Asus WL-140 Manuel utilisateur

ASUS USB SpaceLink Client

WL-140

Quick Start Guide

2ASUS USB SpaceLink Client Quick Start

No part of this manual, including the products and software described in it,

may be reproduced, transmitted, transcribed, stored in a retrieval system,

or translated into any language in any form or by any means, except docu-

mentation kept by the purchaser for backup purposes, without the express

written permission of ASUSTeK COMPUTER INC. (“ASUS”).

ASUS PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY

OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING BUT

NOT LIMITED TO THE IMPLIED WARRANTIES OR CONDITIONS

OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PUR-

POSE. IN NO EVENT SHALL ASUS, ITS DIRECTORS, OFFICERS,

EMPLOYEES OR AGENTS BE LIABLE FOR ANY INDIRECT, SPE-

CIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES (INCLUD-

ING DAMAGES FOR LOSS OF PROFITS, LOSS OF BUSINESS, LOSS

OF USE OR DATA, INTERRUPTION OF BUSINESSAND THE LIKE),

EVEN IFASUS HAS BEENADVISED OFTHE POSSIBILITYOF SUCH

DAMAGES ARISING FROM ANY DEFECT OR ERROR IN THIS

MANUAL OR PRODUCT.

Product warranty or service will not be extended if: (1) the product is re-

paired, modified or altered, unless such repair, modification of alteration is

authorized in writing by ASUS; or (2) the serial number of the product is

defaced or missing.

Products and corporate names appearing in this manual may or may not be

registered trademarks or copyrights of their respective companies, and are

usedonlyforidentificationorexplanationandtotheowners’benefit,without

intent to infringe.

SPECIFICATIONS AND INFORMATION CONTAINED IN THIS

MANUALAREFURNISHEDFORINFORMATIONALUSEONLY,AND

ARE SUBJECT TO CHANGEATANYTIME WITHOUT NOTICE,AND

SHOULDNOTBE CONSTRUEDASACOMMITMENTBYASUS.ASUS

ASSUMES NO RESPONSIBILITY OR LIABILITY FOR ANY ERRORS

OR INACCURACIES THAT MAY APPEAR IN THIS MANUAL, IN-

CLUDING THE PRODUCTSAND SOFTWARE DESCRIBED IN IT.

Product Name: ASUS USB SpaceLink Client (WL-140)

Manual Revision: 1 E1218

Release Date: January 2003

ASUS USB SpaceLink Client Quick Start 3

ASUSTeK COMPUTER INC. (Asia-Pacific)

Address: 150 Li-Te Road, Peitou, Taipei, Taiwan 112

General Tel: +886-2-2894-3447

General Fax: +886-2-2894-3449

General Email: [email protected]

Technical Support

MB/Others (Tel):+886-2-2890-7121 (English)

Notebook (Tel): +886-2-2890-7122 (English)

Desktop/Server: +886-2-2890-7123 (English)

Support Fax: +886-2-2890-7698

Support Email: [email protected]

Web Site: www.asus.com.tw

ASUS COMPUTER INTERNATIONAL (America)

Address: 6737 Mowry Avenue, Mowry Business Center,

Building 2, Newark, CA 94560, USA

General Fax: +1-510-608-4555

General Email: [email protected]

Technical Support

Support Fax: +1-510-608-4555

General Support: +1-502-933-8713

Web Site: www.asus.com

Support Email: [email protected]

ASUS COMPUTER GmbH (Germany & Austria)

Address: Harkortstr. 25, 40880 Ratingen, BRD, Germany

General Fax: +49-2102-442066

General Email: [email protected] (for marketing requests only)

Technical Support

Support Hotline: MB/Others: +49-2102-9599-0

Notebook (Tel): +49-2102-9599-10

Support Fax: +49-2102-9599-11

Support (Email): www.asuscom.de/de/support (for online support)

Web Site: www.asuscom.de

4ASUS USB SpaceLink Client Quick Start

Welcome

The ASUS USB SpaceLink Client is designed for 802.11b wireless net-

works and is equipped with a 6 dBi omnidirectional antenna which pro-

vides a greater coverage area compared with wireless PC cards. TheASUS

USB SpaceLink Client comes with a mounting kit and a detachable 1.8

meter USB cable which allows convenient placement on your desk or of-

fice partition. A USB extension cable can be purchased from third-parties

for mounting the ASUS USB SpaceLink Client on the wall or ceiling. The

advantages of the ASUS USB SpaceLink Client is the increased wireless

coverage due to the ability to raise theASUS USB SpaceLink Client above

obstructions.

Installing the SpaceLink Driver

1. Turn ON your computer and enter Windows.

2. Connect the small end of the USB cable into

the back of the ASUS USB SpaceLink Client.

3. Insert the larger end of the USB cable into your

computer’s USB port.

4. Windows will automatically detect the ASUS USB SpaceLink Client

once it is inserted. When the “Add New Hardware Wizard” dialog ap-

pears, click Next to begin driver installation.

5. Select “Search for the best driver for your device (Recommended)”.

Click Next to continue.

6. Specify the location with “[CD]\Card\Driver\USB” and click Next.

Where [CD] represents the drive letter of your CD-ROM drive.

7. Wait while Windows searches for the device driver for the ASUS USB

SpaceLink Client. Windows will display the search result: “ASUS

SpaceLink WL-140 WLAN USB Adapter”. Click Next.

8. During the installation, Windows may prompt you to insert the “Win-

dows Operating System CD” which contains some driver files. Insert

your Windows setup disc and type the path if necessary and click Yes.

Windows will start copying the necessary files.

9. When the installation procedure is completed, click Finish.

10.Restart your Windows to make the driver take effect.

Quick Start Guide

ASUS USB SpaceLink Client Quick Start 5

Verifying the SpaceLink Driver

Windows 98/Me

Right-click My Computer on the desktop and select Properties. Click

DeviceManagerand look under Network adapters. If you find the “ASUS

SpaceLink WL-140 WLAN USB Adapter” string, it means the driver is

installed correctly.

Windows 2K/XP

Open the Control Panel through the Start menu. Double-click System

icon. Click Device Manager on the “Hardware” page. Click Network

adapters. If you find the “ASUS SpaceLink WL-140WLAN USBAdapter”

string, it means the driver is installed correctly.

Verifying the TCP/IP Protocol

Windows 98/Me

Right-click My Network Places on the desktop and select Properties.

Scroll down and look for “TCP/IP -> ASUS SpaceLink WL-140 WLAN

USBAdapter”. Make sure that the TCP/IPprotocol parameters (IPaddress,

gateway, and subnet mask) are set correctly.

Windows 2K/XP

Open the Control Panel through the Start menu. Double-click Network

Connection icon. Right click “ASUS SpaceLink WL-140 WLAN USB

Adapter” and select Properties. Look for “Internet Protocol (TCP/IP)”.

Make sure that the TCP/IP protocol parameters (IP address, gateway, and

subnet mask) are set correctly.

Quick Start Guide

6ASUS USB SpaceLink Client Quick Start

Installing the SpaceLink Utilities

After you have installed the SpaceLink driver, you can install the SpaceLink

utilities. Refer to the User’s Manual for detailed information.

1. Insert the ASUS USB SpaceLink Client support CD and an autorun

menu will appear. If your autorun is disabled, double click SETUP.EXE

in the root directory of the support CD.

2. From the autorun menu, click Install ASUS WLAN Card Utilities.

3. Follow the on-screen instructions to complete the installation.

Reading the SpaceLink LEDs

The front of the ASUS USB SpaceLink Client

consists of two LEDs that indicate the status of

the ASUS USB SpaceLink Client.

Link LED

Solid Light: TheASUS USB SpaceLink Client

is linked to a wireless network.

Blinking: The ASUS USB SpaceLink Client is

searching for a wireless network to connect to.

Power LED

Solid Light: TheASUS USB SpaceLink Client

is receiving power from a computer’s USB port.

No Light: The ASUS USB SpaceLink Client is not receiving power. The

cable may not be connected or the computer is turned OFF.

Orientating the Antenna

TheASUS USB SpaceLink Client has an

omnidirectional antenna that can be tilted

forwards or backwards. It is recom-

mendedthatyouadjusttheantenna’s front

face towards the nearest access point for

maximum range and higher link quality.

Lower the antenna when transporting the

ASUS USB SpaceLink Client .

Link LED Power LED

Quick Start Guide
