ASROCK Z97 Pro4 Manuel utilisateur

Z97 Pro4Z97 Pro4

Version 1.0

Published April 2014

No part of this documentation may be reproduced, transcribed, transmitted, or

translated in any language, in any form or by any means, except duplication of

documentation by the purchaser for backup purpose, without written consent of

ASRock Inc.

Products and corporate names appearing in this documentation may or may not

be registered trademarks or copyrights of their respective companies, and are used

only for identication or explanation and to the owners’ benet, without intent to

infringe.

Disclaimer:

Specications and information contained in this documentation are furnished for

informational use only and subject to change without notice, and should not be

constructed as a commitment by ASRock. ASRock assumes no responsibility for

any errors or omissions that may appear in this documentation.

With respect to the contents of this documentation, ASRock does not provide

warranty of any kind, either expressed or implied, including but not limited to

the implied warranties or conditions of merchantability or tness for a particular

purpose.

In no event shall ASRock, its directors, ocers, employees, or agents be liable for

any indirect, special, incidental, or consequential damages (including damages for

loss of prots, loss of business, loss of data, interruption of business and the like),

even if ASRock has been advised of the possibility of such damages arising from any

defect or error in the documentation or product.

is device complies with Part 15 of the FCC Rules. Operation is subject to the following

two conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that

may cause undesired operation.

CALIFORNIA, USA ONLY

e Lithium battery adopted on this motherboard contains Perchlorate, a toxic substance

controlled in Perchlorate Best Management Practices (BMP) regulations passed by the

California Legislature. When you discard the Lithium battery in California, USA, please

follow the related regulations in advance.

“Perchlorate Material-special handling may apply, see www.dtsc.ca.gov/hazardouswaste/

perchlorate”

ASRock Website: http://www.asrock.com

e terms HDMI™ and HDMI High-Denition Multimedia Interface, and the HDMI

logo are trademarks or registered trademarks of HDMI Licensing LLC in the United

States and other countries.

Contents

Chapter 1 Introduction 1

1.1 Package Contents 1

1.2 Specications 2

1.3 Unique Features 6

1.4 Motherboard Layout 10

1.5 I/O Panel 12

Chapter 2 Installation 14

2.1 Installing the CPU 15

2.2 Installing the CPU Fan and Heatsink 18

2.3 Installing Memory Modules (DIMM) 19

2.4 Expansion Slots (PCI and PCI Express Slots) 21

2.5 Jumpers Setup 22

2.6 Onboard Headers and Connectors 23

2.7 CrossFireXTM and Quad CrossFireXTM Operation Guide 28

2.7.1 Installing Two CrossFireXTM-Ready Graphics Cards 28

2.7.2 Driver Installation and Setup 30

2.8 M.2_SSD (NGFF) Module Installation Guide 31

Chapter 3 Software and Utilities Operation 34

3.1 Installing Drivers 34

3.2 A-Tuning 35

3.3 Intel® Rapid Start Technology 41

3.4 Intel® Smart Connect Technology 46

3.5 ASRock Cloud 51

3.6 ASRock APP Shop 61

3.6.1 UI Overview 61

3.6.2 Apps 62

3.6.3 BIOS & Drivers 65

3.6.4 Setting 66

3.7 Start8 67

Chapter 4 UEFI SETUP UTILITY 70

4.1 Introduction 70

4.1.1 UEFI Menu Bar 70

4.1.2 Navigation Keys 71

4.2 Main Screen 72

4.3 OC Tweaker Screen 73

4.4 Advanced Screen 82

4.4.1 CPU Conguration 83

4.4.2 Chipset Conguration 85

4.4.3 Storage Conguration 87

4.4.4 Intel® Rapid Start Technology 89

4.4.5 Intel® Smart Connect Technology 90

4.4.6 Intel® Thunderbolt™ 91

4.4.7 Super IO Conguration 92

4.4.8 ACPI Conguration 93

4.4.9 USB Conguration 95

4.4.10 Trusted Computing 97

4.5 Tools 98

4.6 Hardware Health Event Monitoring Screen 101

4.7 Boot Screen 102

4.8 Security Screen 105

4.9 Exit Screen 106

PB 1

English

Z97 Pro4

Chapter 1 Introduction

ank you for purchasing ASRock Z97 Pro4 motherboard, a reliable motherboard

produced under ASRock’s consistently stringent quality control. It delivers excellent

performance with robust design conforming to ASRock’s commitment to quality

and endurance.

In this manual, Chapter 1 and 2 contains the introduction of the motherboard

and step-by-step installation guides. Chapter 3 contains the operation guide of the

soware and utilities. Chapter 4 contains the conguration guide of the BIOS setup.

1.1 Package Contents

• ASRock Z97 Pro4 Motherboard (ATX Form Factor)

• ASRock Z97 Pro4 Quick Installation Guide

• ASRock Z97 Pro4 Support CD

• 2 x Serial ATA (SATA) Data Cables (Optional)

• 1 x I/O Panel Shield

• 1 x Screw for M.2_SSD (NGFF) Socket 3

Because the motherboard specications and the BIOS soware might be updated, the

content of this manual will be subject to change without notice. In case any modica-

tions of this manual occur, the updated version will be available on ASRock’s website

without further notice. If you require technical support related to this motherboard,

please visit our website for specic information about the model you are using. You

may nd the latest VGA cards and CPU support list on ASRock’s website as well.

ASRock website http://www.asrock.com.

2 3

English

Z97 Pro4

1.2 Specications

Platform • ATX Form Factor

• High Density Glass Fabric PCB

Unique

Feature

ASRock Super Alloy

• Premium Alloy Choke (Reduces 70% core loss compared to

iron powder choke)

• NexFETTM MOSFET

• 12K Platinum Caps (100% Japan made high quality

conductive polymer capacitors)

• Sapphire Black PCB

ASRock Full Spike Protection

ASRock Cloud

ASRock APP Shop

CPU • Supports 4th Gen & 5th Generation Intel® Coreth Processors

(Socket 1150)

• Digi Power design

• 6 Power Phase design

• Supports Intel® Turbo Boost 2.0 Technology

• Supports Intel® K-Series unlocked CPUs

• Supports ASRock BCLK Full-range Overclocking

Chipset • Intel® Z97

Memory • Dual Channel DDR3 Memory Technology

• 4 x DDR3 DIMM Slots

• Supports DDR3 2933+(OC)/2800(OC)/2400(OC)/2133(OC)/

1866(OC)/1600/1333/1066 non-ECC, un-buered memory

• Max. capacity of system memory: 32GB (see CAUTION)

• Supports Intel® Extreme Memory Prole (XMP) 1.3 / 1.2

Expansion

Slot

• 1 x PCI Express 3.0 x16 Slot (PCIE1: x16 mode)

• 1 x PCI Express 2.0 x16 Slot (PCIE3: x4 mode)

* If PCIE2 or PCIE4 slot is occupied, PCIE3 slot will run at x2

mode.

• 2 x PCI Express 2.0 x1 Slots

• 2 x PCI Slots

• Supports AMD Quad CrossFireXTM and CrossFireXTM

2 3

English

Z97 Pro4

Graphics • Intel® HD Graphics Built-in Visuals and the VGA outputs can

be supported only with processors which are GPU integrated.

• Supports Intel® HD Graphics Built-in Visuals : Intel® Quick

Sync Video with AVC, MVC (S3D) and MPEG-2 Full

HW Encode1, Intel® InTruTM 3D, Intel® Clear Video HD

Technology, Intel® InsiderTM, Intel® HD Graphics 4400/4600

• Pixel Shader 5.0, DirectX 11.1

• Max. shared memory 1792MB

• ree graphics output options: D-Sub, DVI-D and HDMI

• Supports Triple Monitor

• Supports HDMI with max. resolution up to 1920x1200 @

60Hz

• Supports DVI-D with max. resolution up to 1920x1200 @

60Hz

• Supports D-Sub with max. resolution up to 1920x1200 @

60Hz

• Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and

HBR (High Bit Rate Audio) with HDMI Port (Compliant

HDMI monitor is required)

• Supports HDCP with DVI-D and HDMI Ports

• Supports Full HD 1080p Blu-ray (BD) playback with DVI-D

and HDMI Ports

Audio • 7.1 CH HD Audio with Content Protection (Realtek ALC892

Audio Codec)

• Premium Blu-ray Audio support

• Supports Surge Protection (ASRock Full Spike Protection)

• Nichicon Fine Gold Series Audio Caps

LAN • Gigabit LAN 10/100/1000 Mb/s

• Giga PHY Intel® I218V

• Supports Intel® Remote Wake Technology

• Supports Wake-On-LAN

• Supports Lightning/ESD Protection (ASRock Full Spike

Protection)

• Supports Energy Ecient Ethernet 802.3az

• Supports PXE

4 5

English

Z97 Pro4

Rear Panel

I/O

• 1 x PS/2 Mouse/Keyboard Port

• 1 x D-Sub Port

• 1 x DVI-D Port

• 1 x HDMI Port

• 1 x Optical SPDIF Out Port

• 4 x USB 2.0 Ports (Supports ESD Protection (ASRock Full

Spike Protection))

• 4 x USB 3.0 Ports (Supports ESD Protection (ASRock Full

Spike Protection))

• 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED

LED)

• HD Audio Jacks: Rear Speaker / Central / Bass / Line in /

Front Speaker / Microphone

Storage • 6 x SATA3 6.0 Gb/s Connectors, support RAID (RAID 0,

RAID 1, RAID 5, RAID 10, Intel Rapid Storage Technology

13 and Intel Smart Response Technology), NCQ, AHCI and

Hot Plug

• 1 x SATA Express Connector (shared with SATA3_4,

SATA3_5 and M.2_SSD (NGFF) Socket 3)

* Support to be announced

• 1 x M.2_SSD (NGFF) Socket 3, supports M.2 SATA3 6.0 Gb/s

module and M.2 PCI Express module up to Gen2 x2 (10 Gb/s)

Connector • 1 x COM Port Header

• 1 x Chassis Intrusion Header

• 1 x TPM Header

• 1 x Power LED Header

• 2 x CPU Fan Connectors (1 x 4-pin, 1 x 3-pin)

• 2 x Chassis Fan Connectors (1 x 4-pin, 1 x 3-pin)

• 1 x Power Fan Connector (3-pin)

• 1 x 24 pin ATX Power Connector

• 1 x 8 pin 12V Power Connector

• 1 x PCIe Power Connector

• 1 x Front Panel Audio Connector

• 1 x underbolt AIC Connector

• 2 x USB 2.0 Headers (Support 4 USB 2.0 ports) (Supports ESD

Protection (ASRock Full Spike Protection))

• 1 x USB 3.0 Header (Supports 2 USB 3.0 ports) (Supports ESD

Protection (ASRock Full Spike Protection))
