Asus Pro Q570M-C Manuel utilisateur

Motherboard

Pro Q570M-C

E17977

First Edition

February 2021

No part of this manual, including the products and software described in it, may be reproduced,

transmitted, transcribed, stored in a retrieval system, or translated into any language in any form or by any

means, except documentation kept by the purchaser for backup purposes, without the express written

permission of ASUSTeK COMPUTER INC. (“ASUS”).

Product warranty or service will not be extended if: (1) the product is repaired, modied or altered, unless

such repair, modication of alteration is authorized in writing by ASUS; or (2) the serial number of the

product is defaced or missing.

ASUS PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS

OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OR CONDITIONS OF

MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. IN NO EVENT SHALL ASUS, ITS

DIRECTORS, OFFICERS, EMPLOYEES OR AGENTS BE LIABLE FOR ANY INDIRECT, SPECIAL,

INCIDENTAL, OR CONSEQUENTIAL DAMAGES (INCLUDING DAMAGES FOR LOSS OF PROFITS,

LOSS OF BUSINESS, LOSS OF USE OR DATA, INTERRUPTION OF BUSINESS AND THE LIKE),

EVEN IF ASUS HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES ARISING FROM ANY

DEFECT OR ERROR IN THIS MANUAL OR PRODUCT.

SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUAL ARE FURNISHED FOR

INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGE AT ANY TIME WITHOUT NOTICE,

AND SHOULD NOT BE CONSTRUED AS A COMMITMENT BY ASUS. ASUS ASSUMES NO

RESPONSIBILITY OR LIABILITY FOR ANY ERRORS OR INACCURACIES THAT MAY APPEAR IN THIS

MANUAL, INCLUDING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT.

Products and corporate names appearing in this manual may or may not be registered trademarks or

copyrights of their respective companies, and are used only for identication or explanation and to the

owners’ benet, without intent to infringe.

iii

Contents

Safety information...................................................................................................... iv

About this guide.......................................................................................................... v

Package contents....................................................................................................... vi

Pro Q570M-C specifications summary..................................................................... vi

Connectors with shared bandwidth ......................................................................... ix

Chapter 1 Product Introduction

1.1 Before you proceed...................................................................................... 1-1

1.2 Motherboard overview .................................................................................1-1

1.3 Central Processing Unit (CPU).................................................................... 1-7

1.4 System memory............................................................................................ 1-8

Chapter 2 BIOS Information

2.1 BIOS setup program.....................................................................................2-1

2.2 BIOS menu screen........................................................................................2-2

2.3 Event Log ......................................................................................................2-3

2.4 Exit menu ......................................................................................................2-4

Appendix

Notices ..................................................................................................................... A-1

Warranty................................................................................................................... A-6

ASUS contact information...................................................................................... A-8

Safety information

Electrical safety

• To prevent electrical shock hazard, disconnect the power cable from the electrical outlet

before relocating the system.

• When adding or removing devices to or from the system, ensure that the power cables

for the devices are unplugged before the signal cables are connected. If possible,

disconnect all power cables from the existing system before you add a device.

• Before connecting or removing signal cables from the motherboard, ensure that all power

cables are unplugged.

• Seek professional assistance before using an adapter or extension cord. These devices

could interrupt the grounding circuit.

• Ensure that your power supply is set to the correct voltage in your area. If you are not

sure about the voltage of the electrical outlet you are using, contact your local power

company.

• If the power supply is broken, do not try to x it by yourself. Contact a qualied service

technician or your retailer.

Operation safety

• Before installing the motherboard and adding components, carefully read all the manuals

that came with the package.

• Before using the product, ensure all cables are correctly connected and the power cables

are not damaged. If you detect any damage, contact your dealer immediately.

• To avoid short circuits, keep paper clips, screws, and staples away from connectors,

slots, sockets and circuitry.

• Avoid dust, humidity, and temperature extremes. Do not place the product in any area

where it may be exposed to moisture.

• Place the product on a stable surface.

• If you encounter technical problems with the product, contact a qualied service

technician or your retailer.

• Your motherboard should only be used in environments with ambient temperatures

between 0°C and 40°C.

About this guide

This user guide contains the information you need when installing and conguring the

motherboard.

How this guide is organized

This guide contains the following parts:

• Chapter 1: Product Introduction

This chapter describes the features of the motherboard and the new technology it

supports. It includes descriptions of the switches, jumpers, and connectors on the

motherboard.

• Chapter 2: BIOS Information

This chapter tells how to boot into the BIOS.

Where to find more information

Refer to the following sources for additional information and for product and software

updates.

1. ASUS website

The ASUS website provides updated information on ASUS hardware and software

products. Refer to the ASUS contact information.

2. Optional documentation

Your product package may include optional documentation, such as warranty flyers,

that may have been added by your dealer. These documents are not part of the

standard package.

Conventions used in this guide

To ensure that you perform certain tasks properly, take note of the following symbols used

throughout this manual.

CAUTION: Information to prevent damage to the components and injuries to yourself when

trying to complete a task.

IMPORTANT: Instructions that you MUST follow to complete a task.

NOTE: Tips and additional information to help you complete a task.

Pro Q570M-C specifications summary

CPU

Intel®Socket LGA1200 for 11th Gen Intel®Core™ Processors & 10th Gen

Intel®Core™, Pentium®Gold and Celeron®Processors*

Supports Intel®14nm CPU

Supports Intel®Turbo Boost Technology 2.0 and Intel®Turbo Boost Max

Technology 3.0**

*Refer to www.asus.com for CPU support list.

**Intel®Turbo Boost Max Technology 3.0 support depends on the CPU types.

Chipset Intel®Q570 Chipset

Memory

4 x DIMM, Max. 128GB, DDR4 3200(OC)/2933/2800/2666/2400/2133 MHz

Non-ECC, Un-buffered Memory*

Dual Channel Memory Architecture

Supports Intel® Extreme Memory Prole (XMP)

OptiMem

*10th Gen Intel®Core™ i7/i9 processors support 2933/2800/2666/2400/2133

natively, others will run at the maximum transfer rate of DDR4 2666MHz.

*11th Gen Intel®processors support 2933/2800/2666/2400/2133 natively.

*Refer to www.asus.com for the Memory QVL (Qualified Vendors Lists), and

memory frequency support depends on the CPU types.

Graphics

2 x DisplayPort 1.4**

1 x HDMITM 2.0***

*Graphics specifications may vary between CPU types.

**Intel®11th & 10th Gen processors support DisplayPort 1.4 with max. resolution of

4096 x 2304 @60Hz. Please refer to www.intel.com for any updates.

***Only Intel®11th Gen processors support HDMI™ 2.0 with max. resolution

of 4K@60Hz, others will only support HDMI™ 1.4 with max. resolution of

4K@30Hz. Please refer to www.intel.com for any updates.

Expansion Slots

Intel®11th & 10th Gen Processors

1 x PCIe 4.0/3.0 x16 slot

- Intel®11th Gen processors support PCIe 4.0 x16 mode

- Intel®10th Gen processors support PCIe 3.0 x16 mode

Intel®Q570 Chipset

2 x PCIe 3.0 x1 slots

(continued on the next page)

Package contents

Check your motherboard package for the following items.

Motherboard 1 x Pro Q570M-C motherboard

Cables 2 x SATA 6Gb/s cables

Miscellaneous

1 x I/O Shield

1 x M.2 SSD screw package

1 x M.2 Key E screw package

Application DVD 1 x Support DVD

Documentation 1 x ACC Express Activation Key Card

1 x User manual

If any of the above items is damaged or missing, contact your retailer.

vii

Pro Q570M-C specifications summary

Storage

Total supports 2 x M.2 slots and 6 x SATA 6Gb/s ports

Intel®11th & 10th Gen Processors

M.2_1 slot (Key M), type 2242/2260/2280

- Only Intel®11th Gen processors support PCIe 4.0 x4 mode, this slot will

be disabled for other CPUs

Intel®Q570 Chipset

M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 3.0 x4 & SATA

modes) *

6 x SATA 6Gb/s ports

RAID function for PCIe mode SSD in Intel®Rapid Storage Technology is

available with either 1. Intel®SSDs installed in both CPU-attached and

PCH-attached slots, or 2. any other 3rd party SSDs installed in PCH-

attached slots.

To enable Intel®Optane™ Memory (Hybrid Storage device), it must be

installed in PCH-attached slots with Intel®Rapid Storage Technology.

*When a device in SATA mode is installed on the M.2_2 socket, SATA6G_2 port

cannot be used.

Ethernet 1 x Intel®I219-LM 1Gb Ethernet

ASUS LANGuard

Wireless &

Bluetooth

M.2 slot only (Key E) (supports CNVi & PCIe interface)*

*Wi-Fi module is sold separately.

USB

Rear USB (Total 6 ports)

4 x USB 3.2 Gen 2 ports (4 x Type-A)

2 x USB 2.0 ports (2 x Type-A)

Front USB (Total 7 ports)

1 x USB 3.2 Gen 1 front panel connector (supports USB Type-C®)

1 x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports

2 x USB 2.0 headers support additional 4 USB 2.0 ports

Audio

Realtek ALC 897 7.1 Surround Sound High Definition Audio CODEC*

- Supports: Jack detection, Multi-streaming, Front Panel Jack-retasking

- Supports up to 24-Bit/192 kHz playback

*A chassis with an HD audio module in the front panel is required to support 7.1

Surround Sound audio output.

Back Panel I/O Ports

4 x USB 3.2 Gen 2 ports (4 x Type-A)

2 x USB 2.0 ports (2 x Type-A)

2 x DisplayPort

1 x HDMI™ port

1 x Intel®I219-LM 1Gb Ethernet port

3 x Audio jacks

1 x PS/2 keyboard (purple) port

1 x PS/2 mouse (green) port

Internal I/O

Connectors

Fan and Cooling related

1 x 4-pin CPU Fan header

2 x 4-pin Chassis Fan headers

Power related

1 x 24-pin Main Power connector

1 x 8-pin +12V Power connector

(continued on the next page)

viii

Pro Q570M-C specifications summary

Internal I/O

Connectors

Storage related

2 x M.2 slots (Key M)

6 x SATA 6Gb/s ports

USB

1 x USB 3.2 Gen 1 Front Panel connector (supports USB Type-C®)

1 x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports

2 x USB 2.0 headers support additional 4 USB 2.0 ports

Miscellaneous

1 x Clear CMOS header

1 x Chassis Intrusion header

2 x COM Port headers

1 x Front Panel Audio header (AAFP)

1 x COM debug header

1 x Intel®ME jumper

1 x LPT header

1 x Mono-out header(with Amp IC)

1 x M.2 slot (Key E)

1 x SMBUS header

1 x Speaker header

1 x 10-1 pin System Panel header

Special Features

ASUS EZ DIY

- Box Headers

Bespoke Motherboard Design & Business Focused Features

- ASUS Self Recovering BIOS

- ASUS Event Log

- ASUS Commercial BIOS kit

- Anti-Moisture

- 24/7 Reliability

- Overcurrent Protection

TPM 2.0 IC onboard

Software

Features

ASUS Exclusive Software

IT Management software supported

- ASUS Control Center Express(ACCE)

BIOS 128+64 Mb Flash ROM

Manageability WOL by PME, PXE

Operating

System Windows®10 64-bit

Form Factor mATX Form Factor

9.6 inch x 9.6 inch (24.4 cm x 24.4 cm)

Specications are subject to change without notice. Refer to the ASUS website for the

latest specications.

Connectors with shared bandwidth

SATA6G_2

SATA6G_1

SATA6G_4

SATA6G_3

PCIEX1_2

PCIEX1_1

SPEAKER

CHASSIS

CLRTC

DIS_ME F_PANEL

COM_DEBUG

USB813USB1112

LPT

U32G1_56

U32_7

AAFP

MONO_OUT

SMBUS

ATX_12V

ATX_PWR

CPU_FAN

CHA_FAN1

CHA_FAN2

BATTERY

PCIEX16

Super

I/O

DIGI+

VRM

LGA1200

Intel®

Q570

DDR4 DIMM_B1 (64bit, 288-pin module)

2280

2260

2280 2260 2242

2230

2242

M.2_2(SOCKET3)

M.2_1(SOCKET3)

DDR4 DIMM_B2* (64bit, 288-pin module)

DDR4 DIMM_A1 (64bit, 288-pin module)

DDR4 DIMM_A2* (64bit, 288-pin module)

AUDIO

KBMS

HDMI_DP1

ASM

1442K

DP2

LAN_USB910

U32G2_34

U32G2_12

128Mb

BIOS

64Mb

BIOS

TPM

SATA6G_6 SATA6G_5

COM1COM2

Ethernet

Audio

Codec

M.2_1(SOCKET3)

M.2_2(SOCKET3)

PCIE SATA IRST

3.0 X4 V PCH-attached

PCIE SATA IRST

4.0 X4 X CPU-attached

M.2(WIFI)

Configuration 1 2

AM.2_2 x4 SATA

SATA6G_2 V -

• M.2_2 shares bandwidth with SATA6G_2.

• When a device in SATA mode is installed on the M.2_2 slot, SATA6G_2 port cannot

be used.

Table des matières

Autres manuels Asus Carte mère

Asus

Asus ITX 220 - Motherboard - Mini ITX Guide de démarrage rapide

Asus

Asus P4P800-E DELUXE Manuel utilisateur

Asus

Asus A7N8X Series Manuel utilisateur

Asus

Asus A88X-Gamer Manuel utilisateur

Asus

Asus A68HM-F Manuel d'installation et d'exploitation

Asus

Asus Tinker Board Series Manuel utilisateur

Asus

Asus MBD2738 Manuel utilisateur

Asus

Asus KFN5-D - Motherboard - SSI EEB 3.51 Manuel utilisateur

Asus

Asus P4S-X Manuel utilisateur

Asus

Asus P8C WS Manuel utilisateur

Asus

Asus TUF GAMING B550M-PLUS WI-FI Manuel utilisateur

Asus

Asus B150 PRO GAMING D3 Manuel utilisateur

Asus

Asus TX97-XV Manuel utilisateur

Asus

Asus P5KPL IPC/SI Manuel utilisateur

Asus

Asus M4A78T-E - Motherboard - ATX Manuel utilisateur

Asus

Asus A7N266-C Manuel utilisateur

Asus

Asus A8V-VM - SE Motherboard - Micro ATX Manuel utilisateur

Asus

Asus PRO H310M-R R2.0 WI-FI/CSM Manuel utilisateur

Asus

Asus TUF H370-PRO GAMING Manuel utilisateur

Asus

Asus P5GD1 Pro Manuel utilisateur

Asus

Asus PRIME B650M-A WIFI Manuel utilisateur

Asus

Asus P4T533 Manuel utilisateur

Asus

Asus E2KM1I-DELUXE Manuel utilisateur

Asus

Asus TUWE-M 810E2 MICROATX MOTHERBOARD Manuel utilisateur

Manuels Carte mère populaires d'autres marques

DFI

DFI SD170 Manuel utilisateur

ASROCK

ASROCK ROMED8-2T Manuel utilisateur

Winmate

Winmate IC70 Manuel utilisateur

Grantech

Grantech SYS8F377VGGA-3OMN Manuel utilisateur

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Manuel utilisateur

Gigabyte

Gigabyte GA-9IVDT Manuel utilisateur

Texas Instruments

Texas Instruments ADS8372EVM Manuel utilisateur

Commell

Commell MS-C73 Manuel utilisateur

IBT Technologies

IBT Technologies MB860 Manuel utilisateur

Nvidia

Nvidia TEGRA DG-04927-001_V01 Manuel utilisateur

Biostar

Biostar M7VIT Bravo Instructions d'utilisation et d'installation

Intel

Intel D33217CK Manuel utilisateur

EPC

EPC EPC9147C Manuel utilisateur

EPOX

EPOX MU-8KHA0010 Manuel utilisateur

Ski-Doo

Ski-Doo Bombardier MPEM 219 700 090 Manuel utilisateur

Epson

Epson S5U13700P00C000 Manuel utilisateur

Gigabyte

Gigabyte GA-K8N Ultra-SLI Manuel utilisateur

Albatron

Albatron PX925XE Series Manuel utilisateur
