USER

GUIDE

IMPACT WSX

801.130B

USG/WSX/AE-B

02.08.95

Not the actual front page

USER

GUIDE

IMPACT WSX

USER GUIDE LCD PANEL

TABLE OF CONTENTS

INTRODUCTION .....................................................................................5

MAIN FEATURES....................................................................................5

SUPPLIED MATERIAL.............................................................................6

OPTIONAL MATERIAL............................................................................6

SETTING UP THE LCD PANEL ...............................................................7

COMPUTER...............................................................................8

MOUSE......................................................................................9

USING THE LCD PANEL....................................................................... 10

REMOTE CONTROL................................................................ 10

FRONT PANEL ........................................................................ 12

CONNECTORS........................................................................ 12

FEATURES............................................................................................ 13

PRACTICAL HINTS AND TIPS............................................................... 16

MAINTENANCE..................................................................................... 18

SERVICE............................................................................................... 18

TECHNICAL DATA ................................................................................ 18

CONNECTORS ..................................................................................... 23

FCC STATEMENT................................................................................. 24

ENVIRONMENTAL STATEMENT........................................................... 25

SERVICE INFORMATION...................................................................... 26

CONNECTION LAYOUT........................................................................ 27

(Foldout Page)

USER GUIDE LCD PANEL

This publication is printed on recycled paper.

The information contained in this user guide is preliminary, and the products described

herein are subject to change without prior notice.

The symbols and are used in this publication to indicate

Warning and Note respectively.

USER GUIDE LCD PANEL

1INTRODUCTION

The LCD panel is a state of the art projection device that can be connected

to most computers.

The ability to display a multitude of colors simultaneously, makes it the

ideal choice for presenting computer generated text and graphics.

Applications include presentations, software training, educational use,

advertising, information boards and other situations where a small or large

audience shares information.

2MAIN FEATURES

-16.7 million colors

-640x480 to 1280x1024 image resolution

-BatMouse™, infrared remote mouse

-User settings memorized

-Individual settings for all modes

- Housing footprint fits OHP glass exactly

-Low weight

-Intelligent Safecool system

-False light blocking

-4 meter cable

-Scale/pan option

USER GUIDE LCD PANEL

3SUPPLIED MATERIAL

A complete set includes the following components :

1. LCD Panel 6. Power Cord

2. VGA-Cable 7. BatMouse Remote Control

3. Mouse Cable 8. Batteries

4. Mouse Adapter PC 9. Attachè Case

5. Power -5, 12, 5 V 10. User Guide

4OPTIONAL MATERIAL

Optional cables and adapters are available for special computer sources.

USER GUIDE LCD PANEL

5SETTING UP THE LCD PANEL

Switch off all equipment before connecting the components. Be aware of

static electricity that may build up, especially in the dry season and when

operating on synthetic carpets. Discharge any static electricity by touching

a metallic surface before you start.

Place the LCD panel on top of a transmissive overhead projector (OHP).

Select a high intensity type projector, for instance 400W halogen or metal-

halide. Best results are obtained in a dimmed room with no direct sunlight.

The following are guidelines for first time set-up:

Connect the cables and power supply as described in the rear foldout page

(see Connection Layout).

Attach power to the LCD panel, then turn the overhead projector and

computer on.

Do not switch on the OHP unless the LCD panel is powered, as

this may cause permanent damage.

If you are going to use a mouse, make sure to power the LCD panel first.

For more information on set-up see the following sections on

Computer/Mouse.

USER GUIDE LCD PANEL

5.1 COMPUTER

Connect the LCD panel, computer, monitor and power supply as shown in

the rear foldout.

Connect cable (1) between the LCD panel and the computer.

If you have a workstation, insert applicable adapter (4) as described in the

table below.

Connect the power supply to the LCD panel (3).

APPLICABLE ADAPTERS :

COMPUTER ADAPTER

VGA None *)

MACII and newer MAC (option)

SUN 13W3 (option)

HP None or BNC (option)

IBM RS6000 BNC (option)

Silicon Graphics 13W3 (option)

DEC BNC (option)

*) The cable is connected directly without a special adapter.

TO SET UP FROM THE BATMOUSE REMOTE CONTROL :

Use a chequered background when setting up in direct (1:1) mode to

ensure correct frequency setting.

STEP OPERATION

1Press RESET for default settings

2Adjust FREQUENCY if chequered image is not regular

3Adjust TUNE for a stable image

4Press POSITION, then use cursor keys to position the image

5Adjust CONTRAST and BRIGHTNESS as desired

USER GUIDE LCD PANEL

5.2 MOUSE

Connect the mouse to the LCD panel using the appropriate adapter (6) as

described in the table below. Then connect the adapter (6) to the mouse

cable at the computer end. Finally, connect the mouse cable to the LCD

panel (2).

For the computer to recognise the mouse, connect the mouse before

power is applied.

A Y-split is provided with the PC and MAC adapters that enables parallel

use of the local computer mouse and the remote mouse. The local and

remote mice should however not be operated simultaneously, as this may

lead to unpredictable positioning of the mouse pointer.

If you have a Macintosh, make sure to connect your Mac mouse adapter

via the keyboard.

The PS/2 adapter does not have a Y-split.

To use the mouse function with workstations requires workstation

compatibility with one of the mice defined below.

APPLICABLE ADAPTERS :

MOUSE ADAPTER

Microsoft 2 key compatible (9 pin serial port) PC

PS/2 compatible mouse PS/2 (option)

Macintosh ADB-bus mouse MAC (option)

USING THE BATMOUSE :

STEP OPERATION

1Control mouse pointer directly with the cursor keys

2Press LEFT to activate (emulates the left mouse key)

3Press DRAG to tag an object, move it using the cursor keys,

then press DRAG again (or wait 5 seconds) to release the

object.

4Press RIGHT if your application requires emulation of the

right mouse key.

The centre key of three-key mice is not emulated.

If double-click does not work properly, try to adjust the double-click rate

within the computer application in use.
