warranty or service will not be extended if: (1) the product is repaired, modified or

altered, unless such repair, modification of alteration is authorized in writing byASUS; or (2)

the serial number of the product is defaced or missing.

Products and corporate names appearing in this manual may or may not be registered trade-

marks or copyrights of their respective companies, and are used only for identification or

explanation and to the owners’ benefit, without intent to infringe.

• Intel, LANDesk, and Pentium are registered trademarks of Intel Corporation.

• IBM and OS/2 are registered trademarks of International Business Machines.

• Symbios is a registered trademark of Symbios Logic Corporation.

• Windows and MS-DOS are registered trademarks of Microsoft Corporation.

• Adobe and Acrobat are registered trademarks of Adobe Systems Incorporated.

The product name and revision number are both printed on the product itself. Manual revi-

sions are released for each product design represented by the digit before and after the period

of the manual revision number. Manual updates are represented by the third digit in the manual

revision number.

For previous or updated manuals, BIOS, drivers, or product release information, contactASUS

at http://www.asus.com.tw or through any of the means indicated on the following page.

SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUALARE FUR-

NISHED FOR INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGE AT

ANY TIME WITHOUT NOTICE, AND SHOULD NOT BE CONSTRUED AS A COM-

MITMENT BY ASUS. ASUS ASSUMES NO RESPONSIBILITY OR LIABILITY FOR

ANYERRORS ORINACCURACIESTHATMAYAPPEARINTHIS MANUAL, INCLUD-

ING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT.

ASUS MES-VM User’s Manual 3

ASUS CONTACT INFORMATION

ASUSTeK COMPUTER INC. (Asia-Pacific)

Marketing

Address: 150 Li-Te Road, Peitou, Taipei, Taiwan 112

Telephone: +886-2-2894-3447

Fax: +886-2-2894-3449

Email: [email protected]

Technical Support

Tel (English): +886-2-2894-3447 ext. 706

Tel (Chinese): +886-2-2894-3447 ext. 701

Fax: +886-2-2895-9254

Email: [email protected]

Newsgroup: news2.asus.com.tw

WWW: www.asus.com.tw

FTP: ftp.asus.com.tw/pub/ASUS

ASUS COMPUTER INTERNATIONAL (America)

Marketing

Address: 6737 Mowry Avenue, Mowry Business Center, Building 2

Newark, CA 94560, USA

Fax: +1-510-608-4555

Email: [email protected]

Technical Support

Fax: +1-510-608-4555

BBS: +1-510-739-3774

Email: [email protected]

WWW: www.asus.com

FTP: ftp.asus.com.tw/pub/ASUS

ASUS COMPUTER GmbH (Europe)

Marketing

Address: Harkort Str. 25, 40880 Ratingen, BRD, Germany

Telephone: 49-2102-445011

Fax: 49-2102-442066

Email: [email protected]

Technical Support

Hotline: 49-2102-499712

BBS: 49-2102-448690

Email: [email protected]

WWW: www.asuscom.de

FTP: ftp.asuscom.de/pub/ASUSCOM

4ASUS MES-VM User’s Manual

CONTENTS

I. INTRODUCTION.............................................................................. 7

How this manual is organized............................................................. 7

Item Checklist ..................................................................................... 7

II. FEATURES ....................................................................................... 8

The ASUS MES-VM Motherboard .................................................... 8

Introduction to ASUS Smart Series Motherboards ....................... 9

Parts of the ASUS MES-VM Motherboard ...................................... 11

III. HARDWARE SETUP.................................................................... 12

ASUS MES-VM Motherboard Layout ............................................. 12

Hardware Setup Steps ....................................................................... 14

1. Motherboard Settings.................................................................... 14

VGA Shared Memory with One DIMM................................ 16

2. System Memory (DIMM) ............................................................. 16

DIMM Memory Installation .................................................. 17

3. Central Processing Unit (CPU).................................................... 18

4. Expansion Cards ........................................................................... 19

Expansion Card Installation Procedure ................................. 19

Assigning IRQs for Expansion Cards.................................... 19

Assigning DMA Channels for ISA Cards.............................. 20

ISA Cards and Hardware Monitor ......................................... 20

5. External Connectors..................................................................... 21

Power Connection Procedures .......................................................... 29

IV. BIOS SETUP................................................................................... 30

Flash Memory Writer Utility ............................................................ 30

Main Menu .................................................................................. 30

Managing and Updating Your Motherboard’s BIOS................... 32

6. BIOS Setup Program .................................................................... 33

BIOS Menu Bar........................................................................... 34

Legend Bar .................................................................................. 34

Main Menu........................................................................................ 36

Primary Master/Slave & Secondary Master/Slave...................... 37

Advanced (main menu)..................................................................... 42

Advanced (sub-menu 1/4) ........................................................... 43

Advanced (sub-menu 2/4) ........................................................... 45

Advanced (sub-menu 3/4) ........................................................... 47

Advanced (sub-menu 3/4-1/3)..................................................... 48

Advanced (sub-menu 3/4-2/3)..................................................... 49

Advanced (sub-menu 4/4) ........................................................... 50

ASUS MES-VM User’s Manual 5

CONTENTS

Power Menu ...................................................................................... 51

Power (sub-menu 1/2) ................................................................. 53

Power (sub-menu 2/2) ................................................................. 54

Boot Menu ........................................................................................ 55

Exit Menu ......................................................................................... 57

V. APPENDIX ....................................................................................... 59

The ASUS PCI-L101 Fast Ethernet Card ......................................... 59

Features ....................................................................................... 60

Software Driver Support ............................................................. 60

Question and Answer .................................................................. 60

Glossary ............................................................................................ 61

6ASUS MES-VM User’s Manual

FCC & DOC COMPLIANCE

FederalCommunications Commission Statement

This device complies with FCC Rules Part 15. Operation is subject to the following

two conditions:

• This device may not cause harmful interference, and

• This device must accept any interference received, including interference that

may cause undesired operation.

This equipment has been tested and found to comply with the limits for a Class B

digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to

provide reasonable protection against harmful interference in a residential installa-

tion. This equipment generates, uses and can radiate radio frequency energy and, if

not installed and used in accordance with manufacturer’s instructions, may cause

harmful interference to radio communications. However, there is no guarantee that

interference will not occur in a particular installation. If this equipment does cause

harmful interference to radio or television reception, which can be determined by

turning the equipment off and on, the user is encouraged to try to correct the interfer-

ence by one or more of the following measures:

• Re-orient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment to an outlet on a circuit different from that to which the

receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

WARNING! Be sure that there is sufficient air circulation across the processor’s

heatsink by regularly checking that your CPU fan is working. Without sufficient

circulation, the processor could overheat and damage both the processor and the

motherboard. You may install an auxiliary fan, if necessary.

CanadianDepartment of Communications Statement

This digital apparatus does not exceed the Class B limits for radio noise emissions

from digital apparatus set out in the Radio Interference Regulations of the Canadian

Department of Communications.

ASUS MES-VM User’s Manual 7

I. INTRODUCTION

Sections/Checklist

How this manual is organized

This manual is divided into the following sections:

I. Introduction Manual information and checklist

II. Features Information and specifications concerning this product

III. Hardware Setup Instructions on setting up the motherboard

IV. BIOS Setup Instructions on setting up the BIOS software

V. Appendix Optional items and general reference

Item Checklist

Check that your package is complete. If you discover damaged or missing items,

please contact your retailer.

(1) ASUS Motherboard

(1) IDE ribbon cable for master and slave drives

(1) Ribbon cable for (1) 5.25” and (2) 3.5” floppy disk drives

(1) Serial COM2 cable with bracket

(1) Bag of spare jumper caps

(1) Support CD with drivers and utilities

(1) This Motherboard User’s Manual

ASUS IrDA-compliant infrared module (optional)

ASUS PCI-L101 Wake-On-LAN 10/100 Fast Ethernet Card (optional)

8ASUSMES-VMUser’sManual

II. FEATURES

Features

II. FEATURES

The ASUS MES-VM Motherboard

TheASUS MES-VM motherboard is carefully designed for the demanding PC user

who wants many intelligent features in a small package.

•Intel Processor Support: Supports Intel’s Celeron processor designed for the

Socket 370 and packaged in Plastic Pin Grid Array (PPGA).

•SiS Chipset: Features 100MHz FSB SiS’ 620 chipset with SiS 6326 AGP 2X

graphics built-in and support for ATA-66 which allows 66MHz IDE transfers.

•Enhanced ACPI & Anti-Boot Virus BIOS: Programmable BIOS (Flash

EEPROM),offering enhancedACPI forWindows 98 compatibility, built-in hard-

ware-based virus protection, and autodetection of most devices for virtually au-

tomatic setup.

•Versatile Memory: Equipped with two DIMM sockets to support Intel PC100-

compliant SDRAMs (8, 16, 32, 64, 128, or 256MB) up to 512MB.

•Built-in Graphics: Built-in AGP 2X graphics controller can use shared system

memory or optional dedicated onboard 8MB SDRAM.

•OnboardAudio andAC’97 CODEC (optional): Features a 32-bit Crystal PCI

audio onboard. Features an 18-bit stereo, full duplex, audio codec that conforms

to AC’97 analog component specfications. Includes a complete online help to

guide you through the audio software.

•PCI & ISA Expansion: Provides three 32-bit PCI expansion slots and one 16-

bit ISA expansion slot .

•Wake-On-LAN Connector: Supports Wake-On-LAN activity through an op-

tional ASUS PCI-L101 Fast Ethernet card or a similar ethernet card.

•SB-Link™: Features Creative’s SB-Link™, allowing SB16 compatibility, us-

ing Intel’s PC-PCI and serialized IRQ protocols, toAWE64D or compatible PCI

audio cards.

• Super Multi-I/O: Provides two high-speed UART compatible serial ports and

one parallel port with EPP and ECP capabilities.

• Desktop ManagementInterface (DMI): Supports DMI through BIOS, which

allows hardware to communicate within a standard protocol creating a higher

level of compatibility. (Requires DMI-enabled components.)

•IrDA: Supports an optional infrared port module for wireless interface.

ASUS MES-VM User’s Manual 9

II. FEATURES

Smart Series

Introduction to ASUS Smart Series Motherboards

Performance

•ATA-66 & Ultra DMA/33: Comes with an onboard PCI Bus Master IDE con-

troller with two connectors that support four IDE devices in two channels. Sup-

ports ATA-66, Ultra DMA/33, PIO Modes 3 & 4 and Bus Master IDE DMA

Mode 2, and supports Enhanced IDE devices, such as Tape Backup, CD-ROM,

CD-R/RW, and LS-120 drives.

• 66/100MHzAsynchronous&100/100MHzSynchronousHost/DRAMClock

Support: CPU frequency can operate at 66MHz or 100MHz while system

memory operates at 100MHz or 66MHz. This can optimize the VGA perfor-

mance under shared memory configuration.

• DoubleorQuadrupletheIDETransferSpeed: IDE transfers using UltraDMA/

33 Bus Master IDE can handle rates up to 33MB/sec and up to 66MB/sec using

SiS’ATA-66 technology. The best of all is that these new technology is compat-

ible with existing ATA-2 IDE specifications so there is no need to upgrade cur-

rent IDE devices or cables.

•Concurrent PCI: Concurrent PCI allows multiple PCI transfers from PCI mas-

ter buses to memory to CPU.

• SDRAM Optimized Performance: ASUS smart series motherboards support

the new generation memory, Synchronous Dynamic Random Access Memory

(SDRAM), which increases the data transfer rate to 800MB/s max using PC100

SDRAM.

• ACPIReady:ACPI(Advanced Configuration and Power Interface) isalsoimple-

mented on all ASUS smart series motherboards. ACPI provides more Energy

Saving Features for future operating systems (OS) supporting OS Direct Power

Management (OSPM) functionality. With these features implemented in the OS,

PCs can be ready around the clock, yet satisfy all the energy saving standards.

To fully utilize the benefits ofACPI, anACPI-supported OS such as the succes-

sor of Windows 95 must be used.

• PC’98Compliant: BoththeBIOSand hardware levels of the motherboard meets

PC’98 compliancy. The new PC’98 requirements for systems and components are

based on the following high-level goals: Support for Plug and Play compatibility

and power management for configuring and managing all system components,

and 32-bit device drivers and installation procedures for Windows 95/98/NT.

10 ASUSMES-VMUser’sManual

II. FEATURES

Smart Series

II. FEATURES

Intelligence

• Fan Status Monitoring and Alarm: To prevent system overheat and system

damage, the CPU, power supply, and system fans can be monitored for RPM

and failure. All the fans are set for its normal RPM range and alarm thresholds.

•Temperature Monitoring and Alert: To prevent system overheat and system

damage, this motherboard supports Socket 370 processor thermal sensing.

•Voltage Monitoring andAlert: System voltage levels are monitored to ensure

stable current to critical motherboard components. Voltage specifications are

more critical for future processors, so monitoring is necessary to ensure proper

system configuration and management.

• SystemResourcesAlert:Today’s operating systems such as Windows 95, Win-

dows NT, and OS/2, require much more memory and hard drive space to present

enormous user interfaces and run large applications. The system resource moni-

tor will warn the user before the system resources are used up to prevent pos-

sible application crashes. Suggestions will give the user information on manag-

ing their limited resources more efficiently.

• Auto Fan Off: The system fans will power off automatically even in sleep

mode. This function reduces both energy consumption and system noise, and is

an important feature to implement silent PC systems.

• Dual Function Power Button: The system can be in one of two states, one is

Sleep mode and the other is the Soft-Off mode. Pushing the power button for

less than 4 seconds places the system into Sleep mode. When the power button

is pressed for more than 4 seconds, it enters the Soft-Off mode.

• Remote Ring On (requires modem): This allows a computer to be turned on

remotely through an internal or external modem. With this benefit on-hand, any

usercanaccessvitalinformationfromtheircomputerfrom anywhere in the world!

• Message LED (requires ACPI OS support): Chassis LEDs now act as infor-

mation providers. Through the way a particular LED illuminates, the user can

determine the stage the computer is in. A simple glimpse provides useful infor-

mation to the user.

• Keyboard Power Up: Keyboard Power Up can be enabled or disabled to allow

the computer to be powered on by pressing the space bar on the keyboard.

Autres manuels pour MES-VM

Table des matières

Autres manuels Asus Carte mère

Asus

Asus Motherboard PR-DLS533 Manuel utilisateur

Asus

Asus P5E WS PROFESSIONAL Manuel utilisateur

Asus

Asus Pro H510M-C Manuel utilisateur

Asus

Asus TUF GAMING B760-PLUS WIFI D4 Manuel utilisateur

Asus

Asus P5Q SE R Manuel utilisateur

Asus

Asus P5S-VM Manuel utilisateur

Asus

Asus Pro Q670M-C Manuel utilisateur

Asus

Asus P8H61-I LX R2.0 RM SI Manuel utilisateur

Asus

Asus PRIME H510M-E Manuel utilisateur

Asus

Asus Pro B660M-C D4 Manuel utilisateur

Asus

Asus P5P41C Manuel utilisateur

Asus

Asus KFN5-D - Motherboard - SSI EEB 3.51 Manuel utilisateur

Asus

Asus M2N68-AM SE Manuel utilisateur

Asus

Asus P5N7A-VM Manuel utilisateur

Asus

Asus A8N32-SLI - Socket 939 NVIDIA nForce SPP 100 ATX AMD Motherboard... Manuel utilisateur

Asus

Asus P5N32-SLI SE DELUXE Instructions d'utilisation

Asus

Asus B85B-V Plus Manuel utilisateur

Asus

Asus AAEON UP Xtreme UP-WHL01 Manuel utilisateur

Asus

Asus P8H61-M LK R2.0 Manuel utilisateur

Asus

Asus P5WD2-E Premium Manuel utilisateur

Asus

Asus TUF GAMING B450M-PRO S Manuel utilisateur

Asus

Asus ROG STRIX Z390-E GAMING Manuel utilisateur

Asus

Asus P5N73-AM Manuel utilisateur

Asus

Asus F1A55-M/CSM Manuel utilisateur

Manuels Carte mère populaires d'autres marques

DFI

DFI SD170 Manuel utilisateur

ASROCK

ASROCK ROMED8-2T Manuel utilisateur

Winmate

Winmate IC70 Manuel utilisateur

Grantech

Grantech SYS8F377VGGA-3OMN Manuel utilisateur

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Manuel utilisateur

Gigabyte

Gigabyte GA-9IVDT Manuel utilisateur

Texas Instruments

Texas Instruments ADS8372EVM Manuel utilisateur

Commell

Commell MS-C73 Manuel utilisateur

IBT Technologies

IBT Technologies MB860 Manuel utilisateur

Nvidia

Nvidia TEGRA DG-04927-001_V01 Manuel utilisateur

Biostar

Biostar M7VIT Bravo Instructions d'utilisation et d'installation

Intel

Intel D33217CK Manuel utilisateur

EPC

EPC EPC9147C Manuel utilisateur

EPOX

EPOX MU-8KHA0010 Manuel utilisateur

Ski-Doo

Ski-Doo Bombardier MPEM 219 700 090 Manuel utilisateur

Epson

Epson S5U13700P00C000 Manuel utilisateur

Gigabyte

Gigabyte GA-K8N Ultra-SLI Manuel utilisateur

Albatron

Albatron PX925XE Series Manuel utilisateur
