Asus P4SP-MX SE Manuel utilisateur

Motherboard

P4SP-MX SE

User Guide

Checklist

No part of this manual, including the products and software described in it, may be

reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any

language in any form or by any means, except documentation kept by the purchaser for

backup purposes, without the express written permission of ASUSTeK COMPUTER INC.

(“ASUS”).

Product warranty or service will not be extended if: (1) the product is repaired, modified or

altered, unless such repair, modification of alteration is authorized in writing by ASUS; or (2)

the serial number of the product is defaced or missing.

ASUS PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER

EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES

OR CONDITIONS OF MERCHANTABILITY OR FITNESS FORA PARTICULAR PURPOSE.

IN NO EVENT SHALLASUS, ITS DIRECTORS, OFFICERS, EMPLOYEES OR AGENTS BE

LIABLE FOR ANY INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES

(INCLUDING DAMAGES FOR LOSS OF PROFITS, LOSS OF BUSINESS, LOSS OF USE

OR DATA, INTERRUPTION OF BUSINESS AND THE LIKE), EVEN IF ASUS HAS BEEN

ADVISED OF THE POSSIBILITY OF SUCH DAMAGES ARISING FROM ANY DEFECT OR

ERROR IN THIS MANUAL OR PRODUCT.

SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUALARE FURNISHED

FOR INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGEATANY TIME

WITHOUT NOTICE,AND SHOULD NOT BE CONSTRUED AS A COMMITMENT BYASUS.

ASUS ASSUMES NO RESPONSIBILITY OR LIABILITY FOR ANY ERRORS OR

INACCURACIES THAT MAY APPEAR IN THIS MANUAL, INCLUDING THE PRODUCTS

AND SOFTWARE DESCRIBED IN IT.

Products and corporate names appearing in this manual may or may not be registered

trademarks or copyrights of their respective companies, and are used only for identification or

explanation and to the owners’ benefit, without intent to infringe.

E1676

First Edition V1

July 2004

iii

Contents

Notices ............................................................................................v

Safety information ..........................................................................vi

P4SP-MX SE specification summary ............................................ vii

About this guide............................................................................ viii

Chapter 1: Product introduction

1.1 Welcome! ........................................................................... 1-2

1.2 Package contents............................................................... 1-2

1.3 Special features.................................................................. 1-2

1.3.1 Product highlights .................................................. 1-2

1.3.2 ASUS unique features ........................................... 1-4

1.4 Before you proceed ............................................................ 1-5

1.5 Motherboard overview........................................................ 1-6

1.5.1 Motherboard layout ................................................ 1-6

1.5.2 Placement direction ............................................... 1-7

1.5.3 Screw holes ........................................................... 1-7

1.6 Central Processing Unit (CPU)........................................... 1-8

1.6.1 Overview ................................................................ 1-8

1.6.2 Installing the CPU .................................................. 1-9

1.7 System memory ............................................................... 1-10

1.7.1 DIMM sockets location......................................... 1-10

1.7.2 Memory configurations ........................................ 1-10

1.7.3 Installing a DIMM ..................................................1-11

1.7.4 Removing a DIMM ................................................1-11

1.8 Expansion slots ................................................................ 1-12

1.8.1 Installing an expansion card ................................ 1-12

1.8.2 Configuring an expansion card ............................ 1-12

1.8.3 PCI slots .............................................................. 1-14

1.8.4 AGP slot............................................................... 1-14

1.9 Jumpers............................................................................ 1-15

1.10 Connectors ....................................................................... 1-17

1.10.1 Rear panel connectors......................................... 1-17

1.10.2 Internal connectors .............................................. 1-18

Safeguards

Contents

Chapter 2: BIOS information

2.1 Managing and updating your BIOS .................................... 2-2

2.1.1 Creating a bootable floppy disk ............................. 2-2

2.1.2 Using ASUS EZ Flash to update the BIOS ............ 2-3

2.1.3 Using the AFLASH utility........................................ 2-4

2.1.4 Recovering the BIOS with CrashFree BIOS .......... 2-6

2.1.5 ASUS Update ........................................................ 2-7

2.2 BIOS Setup program .......................................................... 2-9

2.2.1 BIOS menu bar ...................................................... 2-9

2.2.2 Legend bar........................................................... 2-10

2.3 Main menu.........................................................................2-11

2.3.1 Primary and Secondary Master/Slave ................. 2-13

2.3.2 Keyboard Features .............................................. 2-15

2.4 Advanced menu ............................................................... 2-16

2.4.1 Chip Configuration ............................................... 2-18

2.4.2 I/O Device Configuration...................................... 2-20

2.4.3 PCI Configuration ................................................ 2-21

2.5 Power menu ..................................................................... 2-23

2.5.1 Power Up Control ................................................ 2-24

2.5.2 Hardware Monitor ................................................ 2-25

2.6 Boot menu ........................................................................ 2-26

2.7 Exit menu ......................................................................... 2-28

Chapter 3: Software support

3.1 Install an operating system................................................. 3-2

3.2 Support CD information...................................................... 3-2

3.2.1 Running the support CD ........................................ 3-2

3.2.2 Installation items .................................................... 3-3

Notices

Federal Communications Commission Statement

This device complies with FCC Rules Part 15. Operation is subject to the

following two conditions:

• This device may not cause harmful interference, and

• This device must accept any interference received including interference

that may cause undesired operation.

This equipment has been tested and found to comply with the limits for a

Class B digital device, pursuant to Part 15 of the FCC Rules. These limits

are designed to provide reasonable protection against harmful interference

in a residential installation. This equipment generates, uses and can radiate

radio frequency energy and, if not installed and used in accordance with

manufacturer’s instructions, may cause harmful interference to radio

communications. However, there is no guarantee that interference will not

occur in a particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be determined by

turning the equipment off and on, the user is encouraged to try to correct the

interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment to an outlet on a circuit different from that to

which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Canadian Department of Communications Statement

This digital apparatus does not exceed the Class B limits for radio noise

emissions from digital apparatus set out in the Radio Interference

Regulations of the Canadian Department of Communications.

This class B digital apparatus complies with Canadian ICES-003.

The use of shielded cables for connection of the monitor to the

graphics card is required to assure compliance with FCC regulations.

Changes or modifications to this unit not expressly approved by the

party responsible for compliance could void the user’s authority to

operate this equipment.

Safety information

Electrical safety

• To prevent electrical shock hazard, disconnect the power cable from

the electrical outlet before relocating the system.

• When adding or removing devices to or from the system, ensure that

the power cables for the devices are unplugged before the signal

cables are connected. If possible, disconnect all power cables from the

existing system before you add a device.

• Before connecting or removing signal cables from the motherboard,

ensure that all power cables are unplugged.

• Seek professional assistance before using an adpater or extension

cord. These devices could interrupt the grounding circuit.

• Make sure that your power supply is set to the correct voltage in your

area. If you are not sure about the voltage of the electrical outlet you

are using, contact your local power company.

• If the power supply is broken, do not try to fix it by yourself. Contact a

qualified service technician or your retailer.

Operation safety

• Before installing the motherboard and adding devices on it, carefully

read all the manuals that came with the package.

• Before using the product, make sure all cables are correctly connected

and the power cables are not damaged. If you detect any damage,

contact your dealer immediately.

• To avoid short circuits, keep paper clips, screws, and staples away from

connectors, slots, sockets and circuitry.

• Avoid dust, humidity, and temperature extremes. Do not place the

product in any area where it may become wet.

• Place the product on a stable surface.

• If you encounter technical problems with the product, contact a

qualified service technician or your retailer.

vii

P4SP-MX SE specification summary*

CPU

Chipset

Front Side Bus (FSB)

Memory

Expansion slots

VGA

Storage

Audio

LAN

Special features

Rear panel I/O

Internal I/O

BIOS features

(Continued on the next page.)

Socket 478 for Intel

Pentium

4/Celeron processor

Intel

Hyper-Threading technology ready

New power design for next generation Intel

Prescott CPU

SiS651 Northbridge

SiS962L Southbridge

533/400MHz

2 x 184-pin DDR DIMM sockets for up to 2GB memory

Supports PC2700/2100/1600 unbuffered non-ECC DDR

DIMMs.

1 x AGP 4X (1.5V only)

3 x PCI

Integrated 3D graphics controller in SiS 651 chip

2 x UltraDMA133, PIO Mode 0 ~ 4

ADI AD1888 6-channel audio CODEC

SiS962L integrated 10/100 Mbps Fast Ethernet with Realtek

external PHY

Power loss restart

Digital audio via an S/PDIF out inteface

1 x Parallel port

1 x S/PDIF out port

1 x Video port

1 x PS/2 keyboard port

1 x PS/2 mouse port

1 x RJ-45 port

4 x USB 2.0/USB 1.1 ports

Line In/Line Out/Microphone ports

USB 2.0 connector for two additional USB ports

CPU and chassis fan connectors

20-pin/4-pin ATX 12V power connectors

CD/AUX audio connectors

GAME/MIDI connector

Front panel audio connector

Serial (COM1) connector

Panel connector

2Mb Flash ROM, DMI 2.0, Award BIOS. TCAV PnP features,

SM BIOS 2.3, WfM 2.0, ASUS CrashFree BIOS, ASUS EZ

Flash

* Specifications are subject to change without notice.

viii

P4SP-MX SE specification summary

PCI 2.2, USB 2.0/1.1

WOL/WOR by PME, DMI 2.0, WfM 2.0

Micro-ATX form factor: 9.6 in x 9.6 in (24.5 cm x 24.5 cm)

Device drivers

ASUS PC Probe

ASUS LiveUpdate

ASUS Screensaver

Adobe Acrobat Reader

Trend Micro™ PC-cillin 2002 anti-virus software

Microsoft

DirectX 9.0

Industry standard

Manageability

Form Factor

Support CD contents

About this guide

Conventions used in this guide

To make sure that you perform certain tasks properly, take note of the

following symbols used throughout this guide.

WARNING: Information to prevent injury to yourself when trying

to complete a task.

CAUTION: Information to prevent damage to the components

when trying to complete a task.

IMPORTANT: Information that you MUST follow to complete a

task.

NOTE: Tips and additional information to aid in completing a task.

Chapter 1

This chapter describes the features of the

motherboard. It includes brief descriptions of the

motherboard components, and illustrations of the

layout, jumper settings, and connectors.

Product introduction

1-2

Chapter 1: Product introduction

1.1 Welcome!

Thank you for buying the ASUS

P4SP-MX SE motherboard!

The ASUS

P4SP-MX SE motherboard delivers a host of new features and latest

technologies making it another standout in the long line of ASUS quality

motherboards!

Before you start installing the motherboard, and hardware devices on it, check the

items in your package with the list below.

1.2 Package contents

Check your P4SP-MX SE package for the following items.

ASUS P4SP-MX SE motherboard

Micro-ATX form factor: 9.6 in x 9.6 in (24.5 cm x 24.5 cm)

ASUS P4SP-MX SE series support CD

9-pin COM cable

80-conductor UltraDMA cable

Ribbon cable for a 3.5-inch floppy drive

I/O shield

Bag of extra jumper caps

User Guide

If any of the above items is damaged or missing, contact your retailer.

1.3 Special features

1.3.1 Product highlights

Intel

Prescott CPU support

The motherboard comes with a 478-pin surface mount, Zero Insertion Force (ZIF)

socket for the Intel

Pentium

4 processor and 512/256KB L2 cache on 0.13

micron process. This motherboard supports 533/400 MHz system front side bus

that allows 4.3GB/s and 3.2GB/s data transfer rates, respectively. The P4SP-MX

SE also supports the next-generation Intel

Prescott CPU and the Intel

Hyper-Threading Technology. See page 1-8.

SiS651/962L chipset

Embedded in this motherboard is the SiS651/962L chipset that integrates various

SiS-developed technologies to ensure an efficient and reliable computing

performance.

Autres manuels pour P4SP-MX SE

Table des matières

Autres manuels Asus Carte mère

Asus

Asus A7VL-VM Manuel utilisateur

Asus

Asus Motherboard A7N8X-VM Manuel utilisateur

Asus

Asus H81-M2 Manuel utilisateur

Asus

Asus Maximus VIII Ranger Manuel utilisateur

Asus

Asus PRIME A320M-A Manuel utilisateur

Asus

Asus P4U800-X Manuel utilisateur

Asus

Asus A7V133 Manuel utilisateur

Asus

Asus CUW Manuel utilisateur

Asus

Asus Pro Q570M-C Manuel utilisateur

Asus

Asus KFN32-D - Motherboard - SSI EEB 3.51 Manuel utilisateur

Asus

Asus PRIME A320M-K Manuel utilisateur

Asus

Asus M3N-H/HDMI Manuel utilisateur

Asus

Asus PRIME H610M-F D4 Manuel utilisateur

Asus

Asus B85M-K Manuel utilisateur

Asus

Asus P5G41-M SI Manuel utilisateur

Asus

Asus Prime H270-PRO Manuel utilisateur

Asus

Asus PRIME H770-PLUS D4 Manuel utilisateur

Asus

Asus Pentium Motherboard HX97 Manuel utilisateur

Asus

Asus P/I-XP55T2P4 Manuel utilisateur

Asus

Asus Z97-AR Manuel utilisateur

Asus

Asus PRIME H310M-R R2.0 Manuel utilisateur

Asus

Asus Z170 PRO GAMING Manuel utilisateur

Asus

Asus GRYPHON Z97 ARMOR EDITION Manuel utilisateur

Asus

Asus B250M-C PRO Manuel utilisateur

Manuels Carte mère populaires d'autres marques

DFI

DFI SD170 Manuel utilisateur

ASROCK

ASROCK ROMED8-2T Manuel utilisateur

Winmate

Winmate IC70 Manuel utilisateur

Grantech

Grantech SYS8F377VGGA-3OMN Manuel utilisateur

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Manuel utilisateur

Gigabyte

Gigabyte GA-9IVDT Manuel utilisateur

Texas Instruments

Texas Instruments ADS8372EVM Manuel utilisateur

Commell

Commell MS-C73 Manuel utilisateur

IBT Technologies

IBT Technologies MB860 Manuel utilisateur

Nvidia

Nvidia TEGRA DG-04927-001_V01 Manuel utilisateur

Biostar

Biostar M7VIT Bravo Instructions d'utilisation et d'installation

Intel

Intel D33217CK Manuel utilisateur

EPC

EPC EPC9147C Manuel utilisateur

EPOX

EPOX MU-8KHA0010 Manuel utilisateur

Ski-Doo

Ski-Doo Bombardier MPEM 219 700 090 Manuel utilisateur

Epson

Epson S5U13700P00C000 Manuel utilisateur

Gigabyte

Gigabyte GA-K8N Ultra-SLI Manuel utilisateur

Albatron

Albatron PX925XE Series Manuel utilisateur
